XtendLan NVR-14xxD User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NVR-14xxD
NVR-12xxDP
Network Video Recorder
User's Guide
i

Advertisement

Table of Contents
loading

Related Manuals for XtendLan NVR-14xxD

Summary of Contents for XtendLan NVR-14xxD

  • Page 1 NVR-14xxD NVR-12xxDP Network Video Recorder User’s Guide...

  • Page 2: Table Of Contents

    Table of Contents Features and Specifications ........................1 Overview ............................1 Features ............................1 Specifications ..........................2 1.3.3 12xxDP Series ........................7 1.3.4 14xxD Series ..........................8 Front Panel and Rear Panel ......................17 Front Panel ..........................17 12xxDP Series ........................22 2.1.2 2.1.3 14xxD Series ........................23 Rear Panel ..........................
  • Page 3 Main Menu ..........................57 Search & Playback ........................57 Information ..........................61 5.5.1 HDD Information ........................ 62 5.5.2 BPS ............................63 Log ............................64 5.5.3 Version ..........................65 5.5.4 Online Users ........................65 5.5.5 5.5.6 Remote Device Information ..................... 66 Network Info ........................67 5.5.7 5.5.7.1 Network Test ......................
  • Page 4 5.6.11.3 Remote Device ....................... 101 5.6.11.4 Short-cut Menu ....................... 104 Advanced ..........................105 5.7.1 HDD Management ......................106 5.7.2 Abnormality ........................108 Alarm Output ........................109 5.7.3 Manual Record ........................ 109 5.7.4 5.7.4.1 Manual record menu ....................110 5.7.4.2 Basic operation ......................110 5.7.4.3 Enable/disable record .....................
  • Page 5 System Configuration ...................... 133 7.4.2 7.4.2.1 General Setup ......................133 7.4.2.2 Encode ........................135 7.4.2.3 Schedule ........................136 7.4.2.4 RS232 ........................138 7.4.2.5 Network ........................139 7.4.2.6 Alarm ........................147 7.4.2.1 Detect ........................149 7.4.2.2 PTZ ..........................151 7.4.2.3 Default & Backup ....................152 7.4.3 Advanced ..........................
  • Page 6 Welcome Thank you for purchasing our network video recorder! This user’s manual is designed to be a reference tool for your system. Please open the accessory bag to check the items one by one in accordance with the list below. Contact your local retailer ASAP if something is missing or damaged in the bag.

  • Page 7: Installation Environment

    Important Safeguards and Warnings 1．Electrical safety All installation and operation here should conform to your local electrical safety codes. We assume no liability or responsibility for all the fires or electrical shock caused by improper handling or installation. 2．Transportation security Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.
  • Page 8 Check the following accessories after opening the box： • Please refer to the packing list in the box * viii...

  • Page 9: Features And Specifications

    1 Features and Specifications 1.1 Overview This series NVR is a high performance network video recorder. This series product support local preview, multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation, and remote management and control function. This series product supports centre storage, front-end storage and client-end storage.

  • Page 10: Specifications

    • Support network backup, USB2.0 record backup function, the recorded files can be saved in network storage server, peripheral USB2.0 Backup device, burner and etc. • Network Supervise NVR configuration and control power via Ethernet. • Management Support management via WEB. •...
  • Page 11 Multiple-chann Max 16-channel D1/8-channel 720P/4-channel 1080P playback. el Playback Alarm Input 4/8/16-ch series product support 4/8/16-ch alarm input respectively. 3-ch alarm output Alarm Output Relay output. Relay （DC 30V 1A，AC 125V 0.5A（Activation output） ） Including one controllable DC +12V output. 2 built-in SATA ports Storage 1 peripheral eSATA port...

  • Page 12: 14Xxd Series

    USB2.0 Port 3 peripheral USB2.0 ports. Network One RJ45 10/100M/1000Mbps self-adaptive Ethernet port. Connection One power port, power adapter. Input DC Two power ports, power adapter. Input DC Power Port 12V. 12V or DC 48V. Power Button One power button in the rear panel. Power Button One power button in the front panel.

  • Page 13: Front Panel And Rear Panel

    Video Input 4/8/16-ch network compression video input 2.1 Front Panel 1-ch HDMI output. HDMI 2.1.1 21/21-P/21-S/31/31-P/31-S/31-W Audio Input 1-ch bidirectional audio input Series Audio Output 1-channel bidirectional talk output. The front panel is shown as in Figure 2-1. Window Split 4/8/9/16-window Multiple-chann Max 16-channel D1/8-channel 720P/4-channel 1080P playback.
  • Page 14 Figure 2-1 Please refer to the following sheet for detailed information. Icon Name Function The blue light becomes on when the power Power indicator light connection is OK. Network status indicator The blue light becomes on when the network light connection is abnormal or offline.

  • Page 15: 12Xxdp Series

    or numeral keys to select the recording channel. 2.1.2 12xxDP Series The front panel is shown as below. See Figure 2-6. Figure 2-6 Please refer to the following sheet for front panel button information. Name Icon Function Power button Power button, press this button for three seconds to boot up or shut down NVR.

  • Page 16: 14Xxd Series

    Power Power indication light. indication light HDD abnormal HDD error occurs or HDD capacity is below specified threshold indication light value, the light becomes red to alert you. Network Network error occurs or there is no network connection, the light abnormal becomes red to alert you.
  • Page 17 • In motion detection setup, working with Fn and direction keys to realize setup. • In text mode, click it to switch between numeral, English character (small/capitalized) and etc. • In HDD management interface, you can click it to switch HDD record information and other information (Menu prompt) •...

  • Page 18: Rear Panel

    2.2 Rear Panel 2.2.1 16xxK Series The rear panel is shown as below. See Figure 2-16. Figure 2-16 Please refer to the following sheet for detailed information. Port Name Connection Function USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port.

  • Page 19: 12Xxdp Series

    Port Name Connection Function HDMI High Definition Media High definition audio and video signal Interface output port. It transmits uncompressed high definition video and multiple-channel data to the HDMI port of the display device. VGA video output port VGA video output port. Output analog video signal.
  • Page 20 Figure 2-19 The 32V-P rear panel is shown as below. See Figure 2-20. Figure 2-20 Please refer to the following sheet for detailed information.
  • Page 21 Port Name Connection Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port. Connect to the network cable. High Definition High definition audio and video signal output HDMI Media port. It transmits uncompressed high Interface definition video and multiple-channel data to the HDMI port of the display device.
  • Page 22 Port Name Connection Function MIC IN Audio input Bidirectional talk input port. It is to receive the port analog audio signal output from the devices such as mike phone, pickup. MIC OUT Audio output Audio output port. It is to output the analog port audio signal to the devices such as the sound box.
  • Page 23 Figure 2-22 Please refer to the following sheet for detailed information. Port Name Connection Function USB2.0 USB2.0 port. Connect to USB2.0 mouse. Network port 10M/100M/1000Mbps self-adaptive Ethernet port. Connect to the network cable. HDMI High Definition High definition audio and video signal output Media port.

  • Page 24: Alarm Connection

    Port Name Connection Function there is power to the external alarm device. NO：Normal open alarm output port. • C：Alarm output public end. • RS485 (RS- RS485_A port. It is the cable A. You can 485) connect to the control devices such as speed communication dome PTZ.

  • Page 25: Bidirectional Talk

    2.4 Bidirectional talk 2.4.1 Device-end to PC-end Device Connection Please connect the speaker or the pickup to the first audio input port in the device rear panel. Then connect the earphone or the sound box to the audio output port in the PC. Login the Web and then enable the corresponding channel real-time monitor.

  • Page 26: Pc-End To The Device-End

    Figure 2-28 Listening Operation At the device end, speak via the speaker or the pickup, and then you can get the audio from the earphone or sound box at the pc-end. See Figure 2-29. Figure 2-29 2.4.2 PC-end to the device-end Device Connection Connect the speaker or the pickup to the audio output port in the PC and then connect the earphone or the sound box to the first audio input port in the device rear panel.

  • Page 27: Hdd Installation

    Left click When you have selected one menu item, left click mouse to view menu mouse content. Modify checkbox or motion detection status. Click combo box to pop up dropdown list In input box, you can select input methods. Left click the corresponding button on the panel you can input numeral/English character (small/capitalized).

  • Page 28: 12Xxdp/14Xxd Series

    You can refer to the Appendix for recommended HDD brand. Please use HDD of 7200rpm or higher. Usually we do not recommend the PC HDD. Please follow the instructions below to install hard disk. 3.3 12xxDP/14xxD Series ①Use 4 screws to secure the HDD ②Put the HDD to the HDD box at the front.
  • Page 29 ③Pull the HDD knob up when you put the HDD ④Put the knob back after you insert the HDD into the box in case the knob buckle may strike to the SATA board. the front panel.

  • Page 30: Network Connection

    4 Network Connection Please refer to Figure 4-1 for connection sample. The following figure is based on the 38 series product. Figure 4-1...

  • Page 31: Gui Operation

    5 GUI Operation Connect the device to the monitor and then connect a mouse and power cable. Click the power button at the rear panel and then boot up the device to view the analog video output. You can use the mouse to implement some GUI operation.
  • Page 32 Figure 5-2 You can overlay the corresponding date, time and channel name on each screen. You can refer to the following sheet for channel record or alarm status information. Recording status Video loss Motion detection Camera lock Preview Control The preview control function has the following features. •...

  • Page 33: Right Click Menu

    record of current channel. Please go to the Main Menu->General to set real-time playback time. System may pop up a dialogue box if there is no such record in current channel. It is to zoom in specified zone of current channel. It supports zoom in function of multiple-channel.

  • Page 34: Main Menu

    After you logged in the device, right click mouse, you can see the short cut menu. Please see Figure 5-4. Here you can set local playback window, PTZ control, video color, search records, remote device and etc. The local playback window includes 1/4/8/9/16. You can set the detail channel amount in 1/4-window.
  • Page 35 Figure 5-6 Please refer to the following sheet for more information. Name Function • Display Here is to display the searched picture or file. • window Support 1/4/9/16-window playback. • Here you can select to search the picture or the recorded file. •...
  • Page 36 In 9-window playback mode, you can switch between 1-8 and 9-16 channels. selection pane. In 16-window playback mode, you can switch between1-16 and 17-32 channels. • The time bar will change once you modify the playback mode or the channel option.
  • Page 37 │€ to begin frame by frame playback. In frame by frame playback mode, click ►/" to restore normal playback. ► Slow play In playback mode, click it to realize various slow play modes such as slow play 1, slow play 2, and etc. Fast forward In playback mode, click to realize various fast play modes such as fast...

  • Page 38: Information

    type • When system is playing, you can select a zone in the window to begin motion detect. Click the motion detect button to begin play. • Current button is null once the motion detect play has begun. • Smart The system will take the whole play zone as the motion detect region by default.

  • Page 39: Hdd Information

    5.5.1 HDD Information Here is to list hard disk type, total space, free space, and status. See Figure 5-8. For 16xxK Series product there are max 2 HDDs. For 38 series product there are max 8 HDDs. ○ means current HDD is normal.. - means there is no HDD. If disk is damaged, system shows as “?”.

  • Page 40: Bps

    Type The corresponding HDD property. Total space The HDD total capacity. Free space The HDD free capacity. Status HDD can work properly or not. Bad track Display there is bad track or not. Page up Click it to view previous page. Page down Click it to view the next page.

  • Page 41: Log

    Figure 5-11 5.5.3 Log Here is for you to view system log file. System lists the following information. See Figure 5-12. Log types include system operation, configuration operation, data management, alarm event, record operation, log clear and etc. • Start time/end time: Pleased select start time and end time, then click search button. You can view the log files in a list.

  • Page 42: Version

    Figure 5-13 5.5.4 Version Here is for you to view some version information. See Figure 5-14. • Channel • Alarm in • Alarm out • System version: • Build Date • • Serial number Figure 5-14 5.5.5 Online Users Here is for you manage online users connected to the local device. See Figure 5-15. You can disconnect one user or block one user if you have proper system right.

  • Page 43: Remote Device Information

    Figure 5-15 5.5.6 Remote Device Information Here you can view the channel status of the remote device, connection log and etc. Channel status: Here you can view the IPC status of the corresponding channel such as motion detect, video loss, camera masking, alarm and etc. See Figure 5-16. Figure 5-16 Connection log: In this interface, you can search the IPC log information of the corresponding channel.

  • Page 44: Network Info

    Figure 5-17 5.5.7 Network Info In this interface, you can see network test and network load information. 5.5.7.1 Network Test Network test interface is shown as in Figure 5-18. Destination IP: Please input valid IPV4 address and domain name. Test: Click it to test the connection with the destination IP address. The test results can display average delay and packet loss rate and you can also view the network status as OK, bad, no connection and etc.

  • Page 45: Network Load

    Figure 5-18 5.5.7.2 Network Load Network load is shown as in Figure 5-19. Here you can view the follow statistics of the device network adapter. Here you can view information of all connected network adapters. The connection status is shown as offline if connection is disconnected.

  • Page 46: General

    Figure 5-20 Important Please note you need to have the proper right to implement the following operation. 5.6.1 General General setting includes the following items. See Figure 5-21. • System time: Here is for you to set system time • Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY.
  • Page 47 • Holiday setting: Click it you can see an interface shown as in Figure 5-24. Here you can set holiday date. Please go to the Holidays Period interface to set the holiday date record setup. When you enable Holiday settings and schedule setup at the same time, holiday setting has the priority.

  • Page 48: Encode

    Figure 5-22 Figure 5-23 Figure 5-24 Figure 5-25 5.6.2 Encode Encode setting includes the following items. See Figure 5-26. Please note some series do not support extra stream. • Channel: Select the channel you want. • Type: Please select from the dropdown list. There are three options: regular/motion detect/alarm.
  • Page 49 • Resolution: The mainstream resolution type is IPC’s encoding config. Generally there is D1/720P/1080P. • Frame rate: It ranges from 1f/s to 25f/s in NTSC mode and 1f/s to 30f/s in PAL mode. • Bit rate type: System supports two types: CBR and VBR. In VBR mode, you can set video quality.

  • Page 50: Schedule

    Figure 5-27 Figure 5-28 Figure 5-29 5.6.3 Schedule In the main menu, from setting to schedule, you can go to schedule menu. See Figure 5-30. • Channel: Please select the channel number first. You can select “all” if you want to set for the whole channels.

  • Page 51: Quick Setup

    menu->Advanced->HDD Management). Please note this function is null if there is only one HDD. • Snapshot: You can enable this function to snapshoot image when an alarm occurs. • Record types: There are four types: regular, motion detection (MD), Alarm, MD & alarm. •...

  • Page 52: Rs232

    Figure 5-31 5.6.4 RS232 RS232 interface is shown as below. There are five items. See Figure 5-32. • Function: There are various devices for you to select. Console is for you to use the COM or mini-end software to upgrade or debug the program. The control keyboard is for you to control the device via the special keyboard.
  • Page 53 • IP Version: There are two options: IPv4 and IPv6. Right now, system supports these two IP address format and you can access via them. • MAC address: The host in the LAN can get a unique MAC address. It is for you to access in the LAN.

  • Page 54: Network Setting

    input value shall be 128-digit. It shall not be left in blank. After completing all the setups please click save button, system goes back to the previous menu. Figure 5-33 5.6.5.1 Network Setting Network setting interface is shown as in Figure 5-34. Please draw a circle to enable corresponding function and then double click current item to go to setup interface.

  • Page 55: Ntp Setup

    • Start address/end address: Select one type from the dropdown list, you can input IP address in the start address and end address. Now you can click Add IP address or Add IP section to add. For the newly added IP address, it is in enable status by default. Remove the √ before the item, then current item is not in the list.

  • Page 56: Multicast

    Here is a sheet for your time zone setup. City /Region Name Time Zone London GMT+0 Berlin GMT+1 Cairo GMT+2 Moscow GMT+3 New Deli GMT+5 Bangkok GMT+7 Beijing (Hong Kong) GMT+8 Tokyo GMT+9 Sydney GMT+10 Hawaii GMT-10 Alaska GMT-9 Pacific Time(P.T) GMT-8 American Mountain Time(M.T) GMT-7...

  • Page 57: Pppoe

    -224.0.0.0-239.255.255.255 -“D” address space • The higher four-bit of the first byte=”1110” • Reserved local multiple cast group address -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example 224.1.1.1 All systems in the sub-net 224.1.1.2 All routers in the sub-net 224.1.1.4 DVMRP router 224.1.1.5 OSPF router...
  • Page 58 You need a PC of fixed IP in the internet and there is the DDNS software running in this PC. In other words, this PC is a DNS (domain name server). In network DDNS, please select DDNS type and highlight enable item. Them please input your PPPoE name you get from you IPS and server IP (PC with DDNS ) .

  • Page 59: Upnp

    • Domain name：There are two modes: Default domain name and customized domain name. Except default domain name registration, you can also use customized domain name (You can input your self-defined domain name.). After successful registration, you can use domain name to login installed of the device IP.

  • Page 60: Wifi Setting

    Figure 5-40 Figure 5-41 5.6.5.8 WIFI Setting You can view the WIFI connection status in the Network Setting interface. See Figure 5-42. You can view current connection status and IP address if there is a connection. Figure 5-42 The WIFI interface is shown as below. See Figure 5-43.
  • Page 61 • Auto connect WIFI: Check the box here, system automatically connects to the previous WIFI hotspot. • Refresh: You can click it to search the hotspot list again. It can automatically add the information such as the password if you have set it before. •...

  • Page 62: Email

    Figure 5-45 • WIFI working status: Here you can view current connection status. Please note: • After successful connection, you can see WIFI connection icon at the top right corner of the preview interface. • When the hotspot verification type is WEP, system displays as AUTO since the device can not detect its encryption type.

  • Page 63: Ftp

    • Title: Please input email subject here. System support English character and Arabic number. Max 32-digit. • Receiver: Please input receiver email address here. System max supports 3 email boxes. • SSL enable: System supports SSL encryption box. • Interval: The send interval ranges from 0 to 3600 seconds. 0 means there is no interval. •...
  • Page 64 Figure 5-49 You can use a PC or FTP login tool to test setup is right or not. For example, you can login user ZHY to F TP://10.10.7.7 and then test it can modify or delete H 1 4 0 H 1 4 0 H 1 4 0 H T U folder or not.

  • Page 65: Alarm Center

    Figure 5-51 Figure 5-52 5.6.5.11 Alarm center Interface is pre-reserved for the users to develop this function. 5.6.5.12 SNMP SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network management frame of the network management system. The SNMP widely used in many environments.

  • Page 66: Auto Register

    Please enable the SNMP function. Use the corresponding software tool (MIB Builder and MG- SOFT MIB Browser. You still need two MIB file: BASE-SNMP-MIB, NVR-SNMP-MIB) to connect to the device. You can get the device corresponding configuration information after successfully connection. Please follow the steps listed below to configure.

  • Page 67: Alarm

    4) Now you can boot up the proxy server. When you see the network status is Y, it means your registration is OK. You can view the proxy server when the device is online. Important The server IP address can also be domain. But you need to register a domain name before you run proxy device server.
  • Page 68 • Alarm output: The number here is the device alarm output port. You can select the corresponding ports(s) so that system can activate the corresponding alarm device(s) when an alarm occurred. • Latch: When the anti-dither time ended, the channel alarm you select in the alarm output may last the specified period.
  • Page 69 Figure 5-55 Figure 5-56 Figure 5-57...

  • Page 70: Detect

    Figure 5-58 For the 32-channel series product, the alarm interface and PTZ setup is shown as below. See Figure 5-59 and Figure 5-60. Figure 5-59 Figure 5-60 5.6.7 Detect Go to Detect Menu In the main menu, from Setting to Detect, you can see motion detect interface. See Figure 5-61.There is three detection types: motion detection, video loss, camera masking.

  • Page 71: Motion Detect

    detection region setup. • You can see motion detect icon if current channel has enabled motion detect alarm. • You can drag you mouse to set motion detect region without Fn button. Please click OK button to save current region setup. Right click mouse to exit current interface. 5.6.7.1 Motion Detect Detection menu is shown as below.
  • Page 72 save button, system goes back to the previous menu. Note: In motion detection mode, you can not use copy/paste to set channel setup since the video in each channel may not be the same. In Figure 5-62, you can left click mouse and then drag it to set a region for motion detection. Click Fn to switch between arm/withdraw motion detection.

  • Page 73: Video Loss

    Figure 5-64 Figure 5-65 5.6.7.2 Video Loss In Figure 5-61, select video loss from the type list. You can see the interface is shown as in Figure 5-66.This function allows you to be informed when video loss phenomenon occurred. You can enable alarm output channel and then enable show message function. You can refer to chapter 5.6.7.1Motion detect for detailed information.

  • Page 74: Ptz

    environments light change, the system can alert you to guarantee video continuity. Camera masking interface is shown as in Figure 5-67. You can enable alarm output channel and then enable show message function. You can refer to chapter 5.6.7.1Motion detect for detailed information.
  • Page 75 • Address: Default address is 1. • Baud rate: Select corresponding baud rate. Default value is 9600. • Data bit: Select corresponding data bits. Default value is 8. • Stop bit: Select corresponding stop bits. Default value is 1. • Parity: There are three options: odd/even/none.

  • Page 76: Display

    Please click icon to adjust zoom, focus and iris. Figure 5-70 In Figure 5-70, please click direction arrows to adjust PTZ position. There are total 8 direction arrows. Figure 5-71 Here is a sheet for you reference. Name Function function Shortcut Function function...

  • Page 77: Default

    Figure 5-72 In Figure 5-72, click modify button after channel. You can see an interface shown as in Figure 5-73. Please note all your modification here applies to local end only. You need to refresh web or client-end to get the latest channel name. System max support 25-digital character. Figure 5-73 5.6.10 Default Click default icon, system pops up a dialogue box.

  • Page 78: Remote Device

    • Display • Channel name Please highlight icon to select the corresponding function. After all the setups please click OK button, system goes back to the previous menu. Warning! System menu color, language, time display mode, video format, IP address, user account will not maintain previous setup after default operation! 5.6.11 Remote Device Important...
  • Page 79 Figure 5-76 The remote device interface is shown as in Figure 5-77. • IP search: Click it to search IP address. • Add: Click it to connect to the selected device and add it to the Added device list. Support Batch add.
  • Page 80 Figure 5-77 Figure 5-78 Click the Manual Add button; you can go to the following interface. See Figure 5-79. This series product max supports 32-channel standard definition video/high definition non- real-time video and the transmission rate is 1Mbps per channel. It can also max supports 4- channel high definition video and the transmission rate is 8Mbps.

  • Page 81: Short-Cut Menu

    Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P. 8-ch series Max support 8-channel video. Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P. 16-ch series Max support 16-channel video. Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P. 32-ch series Max support 32-channel standard definition video. Support 8-channel 1080p/5Mbps (extra stream D1/1Mbps), 16-channel 720p/2Mbps (extra CIF/640kbps), 32-channel D1/1Mbps. This series product supports the IPC from many popular manufactures such as Sony, Hitachi, dynacolor, Axis, Samsung, arecont, Dahua, onvif and custom type.

  • Page 82: Advanced

    Figure 5-80 Figure 5-81 5.7 Advanced Double click advanced icon in the main window, the interface is shown as below. See Figure 5-82.There are total eight function keys: HDD management, alarm output, abnormity, manual record, account, auto maintenance, TV adjust and video matrix.

  • Page 83: Hdd Management

    Figure 5-82 5.7.1 HDD Management Here is for you to view and implement hard disk management. See Figure 5-83. You can see current HDD type, status, capacity and record time. When HDD is working properly, system is shown as O. When HDD error occurred, system is shown as X. •...
  • Page 84 Figure 5-84 For the HDD group setup operation, please note: • Each channel’s records can be stored into the specified HDD Group. • Each HDD Group is corresponding to several hard disks, while one hard disk is only included in one HDD Group. •...

  • Page 85: Abnormality

    Figure 5-85 Channels Setting Click the button named with “Channels Settings” at the top right corner of the Figure 5-83, system will pop up an interface shown as in Figure 5-86. You can set HDDs for main stream, extra stream and snap pictures respectively. The main stream and extra stream of one channel can be saved to different groups.

  • Page 86: Alarm Output

    • Event type: There are several options for you such as disk error, no disk, disconnection, IP conflict and etc. • Alarm output: Please select alarm activation output port (multiple choices). • Latch: Here you can set corresponding delaying time. The value ranges from 10s-300s. System automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.

  • Page 87: Manual Record Menu

    Note: You need to have proper rights to implement the following operations. Please make sure the HDD has been properly installed. 5.7.4.1 Manual record menu Right click mouse or in the main menu, Advanced->Manual Record. Manual record menu is shown as in Figure 5-89. 5.7.4.2 Basic operation There are three statuses: schedule/manual/stop.

  • Page 88: Stop All Channel Recording

    • All channel schedule record Please highlight “ALL” after “Schedule”. See Figure 5-91. When system is in schedule recording, all channels will record as you have previously set (Main menu->Setting->Schedule). The corresponding indication light in front panel will turn on. Figure 5-91 •...

  • Page 89: Account

    Figure 5-93 5.7.5 Account Here is for you to implement account management. See Figure 5-94. Here you can: • Add new user • Modify user • Add group • Modify group • Modify password. For account management please note: • For the user account name and the user group, the string max length is 6-byte.

  • Page 90: Modify Password

    Figure 5-94 5.7.5.1 Modify Password Click password button, the interface is shown as in Figure 5-95. Here you can modify account password. Please select the account from the dropdown list, input the old password and then input the new password twice. Click the Save button to confirm current modification. For the users of user account right, it can modify password of other users.

  • Page 91: Add/Modify User

    Figure 5-96 5.7.5.3 Add/Modify User Click add user button, the interface is shown as in Figure 5-97. Please input the user name, password, select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user. For convenient user management, usually we recommend the general user right is lower than the admin account.

  • Page 92: Config Backup

    Figure 5-98 5.7.7 Config Backup The configuration file backup interface is shown as below. See Figure 5-99. This function allows you to copy current system configuration to other devices. It also supports import, create new folder, delete folder and etc function. Figure 5-99 5.8 Shutdown Double click shutdown button, system pops up a dialogue box for you to select.
  • Page 93 Figure 5-100...

  • Page 94: Quick Configuration Tool

    6 Quick Configuration Tool 6.1 Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. 6.2 Operation Double click the “ConfigTools.exe”...
  • Page 95 Select the “Open Device Web” item; you can go to the corresponding web login interface. See Figure 6-3. Figure 6-3 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set. In the configuration tool search interface (Figure 6-1), please select a device IP address and then double click it to open the login interface.
  • Page 96 Figure 6-5 For detailed information and operation instruction of the quick configuration tool, please refer to the Quick Configuration Tool User’s Manual included in the resources CD.

  • Page 97: Web Operation

    7 Web Operation 7.1 General Introduction The device web provides channel monitor menu tree, search, alarm setup, system setup, PTZ control and monitor window. Important The following operation is based on 16-channel series device. For the 32-channel series product, there is 32-channel option. 7.1.1 Preparation Before log in, please make sure: •...

  • Page 98: Log In

    If it is your second time to insert the PoE, system can check the saved MAC address according to <Channel>---<IPC mac> map to make sure current IPC has connected or not. If system finds the previous information and the channel is idle, system can map it to the previously used channel.

  • Page 99: Lan Mode

    Figure 7-2 IE Safety Setup After installation, the interface is shown as below. See Figure 7-3. Figure 7-3 Login interface Please input your user name and password. Default factory name is admin and password is admin. Note: For security reasons, please modify your password after you first login. 7.2 LAN Mode...

  • Page 100: Monitor Channel Menu Tree

    For the LAN mode, after you logged in, you can see the main window. See Figure 7-4. ② ③ ① ④ ⑤ ⑥ Figure 7-4 Main Interface There are six sections: • Section 1: Monitor channel menu tree • Section 2: System menu •...
  • Page 101 Figure 7-5 Monitor Channel Menu Tree Please refer to the following sheet for detailed information. Parameter Function channel 1 to channel 16 CAM 1 to CAM Open all /close Click this button to open all video channels. Once all video channels are open, it becomes close all button. You can click this button to enable audio talk.
  • Page 102 The Web can playback the saved (Extension name is dav) files in Local play the PC-end. Click local play button, system pops up the following interface for you to select local play file. See Figure 7-6. Figure 7-6 Refresh Click this button to refresh monitor channel name. Please left click one monitor to view real-time video, the monitor window is shown as in Figure 7-7.

  • Page 103: System Menu

    Resize or switch to full screen mode. Change show mode When you click local record button, the system begins Local record recording. The recorded file is saved to system folder: \ RecordDownload(default). You can snapshoot important video. All images are Snapshot memorized in system folder: \ picture download (default).
  • Page 104 You can click this icon to display or hide the PTZ control platform. Figure 7-10 PTZ Interface Click PTZ set button, the interface is shown as in Figure 7-11. Figure 7-11 PTZ Setup...

  • Page 105: Color And More Setup

    Please refer to the following sheet for PTZ setup information. Parameter Function • Move the camera to you desired location and then click left limit Scan button. • Then move the camera again and then click right limit button to set a right limit.

  • Page 106: Wan Login

    operation here It is to adjust monitor video contrast ness. applies to WEB end only. It is to adjust monitor video saturation. It is to adjust monitor video hue. Reset Restore system default value. Click more button, the interface is shown as in Figure 7-13. Figure 7-13 Color and More Please refer to the following sheet for detailed information.
  • Page 107 Figure 7-14 Please refer to the following contents for LAN and WAN login difference. 1) In the WAN mode, system opens the main stream of the first channel to monitor by default. The open/close button on the left pane is null. 2) You can select different channel and different monitor mode at the bottom of the interface.

  • Page 108: Configuration

    main stream. A stands for 4) When you switch from Monitor to Search or Configuration, system pops a dialogue box asking you leave current interface or not. See Figure 7-16.Click the OK button, system will close current monitor window. For example, you click the Config button when you are monitoring, system pos up a following dialogue.

  • Page 109: Hdd Information

    Figure 7-17 Version Information 7.4.1.2 HDD information Here you can view local storage status such as free capacity and total capacity. See Figure 7-18. Figure 7-18 HDD Information 7.4.1.3 Log Here you can view system log. See Figure 7-19...

  • Page 110: System Configuration

    Figure 7-19 Log Please refer to the following sheet for log parameter information. Parameter Function Log types include: system operation, configuration operation, data Type management, alarm event, record operation, user management, log clear and file operation. Set time to start search. Start time Set time to finish search Finish time...
  • Page 111 Figure 7-20 General Setup Figure 7-21 DST Figure 7-22 DST Please refer to the following sheet for detailed information. Parameter Function Here is for you to modify system time. Please click Save button after System Time your completed modification Sync PC You can click this button to save the system time as your PC current time.

  • Page 112: Encode

    Please select separator such as – or /. Data Separator There are two options: 24-H and 12-H. Time Format Here you can set day night save time begin time and end time. See Figure 7-21and Figure 7-22. Language Here you can view the system current language. You can select from the dropdown list.

  • Page 113: Schedule

    For the main stream, recorded file only contains video by default. You need to draw a circle here to enable audio function. Audio / video For extra stream, you need to draw a circle to select the video first and then select the audio if necessary.
  • Page 114 Figure 7-25 Schedule Time Figure 7-26 Copy Figure 7-27 Please refer to the following sheet for detailed information. Parameter Function Please select a channel first. Channel...

  • Page 115: Rs232

    Parameter Function Pre-record Please input pre-record value here. When alarm record or motion detection record occurs, system can record the several seconds video before activating the record operation into the file. (Depends on data size). Setup In Figure 7-24, click set button, you can go to the corresponding setup interface.

  • Page 116: Network

    Parameter Function RS232 There is only one option COM 01, corresponding to RS232. Console is for debug. Function Control keyboard: Switch between RS232 and control keyboard. Network keyboard: COM control protocol. You can use network keyboard to control NVR via COM. Transparent COM: Network user can communicate with RS232 COM device.
  • Page 117 Parameter Function MAC Address The host in the LAN can get a unique MAC address. It is for you to access in the LAN. It is read-only. IP Address Here you can use up/down button (K7) or input the corresponding number to input IP address. Then you can set the corresponding subnet mask the default gateway.
  • Page 118 Parameter Function Remote PPPOE Input the user name and password which ISP(Internet service supplier) host provided and chose enable. Reboot system after configuration is saved and the device will auto connect to Internet. The IP address is the WAN IP. There are two conditions for reboot, 1.
  • Page 119 Parameter Function Input email subject here. Max 32-digit. Subject Input receiver email address here. Max input three addresses. Address Please input the send interval value here. Interval DDNS The DDNS interface is shown as in Figure 7-32. Figure 7-32 DDNS Please refer to the following sheet for detailed information.
  • Page 120 works with the device from the manufacturer so that it can add the extension function. 2) Function Introduction The private DDNS client has the same function as other DDNS client end. It realizes the bonding of the domain name and the IP address. Right now, current DDNS server is for our own devices only.
  • Page 121 Figure 7-34 NAS Setup Please refer to the following sheet for detailed information. Parameter Function Please select network storage protocol and then enable NAS enable NAS function. The network storage protocol includes FTP. Server IP Input remote storage server IP address. Input Remote storage server port number.
  • Page 122 Here you can realize network time synchronization. Please enable current function and then input server IP, port number, time zone and time. Figure 7-35 NTP Please refer to the following sheet for detailed information. Parameter Function Enable Enable NTP function or not. Server IP Server IP address Port...
  • Page 123 Figure 7-36 Alarm Centre UNPN Go to the UPnP interface, you can see an image is shown as in Figure 7-37. It allows you to establish the mapping relationship between the LAN and the public network. Here you can also add, modify or remove UPNP item. Figure 7-37 UNPN SNMP The SNMP interface is shown as in Figure 7-38.

  • Page 124: Alarm

    Please refer to chapter 5.6.5.12 SNMP for detailed information. Figure 7-38 SNMP 7.4.2.6 Alarm Alarm setup interface is shown as in Figure 7-39. Figure 7-39 Alarm Setup...
  • Page 125 Figure 7-40 PTZ Setup Figure 7-41 Please refer to the following sheet for detailed information. Parameter Function Event type: There are four types. Local input/network input/IPC Event Type external/IPC offline alarm. Local input alarm: The alarm signal system detects from the alarm input port.

  • Page 126: Detect

    Parameter Function There are two options: normal open and normal close. NO becomes Type activated in low voltage, NC becomes activated in high voltage. Period Alarm record function becomes activated in the specified periods. There are six periods in one day. Please draw a circle to enable corresponding period.
  • Page 127 signal which meets the senility standard that is previously set. See Figure 7-42.

  • Page 128: Ptz

    Figure 7-42 Detect Please refer to the following sheet for detailed information. Parameter Function Event type Motion detect, video loss and video masking Select a channel from the dropdown list to set motion detect, video loss and vid Channel masking function. Sensitivity System supports 6 levels.

  • Page 129: Default & Backup

    Please note, before operation please make sure you have set speed dome address and the NVR and speed dome connection is OK. Figure 7-43 PTZ Please refer to the following sheet for detailed information. Parameter Function You can select monitor channel from the dropdown list. . Channel Select the corresponding dome protocol.(such as PELCOD) Protocol...

  • Page 130: Advanced

    Figure 7-44 Default and Backup Please refer to the following sheet for detailed information. Parameter Function Select All Restore factory default setup. Export Export system configuration to local PC. Configuration Import Import configuration from PC to the system. Configuration 7.4.3 Advanced 7.4.3.1 HDD Management Please select the storage device first and then you can see the items on your right become valid.

  • Page 131: Abnormity

    Please refer to the following sheet for detailed information. Parameter Function Format Clear data in the HDD. Read/write Set current HDD as read/write Read only Set current HDD as read. Redundant Set current HDD as redundant HHD. Recover Fix the HDD error. Right now the device does not support this function.

  • Page 132: Alarm I/O

    Parameter Function Event The abnormal events include: no disk, no space, disk error, offline, IP Type conflict. You need to draw a circle to enable this function. Threshold: It refers to the HDD free space threshold. Normal The corresponding alarm output channel when an alarm occurs. The alarm output channel may vary.

  • Page 133: Record

    Please refer to the following sheet for detailed information. Parameter Function Alarm output The alarm output channel may vary. The interface here is for reference only. Please click the corresponding number and then click the trigger button. Trigger Enable/disable alarm output. Please note once you activate an alarm manually, you need to click the output channel number again and then click trigger button to disable it.
  • Page 134 Figure 7-50 Account Figure 7-51 Add user Please refer to the following sheet for detailed information. Parameter Function User Input the user name of the new established account. Reusable The reusable account means that this account can be used in more than one PC at the same time.

  • Page 135: Snapshot

    Password Input the password of the new established account. Confirm Input the password of the new established account again. Group Select the group which the new account belongs to. Memo Memo about the new account Authority/All User can select all to entitle this account to all authorities or set authority of each item respectively.

  • Page 136: Remote Device

    Figure 7-53 Auto Maintenance 7.4.3.8 Remote device Remote device interface is shown as in Figure 7-54. Figure 7-54 Remote device...

  • Page 137: Preview Control

    Figure 7-55 Manual Add Please refer to the following sheet for detailed information. Parameter Function Remote device Here you can see searched remote device name, IP address, TCP port information and manufacturer name. Channel Please select the local device channel number to connect to the remote device.

  • Page 138: Additional Function

    Figure 7-56 Preview Control 7.4.4 Additional Function 7.4.4.1 IPC Config IPC configuration interface is shown as in Figure 7-57. Here you can set gain, iris, brightness, contrastness, hue, saturation BLC and etc of the network camera. Figure 7-57 IPC Config Please refer to the following sheet for detailed information.
  • Page 139 Parameter Function It is to adjust monitor window bright. The value ranges from 0 to Brightness 100. The default value is 50. The larger the number, the bright the video is. When you input the value here, the bright section and the dark section of the video will be adjusted accordingly.

  • Page 140: Auto Register

    Mirror It is to switch video left and right limit. This function is disabled by default. Flip It is to switch video up and bottom limit. This function is disabled by default. Please note the video resolution shall be 720P or lower when it is to flip 90°.

  • Page 141: Wifi Config

    Figure 7-59 Mobile Setup 7.4.4.4 WIFI Config The WIFI interface is shown as in Figure 7-60. Here you can view WIFI connection status. System displays as no connection if there is no connection. You can view connection status and IP address if there is a connection. See Figure 7-61.

  • Page 142: Search

    Figure 7-61 Please refer to the following sheet for detailed information. Parameter Function Refresh Search hotspot again and system can automatically add the information such as password (If there is any record of the hotspot.) WIFI working Here you can view current connection status. information You can view connection status and IP address if there is a connection.
  • Page 143 Figure 7-62 Then please click search button, you can see the corresponding files in the list. See Figure 7-61. Figure 7-63 Select the file(s) you want to download and then click download button, system pops up a dialogue box shown as in F igure 7-62, then you can specify file name and path to download the X 4 8 0 H 4 8 0 H 4 8 0 H file(s) to your local pc.
  • Page 144 Figure 7-64 Load more It is for you to search record or picture. You can select record channel, record type and record time to download. See Figure 7-65. Figure 7-65 In Figure 7-65, there is a remote back pane at the left bottom of the pane. It allows you to backup the record or picture to your local USB2.0 storage media via the Web remotely.

  • Page 145: Alarm

    Figure 7-66 Now you can see system begins download and the download button becomes stop button. You can click it to terminate current operation. At the bottom of the interface, there is a process bar for your reference. 7.6 Alarm Click alarm function, you can see an interface is shown as in Figure 7-67.
  • Page 146 Figure 7-67 Alarm Please refer to the following sheet for detailed information. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs, Disk full System alarms when disk is full. Disk error System alarms when disk error occurs.

  • Page 147: About

    Type Parameter Function Sound pop up System sends out alarm sound when an alarm occurs. You can specify as you wish. Path Here you can specify alarm sound file. 7.7 About Click about button, you can view the web information. See Figure 7-68. Figure 7-68 About 7.8 Log out Click log out button, you can go back to log in interface.

  • Page 148: Faq

    8 FAQ 1. Device can not boot up properly. There are following possibilities: • Input power is not correct. • Power connection is not correct. • Power switch button is damaged. • Program upgrade is wrong. • HDD malfunction or something wrong with HDD ribbon. •...
  • Page 149 • Device color or brightness setup is not correct. 6. Can not search local records. There are following possibilities: • HDD ribbon is damaged. • HDD is broken. • Upgraded program is not compatible. • The recorded file has been overwritten. •...
  • Page 150 • PTZ decoder and device address is not compatible. • When there are several decoders, please add 120 Ohm between the PTZ decoder A/B cables furthest end to delete the reverberation or impedance matching. Otherwise the PTZ control is not stable. •...
  • Page 151 • System uses too much CPU resources. Please stop record first and then begin backup. • Data amount exceeds backup device capacity. It may result in burner error. • Backup device is not compatible. • Backup device is damaged. 17. Keyboard can not control device. There are following possibilities: •...
  • Page 152 • There is no DivX503Bundle.exe control when you play the file transformed to AVI via media player. • No DivX503Bundle.exe or ffdshow-2004 1012 .exe in Windows XP OS. 23. I forgot local menu operation password or network password Please contact your local service engineer or our sales engineer for help. We can guide you to solve this problem.

  • Page 153: Appendix A Hdd Capacity Calculation

    Appendix A HDD Capacity Calculation Calculate total capacity needed by each device according to video recording (video recording type and video file storage time). Step 1: According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.

  • Page 154: Appendix B Compatible Sata Hdd

    10 Appendix B Compatible SATA HDD Manufacturer Series Model Capacity Port Mode Seagate Seagate SV35.1 ST3250824SV 250G SATA Seagate Seagate SV35.1 ST3500641SV 500G SATA Seagate Seagate SV35.2 ST3250820SV 250G SATA Seagate Seagate SV35.2 ST3320620SV 320G SATA Seagate Seagate SV35.2 ST3500630SV 500G SATA Seagate...
  • Page 155 Seagate Seagate Pipeline ST3500414CS 500G SATA Seagate Seagate Pipeline ST3500312CS 500G SATA Seagate Seagate Pipeline ST31000424CS SATA Seagate Seagate Pipeline ST31000322CS SATA Seagate Seagate Pipeline ST1000VM002 SATA Seagate Seagate Pipeline ST1500VM002 Seagate Seagate Pipeline ST2000VM002 SATA Seagate Seagate Pipeline ST2000VM003 SATA Seagate Seagate...
  • Page 156 Constellation ES Seagate Seagate ST500NM0051 500G SATA Constellation ES Seagate Seagate ST33000650NS SATA Constellation ES.2 Seagate Seagate ST32000645NS SATA Constellation ES.2 Seagate Seagate ST33000651NS SATA Constellation ES.2 Seagate Seagate ST32000646NS SATA Constellation ES.2 Seagate Seagate ST33000652NS SATA Constellation ES.2 Seagate Seagate ST32000647NS SATA...
  • Page 157 Digital Westem WD AV—AVJS WD3200AVJS-63WDA0 320G SATA Digital Westem WD AV—AVJS WD5000AVJS-63YJA0 500G SATA Digital Westem WDAV-GP—AVCS WD5000AVCS-63H1B1 500G SATA Digital Westem WDAV-GP—AVCS WD7500AVCS-63ZLB0 750G SATA Digital Westem WDAV-GP—AVCS WD3200AVCS 320G SATA Digital Westem WDAV-GP—AVCS WD2500AVCS 250G SATA Digital Westem WDAV-GP—EVCS WD10EVCS-63ZLB0 SATA...
  • Page 158 Digital Westem WD AV-GP WD20EURS SATA Digital Westem WD AV-GP WD15EURS 1.5T SATA Digital Westem WD AV-GP WD10EURS SATA Digital Westem WD AV-GP WD10EURX SATA Digital Westem WD AV-GP WD7500AURS 750G SATA Digital Westem WD AV-GP WD7500AVDS 500G SATA Digital Westem WD AV-GP WD500AVDS...

  • Page 159: Appendix C Compatible Usb2.0 List

    11 Appendix C Compatible USB2.0 List Manufacturer Model Capacity Sandisk Cruzer Micro 512M Sandisk Cruzer Micro Sandisk Cruzer Micro Sandisk Cruzer Freedom 256M Sandisk Cruzer Freedom 512M Sandisk Cruzer Fredom Sandisk Cruzer Freedom Kingston Data Traveler II Kingston Data Traveler II Kingston Data Traveler Kingston...
  • Page 160 Teclast Ti Cool 512M Teclast Ti Cool Teclast Ti Cool...

  • Page 161: Appendix D Compatible Displayer List

    12 Appendix D Compatible Displayer List Brand Model Dimension (Unit: inch) BENQ（LCD） ET-0007-TA 19-inch (wide screen) DELL（LCD） E178FPc 17-inch BENQ（LCD） Q7T4 17-inch BENQ（LCD） Q7T3 17-inch LENOVO（LCD） LXB-L17C 17-inch SANGSUNG（LCD） 225BW 22-inch (wide screen) LENOVO(CRT) LXB-FD17069HB 17-inch LENOVO(CRT) LXB-HF769A 17-inch LENOVO(CRT) LX-GJ556D 17-inch Samsung (LCD)

  • Page 162: Appendix H Toxic Or Hazardous Materials Or Elements

    Appendix H Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Sheet ○ ○ ○ ○ ○ ○ Metal(Case) Plastic Parts ○ ○ ○ ○ ○ ○ （Panel） ○ ○ ○ ○ ○...
