Overview of the appliance

2 Overview of the appliance
2.1

The appliances at a glance

1
9
8
7
Fig. 1: Caffeo® Passione® and Caffeo® Varianza® CS from front left
1 Water tank with lid
2 Bean container with lid
3 Cup rest
4 Control panel
5 Coffee grounds container (inner)
60
2
3
4
5
6
6 Drip tray
7 ON/OFF button
8 Height-adjustable outlet for
coffee beverages with 2 coffee noz-
zles
"
9
Grinding fineness adjustment" lever
(inner)
10 Measuring spoon* for the
My Bean Select
*Only present in Caffeo® Varianza® CS
10
®
function
