STORAGE - DESCRIPTION OF OPERATION
ON RECEIPT INSPECTION ... Continued
product was shipped directly to you, report any damages to the carrier and arrange for
inspection of goods immediately.
Before you store the air compressor, make sure you do the following:
1) Review the "Maintenance" and "Operating Procedures" sections and perform
maintenance necessary.Be sure to drain water from the air tank.
2)
Protect the electrical cord and air hose from damage (such as being stepped
on or run over).Store the air compressor in a clean and dry location.
DRAIN VALVE: The drain valve is located at the bottom of the air tank and is used to drain
condensation at the end of each use.
MOTOR THERMAL OVERLOAD PROTECTOR: The electric motor has a manual thermal
overload protector. If the motor overheats for any reason, the thermal overload protector will shut
off the motor. Turn pressure switch to the "off" position and wait for unit to cool before pushing
the reset button and restarting the compressor.
ON/AUTO - OFF SWITCH: Turn this switch to "on" to provide automatic power to the pressure
switch and to "off" to remove power when finished using the compressor or when compressor
will be left unattended.
AIR INTAKE FILTER: This filter is designed to clean air coming into the compressor pump. This
filter must always be clean and free from obstructions. See "Maintenance".
AIR COMPRESSOR PUMP: To compress air, the piston moves up and down in the cylinder. On
the down stroke, air is drawn in through the air intake valve. The exhaust valve remains closed.
On the upstroke of the piston, air is compressed. The intake valve closes and compressed air is
forced out through the exhaust valve, through the outlet tube, through the check valve and into
the air tank. Useable air is not available until the compressor has raised the air tank pressure
above that required at the air outlet.
CHECK VALVE: When the air compressor is operating, the check valve is "open", allowing
compressed air to enter the air tank. When the air compressor reaches "cut-out" pressure, the
check valve "closes", allowing air pressure to remain inside the air tank.
