Use and Care Manual
Installation
Start-Up
Maintenance
Parts
Warranty
Residential EVR Models
This manual must only be used by a qualified installer / service technician. Read all instructions in this manual before
installing. Perform steps in the given order. Failure to do so could result in substantial property damage, severe
personal injury, or death.
California Proposition 65 Warning: This product contains chemicals known to the State of California to cause cancer,
birth defects, or other reproductive harm.
HTP reserves the right to make product changes or updates without notice and will not be held liable for
typographical errors in literature.
The surfaces of these products contacted by potable (consumable) water contain less than 0.25% lead by weight as
required by the Safe Drinking Water Act, Section 1417.
NOTE TO CONSUMER: PLEASE KEEP ALL INSTRUCTIONS FOR FUTURE REFERENCE.
120 Braley Road P.O. Box 429
Everlast Electric

Water Heaters

East Freetown, MA 02717-0429
www.htproducts.com
lp-473 Rev. 3.13.15
