Access Easy Controller
NOTICE!
i
The number of digits for the User PIN code range from 1 to 7 digits. Please refer to the AEC
Software User Manual Chapter on Card Assignment, Card Functionality for detail.
21.2.5

Entry and Arm/Disarm Reader

A Reader can be configured to allow arming or disarming a group of Input Points (collectively
called an Alarm Zone), using methods similar to Door Access such as, Manual Card Number
entry, Card only, Card + PIN code and common Reader's PIN code (please refer to the previ-
ous section for detail).
Cardholders allowed to arm/disarm the Alarm Zone are configured under the section Card
Assignment, Card Functionality.
The statuses of the Alarm Zone are indicated via the LED. The following tables shows the HID
compliant reader and S-series reader indicators for easy reference.
HID reader LED indicators
HID reader
Armed.
The zone is Armed
Part Armed
The zone is Armed with some
Input Point(s) bypassed.
Card is presented to the
Reader when the LED is
flashing.
Ready/Disarmed
All Input Points in the zone
are in the Normal state and
are ready for Arming.
Not Ready/Disarmed
One or more Input Points is
not in the Normal state and
not ready for Arming
Alarm
The zone is Armed and one
or more Input Point is in
Alarm State
Bosch Security Systems
LED
Red
Green/Red Alternating at
slow rate
Green
Green/Red Alternating at
medium rate
Red
Hardware Manual
Card Reader Keypad Functions | en 165
Buzzer
Off or Beeping During Arm
Delay
Off or Beeping During Arm
Delay
Off
Off
0.5 sec On and 0.5 sec Off
