Control Panel
D9412GV4/D7412GV4 v2.03
en
Quick Reference Guide

Advertisement

Table of Contents
loading

Related Manuals for Bosch D9412GV4

Summary of Contents for Bosch D9412GV4

  • Page 1 Control Panel D9412GV4/D7412GV4 v2.03 Quick Reference Guide...

  • Page 3: Table Of Contents

    Upgrade D9412GV4/D7412GV4 Hardware and Programming Receive Existing Control Panel Programming 3.1.1 Receive Existing Control Panel Programming with RPS Upgrade Previous GV Series Hardware to a D9412GV4/D7412GV4 v1.00 Control Panel 3.2.1 Prepare to Remove Existing Hardware 3.2.2 Remove the Existing Control Panel 3.2.3...
  • Page 4 11.3 Device Numbers (zzz, dddd) 11.4 Communication Trouble Device Numbers (zzzz) 11.5 Special User IDs (uuuu, iiii) 11.6 Keypad Alarm Virtual Point Numbers (ppp, pppp) Frequently Asked Questions 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 5: Introduction

    Determine Bosch Security Systems, Inc. Product Manufacturing Dates Use the serial number located on the product label and refer to the Bosch Security Systems, Inc. website at http://www.boschsecurity.com/datecodes/. The following image shows an example of a product label and highlights where to find the manufacturing date within the serial number.

  • Page 6: D9412Gv4/D7412Gv4 Control Panel Connections

    | D9412GV4/D7412GV4 Control Panel Connections Control Panel D9412GV4/D7412GV4 Control Panel Connections Pages 6 and 7 describe the D9412GV4/D7412GV4 v2.00 configuration and supported devices. 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
  • Page 7 Control Panel D9412GV4/D7412GV4 Control Panel Connections | en Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...

  • Page 8: Upgrade D9412Gv4/D7412Gv4 Hardware And Programming

    Click Connect. Once connected, the Panel Sync window appears. Select the Receive Panel Data option button and click OK. Upgrade Previous GV Series Hardware to a D9412GV4/ D7412GV4 v1.00 Control Panel Use the following procedure to upgrade the hardware from a previous GV Series control panel to a D9412GV4/D7412GV4 v1.00 control panel.

  • Page 9: Remove The Existing Control Panel

    3.2.3 Install the D9412GV4/D7412GV4 v2.00 Control Panel in the Enclosure Place the D9412GV4/D7412GV4 v2.00 Control Panel in the enclosure using the mounting skirt hook holes on the back of the control panel and the mounting skirt hooks on the enclosure.

  • Page 10: Replace The Terminal Strips

    Notice! If the control panel was previously mounted using the screw hole configuration, then you must re-mount the new control panel. The D9412GV4/D7412GV4 v2.00 control panel mounting screw hole locations do not align with the locations for older control panels.

  • Page 11: Upgrade A Gv4 (Version 1.00 - 1.99), Gv3 Series, Gv2 Series, G Series, Or Non-G Series

    Control Panel Upgrade D9412GV4/D7412GV4 Hardware and Programming | en 3.3.1 Upgrade a GV4 (version 1.00 – 1.99), GV3 Series, GV2 Series, G Series, or Non-G Series Control Panel to a GV4 v2.00 or Later Using Remote Programming Software (RPS) 5.15 or Later RPS version 5.15 or newer is required to upgrade an existing G Series, GV2, or GV3 Series...
  • Page 12 View. In the control panel Data View window, click Edit, and then from the Panel Type drop down list, select the correct control panel type with [V2.00 or greater] (i.e. D9412GV4 v2.00 or greater), and then click OK.

  • Page 13: Programming The Control Panel

    For additional information, refer to Programming Through a Control Panel in the B426 Conettix Ethernet Communication Module Installation and Operation Guide. Programming Using the Installer Menu For additional information, refer to the Control Panels (D9412GV4/D7412GV4 v2.00) Installation and System Reference Guide. Bosch Security Systems, Inc.

  • Page 14: Programming To Set Up Central Station Reporting

    Notice! You can program these items using RPS (version 5.15 or greater) and the steps listed below. You can also use keypad programming (refer to the D9412GV4/D7412GV4 v2.00 Program Entry Guide). Basic Telephone Set Up in RPS Go to PANEL WIDE PARAMETERS→ Phone and Phone Parameters.

  • Page 15: Account Number

    In RPS, go to AREA WIDE PARAMETERS and enter the account number (up to 10 digits) in the Account Number parameter. Notice! Area 1 is the only area turned on by default. Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...

  • Page 16: Programming The Control Panel For Common Reporting Options

    Go to the Authority Level to be used by users sending Open and Close reports. Select E (enabled) for Area Open/Close. Select E for Restricted Open/Close. Select E for Perimeter Open/Close. 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 17: Setting Up Points And Outputs

    Programmers must be aware of the following considerations: Do not use relays designated within Point Assignments for multiple functions. For example, Relays 73 through 80 on the D9412GV4 should not be used for relay-follow-point or area-wide or panel-wide relays. Relays should not be selected to follow points programmed as Invisible Points.

  • Page 18: Point Index (Default Values)

    Description Description 24-Hour Open/Close Point Part On Fire Point Interior Aux AC Supervision Interior Follower Gas Point Keyswitch Maintained Custom Function Keyswitch Momentary Table 7.4: Point Type Selections 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
  • Page 19 Short 24-Hour Open Short *Selections: D = Delayed Response, I = Instant Alarm, S = Supervisory, T = Trouble, B = No Response Table 7.5: Point Response Selections* Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...

  • Page 20: Add System Users Locally With A Keypad

    RADION keyfob or an Inovonics Transmitter. Press [Edit] softkey to continue. Enter the RFID. Press [Save] softkey to save the RFID and return to the previous menu. 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 21: Adding A Card For The User

    Press [ESC] to exit the menu. Notice! You can add a keyfob, transmitter, or card to an existing user by selecting the Edit User menu instead of the Add User menu. Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...

  • Page 22: Turning The System On Or Off And Keypad Commands For B920/B930

    If your system includes D1255, D1260, or D1265 legacy keypads, you can initiate the commands described in the previous table from those keypads. These are the only commands available from those keypads. 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 23: Sia Cp-01 False Alarm Prevention Options

    Entry Delay Warning=YES: When this parameter is set to YES, the alarm bell pulses on and off every two seconds for the remaining 10 sec of Entry Delay. Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...

  • Page 24: Device Address Settings

    Operation Guide. 10.10 D9127 U/T POPIT Dip Switch Key POPIT addresses are binary. Refer to the table below. Switch Number 0 Binary Value Table 10.1: POPIT Dip Switch Keys 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 25: D9210C Access Control Interface Module Rotary Address Switch Settings

    For additional information, refer to the D8129 OctoRelay Module Operating and Installation Guide. 10.14 D8128D OctoPOPIT Dip Switch Settings For additional information, refer to the D8128D OctoPOPOIT Module Installation Guide. Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...

  • Page 26: Reporting And Device Number Information

    Aspppp NriaBMpppp Burglary 1 130 aa ppp Alarm Exit Error Aspppp Nria/idiiiiEApppp Entry/Exit 1 134 aa ppp Alarm with Recent Closing Aspppp Nria/CRpppp Entry/Exit 1 459 aa uuu 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
  • Page 27 1 330 00 zzz Cellular Service Not Activated RssssD NpiddddER System Peripheral Trouble 3 330 00 zzz Restoral Restore Change another’s password NsDO4 NidiiiiiJViiiii Local Only Local Only or card Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...
  • Page 28 Date changed by user NsD07 NidiiiiJD Time/Date Reset 1 625 00 uuu Delete User by User NsD05 NidiiiiJXiiii Local Only Local Only DNS Failure TsB01 NpiddddYS Communication Trouble 1 350 00 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
  • Page 29 NriaaFHpppp Fire 3 110 aa ppp Fire Restoral from Trouble Hspppp NriaaFJpppp Fire Trouble 3 373 aa ppp Fire Supervision Espppp NriaaFSpppp Fire Supervisory 1 200 aa ppp Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...
  • Page 30 1 642 00 iii Key fob Missing Restoral RsD10 NidiiiiUR Latch-Key Supervision 3 642 00 iii Rest. Key fob Panic Assss NidiiiiPA Duress Alarm 1 121 00 iii 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
  • Page 31 Telco 1 Fault 3 351 00 000 Phone Line Restored 2 RsssB NLR2 Telco 2 Fault 3 352 00 000 Point Bus Fail TsssD Protection Loop 1 370 00 000 Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...
  • Page 32 1 393 aa ppp ROM Checksum Fail AsD12 ROM Checksum bad 1 304 00 000 SDI Bus Fail Ground Fault TsssD Ground Fault 1 310 00 (SDI2 only) 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
  • Page 33 SDI2 Open Trouble Restoral RsssD NpiddddER Expansion Module Failure 3 333 00 Sensor Reset NsD27 Nriaa/idiiiiXlrrrr Sounder/Relay 3 320 00 000 Service Bypass Npppp NriaaUBpppp Service Request 1 616 aa ppp Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...
  • Page 34 Test Report – System Off- RsssE Periodic Test – System 1 608 00 000 normal, Non-expanded Status Trouble Present Time Changed – No User NsD07 Time/Date Reset 1 625 00 000 Identified 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 35: Sdi/Sdi2 Address Information

    SDI2 Octo-input Modules 1 through 24 66-77 301-312 SDI2 Octo-output Modules 1 through 12 SDI2 Premises RF Module 161-168 851-858 SDI2 RF Repeater 1 through 8 SDI2 Network Module 1 Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...

  • Page 36: Device Numbers (Zzz, Dddd)

    88 – 91 88 – 91 Paths 1 through 4 on SDI Network Module 1 92 - 95 92 - 95 Paths 1 through 4 on SDI Network Module 2 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 37: Special User Ids (Uuuu, Iiii)

    Originating Keypad (SDI2 only) Reported Number Originating Keypad (SDI2 Reported Number only) Keypad 1 Keypad 9 Keypad 2 Keypad 10 Keypad 3 Keypad 11 Keypad 4 Keypad 12 Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...
  • Page 38 | Reporting and Device Number Information Control Panel Keypad 5 Keypad 13 Keypad 6 Keypad 14 Keypad 7 Keypad 15 Keypad 8 Keypad 16 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.

  • Page 39: Frequently Asked Questions

    – obtain the firmware update file from Bosch and, using the RPS Firmware Update Wizard, connect to the panel and send the new version to the control panel (local user authorization may be required). Always re-test your system when the firmware version has been changed.
  • Page 40 RPS passcode. Refer to Programming Using the Installer Menu, page 13. How do I set the address for the D1265 keypad? Hold the Zero key for approximately 10 seconds. 2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
  • Page 41 What is SDI XX Comm Trouble? This error occurs when you have a SDI communication device that is no longer communicating with the Central Station. Bosch Security Systems, Inc. Quick Reference Guide 2014.05 | 05 | F.01U.265.463...
  • Page 44 Bosch Security Systems, Inc. 130 Perinton Parkway Fairport, NY 14450 www.boschsecurity.com © Bosch Security Systems, Inc., 2014...
