YCR-M05
User Guide
Vacuum Cleaning Robot iClebo Arte
■Please be sure to read the Safety Precautions before use.
www.i c l e bo.com/engl i s h

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Arte YCR-M05 and is the answer not in the manual?

Questions and answers

Related Manuals for Iclebo Arte YCR-M05

Summary of Contents for Iclebo Arte YCR-M05

  • Page 1 YCR-M05 User Guide Vacuum Cleaning Robot iClebo Arte ■Please be sure to read the Safety Precautions before use. www.i c l e bo.com/engl i s h...

  • Page 2: Safety Precautions

    • Random Mode • Spot Mode • Max (Auto + Random) mode • Mopping Mode / Door sill adjust Timer cleaning Iclebo Care & Maintenance Emptying dust bin and servicing the antibacterial filter Cleaning Side Brush Cleaning Sensor Cleaning Main Brush...
  • Page 3 This content is for the user’s safety and to prevent any property loss. Read the below carefully and use it with care. Users must be aware of necessary details for using this product. Prohibition Users must follow the instructions to avoid serious injury or death.
  • Page 4 Precautions before using - Do not touch the power cord of the charger with wet hands. It may cause electric shock. Prohibition - Arrange any cables or wires before use to avoid them being wrapped or caught by the robot Warning It may cause re or electric shock due to damaged cable.
  • Page 5 Precautions while using - In case the robot cleaner has unusual sound, smell or smoke turn o the robot immediately and place well away from ammable objects. Warning It may cause electric shock or re. - Do not use the robot cleaner on the table or any place high. It may damage the product.
  • Page 6 Components YCR -M0 5-02 Qu ick Gu ide Vacuu m Clean ing Robo t Robot cleaner Charging Cleaning brush Remote control Quick Guide station (included battery) User Guide(CD) Adapter Antibacterial filter Mop plate Side-brush(R) Side-brush(L) Area boundary Ultra microfiber Double sided tape wet mop tape...
  • Page 7 ● Charging station ● Dust bin Filter Antibacterial /blackout filter Filter case Charging display Dust bin Infrared generator Blade non-slip Charging terminal ● Remote control ● Display screen Start/stop Power button Battery button Set-time status Time setting status Timer button button Door sill height Clock/...
  • Page 8 For effective cleaning Please follow the instructions below for high cleaning e ciency. - Empty the dust bin a er each use of the robot cleaner. - Use Magnetic strip to con ne the robot to an area or by closing the door. (Refer to P.10 How to install entrance prevention tape) - Fix up the magnetic strip not to apart from the oor.
  • Page 9 Check list before using Assemble side-brush 1. A er turning over the vacuum cleaning robot, verify the positions of the le and right side brushes. 2. Match L side brush to L marked part in the direction of the groove, and push in hard. 3.
  • Page 10 Check list before cleaning Install base (charging) station 1. Open the cover of the backside of the charging station, and install the adapter with connected power plug as in the gure. 2. Completely connect the charging jack of the adapter to the jack inside the charging station.
  • Page 11 Current Time setting ※ Make sure to set time for timer cleaning. 1. Press the Clock bu on on the remote control. Time display of the display screen will ash. 2. Set “hour” with (+)(-) bu on of the remote controller, and press Enter bu on.
  • Page 12 ※During the basic cleaning, robot performs the 3. Use MODE to select AUTO or NDOM. (During the se ing of NDOM mode, set cleaning in vision mapping method, and the robot cleaning time using +,- bu on: Default is 60 min.) decides when to nish the cleaning.
  • Page 13 ※ The default climbing height of obstacles for the robotic vacuum cleaner is up to about 18mm. Cleaning ※ If you wish to set the robot not to go over obstacles over 5mm or mode doorsill, etc., click CLIMB button to turn off CLIMB mode! : Please turn off CLIMB mode if you wish to protect carpet, etc.
  • Page 14 Emptying dust bin and servicing the antibacterial filter 1. While pressing the dust bin out bu on of the main body as in the gure and carefully separate the dust bin toward the back. 2. Hold the blade of the dust bin as in the gure, and dust o the li er. 3.
  • Page 15 Cleaning Main brush 4. Separate the brush cover then remove the main brush. Furrow 6. A er cleaning, put the pyramid-shaped bump on the side of the main brush to the pyramid-shaped recess on the drive cam. (Insert rmly to ensure there is No gap between the brush and the cam.) Cleaning Front Wheel...
  • Page 16 Storage 1. If the vacuum cleaning robot is not used for a long period of time, turn o the power switch on the side of the main body. 2. Place it where it is cool and ventilated.
  • Page 17 Below is the explanation about the most occurred ‘breakdowns’ when using this product. If you can’t solve the problem with information below, please call your Customer service center. Problem C a u s e S o l u t i o n See <Product control &...
  • Page 18 Dust bin is full or lter is Empty and clean the dust bin. dirty. Noise of the See <Product control & maintenance> Main brush is dirty. robot cleaner is (page 13) and clean the lter. Main brush is dirty or hairs ge ing worse.
  • Page 19 This vacuum cleaning robot contains open source software. Yujinrobot Co., Ltd. hereby provides a complete copy of the corresponding source code.
  • Page 20 Noise 55 db ※ Cleaners from YUJIN Robots, iclebo series is designed to comply with Energy star standard, which is the new energy consumption efficiency certification system in Europe, and it achieves the highest energy efficiency level in the industry.
