Chapter 2
available in either 208 VAC or 230/240 VAC configurations for
international markets
Uninterruptible Power Supply (UPS) models rated at 3000 Watts are
available for either voltage range; or a 2250 Watt UPS is available for
230/240 VAC (see Table 2-1)
for both 208 and 230/240 voltages, two wide range Power Distribution
Unit (PDU) models (rated 10 A and 16 A) are available
(see Figure 2-1)
one or more PDUs can be used in each rack enclosure, depending upon
requirements for power, current, and number of receptacles
(see Table 2-4)

Power Cables and Components Available

When components are installed in a rack, a power supply subsytem for the rack is
required. HP recommends the NetServer LXr 8500 be connected as follows:
connected to a Power Distribution Unit (PDU)--see Figure 2-1.
through an Uninterrupible Power Supply (UPS)--see Table 2-1
to a properly protected branch circuit or circuits--see "Site Preparation--
Circuit Breakers" in Chapter 1
NOTE
A Redundant Switch is available for use between the UPS and
the branch circuit or between the PDU and the branch circuit.
More information is listed in Table 2-2 and in Appendix B.
Table 2-2 lists details of the cables, components, plugs and receptacles for the two
rack power supply subsystems for the HP NetServer LXr 8500.
Table 2-1. UPS Models and Power Ratings
Uninterruptible Power Supplies (UPS) Available
APC Model
NS3000RMT3U
NS2200RMI3U
NS3000RMI3U
Note 1. Ensure UPS Volt Amps rating is not exceeded. Add power in Volt Amps of each
component and connect no more than those the UPS supports.
Note 2. Also ensure UPS Wattage rating is not exceeded. Add power in Watts of each
component and connect no more than those the UPS supports.
16
1
Power (VA)
3000
2200
3000
Rack Cabling References
2
Power (Watts)
2250
1600
2250
