Programming technology functions (cycles)
9.3 Contour turning
Parameters in the "Input simple" mode
G code program parameters
Input
PRG Name of the program to be generated
RP Retraction plane – (only for
machining direction, longi-
tudinal, inner)
F Feedrate
Parameter Description
Machining
•
•
•
Machining
•
direction
•
•
The machining direction depends on the stock removal direction and choice of tool.
Position
•
•
•
•
D Maximum depth infeed - (only for ∇)
DX Maximum depth infeed - (only for parallel to the contour, as an alternative to D)
DZ Maximum depth infeed - (only for position parallel to the contour and UX)
UX or U Finishing allowance in X or finishing allowance in X and Z – (only for ∇)
UZ Finishing allowance in Z – (only for UX)
BL Blank description (only for ∇)
•
•
•
410
simple
•
mm
*
∇ (roughing)
∇∇∇ (finishing)
∇+∇∇∇ (complete machining)
face
•
longitudinal
parallel to the contour
•
•
•
front
back
inside
outside
Cylinder (described using XD, ZD)
Allowance (XD and ZD on the finished part contour)
Contour (additional CYCLE62 call with blank contour – e.g. cast iron mold)
ShopTurn program parameters
T Tool name
D Cutting edge number
F Feedrate
S / V Spindle speed or constant cutting
rate
from inside to outside
from outside to inside
from end face to rear side
from rear side to end face
