Summary of Contents for Airflow OW7205
- Page 1 Smart Series Wall/Window Fans Warranty and Installation Instructions OW7205, OW7213, OW7221, OW7148, OW7155...
-
Page 2: Specifications
254 to 262 OW7213 23/9 M 254 to 262 OW7221 23/9 SELV 254 to 262 OW7148 30/12 AR 324 to 337 1350 OW7155 30/12 SELV 324 to 337 1350 Example of finished Wall & Window installations. Arrows indicate airflow direction. - Page 3 OW7221 and OW7155. OW3105 OW3113 OW3121 • Remote Control of Smart OW7205 and OW7148 can be carried out by using the Radio Transmitter Kit OW9136. It allows reversing or speed control from up to 20m away. OW9136 • Where a flush finish on walls is required two sizes of wall recess kits are available, OW7965 for 23/9 series or OW7973 for 30/12 series.
-
Page 4: Installation Instructions
• Where double glazed windows are required the Double-Glazing Kit OW7957 for the 23/9 series or the OW7999 for the 30/12 series can be used. They suit applications with up to 300mm intervals between the windows. INSTALLATION INSTRUCTIONS All fans should be installed by a suitably qualified person in accordance with AS/ NZ3000.2000 and relevant building codes. - Page 5 3. Mount the Enclosure on inside wall ensuring terminal block is at the top and stripped supply cable is in position. (Remove terminal block for easy supply cable access.) 4. Make electrical connections to terminal block of fan. 5. Measure wall depth and if required cut supplied PVC sheet to suit 6.
- Page 6 ELECTRICAL CONNECTION GUIDE OW7213 - PULL CORD OPERATION OW7205, OW7148 - EXTRACT ONLY OW7205, OW7148 - EXTRACT AND INTAKE OW7221, OW7155...
-
Page 7: Controller Operation
(Humidity, Infra-red or Air Quality). REMOTE CONTROL KIT (Sold separately and used on models OW7148 and OW7205.) Cat. No. OW9136 is labelled KIT RADIOCOMANDO and is supplied with operating instructions. -
Page 8: Warranty
WARRANTY The benefits conferred herein are in addition to, and in no way shall be deemed to derogate: either expressly or by implication, any or all other rights and remedies in respect to this Clipsal Electronic Product, which the consumer has under the Commonwealth Trade Practices Act or any other similar State or Territorial laws.
