Changing the settings

Example to change setting from 10 CPI to 15 CPI
Step
1
Load the continuous paper and set the printer ONLINE.
2
Press the PAPER FEED
Switch for 5 seconds. LED will turn red.
3
To select Menu mode,
Press the "PAPER FEED" Switch once
4 You will enter into "Menu settings". Skip this menu by
pressing the PAPER FEED Switch
5 As we want to change the pitch, Press the
START/STOP Switch, now the printer has entered
into"STYLE SELECTION"
To "SKIP" Font Menu, Press
6
the PAPER FEED Switch
7 We have entered the Pitch setting menu,
to skip 10 CPI, press the PAPER FEED Switch
To "SKIP" 12 CPI
8
press the PAPER FEED Switch
Now, Press the START/STOP Switch
9
to select 15 CPI PITCH
10 We now enter into the next menu option
of page layout.To "SAVE & EXIT" Press both
the Switches simultaneously
To "SAVE" Menu Setting,
11
Press the START/STOP Switch once
To "EXIT" without saving the settings, press
12
the PAPER FEED Switch once
Directions
38
PAPER FEED
START / STOP
Press
5 Sec
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
PAPER FEED
START / STOP
PAPER EJECT
