C
ALIBRATION PROCESS
ADTS552/553/554F
Pneumatic pressure
Table 4-2: Calibration requirements ADTS552/553/554F
Equipment Type
Calibration standard (absolute)
All traceable to national standards.
If a calibration standard with higher uncertainty is used, the ADTS accuracy will be degraded and may exceed
the ADTS sales data sheet specification.
Table 4-3: Calibration equipment uncertainty

Suggested two-point calibration adjustment points

Calibration points are nominal pressures to allow for slight differences due to primary standard
weights and actual corrected pressure calculations.
- Ps: two point cal points = 1st point is 1128mbar (FS) followed by 92mbar (suggest to be done in
this order).
- Pt: two point cal points = 1st point 92mbar followed by 1997mbar (FS) (suggest to be done in
this order).
[EN] English
Accuracy specifications(k = 2,
95% uncertainty)Includes: NL, H
and R over the ADTS operating
temperature range and
calibration stability over 12
months and calibration
equipment uncertainty stated in
Table 4-3
Ps Range:
72 mbar to 1130 mbar absolute
(EALT option 57 mbar)
Accuracy:
Refer to current product data sheet
Pt Range:
72 mbar to 1997 mbar absolute
(EALT option 57 mbar)
Accuracy:
Refer to current product data sheet
Minimum use specifications
Range:
35 mbar to 2000 mbar absolute.
Expanded uncertainty (k = 2):
32ppm of reading +0.007
mbar(0.0032% of reading +0.70 Pa)
112
Test method
Compared against calibration
standard
Purpose
Calibration
K0553 Revision D
