Motorola RG2200 User Manual page 18

LED symbols and descriptions.
LED
RG2200 LEDs
Symbol
6. STATUS
7. ONLINE
8. RECORD
9. MESSAGE
18
If the LED is off, there is no power to the RG2200.
A blinking red LED indicates the RG2200 is attempting to communicate with the network.
A blinking amber LED indicates the RG2200 is communicating with the network.
A blinking green LED indicates the RG2200 is not ready to use.
A solid green LED indicates the RG2200 is communicating with the network and is ready to use.
No light, or off, indicates there is no active PC detected on the data port.
An amber light indicates the RG2200 has detected an active PC on the data port, but the RG2200 is not
yet ready for use.
A solid green LED indicates the RG2200 has detected an active Ethernet PC or hub on the Ethernet and
is ready for use.
A red LED indicates a program is being recorded.
A green LED indicates one or more voice mail messages are present.
When the LED is off there are no voice mail messages.
What the lights mean
