MODBUS MEMORY MAP
Address Description
Data Logger (Read/Write Setting)
4B00 Data Logger Function
4B01 Data Logger Block
4B02 Data Logger Rate
4B03 Data Logger Avg Interval
Data Logger Channel Configuration (Read/Write Setting) (16 Modules)
4B10 Data Logger Channel 1 Signal
4B12 Data Logger Channel 1 Name
4B18 Data Logger Channel 1 Mode
4B19 Data Logger Channel 1 Alarming
4B1A Data Logger Channel 1 Reset Alarms
4B1B Data Logger Channel 1 Reset Statistics
4B1C Data Logger Channel 1 Hi Alarm Pickup
4B1D Data Logger Channel 1 Hi Alarm Delay
4B1E Data Logger Channel 1 Hi-Hi Alarm Pickup
4B1F Data Logger Channel 1 Hi-Hi Alarm Delay
4B20 Data Logger Channel 1 Lo Alarm Pickup
4B21 Data Logger Channel 1 Lo Alarm Delay
4B22 Data Logger Channel 1 Lo-Lo Alarm Pickup
4B23 Data Logger Channel 1 Lo-Lo Alarm Delay
4B24 ...Repeated for Data Logger Channel 2
4B38 ...Repeated for Data Logger Channel 3
4B4C ...Repeated for Data Logger Channel 4
4B60 ...Repeated for Data Logger Channel 5
4B74 ...Repeated for Data Logger Channel 6
4B88 ...Repeated for Data Logger Channel 7
4B9C ...Repeated for Data Logger Channel 8
4BB0 ...Repeated for Data Logger Channel 9
4BC4 ...Repeated for Data Logger Channel 10
4BD8 ...Repeated for Data Logger Channel 11
4BEC ...Repeated for Data Logger Channel 12
4C00 ...Repeated for Data Logger Channel 13
4C14 ...Repeated for Data Logger Channel 14
4C28 ...Repeated for Data Logger Channel 15
4C3C ...Repeated for Data Logger Channel 16
Disconnect Interlock (Read/Write Setting) (30 Modules)
4C50 Disconnect 1 Interlock Function
4C51 Disconnect 1 Interlock Tagging
4C52 Disconnect 1 Interlock Status Supv
4C53 Disconnect 1 Interlock Close Interlock 1
4C54 Disconnect 1 Interlock Close Interlock 2
4C55 Disconnect 1 Interlock Close Interlock 3
4C56 Disconnect 1 Interlock Open Interlock 1
4C57 Disconnect 1 Interlock Open Interlock 2
4C58 Disconnect 1 Interlock Open Interlock 3
4C59 Disconnect 1 Interlock Events
4C5A ...Repeated for Disconnect 2
82
Range Units
0 to 1 ---
0 to 65535 ---
1 to 3600 /hr
1 to 86400 /Rate
0 to 4294967295 ---
--- ---
0 to 2 ---
0 to 2 ---
0 to 65535 ---
0 to 65535 ---
-90 to 90 pu
1 to 300 s
-90 to 90 pu
1 to 300 s
-90 to 90 pu
1 to 300 s
-90 to 90 pu
1 to 300 s
0 to 1 ---
0 to 1 ---
0 to 1 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 1 ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
1 F102 0 (Disabled)
1 F300 0
1 F001 60
1 F003 3600
1 F600 0
--- F205 "Channel 1"
1 F091 2 (Mean)
1 F109 0 (Disabled)
1 F300 0
1 F300 0
0.01 F002 100
0.1 F001 10
0.01 F002 100
0.1 F001 10
0.01 F002 100
0.1 F001 10
0.01 F002 100
0.1 F001 10
1 F102 0 (Disabled)
1 F102 0 (Disabled)
1 F102 0 (Disabled)
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F300 0
1 F102 1 (Enabled)
