Casio EX-Z1050 Service Manual & Parts List

Ex-z1050 casio
Hide thumbs Also See for EX-Z1050:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
(without price)
EX-Z1050
FEB. 2007
I REFER TO THE PAGE 18 AFTER CHANGING THE MAIN PCB.
Ver.4 : Dec. 2007
INDEX
R

Advertisement

Table of Contents
loading

Related Manuals for Casio EX-Z1050

Summary of Contents for Casio EX-Z1050

  • Page 1 (without price) EX-Z1050 FEB. 2007 I REFER TO THE PAGE 18 AFTER CHANGING THE MAIN PCB. Ver.4 : Dec. 2007 INDEX...

  • Page 2: Table Of Contents

    CONTENTS SPECIFICATIONS ............................1 BLOCK DIAGRAM ............................5 TEST MODE ..............................6 PROGRAM VERSION UPGRADING ......................7 1. To update the firmware version ..................... 7 2. How to restore the firmware ......................8 3. To install the firmware ........................9 ADJ TOOL ..............................

  • Page 3: Specifications

    SPECIFICATIONS Image Files Format Snapshots: JPEG (Exif Version 2.2); DCF (Design Rule for Camera File System) 1.0 standard; DPOF compliant Movies: Motion JPEG AVI format Audio: Recording Media Built-in Memory 15.4 MB, SDHC Memory Card, SD Memory Card, MMC (MultiMediaCard), MMCplus (MultiMediaCardplus) Approximate Memory Capacity and File sizes •...
  • Page 4 Delete Single-file, all files (with protection) Effective Pixels 10.1 million Imaging Element 1/1.75-inch square pixel color CCD (Total pixels: 10.3 million) Lens/Focal Distance Lenses: F2.8 (W) to 5.1 (T); f=7.9 (W) to 23.7mm (T) (equivalent to approximately 38 (W) to 114mm (T) for 35mm film) 7 lenses in 5 groups, with aspherical lans Zoom...

  • Page 5: Power Requirements

    Power Requirements Power Requirements Lithium ion rechargeable battery (NP-40) x 1 Approximate Battery Life: The values below indicate the amount of time under the conditions defined below, until power automatically turns off due to battery failure. They do not guarantee that you will be able to achieve this level of operation. Low temperatures shorten battery life. Operation Approximate Battery Life Number of Shots (CIPA Standard)*...
  • Page 6 Rechargeable Lithium Ion Battery (NP-40) Rated Voltage 3.7 V Rated Capacitance 1300 mAh Operating Temperature 0 to 40°C (32 to 104°F) 38.5 (W) ✕ 38.0 (H) ✕ 9.3( D) mm (1.52˝(W) ✕ 1.50˝(H) ✕ 0.37˝(D)) Dimensions Weight Approximately 34 g (1.2 oz) Battery Charger (BC-31L) Power Requirement 100 to 240V AC, 80mA, 50/60Hz...

  • Page 7: Block Diagram

    BLOCK DIAGRAM — 5 —...

  • Page 8: Test Mode

    TEST MODE Note: Never perform the menu items unless otherwise instructed. Doing so may cause destruction of the data inside, which will make the camera unusable. I To boot the test mode 1. While firmly pressing down both [BS] and [UPPER], turn the power on. [UPPER] button [BS] button 2.

  • Page 9: Program Version Upgrading

    PROGRAM VERSION UPGRADING 1. To update the firmware version 1. Prepare the memory card which contains the firmware for EX-Z1050 in the root directory. EX-Z1050.bin 2. Insert the above memory card into the camera, and set a fully charged battery in the camera.

  • Page 10: How To Restore The Firmware

    2. How to restore the firmware 1. Prepare the firmware restoration program. uranus.bin NOTE: This software and procedure automatically restores the firmware even if the firmware belongs to a wrong model code. Make sure to use the correct software for the correct model. 2.

  • Page 11: To Install The Firmware

    1. Copy the following software to the root directly of the SD card. Restoration software: uranus.bin Firmware: EX-Z1050.bin 2. Insert the SD card into the camera. 3. Insert the battery while holding the [shutter release] button depressed. The LED next to the optical viewfinder changes from “green/red blinking”, “green blinking” to “green steady”.

  • Page 12: Adj Tool

    ADJ TOOL I Introduction Make sure to perform the adjustment by the USB ADJ Tool “AdjUSB.exe” when replacing the lens unit or the PCB. Here the necessary software, driver and setting are explained to use “AdjUSB.exe”. Note that the tool, drivers etc. are available only for Windows. 1.
  • Page 13 7) Check “Designate the place to search”, designate the place which contains “inf” file in the driver by pressing “Reference” button, and then press “Next” button. 8) When “Universal USB Driver (VMEM manufacturer’s name)” appears upon message “Searching for the driver file for the following devices”, press “Next” button. 9) The file copy starts.

  • Page 14: How To Use Adj Tool When Replacing Lens Unit

    3 Boot "AdjUSB" . 4 Select the model name and click "Load FW " Key. • Kx847 EX-Z1050 5 Click "ADJ ALL READ", and display the data on the "AdjUSB". 6 Find the No.1163, "LCD VCOM DC". 7 Write down this value(data).

  • Page 15: How To Use Adj Tool When Replacing Main Pcb

    2 Connect the camera to the PC by the USB cable. 3 Boot "AdjUSB". 4 Select the model name and click "Load FW " Key. • Kx847 EX-Z1050 5 Click "ADJ ALL READ", and display the data on the "AdjUSB". 6 Save the data. 7 Replace the MAIN PCB.

  • Page 16: Vcom Dc Adjustment

    VCOM DC ADJUSTMENT I Purpose Readjust the VCOM value to minimize the flicker of the LCD after replacing the LCD or the main PCB. I Necessary tools 1. Camera (Charge its battery fully) 2. Photo diode (S2281-01) : See Fig 1. 3.
  • Page 17 I Procedure 1. Camera setting Figure (a) a) Turn the power on while pressing “BS” and “UPPER”. 1: VERSION INFO After pressing “DOWN” key twice, press “BS” and “MENU”. 2: USB TCC TEST Select "2:USB TCC TEST", and press "SET" button. 3: ROM UPDATE 4: LAST MEMORY Select "1:USB TCC ON", and press "RIGHT"...
  • Page 18 3. Measurement a) Connect S2281-01 to the camera’s LCD monitor (see below). AC Waveforms appear on the monitor screen of the oscilloscope. * Change the Rf range of C9329 in case the range does not match. Photo diode Oscilloscope INPUT OUTPUT S2281-01 Photo sensor amp...

  • Page 19: Current Consumption

    CURRENT CONSUMPTION (1) Current consumption (DC in = 3.80 ± 0.1 [V]) • Make sure that current consumption is less than 185 mA in PLAY mode. • Make sure that current consumption is less than 420 mA in REC mode. •...

  • Page 20: Resetting The Place Of Destination

    RESETTING THE PLACE OF DESTINATION When the main PCB is replaced, the setting of the destination will be changed, therefore resetting is required. However, when the firmware is changed or fixed, the setting of the destination will be held, therefore resetting is not required.

  • Page 21: Disassembly

    DISASSEMBLY Please note that the product on this manual may appear to be different from the actual one according to the changes such as engineering design change. * Make sure to use correct screws when assembling since there are several kinds of them. It is a good idea to sort them as shown in the right when disassembling.
  • Page 22 4. Remove the screw and then remove the C-CASE-CA. Screw (S2) 5. Remove two screws and then remove the C-CASE-AA. Screw (S1) Hook Screw (S2) 6. Remove 14 screws. Screws (S3) Screws (S3) Screws (S4) Screw (S2) Screw (S1) Screws (S3) Screws (S3) Screws (S2) —...
  • Page 23 7. Remove the rear panel assy. Note: The strap come off. Be sure not to lose the strap. Strap 8. Remove the front panel assy. 9. Discharge the strobe condenser. I Removing the LCD unit 10. Remove two screws. 11. Unsolder to remove two lead wires. Screw (S1) Screw (S2) —...
  • Page 24 12. Remove the FPC and then remove the LCD unit. Hooks are located at two locations as below. Release the connector lock and remove the FCP. Hooks I Removing the Shutter sub assy 13. Remove the Shutter sub assy. Hook Hooks —...
  • Page 25 Removing the lens unit 14. Remove the speaker holder. 15. Release the connector lock and remove two FPCs. 16. Remove the lens unit. Do not touch or press here. Removing the main PCB 17. Release the FPC. Release the lock and remove the FPC. Release the FPC.
  • Page 26 18. Remove the tape. 19. Unsolder to remove five lead wires. 20. Remove two screws. Screw (S4) Screw (S2) 21. Remove the main PCB. — 24 —...
  • Page 27 I Removing the LED, SP and MIC 22. Unsolder to remove four lead wires. 23. Remove the holder. 24. Remove the LED, SP and MIC. LED and SP: Fixed with double-sided tape. I Removing the buttery cover 25. Remove the BOTTOM-SUB-ASSY. BOTTOM-SUB-ASSY 26.
  • Page 28 I Removing the Strobe unit 27. Remove the Strobe unit. Strobe unit I Removing the JACK cover 28. Remove the buttery frame. Buttery frame Hooks 29. Remove two screws and then remove the buttery case. 30. Remove the JACK cover. Screws (S2) JACK cover —...

  • Page 29: Assembly

    ASSEMBLY FOR THE SCREWS WITH A TORQUE VALUE INDICATED, USE A TORQUE DRIVER AND TIGHTEN IT ACCORDING TO THE VALUE INDICATED ON THE SCREW. I Assembling the buttery case assy 1. Set the JACK cover. 2. Set the buttery case and fix it with two screws. JACK cover Screws (S2) 3.
  • Page 30 Assembling the LED, SP and MIC 5. Set the LED, SP and MIC. 6. Solder four lead wires. Assembling the buttery cover 7. Set the buttery cover. buttery cover — 28 —...
  • Page 31 I Assembling the main PCB 8. Set the main PCB. 9. Solder five lead wires. 10. Fix with the screw. 11. Affix a tape in order to shield the end terminal. Screw (S4) 12. Insert the FPC. Make sure to insert the FPC firmly Insert it firmly and lock up I Assembling the Lens unit 13.
  • Page 32 I Assembling the Battery cover 14. Set the BOTTOM-SUB-ASSY. * Please take note how to install it on the reverse side. — 30 —...
  • Page 33 15. Set the main PCB and fix it with one screw. 16. Set the Speaker holder and fix it with the hook. Screw (S2) 17. Set the shutter SUB assy and fix it with the hook. Hooks Hook Assembling the LCD unit 18.
  • Page 34 I Assembling the CASE 22. Set the plate. 23. Set the rear panel. plate 24. Fit the strap on the rear panel. 25. Set the rear panel. Strap 26. Assemble with 14 screws. Screws (S3) Torque: 8.0 ± 1.0 N•cm Screws (S4) Torque: 8.0 ±...
  • Page 35 27. Set the C-CASE-DE and fix it with two screws. Screws (S1) Torque: 5.5 ± 1.0 N•cm *Do not tighten it excessively Screws (S2) Torque: 7.5 ± 1.0 N•cm 28. Set the C-CASE-CE and fix it with the screw. Screws (S2) Torque: 7.5 ±...

  • Page 36: Exploded View

    EXPLODED VIEW 25-3 25-2 25-1 — 34 —...

  • Page 37: Parts List

    PARTS LIST 1 EX-Z1050_SILVER_DI 6 EX-Z1050_BLACK_DI 11 EX-Z1050_GOLD_DI 16 EX-Z1050_PINK_DI 21 EX-Z1050_BLUE_DI 2 EX-Z1050_SILVER_CHINA 7 EX-Z1050_BLACK_CHINA 12 EX-Z1050_GOLD_CHINA 17 EX-Z1050_PINK_CHINA 22 EX-Z1050_BLUE_CHINA 3 EX-Z1050_SILVER_EU 8 EX-Z1050_BLACK_EU 13 EX-Z1050_GOLD_EU 18 EX-Z1050_PINK_EU 23 EX-Z1050_BLUE_EU 4 EX-Z1050_SILVER_UK 9 EX-Z1050_BLACK_UK 14 EX-Z1050_GOLD_UK 19 EX-Z1050_PINK_UK 24 EX-Z1050_BLUE_UK 5 EX-Z1050_SILVER_US 10 EX-Z1050_BLACK_US...
  • Page 38 1 EX-Z1050_SILVER_DI 6 EX-Z1050_BLACK_DI 11 EX-Z1050_GOLD_DI 16 EX-Z1050_PINK_DI 21 EX-Z1050_BLUE_DI 2 EX-Z1050_SILVER_CHINA 7 EX-Z1050_BLACK_CHINA 12 EX-Z1050_GOLD_CHINA 17 EX-Z1050_PINK_CHINA 22 EX-Z1050_BLUE_CHINA 3 EX-Z1050_SILVER_EU 8 EX-Z1050_BLACK_EU 13 EX-Z1050_GOLD_EU 18 EX-Z1050_PINK_EU 23 EX-Z1050_BLUE_EU 4 EX-Z1050_SILVER_UK 9 EX-Z1050_BLACK_UK 14 EX-Z1050_GOLD_UK 19 EX-Z1050_PINK_UK 24 EX-Z1050_BLUE_UK 5 EX-Z1050_SILVER_US 10 EX-Z1050_BLACK_US 15 EX-Z1050_GOLD_US...
  • Page 39 1 EX-Z1050_SILVER_DI 6 EX-Z1050_BLACK_DI 11 EX-Z1050_GOLD_DI 16 EX-Z1050_PINK_DI 21 EX-Z1050_BLUE_DI 2 EX-Z1050_SILVER_CHINA 7 EX-Z1050_BLACK_CHINA 12 EX-Z1050_GOLD_CHINA 17 EX-Z1050_PINK_CHINA 22 EX-Z1050_BLUE_CHINA 3 EX-Z1050_SILVER_EU 8 EX-Z1050_BLACK_EU 13 EX-Z1050_GOLD_EU 18 EX-Z1050_PINK_EU 23 EX-Z1050_BLUE_EU 4 EX-Z1050_SILVER_UK 9 EX-Z1050_BLACK_UK 14 EX-Z1050_GOLD_UK 19 EX-Z1050_PINK_UK 24 EX-Z1050_BLUE_UK 5 EX-Z1050_SILVER_US 10 EX-Z1050_BLACK_US 15 EX-Z1050_GOLD_US...
  • Page 40 1 EX-Z1050_SILVER_DI 6 EX-Z1050_BLACK_DI 11 EX-Z1050_GOLD_DI 16 EX-Z1050_PINK_DI 21 EX-Z1050_BLUE_DI 2 EX-Z1050_SILVER_CHINA 7 EX-Z1050_BLACK_CHINA 12 EX-Z1050_GOLD_CHINA 17 EX-Z1050_PINK_CHINA 22 EX-Z1050_BLUE_CHINA 3 EX-Z1050_SILVER_EU 8 EX-Z1050_BLACK_EU 13 EX-Z1050_GOLD_EU 18 EX-Z1050_PINK_EU 23 EX-Z1050_BLUE_EU 4 EX-Z1050_SILVER_UK 9 EX-Z1050_BLACK_UK 14 EX-Z1050_GOLD_UK 19 EX-Z1050_PINK_UK 24 EX-Z1050_BLUE_UK 5 EX-Z1050_SILVER_US 10 EX-Z1050_BLACK_US 15 EX-Z1050_GOLD_US...

  • Page 41: Printed Circuit Board

    PRINTED CIRCUIT BOARD MAIN PCB (TOP VIEW) FU181 — 39 —...
  • Page 42 MAIN PCB (BOTTOM VIEW) FU180 — 40 —...
  • Page 43 • Correction of the DISASSEMBLY. (P23, P25) Ver.3 : May. 2007 • Correction of the ASSEMBLY. (P27, P32, P33) Ver.4 : Dec. 2007 • Correction of the DISASSEMBLY. (P23) CASIO COMPUTER CO.,LTD. Overseas Service Division 6-2, Hon-machi 1-Chome Shibuya-ku, Tokyo 151-8543, Japan...
