SITRANS F Ultrasonic Flowmeters
with PROFIBUS PA Interface
7ME30xx-xxxxx-1xxx
Instruction Manual (Supplement)
Note:
This document is a supplement to the Instruction Manual C79000-B5676-C110 for the
PROFIBUS PA-version. Knowledge of this Instruction Manual is assumed, since this
supplement only describes the differences from the standard version.
Special notice must also be taken of the warnings specified for the standard version.
C79000-B5676-C114-03

Advertisement

Table of Contents
loading

Related Manuals for Siemens 7ME30

Summary of Contents for Siemens 7ME30

  • Page 1 SITRANS F Ultrasonic Flowmeters with PROFIBUS PA Interface 7ME30xx-xxxxx-1xxx Instruction Manual (Supplement) C79000-B5676-C114-03 Note: This document is a supplement to the Instruction Manual C79000-B5676-C110 for the PROFIBUS PA-version. Knowledge of this Instruction Manual is assumed, since this supplement only describes the differences from the standard version. Special notice must also be taken of the warnings specified for the standard version.
  • Page 2 SIPART, SITRANS, SIMATIC are Siemens registered trademarks. All other product or system names are (registered) trademarks of their respective owners and must be treated accordingly. The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages.

  • Page 3: Table Of Contents

    Instruction Manual Contents Page Technical Description ..............PROFIBUS .

  • Page 4: Technical Description

    Instruction Manual Technical Description PROFIBUS The PROFIBUS (Process Field Bus) is an open communication system for automation engineering which is being used in its thousands all over the world and which is specified in the European standard EN 50170. 1.1.1 General Information about PROFIBUS DP and PA The PROFIBUS PA is a variant of the PROFIBUS DP which is used widely in production engineering.

  • Page 5: Properties Of The Profibus Pa

    Instruction Manual 1.1.2 Properties of the PROFIBUS PA The PROFIBUS PA (PA = Process Automation) enables di-directional communication between a bus master and the field devices over a two-wire cable. At the same time the power is supplied to the two-wire field devices through the same cables (current I in Figure 1--1).

  • Page 6: Function Of The Device

    Instruction Manual Warning Only certified supply units (DP/PA couplers or DP/PA links) may be used to feed the intrinsically safe PROFIBUS. See the EC Type Examination Certificate for requirements. The number of devices which can be connected to a bus line is given by the total of maximum current consumptions of the connected devices (³...

  • Page 7: Scope Of Functions

    Instruction Manual Scope of Functions SITRANS F provides the following measured values and values derived from measured values using PROFIBUS and local display. · Flow (volume or mass flow) · Sound velocity · Temperature · Ultrasonic amplitude · Quantity (volume or mass) net, forward and reverse An upper and lower limit can be specified for all measured values.

  • Page 8: Technical Data

    Instruction Manual Technical Data Device version Order number 7ME30xx-xxxxx-1xxx (Software version 2.00 onward) Data According to operating manual of the 20 mA/HART version (order number C79000-B5600-C110) with the following deviations: Communication Layer 1+2 acc. to PROFIBUS PA, transmission technique acc. to IEC 61158-2;...

  • Page 9: Installation

    The following rules apply generally for laying the bus cable: Only use shielded, two-wire cables Only use the recommended cable types, e.g.: in intrinsically safe circuits: Siemens 6XV1 830-5AH10 (color blue); in circuits with enhanced safety or non-Ex applications: Siemens 6XV1 830-5BH10 (color black) Lay cable separately from cable with voltages >...

  • Page 10: Commissioning

    Instruction Manual Earth connection for bus cable shield Not used Digital output 1 PROFIBUS PA Power supply: L/N for AC 120 to 230 V L+/L- - for UC 24 V Earth terminal for PE PROFI- L- - BUS PA Figure 2--1 Electrical connection A bus termination must be fitted at both ends of the bus for error-free communication (see Figure 1--2).

  • Page 11: Operation, Communication

    Instruction Manual Operation, Communication PROFIBUS Communication SITRANS F has a PROFIBUS PA connection corresponding with IEC 1158 (synchronous transmission). The only possible baud rate is 31.25 kbits/s. The min T (smallest station delay time, chapter 5.4.1, Seite 32) at startup is 11 bit times and can subsequently be changed using the Set_Prm service. The bus address has the value 126 as-delivered and can either be changed with the Set_Slave_Add DP service or on the local keyboard (menu 4.1.1).

  • Page 12: Input Data (From Device To Master)

    Instruction Manual 4.1.1.1 Input Data (from device to master) Input data are user data (measured values) which are transmitted from the device to the master in the following format: Every measured value consists of 5 bytes which are composed of a floating point value corresponding with IEEE -- 754 (4 bytes) and the appropriate measured value status (1 byte).
  • Page 13 Instruction Manual (Profile) description Meaning configuration error Parameter error, i.e. upper and lower value for measuring or output scale are identical device failure RAM or EEPROM defective; Diagnosis bit “Memory error” is also set and the diagnosis message “RAM error” or “EEPROM error” displayed locally.
  • Page 14 Instruction Manual The following combinations of the status byte values described above are possible in normal operation (i.e. when the input value of the respective function block incl. status is not simulated): Value Meaning Applies to Quality Substatus Limit Flow Sound Tem- Ultra-...

  • Page 15: Output Data (To The Device)

    Instruction Manual 4.1.1.2 Output Data (to the Device) The output data consist of one byte each per resettable totalizer (net, forward and reverse) of which only the two respective least significant bits are evaluated. All other bits are not evaluated but should be set to 0.

  • Page 16: Acyclic Data Transmissio

    Instruction Manual Example: The measured values sound velocity, temperature and ultrasonic amplitude are to be transmitted. The following identifier combination should set: 1. Free Place (for flow) 2. short Identifier or long Identifier (for sound velocity) 3. Free Place (for net quantity) 4.

  • Page 17: Diagnosis

    Instruction Manual 4.1.3 Diagnosis The diagnostic data can be requested with the Slave_Diag service. If extended diagnostic messages exist, this is displayed with the Diag_Flag of the Data_Exchange service. If the master then calls the Slave_Diag service, the user diagnostic data are supplied in the following form: Byte Profile description Value...
  • Page 18 Instruction Manual The DIAGNOSIS part contains device diagnostic messages and has the following structure (bit 0 = LSB, bit 7 = MSB): Bit no. Description Meaning Causes (= local message) DIA_HW_ELECTR Hardware failure of the “Temperature measurement electronic error” “SSC error” Error in communication with internal peripherals “Communications module not...
  • Page 19 Instruction Manual Examples of telegrams with diagnostic data (Ext_Diag_Data): Output state: all diagnostic bits are reset. When the “Temperature measurement error” (byte 5, bit 0 set) and “Unreliable flow value” (byte 5, bit 5 set) events occur, the following diagnostic data will result: Diagnostic byte no.

  • Page 20: Local Operation And Display

    Instruction Manual Local Operation and Display The menu structure for local operation is mostly repeated in the SIMATIC PDM PC user interface. It is based on the block structure which is a mandatory setting from the PROFIBUS PA profile. Substantial differences from the menu structure of the device with HART communication therefore cannot be avoided.
  • Page 21 Instruction Manual Menu Device function, Description Factory setting Options for settings code parameter () = display only 1.9.5 LCD lighting LCD illumination automatically switched off after 1 h. off: automatically switched on by pressing key, switches off after 3 min. Diagnostics Device status Error messages...
  • Page 22 Instruction Manual Menu Device function, Description Factory setting Options for settings code parameter () = display only 3.1.7 Meas. Scale Scaling of the physical measuring range 3.1.7.1 Unit l/h [kg/h] /s, m /min, m /h, m /d, l/s, l/min, l/h, ML/d, CFS, CFM, CFH, ft /d, gal/s, GPM, gal/h, Mgal/d, ImpGal/s,...
  • Page 23 Instruction Manual Menu Device function, Description Factory setting Options for settings code parameter () = display only 3.2.3 Output Scale Scaling of the output range 3.2.3.1 Lower Value +600.00 m/s 600 to upper value 3.2.3.2 Upper Value +2000.00 m/s Lower value to 2000 m/s 3.2.4 Limits 3.2.4.1...
  • Page 24 Instruction Manual Menu Device function, Description Factory setting Options for settings code parameter () = display only Totalizer forw. Volume totalizer [Mass totalizer] forward 3.5.1 Set totalizer to zero or Start Start start Stop+Reset 3.5.2 Unit Physical unit for volume , l, gallon, ImpGal [mass] [kg]...
  • Page 25 Instruction Manual Menu Device function, Description Factory setting Options for settings code parameter () = display only Device Outputs PROFIBUS 4.1.1 Bus Address PROFIBUS address 0 to 126 4.1.2 min Tsdr min. “Station Delay” of the (11 bits) responder Dig. Output 1 Frequency or pulse signal for the flow alarm signal 4.2.1...
  • Page 26 Instruction Manual Menu Device function, Description Factory setting Options for settings code parameter () = display only Control values 6.4.1 Gain Gain of the received signal (0 -- 255) 6.4.2 Amplitude Amplitude of the received (0 -- 255) signal optimal: 95 -- 105 6.4.3 Trigger Level Trigger level...

  • Page 27: Locking Operation

    Instruction Manual The display limits the input of numerical values with local operation to the value range --10 to + 10 . With PROFIBUS the range of values is in principle extended to --10 to + 10 . This is only reached in extreme cases with totalizer readings when the value 999 999 999 then appears in the display.

  • Page 28: Locking Local Operation

    Instruction Manual Hardware Write Protection: If write protection with hardware components is not set, the HW_WRITE_PROTECTION PROFIBUS parameter will not be of any significance. Calibration data: Access to calibration data and special service parameters can only be enabled by entering a factory code. Improper changes to these data can cause the device to seriously malfunction.

  • Page 29: Device Functions And Parameters

    Instruction Manual Device Functions and Parameters The following section only describes deviations from and additions to the operation menu for the standard device: Display Function Group Totalizer (menu 1.3) The totalizer readings are displayed with the correct sign, i.e. reverse totalizers with a minus sign. Set Totalizer (menu 1.3.4) “Stop+Reset”: All quantity totalizers are stopped and set to “0”.
  • Page 30 Instruction Manual Scaling (menu 3.1.7, 3.1.8, 3.2.2, 3.2.3, 3.3.2, 3.3.3, 3.4.2, 3.4.3) According to the PROFIBUS PA profile there are no selectable measuring ranges for process devices only sensor limits. Valid measured values (status “good”) are always inside the following sensor limits: Measured variable Lower sensor limit Upper sensor limit...
  • Page 31 Instruction Manual Output value Upper alarm limit Upper value Upper warning limit Lower value Current output value Lower warning limit Lower alarm limit Measured value Lower Upper Current Lower Upper sensor sensor measured value value value limit limit Measuring scale Valid measured values Figure 5--1 Assignment between measured value and output value (example) Limit values (menu 3.1.9, 3.2.4, 3.3.4, 3.4.4)

  • Page 32: Totalizer (Menu 3.5

    Instruction Manual 5.3.2 Totalizer (menu 3.5...3.7) The totalizers have fixed counting direction settings. The counting direction cannot be changed. The totalizers directly accumulate the physical measured values according to the negative or positive sign, i.e. the reverse totalizer only accepts negative values. The reading of the net totalizer is cumulated from the flow values with the correct sign and is not calculated from the difference of the contents of the forward and reverse totalizer.

  • Page 33: Digital Output 1 (Menu 4.2)

    Instruction Manual min Tsdr (= minimum station delay time of responder) In this parameter the master on the PROFIBUS sets the minimum waiting time which the SITRANS F slave has to observe before it answers a master telegram (unit: bit time = time for 1 bit at 31.25 kbit/s = 32 ms).

  • Page 34: Identification Function Group

    Instruction Manual If the “invalid” message appears when the function is switched over to “pulse”, the following can occur: · Pulse valency is too high for the set upper value ----> change required in menu 4.2.3. · Flow and totalizer are not uniformly set to volume or mass flow (only possible under PROFIBUS) ----> change volume or mass flow switchover (channel switchover using PROFIBUS) Signal Type (menu 4.2.2) Only passive signals with selectable signal logic (positive or negative) are available for this output, i.e.

  • Page 35: Error Filter (Menu 6.6.3)

    Instruction Manual 5.6.2 Error Filter (menu 6.6.3) Here you can enter limits for reliability evaluation of flow measured values: The appropriate error message will only appear when the proportion of bad measured values exceeds the selected percentage value: “uncertain”: · Quality in measured value status is set to “uncertain” (uncertain, non specific”) ·...

  • Page 36: Certificates

    Instruction Manual Certificates EC Declaration of Conformity See operating manual for basic unit SITRANS F with PROFIBUS PA C79000-B5676-C114-03...

  • Page 37: Ec Type Examination Certificate

    Instruction Manual EC Type Examination Certificate (Translation; EC Type Examination Certificate PTB 97 ATEX 1054X, 1st supplement to 4th supplement original in german, see page 41) SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 38 Instruction Manual SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 39 Instruction Manual SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 40 Instruction Manual SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 41 Instruction Manual German Original SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 42 Instruction Manual SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 43 Instruction Manual SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 44 Instruction Manual SITRANS F with PROFIBUS PA C79000-B5676-C114-03...

  • Page 45: Pno Certificate

    Instruction Manual PNO Certificate Certification from PNO is not possible at present. SITRANS F with PROFIBUS PA C79000-B5676-C114-03...

  • Page 46: Literature And Catalogs

    76131 Karlsruhe 76131 Karlsruhe PROFIBUS PA -- Profile for Process Control Devices Data Sheet Transmitter V3.0 PROFIBUS & AS--Interface, Components on Siemens AG E86060-K4660-A101-A2 the Field Bus, Catalog ST PI Programmable Logic Controls, Siemens AG E86060-K4650-A101-A7 SIMATIC S5, Catalog ST50...

  • Page 47: Appendix: Device Data Base File (Gsd File)

    Instruction Manual Appendix: Device Data Base File (GSD File) ;********************************************************************* GSD Datei für SITRANS F, SIEMENS AG MLFB: 7ME30**-*****-1*** Stand: 25.11.1999 SIEM8091.GSD ;********************************************************************* Profibus_DP GSD_Revision Vendor_Name = ”SIEMENS AG” Model_Name = ”SITRANS F” Revision = ”Revision 02” Ident_Number = 0x8091...
  • Page 48 Instruction Manual Unit_Diag_Bit(39) = ”Ident_Number violation” Unit_Diag_Bit(55) = ”Extension Available” User_Prm_Data_Len = 0 ;=========== Description of modules ======================================= ; Use always the module order specified in this file. ; Use exactly one identifier per module. ; If you don’t want to get the measuring value of a certain module ;...
  • Page 49 Module = ”Resettable quant. rev. (long)” 0xC1, 0x80, 0x84, 0x85 EndModule GSD and Bitmap are already stored in the Siemens control systems. They can however also be found on the Internet at http://www.ad.siemens.de/csi/gsd (search for “sitrans f”). SITRANS F with PROFIBUS PA C79000-B5676-C114-03...

  • Page 50: Index

    Instruction Manual Index Abbreviations, 50 EC Declaration of Conformity, 36 EC Type Examination Certificate, 37 Electrical connection, 9, 10 Bus cable, 9 Bus address, 32 Enter code, 25 Error filter, 35 Catalogs, 44 Certificates, 36 Factory setting, 20 EC Declaration of Conformity, 36 Flow, 29 EC Type Examination Certificate, 37 PNO Certificate, 43...
  • Page 51 Instruction Manual Order data, 8 Scope of functions, 7 Flow, 7 Quantity, 7 ultrasonic amplitude, 7 Sound velocity, 7 Temperature, 7 Parameters, 20, 29 Sensor limits, 30 PNO Certificate, 43 Service, 25, 34 PROFIBUS, 4 Code, 34 Acyclic data transmission, 16 Error filter, 35 Automation system, 4 Bus address, 32...

  • Page 52: Abbreviations

    Instruction Manual Abbreviations GSD: Device Data Base File PDM: Process Device Manager PNO: PROFIBUS user organization PROFIBUS PA: Process Field Bus for Process Automation SITRANS F with PROFIBUS PA C79000-B5676-C114-03...
  • Page 54 Siemens AG Bereich Automatisierungs- und Antriebstechnik Geschäftsgebiet A&D PA D-76181 Karlsruhe E Siemens AG 1999 All rights reserved C79000-B5676-C114 Siemens Aktiengesellschaft Printed in France AG 0300 MG 52 GB...
