Mounting and installation
The accessory HAS05.1-015-NNN-NN (snap-on ferrite) ensures that
Class C3 of the EMC Directive EN 61800-3 is complied with for braking resis‐
tors installed outside of the control cabinet.
The snap-on ferrite is designed for the following components:
■ HCS01.1E-W0018 + HLR01.2N-01K0-N68R0-E-007
■ HCS01.1E-W0028 + HLR01.2N-01K0-N68R0-E-007
■ HCS01.1E-W0054 + HLR01.2N-01K0-N28R0-E-007
WARNING
The temperature of the housing surface of an external HLR braking resistor
can rise up to 150 °C. Run the connection lines with a sufficient distance
(> 200 mm) to the housing of the HLR braking resistor to avoid damaging the
insulation of the connection lines. Outside of the control cabinet, run the con‐
nection lines of an HLR braking resistor in a metal pipe with a wall thickness
of at least 1 mm.
Do not touch hot housing surfaces! Mount the HLR braking resistor on a tem‐
perature-resistant mounting surface. Provide a sufficient distance between
the HLR braking resistor and heat-sensitive materials. Make sure the cooling
air supply is unrestricted. Take care that the environment can discharge the
dissipation heat.
NOTICE
Protect the lines with the appropriate fusing elements in the supply feeder.
For the connection lines at X9, use at least the cross section of the lines for
mains connection at X3. If this is impossible, select the cross section of the
connection line at X9 in accordance with the continuous power of the braking
resistor.
