- Page 1 Installation Manual DECT Repeater KX-A405 Model No. Thank you for purchasing a Panasonic DECT Repeater. Please read this manual carefully before using this product and save this manual for future use.
- Page 2 Important Information Important Information SAVE THESE INSTRUCTIONS Safety Notices Please observe the safety notices in this manual in order to avoid danger to users or other people, and prevent damage to property. The notices are classified as follows, according to the severity of injury or damage: WARNING This notice means that misuse could result in death or serious injury.
- Page 3 Important Information • When driving the screws into the wall, be careful to avoid touching any metal laths, wire laths or metal plates in the wall. • To prevent malfunction, deformity, overheating, rust, and discolouration, do not install or place equipment in the following types of locations: –...
- Page 4 Important Information Additional Information For users in the European Union only Information for Users on Collection and Disposal of Old Equipment and used Batteries These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste.
-
Page 5: Table Of Contents
Table of Contents Table of Contents 1 Overview ....................6 System Overview ......................6 System Connection Example ...................6 Names and Locations .......................6 Unpacking ..........................7 LED Indications .........................7 Compatible Devices ......................10 Specifications ........................11 2 Procedure Overview ................12 Registering the Repeater ....................12 Installing the Repeater ....................13 3 Registering the Repeater ...............14 Easy Registration ......................14 Manual Registration ......................15... -
Page 6: Overview
1 Overview 1 Overview System Overview A repeater is used when you need to extend the range of a DECT Portable Station (PS) to include areas where reception was previously not available. The repeater extends the range in all directions, allowing several floors to be covered. -
Page 7: Unpacking
1 Overview Unpacking Unpack the box and check the items below: Repeater (KX-A405) AC Adaptor (PQLV219) Screws Washers LED Indications The LED patterns and the corresponding status of the repeater in each mode are as follows. For details about each mode, refer to "3 Registering the Repeater" or "4 Using the Repeater". - Page 8 1 Overview Mode Status STATUS RSSI/ID Entering Manual Registration Quick Green Flashing Mode (after 5 seconds 1 Red Flash 2 Red Flashes Manual Registration 3 Red Flashes Mode 4 Red Flashes Green On 5 Red Flashes 6 Red Flashes ID assigned Red On Entering ID Modification Quick Amber Flashing...
- Page 9 1 Overview Mode Status STATUS RSSI/ID Channel 1 1 Green Flash Channel 2 2 Green Flashes Channel 3 3 Green Flashes Channel 4 4 Green Flashes Channel 5 5 Green Flashes Site Survey Mode Channel 6 6 Green Flashes Channel 7 7 Green Flashes Channel 8 8 Green Flashes...
-
Page 10: Compatible Devices
1 Overview Compatible Devices Compatible Device Model No. • KX-TDA0141 • KX-TDA0142 • KX-TDA0155 • KX-TDA0156 • KX-TDA0158 • KX-NCP0158 (IP-CS) • KX-TCA155 • KX-TCA175 • KX-TCA256 • KX-TCA275 • KX-TCA355 • KX-TCA364 • KX-WT115 Not supported by the KX-A405X. Installation Manual... -
Page 11: Specifications
1 Overview Specifications Basic Specifications Maximum Number of Simultaneous Calls Maximum Number of Cascade Steps Maximum Number of Repeaters Registered to a CS The maximum number of simultaneous calls may decrease depending on the wireless environment or the PBX’s system configuration. General Specifications 111 mm (W) ´... -
Page 12: Procedure Overview
2 Procedure Overview 2 Procedure Overview When registering and installing the repeater, follow the procedure below to ensure smooth operation. Registering the Repeater Note • Register repeaters one by one. Do not register multiple repeaters simultaneously. • Do not disconnect the AC adaptor of any registered repeaters until the registration of all repeaters is complete. -
Page 13: Installing The Repeater
2 Procedure Overview Installing the Repeater After all registration is complete, place the repeater where you want to install it. Repeater Coverage Area As a guideline, the example below shows the size of the coverage area where one repeater can synchronise with a CS/destination repeater, or provide coverage for a PS, if it is installed in an area with no obstacles. -
Page 14: Registering The Repeater
3 Registering the Repeater 3 Registering the Repeater Easy Registration In easy registration, the repeater can be registered to a CS easily. WARNING • When installing or testing a product with an external AC adaptor, the AC adaptor should be plugged into a wall outlet or floor-mounted AC outlet. -
Page 15: Manual Registration
3 Registering the Repeater Manual Registration In manual registration, the repeater can be registered to another repeater to create a cascade configuration. WARNING • When installing or testing a product with an external AC adaptor, the AC adaptor should be plugged into a wall outlet or floor-mounted AC outlet. -
Page 16: De-Registration
3 Registering the Repeater De-registration Perform de-registration to delete the ID of the CS/repeater that the repeater is registered to. WARNING • When installing or testing a product with an external AC adaptor, the AC adaptor should be plugged into a wall outlet or floor-mounted AC outlet. Do not connect the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become disconnected. -
Page 17: Id Modification
3 Registering the Repeater ID Modification In ID Modification mode, the ID of the repeater (RPN [Radio Part Number]) can be selected. Registered repeaters are automatically assigned an ID during the registration process. This ID can be changed by following the procedure below. -
Page 18: Using The Repeater
4 Using the Repeater 4 Using the Repeater ID Confirmation/Verification Tone Mode The ID of currently registered repeaters can be checked in ID Confirmation mode. Also, the coverage area of registered repeaters can be checked using a PS, in Verification Tone mode. When the beep is no longer heard, the PS is no longer in range of the repeater. -
Page 19: Site Survey Mode
4 Using the Repeater Site Survey Mode This function can be used to measure the transmission quality, and identify problematic transmission areas of the repeater installation. This function can be used when registered or de-registered. WARNING • When installing or testing a product with an external AC adaptor, the AC adaptor should be plugged into a wall outlet or floor-mounted AC outlet. -
Page 20: Wall Mounting
5 Wall Mounting 5 Wall Mounting Mounting WARNING • Make sure that the wall that the unit will be attached to is strong enough to support the unit (approx. 88 g). If not, it is necessary for the wall to be reinforced. •... -
Page 21: Reference For Wall Mounting
5 Wall Mounting Reference for Wall Mounting Print this page and use as a reference for wall mounting. Install a screw here. 37 mm Install a screw here. Note Make sure to set the print size to correspond with the size of this page. If the dimension of the paper output still deviates slightly from the measurement indicated here, use the measurement indicated here. -
Page 22: Troubleshooting
6 Troubleshooting 6 Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION • • • The repeater does not turn The AC adaptor is not Make sure that the AC adaptor is connected properly. properly connected to both the repeater and the AC outlet. •... - Page 23 6 Troubleshooting PROBLEM PROBABLE CAUSE SOLUTION • • • The PS is beeping. The verification tone is Turn the verification tone off (refer to turned on. "ID Confirmation/Verification Tone Mode"). • • • Poor audio quality. The CS is out of range. Move the repeater closer to the CS.
- Page 24 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Copyright: This material is copyrighted by Panasonic System Networks Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic System Networks Co., Ltd.
