Summary of Contents for Baumatic BWC1215SS
- Page 1 BWC1215SS 94 Bottle Wine Cabinet...
- Page 2 USER MANUAL FOR YOUR BAUMATIC BWC1215SS 94 bottle dual temperature electronic wine cabinet NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference, for you or any person not familiar with the operation of the appliance.
-
Page 3: Table Of Contents
Description of the appliance 8-10 Product features Control panel Description of the product features 9-10 Using your Baumatic wine cabinet 10-15 Before switching on During first use Turning the appliance on and off Unlocking the control panel The interior light... -
Page 4: Environmental Note
This should be undertaken by a competent person. Disable the door lock to make sure that children cannot get stuck inside the appliance. o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the... -
Page 5: Important Safety Information
Important safety information Your safety is of the utmost importance to Baumatic. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Baumatic Customer Care Department. - Page 6 Child safety o Packaging material should be kept away from children. o This appliance is intended for use by persons with sufficient experience and knowledge of electrical appliances. other persons (including children) should be supervised or given instruction concerning use of the appliance by a person responsible for their safety.
-
Page 7: Specifications Of Your Wine Cabinet
Service You should not attempt to repair the appliance yourself, as this could cause injury or a more serious malfunction. If you require a service call then please contact the Customer Care Department. Specifications of your wine cabinet Dimensions of appliance Height: 1215 mm Width:... -
Page 8: Description Of The Appliance
Model number ……………………………………………… Serial number ……………………………………………… Date of purchase …………………………………………….. Description of the appliance... -
Page 9: Control Panel
Control panel The control panel is located in the middle of the appliance. Description of the product features Control panel o The control panel is located in the middle of the appliance, behind the glass door. This means it is easy to set the temperature of the appliance and see what temperature the appliance is set to. -
Page 10: Using Your Baumatic Wine Cabinet
All of the deep shelves have telescopic rails which have stoppers of their own. Using your Baumatic wine cabinet Before switching on o Make sure that it has been installed by a suitably qualified person, information contained Baumatic’s installation instructions. -
Page 11: During First Use
During first use IMPORTANT: When you use the wine cabinet for the first time or restart the appliance after it has been turned off for a long time, there could be a few degrees variance between the temperature you select and the one indicated on the LED display. -
Page 12: The Interior Light
The interior light o When the control panel is unlocked, you can use the light button to switch the interior light on and off. o The light will remain on unless it is turned off manually by pressing the light button. Setting the temperature o The temperature setting for the upper zone is adjustable within the range of 5°C - 12°C / 41°F - 54°F. -
Page 13: Loading The Wine Cabinet
Loading the wine cabinet o IMPORTANT: Your appliance is ideally suited to store 0.75 litre Bordeaux style wine bottles. You must make sure that they do not prevent the door from shutting properly. o Always check that you can close the door without it fouling on a wine bottle, before shutting it. - Page 14 o Wines kept at a higher temperature will age faster. Wine that is exposed to temperatures that are greater than 21°C (70°F) will suffer from poorer flavour and aroma. o If wine is kept at too low a temperature, this can result in the development of harmful deposits.
-
Page 15: Wine Storage Problems
Wine storage problems Corking- a tiny percentage of bottled wine (about 1%) will suffer from this. The cork reacts with the wine and gives it a musty, unpleasant taste. It is the most common wine storage problem and is caused by harmless bacteria growing on the cork. -
Page 16: Cleaning And Maintenance
Cleaning and maintenance WARNING: PLEASE ENSURE THAT YOUR APPLIANCE IS DISCONNECTED FROM YOUR MAINS SUPPLY BEFORE ATTEMPTING TO CLEAN IT. o Do not clean the appliance by pouring water onto it or spraying water over it. o The interior of the wine cooler should be cleaned periodically, using a solution of bicarbonate of soda and lukewarm water. -
Page 17: Moving Your Wine Cabinet
automatic defrosting process and deflect water into the base of your wine cabinet. Moving your wine cabinet If you need to move your wine cabinet to another location you should follow the steps outlined below. o Remove all items from the wine cabinet. o Securely tape down all loose items such as the shelves inside of the appliance. -
Page 18: Installation
Installation IMPORTANT: Before installation and usage read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the rating plate are exactly the same as the voltage and frequency in your home. The rating plate can be found on the front left edge of the inside of the wine cabinet. -
Page 19: Positioning
o When the connection is completed, no stray strands or cut wire should be present. The cord clamp must be secured over the outer sheath. Positioning o It is advisable that your appliance is only installed in a location where the ambient temperature of the room, corresponds with the climate classification that is stated on the rating plate of your appliance. -
Page 20: Installing The Handle
o Tilt the appliance approximately 60° to allow access to the adjustable feet. o Take care to ensure the cabinet is supported at all times. o Twist the foot into a suitable position to level the cabinet. o Repeat these steps for the other adjustable feet. IMPORTANT: If the appliance is not level, then the door and door seal may be affected. -
Page 21: Reversing The Door Of Your Wine Cabinet
Reversing the door of your wine cabinet This appliance has the capability of the door opening from either the left or right hand side. o The instructions provided below are based on a wine cabinet with a right door hinge installed already. 1) Remove the hinge hole cover from the left hand side and the hinge cover from the upper hinge on the right hand side using a screwdriver. - Page 22 3) Move the hinge hole cap at the top of the door from the left to the right hand side. 4) Remove the bottom hinge cover and take out the bottom hinge by loosening the 4 screws. Remove the screws on the bottom left side.
- Page 23 5) To reinstall the door on the opposite side, insert the door support rod into the bottom hinge through the washer and screw the upper hinge to the door. Finally, cover the hinge and hinge holes using the hinge covers. Any parts that you remove from the appliance whilst reversing the door, should be retained for later use.
-
Page 24: Reversing The Door Handle
o If the seal is not adhering to the cabinet properly, then you should either:- a) Use a warm damp cloth and manipulate the seal until it does adhere to the cabinet properly, all the way around the door. b) Use a hair dryer on its lowest heat setting and lightly heat the areas of the door seal that are not adhering correctly. - Page 25 2) Remove the gasket on the left inner side of the door to expose the 2 handle screws. Unscrew them in an anti-clockwise direction with a cross screwdriver. Take out the screws and washers as well as the handle. 3) Install the handle on the outer right side of the door. 4) Install the 2 decorative screws in the holes on the left hand side of the outer door by following the instructions for removing the decorative screws in reverse (step 1).
-
Page 26: Troubleshooting
5) Tidy and restore the door gasket. Troubleshooting IMPORTANT: If your wine cabinet appears not to be operating properly, before contacting the Customer Care Department, please refer to the checklist below. PROBLEM POSSIBLE CAUSE The wine cabinet will not operate. The appliance is not plugged in. - Page 27 the cabinet or in the compressor chamber are loose. The wine cabinet seems to make too The rattling noise may come from the much noise. flow of the refrigerant which is normal. As each cycle ends, you may hear gurgling noises caused by the flow of refrigerant.
- Page 28 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance.
-
Page 29: Baumatic Consumables
BC005 Stainless Steel Cleaner and Protector (250ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.uk... -
Page 30: Technical Data
Technical Data Manufacturer BAUMATIC Model Number BWC1215SS Product Category 2 – Refrigeration-cellar, Cellar and wine storage appliances Energy Efficiency Class (1) Annual Energy Consumption (2) 402 kWh Storage Volume of Fridge 266 litres Compartment Storage Volume of Freezer Compartment Star Rating Coldest Storage Temperature Upper Zone: 5°C / Lower Zone:... -
Page 31: Contact Details
United Kingdom Baumatic Ltd., Baumatic Buildings, Czech Republic 6 Bennet Road, Baumatic CR s.r.o. Reading, Berkshire Lípovà 665 RG2 0QX 460 01 Liberec 4 United Kingdom Czech Republic Sales Telephone +420 483 577 200 (0118) 933 6900 Sales Fax www.baumatic.cz...
