Quick Set Recording (Qsr) - NEC NDT-42 Owner's Manual

Operation with tape

Quick Set Recording (QSR)

Your VCR allows you to make recordings using a
variety of simple methods:
Quick Set Recording (QSR) start recording imme-
diately for a set period of time or until the video
cassette runs out.
Your VCR incorporates Long Play (LP) which
enables you to record up to twice the amount of
time on a video cassette. For example an E-180 will
record up to 180 minutes using Standard Play (SP);
using LP you will be able to record up to 360 minutes.
Please note there will be a slight loss in picture and
sound quality when using LP.
1. Make sure that you have correctly connected your
VCR as described earlier in this book.
Press OPERATE to turn on your VCR.
2. Insert a video cassette with protection tab into your
VCR.
The video cassette should have the window side
facing up and the arrow facing away from you.
3. Press 3 3 or 4 4 to select the programme number
you wish to record.
You may also directly select programme number
using the numbered buttons on the remote control.
4. If you wish to record directly from the AUDIO L/R
(VCR IN AV1)/ VIDEO (VCR IN AV1) or AUDIO IN
(L(MONO)/R) / VIDEO IN terminals repeatedly press
AV until the socket you wish to record from is dis-
played.
AV 1 for recording from AUDIO L/R (VCR IN AV1)/
VIDEO (VCR IN AV1) terminals on the rear of your
unit.
AV 2 for recording from AUDIO IN (L(MONO)/R)/
VIDEO IN terminals on the front of your unit.
22
5. Press LONG PLAY if you wish to record in Long
Play or Standard Play.
SP will produce improved picture and sound quality,
however LP will provide twice as much recording
time as SP.
6. Press REC/QSR to start recording.
RECORD will appear on the TV screen.
Press REC/QSR several times. Each successive
press will increase the record time by 30 minutes
until you reach a maximum of 9 hours.
7. Press PAUSE/STEP to avoid recording unwanted
scenes.
Press PAUSE/STEP to continue recording.
If you press PAUSE/STEP during QSR, this unit will
enter the record pause mode and QSR is cancelled.
Tapes can be paused for up to 5 minutes; RECP will
be displayed when a tape is paused. After 5 minutes
your VCR will stop recording to prevent damaging
the tape or your VCR.
8. Press STOP to end recording.
Press EJECT.
EJECT will appear on the TV screen for a few
seconds.
Notes
If you do not wish to record on a tape (this can
happen quite easily by accident!) remove the
protection tab on the back edge of the video cassette.
It is possible to record on a video cassette with the
record protection tab removed by covering the hole
with self adhesive tape.
Remember you can record one programme while
watching another by starting your instant recording,
press TV/VCR to appear TV indicator in the
display window and then selecting a different channel
on your TV.
