Tire/Tube Replacement; Tire And Tube Replacement - Huffy Green Machine Owner's Manual

Tire and Tube Replacement

Steps (start opposite Filler Valve):
1. Insert a Tire Lever under Tire Bead (A).
2. Hook end of Tire Lever on a spoke.
3. Insert second Tire Lever and slide along rim to remove tire bead.
4. Remove Inner Tube and Tire.
5. Inspect for cause of flat and remove any foreign object from the tire if necessary.
1. Using your hands, start with one Bead (A) of Tire (B) and install it all the way
around Rim (C).
2. Insert a slightly inflated Inner Tube (D) into
the Tire and make sure the Valve Stem (E) is
straight and aligned with the Rim Hole.
3. Work the second Tire Bead onto the Rim all
the way around. This will take a little more
effort than the first Tire Bead did. Use Tire
Lever Tools if needed.
4. Make sure the Tube does not get pinched
between Rim and Tire.
5. Inflate Tire just enough that it takes shape.
6. Double check that both Tire Beads are seated
properly and that the Valve Stem is pointing
straight out.
7. Fully inflate tube to recommended pressure
listed on Tire side wall - do not over-inflate.
8. Install Valve Cap.
STEP 1 - Remove Existing Tire and Tube:
1
A
STEP 2 - Installing New Tire and Tube:
2 3
D
A
B
C
E
23
