MODBUS MEMORY MAP
Address Description
13F6 Data Logger Channel 14 Average
13F8 Data Logger Channel 14 Unit
13FC Data Logger Channel 15 Maximum
13FE Data Logger Channel 15 Maximum Date
1400 Data Logger Channel 15 Maximum Time
1402 Data Logger Channel 15 Minimum
1404 Data Logger Channel 15 Minimum Date
1406 Data Logger Channel 15 Minimum Time
1408 Data Logger Channel 15 Average
140A Data Logger Channel 15 Unit
140E Data Logger Channel 16 Maximum
1410 Data Logger Channel 16 Maximum Date
1412 Data Logger Channel 16 Maximum Time
1414 Data Logger Channel 16 Minimum
1416 Data Logger Channel 16 Minimum Date
1418 Data Logger Channel 16 Minimum Time
141A Data Logger Channel 16 Average
141C Data Logger Channel 16 Unit
Contact Inputs and Outputs (Read Only States)
1420 Contact Inputs 1 to 16 States
1421 Contact Inputs 17 to 32 States
1422 Contact Inputs 33 through 48 States
1423 Contact Inputs 49 through 64 States
1424 Contact Inputs 65 through 80 States
1425 Contact Inputs 81 through 96 States
1426 Contact Inputs 97 through 112 States
1427 Contact Inputs 113 through 115 States
1430 Contact Outputs 1 to 16 States
1431 Contact Outputs 17 to 32 States
1432 Contact Outputs 33 to 48 States
1433 Contact Outputs 49 through 64 States
1434 Contact Outputs 65 through 80 States
1435 Contact Outputs 81 through 96 States
1436 Contact Outputs 97 through 112 States
1437 Contact Outputs 113 through 115 States
1438 Contact Outputs 1 to 16 Current States
1439 Contact Outputs 17 to 32 Current States
143A Contact Outputs 33 to 48 Current States
143B Contact Outputs 49 through 64 Current States
143C Contact Outputs 65 through 80 Current States
143D Contact Outputs 81 through 96 Current States
143E Contact Outputs 97 through 112 Current States
38
Range Units
-9999999999.999 to ---
9999999999.999
--- ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
--- ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
0 to 4294967295 ---
0 to 4294967295 ---
-9999999999.999 to ---
9999999999.999
--- ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
0 to 65535 ---
PLUS
D90 LINE DISTANCE PROTECTION SYSTEM – COMMUNICATIONS GUIDE
CHAPTER 2: MODBUS COMMUNICATION
Step Format Default
0.001 F060 0
--- F215 (None)
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
--- F215 (None)
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
1 F050 0
1 F050 0
0.001 F060 0
--- F215 (None)
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
1 F500 0
