Page 1 Honeywell Process Solutions Experion PKS Series A Fieldbus Interface Module User's Guide EP-DCX166 R400 July 2010 Release R400 Honeywell...
Page 2: Figure 16 Rtp Model Tc-Ffru01 Is Unpowered And Can Be Used In Division
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and specifications in this document are subject to change without notice.
Page 3 Fieldbus reference data. Release Information Document Name Document ID Release Publication Number Date Series A Fieldbus Interface Module User's EP-DCX166 R400 July 2010 Guide - figd Document Category Purpose R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 4 Honeywell Global TAC – India Phone: +91-20- 6603-9400 Fascimile: +91-20- 6603-9800 Mail: Honeywell Automation India Ltd 56 and 57, Hadapsar Industrial Estate Hadapsar, Pune –411 013, India Email: Global-TAC-India@honeywell.com Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 5 Contact: Honeywell Global TAC – Taiwan Phone: +886-7-536-2567 Fascimile: +886-7-536-2039 Mail: Honeywell Taiwan Ltd. 17F-1, No. 260, Jhongshan 2nd Road. Cianjhen District Kaohsiung, Taiwan, ROC Email: Global-TAC-Taiwan@honeywell.com R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 6 20th Floor, 1-16-1 Kaigan, Minato-ku, Tokyo 105-0022, Japan Email: Global-TAC-JapanJA25@honeywell.com Elsewhere Call your nearest Honeywell office. World Wide Web Honeywell Solution Support Online: http://www.honeywell.com/ps Training Classes Honeywell Automation College: http://www.automationcollege.com Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 7: Symbol Definitions
WARNING symbol on the equipment refers the user to the product manual for additional information. The symbol appears next to required information in the manual. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 8 Chassis Ground: Identifies a connection to the chassis or frame of the equipment shall be bonded to Protective Earth at the source of supply in accordance with national and local electrical code requirements. viii Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 9: Table Of Contents
FIM handles data integration....................42 About link object........................42 Network Management description..................42 System Management description ..................43 About device objects ......................43 About VFD objects .......................43 Type creation makes integration possible ................44 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 10 Fieldbus network switchover considerations ............... 83 Switchover versus fieldbus network activities..............84 Switchover events ....................... 86 Block Instantiation Support................86 About instantiable blocks..................... 86 Control Builder supports block instantiation ................ 86 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 11 Configuration considerations only for redundant CIOM-A FIM applications .......122 Adding CIOM-A FIM block to Project .................123 Checking link configuration ....................133 Creating a Fieldbus device type from vendor DD...............141 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 12 Tabs of FF Detail Displays ....................246 Detail Displays tabs of the different Foundation Fieldbus blocks........247 Common functionalities of faceplates................250 FF Detail Displays example templates for Control Builder ..........252 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 13 Correcting Some Common UTR errors............. 328 Upgrading Firmware in Uncommissioned Device ........328 Changing or Clearing Tag and/or Address of Uncommissioned Device332 Using Fieldbus Device Simulate Function ..........334 R400 Experion PKS Series A Fieldbus Interface Module User's Guide xiii July 2010 Honeywell...
Page 14 Proportional/Derivative block..................... 402 Ratio block ........................412 10.3 Device Descriptions and Block Parameters..........416 About Device Descriptions ....................416 Device Description Language ................... 416 Device Description infrastructure..................416 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 15 CYCLE_SEL ........................432 CYCLE_TYPE........................432 DEV_REV ..........................433 DEV_TYPE ........................433 DD_RESOURCE........................434 DD_REV..........................434 DISC_ALM .........................435 DISC_LIM...........................435 DISC_PRI...........................436 DV_HI_ALM ........................436 DV_HI_LIM.........................437 DV_HI_PRI.........................437 DV_LO_ALM ........................438 DV_LO_LIM ........................439 DV_LO_PRI ........................439 FAULT_STATE ........................439 FEATURES ........................440 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 16 OFFNETALM_ENABLED ....................461 OUT........................... 461 OUT_D ..........................462 OUT_HI_LIM ........................463 OUT_LO_LIM ........................463 OUT_SCALE ........................463 OUT_STATE ........................464 PV ............................. 465 PV_D..........................465 PV_FTIME......................... 466 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 17 SP_LO_LIM........................483 SP_RATE_DN........................483 SP_RATE-UP........................484 ST_REV ..........................484 STATUS_OPTS .........................484 STRATEGY........................486 TAG_DESC........................486 TEST_RW ..........................487 TRK_IN_D..........................488 TRK_SCALE ........................488 TRK_VAL ...........................489 UPDATE_EVT........................490 WRITE_ALM ........................490 WRITE_LOCK........................491 WRITE_PRI........................491 XD_SCALE ........................492 XD_STATE.........................493 APPENDIX C................495 R400 Experion PKS Series A Fieldbus Interface Module User's Guide xvii July 2010 Honeywell...
Page 18 APPENDIX H ................533 17.1 Important Functional Considerations ............533 General ..........................533 APPENDIX I................539 18.1 Link Parameters Reference..............539 Background ........................539 More detailed information....................540 xviii Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 19 Parameters for Link Configuration in Project Mode............540 Parameters for Link Configuration in Monitor Mode ............551 Some term abbreviations ....................555 APPENDIX J ................557 19.1 Load Interactions for Fieldbus Related Operations......557 Summary..........................557 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 20 Contents Tables Tables Table 1 CIOM-AFIM LED Interpretations..............348 Table 2 CONTROL_OPTS Bit Selections..............431 Table 3 IO_OPTS Bit Selections.................451 Table 4 STATUS_OPTS Bit Selections ..............485 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 21 Figure 25 Overview of load operations used to initiate components online....203 Figure 26 Load Dialog box provides more load choices..........204 Figure 27 Typical FIM Detail display in Station............244 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 22 Figure 48 Functional schematic for Ratio function block..........412 Figure 49 Device Descriptions infrastructure..............417 Figure 50 Overview of fieldbus wiring topologies............511 Figure 51 Communications entity architecture............539 xxii Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 23: Introduction
Will be monitoring system operation. This Through Monitoring Tab section provides an overview of functions you can monitor through Station displays and the Monitoring tab in Control Builder. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 24: Conventions
Press <F1> to view the angle brackets. online Help. <Ctrl>+<C> Keys to be pressed together are Press <Ctrl>+<C> to shown with a plus sign. close the window. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 25 Click File->New to start followed by menu selection new drawing. >D:\setup.exe< Data to be keyed in at prompt or in an Key in this path location entry field. >D:\setup.exe<. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 26 1. Introduction 1.2. Conventions Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 27: What Is Fieldbus
It consists of both resource information (what the device can potentially do) and value information (how the device should actually be set up). R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 28 A binary file that provides the definition for parameters in the FBAP of a device. For example, what Function Blocks a device contains, and what parameters are in those blocks. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 29 DD binary files by the Fieldbus Foundation Synthesizer. Device Description A software library developed by the Fieldbus Service Foundation that provides a generic access to a DD. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 30 Each manufacturer has a directory name that is the registered manufacturer ID number. There is a directory for each device type that a manufacturer produces under their ID directory. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 31 VCRs: Publish/Subscribe Client/Server Source/Sink Virtual Field Device The management or FBAP section of a device that is addressable by a VFD tag. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 32 2. What is Fieldbus? 2.3. Fieldbus Terms Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 33: Fieldbus Integration With Experion System
While the Series C FIM is functionally equivalent to the Chassis I/O- Series A (CIOM-A) FIM, its physical design, including mounting and wiring requirements, is drastically different. Please refer to the Series C FIM User's Guide for information that is specific to integrating fieldbus through a Series C FIM.
Page 34: Non-Redundant Fieldbus Integrated Architecture For Ciom-A Fim
FIM = Fieldbus Interface Module 24Vdc Only ControlNet is available as redundant media. Conditioned 24Vdc Conditioned Figure 1 Sample system architecture for non-redundant Fieldbus integration for CIOM-A FIM. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 35: Redundant Fieldbus Integrated Architecture For Ciom-A Fim
No chassis I/O modules are permitted in a remote I/O chassis pair configured for redundant fieldbus support. Only redundancy compliant modules can be used in a Redundant Chassis Pair configuration. The same is true for the redundant Controller chassis. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 36: Figure 2 Sample System Architecture For Redundant Fieldbus Integration For Ciom-A Fim
FIM = Fieldbus Interface Module RM = Redundancy Module Only ControlNet is available as redundant media. Figure 2 Sample system architecture for redundant Fieldbus integration for CIOM-A FIM. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 37: Fieldbus Interface Module (Fim) - The Key To Integration
H1 Link, and create individual block types for each fieldbus device including their function blocks. The fieldbus device block types will reside in the Engineering R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 38 FIM H1 Link through the Project tab in Control Builder. The following figure shows how icons are used to readily identify CIOM-A FIM, H1 Links, and fieldbus devices in the Control Builder Project tab. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 39: Parameter Definition Editor Serves As Key Interoperability Tool
The Parameter Definition Editor (PDE) lets you edit the parameter attributes for a given function block associated with a fieldbus device block type residing in the Control Builder Library tab. The following figure shows a typical Parameter Definition Editor view. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 40: Parameter Definition Editor Supports Fieldbus Methods
Methods tab view for a device block that includes methods data. Methods are usually associated with a device's Transducer and/or Resource blocks. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 41: Station Provides Centralized Operator Interface
The existing access authorization levels apply and will take precedence over fieldbus restrictions specified in Device Descriptions. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 42: Control Integration
Configuring the communication stack; Loading the Link Schedule; Monitoring performance; and Monitoring fault detection. The collection of managed variables is called the Network Management Information Base (NMIB). Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 43: System Management Description
If the VCR configuration is successful, the FIM obtains VFD and resource identification from the device's VFD. During device download, you can overwrite VCR configuration used to access VFD parameters through the Control Builder application. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 44: Type Creation Makes Integration Possible
PID function block in a Control Module that is assigned and loaded to the CEE in the Control Processor Module (CPM). Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 45: Fieldbus Analog Input Data Manipulation
If the fieldbus status byte indicates "BAD", the value must be converted to Not a Number (NaN) for Control Builder representation. The fieldbus data quality of good, bad, and R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 46: Fieldbus Device Analog Output Or Pid Integration
Control Module that is assigned and loaded to the CEE in the Control Processor Module (CPM) is integrated with an Analog Output function block in a fieldbus compliant device. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 47: Figure 7 Integration Of Fieldbus Device Analog Output Signal With Control Builder Control Strategy
Control Module that is assigned and loaded to the CEE in the Control Processor Module (CPM) is integrated with a cascaded Proportional, Integral, Derivative function block in a fieldbus compliant device. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 48: Fieldbus Analog Output Or Pid Data Manipulation
Fieldbus Analog Output or PID data manipulation When the Output from the PID function block is wired to the CAS_IN input for a fieldbus Analog Output or Proportional, Integral, Derivative function block, the Control Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 49 Analog Output and Proportional, Integral, Derivative (PID) through their CAS_IN parameter input connection. This connection is generally used when the downstream control block is in the Cas (cascade) mode. This R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 50: Fieldbus Device Discrete Input Integration
Input function block in a fieldbus compliant transmitter is integrated with a Device Control (DEVCTL) function block in a Control Module that is assigned and loaded to the CEE in the Control Processor Module (CPM). Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 51: Fieldbus Discrete Input Data Manipulation
Device Control (DC) block. The value is converted and represented in Control Builder at the output. The discrete input agent accepts inputs from either a published parameter or a client/server read parameter, depending upon the communication method used. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 52: Fieldbus Device Discrete Output Data Integration
Control (DEVCTL) function block in a Control Module that is assigned and loaded to the CEE in the Control Processor Module (CPM) is integrated with a Discrete Output function block in a fieldbus compliant device. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 53: Fieldbus Discrete Output Data Manipulation
CEE output agent to handle the discrete output to the fieldbus block. The block-like output agent maps the Control Builder DO[n] with status parameter R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 54: Interface Connections Summary
A word about SCM parameter interaction Sequential Control Module (SCM) Steps and Transitions can write to any contained parameter of a fieldbus function block. The value of a contained parameter can be Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 55: Fieldbus Status Data Details
Data Quality (usability) Bad Data Cause Degraded Data Cause Limit Conditions Cascade Control Initialization, Rejection R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 56 Conversion ledged Block Selected Not Accurate Alarm (NS) No Comm- Engineering Unacknow- Do Not unication, Unit Range ledged Select with Last Violation Advisory (DNS) Usable Alarm Value Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 57: Fieldbus Status Indications
MODE_BLK parameter. This structured parameter consists of the Actual, Target, Permitted, and Normal modes. The eight possible modes are described in the About modes of operation paragraph in the Standard Function Blocks section of Appendix A. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 58 Engineer to put a block in Man, Auto, Cas, Rcas, or Normal, if the blocks current target mode is OOS. When a mode is changed, the FIM clears the Experion PKS Series A Fieldbus Interface Module User's Guide R400...
Page 59: Control Mode Priorities And Indications
Mode Mode Abbreviation Priority Interpretation 2-Char 4-Char Priority Control Dominance Order Order Order (8=highest) (8=highest) (6=Highest) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 60 Mode 0 (LSB) Remote Output (ROut) Remote Cascade (RCas) Cascade (Cas) Automatic (Auto) Manual (Man) Local Override (LO) Initialization Manual (IMan) 7 (MSB) Out of Service (OOS) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 61: Rotary Switch Model Versus Toggle Switch Model
Auto and Man bits, set the OOS bit, and optionally reset all the other bits. Reject the request, if the access level is not ENGR or higher. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 62: Display Indications And Mode Calculation
(t) In mode a; not satisfied in MAN (A), CAS (RC), IM (A), LO (CAS), higher target mode t. AUTO (M), CAS (M) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 63: Access Control Through Grant_Deny Parameter
Grant and Deny access permission to groups of function block parameters by other devices. The following table summarizes the attributes for the Grant and Deny elements of the parameter. Element and Bit Attribute Description R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 64: Link And Block Schedules
All links must have a Link Active Scheduler (LAS). The LAS operates at the data link layer as the bus arbiter for the link. It provides the following functions. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 65 LAS. They also act as LAS backups by monitoring the link for failure of the LAS, and by bidding to become the LAS when a LAS failure is detected. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 66: Link Schedule
Function block publications appear in the link data transfer schedule in the order specified by their ORDERINCM parameters. (Duplicate values of ORDERINCM may produce indeterminate ordering of those blocks involved.) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 67: Function Block Execution Schedule
The block algorithm execution phase is always executed in the following ordered sequence as shown in the following figure. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 68 250 millisecond period for a flow loop, a 1 second macrocycle can be downloaded to the device that contains functions blocks used in the 1 second and 250 ms CMs. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 69: Tags, Addresses, And Live List
The Data Link Layer specifies these default addresses as non-visitor node addresses. The following figure shows the general allocation of data link layer addresses to field devices. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 70: A Word About Fieldbus Address Assignments In Control Builder
A set bit at a particular bit number means that a device is present at that address. The LAS of the network owns the live list and maintains it as part of its operation. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 71: Notification Scheme
The fieldbus alarms will be closely integrated with the existing Experion notification system. The Experion Server will handle FIM alarms in the same way it handles Control R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 72 (power-up) BLOCK_ERR bit 15 (Out- of-Service) System Level Diagnostic (High) All other bitstring indications: (BLOCK_ERR bits 0-13, XD_ERROR bits 16-25) 2 (User selected) Journal High High High Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 73: Advanced Alarming
Experion system. The device alarms are associated with actual device conditions or processes within the block as indicated by BLOCK_ERR and XD_ERROR bitstring alarms. These alarms are reported as device or system alarms into the Experion R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 74 DV LO Deviation Low Alarm DEVLO DV HI Deviation High Alarm DEVHI DISC Standard Discrete Alarm OFFNORM DISC Standard Discrete Alarm CHNGOFST DISC DevCtl Fail Alarm FBDCFAIL Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 75 BLOCK_ERR: 10 (Lost Static Data) FFLSTDTA (Static Data Lost) BLOCK BLOCK_ERR: 11 (Lost NV Data) FFLNVDTA (Non-Vol Data Lost) BLOCK BLOCK_ERR: 12 (Readback Check Failed) FFRBCKFL (Readback Check Fail) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 76 TBSWERR (Software Error) BLOCK XD_ERROR: 25 (Algorithm Error) TBALGERR (Algorithm Error) UPDATE TB Static Data Update Event TBSTCHNG UPDATE FB Static Data Update Event FBSTCHNG (Static Revision) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 77: Loading Alarm Conditions
User defined conditions are configured to generate the system alarm. System Alarm: System alarms appear in the System Status Display. The alarm attributes are set as follows: Attribute Value Source Device tag R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 78: Ciom-A Fim Redundancy Functionality
CIOM-A FIM Redundancy Functionality About CIOM-A FIM redundancy If you have redundancy compliant hardware, you can implement redundant Series A FIM operation through a Redundant Chassis Pair (RCP). A RCP consists of two chassis that include identical redundancy compliant modules in matching slot positions within their given chassis.
Page 79: Ciom-A Fim Versus C200 Cpm Redundancy
The RCP does this by providing a pair of chassis, so a component failure in one chassis switches the handling of the assigned functions to the other chassis. This is R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 80: Switchover And Secondary Readiness
Secondary is aligned with the database in the Primary. The Secondary closely tracks database changes to maintain its synchronization with the database of the Primary. Otherwise, the Secondary will revert to a Disqualified state. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 81: Switchover Behavior Considerations
C200 controller. Substitute value functionality is bounded to a maximum of five seconds to account for worse case timing. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 82: Failure Conditions And Switchover
Secondary chassis/FIM loses synchronization. In addition to the failure conditions, these events are reported as diagnostic notifications: Loss of view of redundant partner on H1 network (applies to FIM link). Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 83: Fieldbus Network Switchover Considerations
The new Primary FIM does not publish any data on the network until all switchover actions are completed and it has good data from the Control Data Access (CDA) server. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 84: Switchover Versus Fieldbus Network Activities
Primary does not know anything about pending change tag or address operation. As a result, device whose address or tag is being changed will timeout and abort the operation. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 85 This way new Primary builds fresh (QUB) VCR connection context. QUB connections are point-to-point and therefore can only be opened from the primary. FIM maintains one Management Information Base R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 86: Switchover Events
The Type function in Control Builder only supports Block Instantiation in fieldbus devices with single Capability Levels. It does not support fieldbus devices with multiple Capability Levels. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 87: Instantiable Block Implementation Considerations
If you want Then, Notes and References to . . . R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 88 Project as shown in Adding a fieldbus device the following illustration. to Project for reference. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 89 Check Block Tag column to view assigned tag to see if block is used in a Control Module or not as shown in the following illustration. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 90 3. Fieldbus Integration With Experion System 3.8. Block Instantiation Support If you want Then, Notes and References to . . . Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 91 Central Processing In Resource Statistics grid, check Unit (CPU) or Memory. Limit and Used columns to view resource allocations against assigned limits. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 92 3. Fieldbus Integration With Experion System 3.8. Block Instantiation Support If you want Then, Notes and References to . . . Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 93 Project containing the desired number physical device only instantiable of function blocks as outlined in the occurs during a load. block in a next row. physical device. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 94 Blocks will be removed or de-instantiated. A physical device may go offline while its instantiable blocks are being instantiated through a device load. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 95 Load reconfigured CM. cc) Right-click device icon and select Upload from the shortcut menu. Click Continue to load device data into the Monitor database. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 96 Load Dialog. This means that the SCM will not be automatically loaded. In this case, you must inactivate the SCM and reload it as a separate procedure. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 97 3. Fieldbus Integration With Experion System 3.8. Block Instantiation Support If you want Then, Notes and References to . . . R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 98 3. Fieldbus Integration With Experion System 3.8. Block Instantiation Support Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 99: Installation
FIMs for system capacity calculations, so 50 pairs or 100 FIMs is still the total allowed per Server. Component Total Per Total Per Controller Server R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 100: Ciom-A Fim Only Chassis Configuration Considerations
CNI, RM and up to 6 FIMs (power limit) and a C200 Controller chassis will support a CNI, C200, RM and up to 4 FIMs. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 101: Fieldbus Component References
8 ft (2.5 m) TC-FFC025 16 ft (5 m) TC-FFC050 33 ft (10 m) TC-FFC100 Fieldbus Device Software support for these maximum Usage Licenses number of FIMs: TC-FFLI01 TC-FFLI02 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 102: Fieldbus Network References
9005 Mountain Ridge Voltage Mode, Wire power, and layout network Drive Medium Application Guide components Bowie Building - Suite 190 Austin, Texas 78759-5316 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 103: Fieldbus Wiring Selection And Calculation
Honeywell offers a tool called the Fieldbus Wiring Calculator to assist users in calculating the performance characteristics of a planned fieldbus segment. You only have to visit our website http://www.acs.honeywell.com/...
Page 104: Intrinsically Safe Applications
Installing CIOM-A Fieldbus Interface Module TC- FFIF01 Front View 4-Character 1 - 1 Display Link 1 LED Link 2 LED OK LED RTP Cable Connector Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 105: Inserting Module In Chassis
Position the module at the desired chassis slots location. For example, slots 1 and 2. (Remember that slot numbering is zero-based and the left most slot is number "0".) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 106 4.2. Installing CIOM-A Fieldbus Interface Module TC-FFIF01 Step Action Align the module's circuit board with the top and bottom chassis guides. Top chassis guide alignment Printed circuit board Bottom chassis guide alignment Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 107: Connecting Rtp Cable To Module
CIOM-A FIM is installed in an unpowered chassis. Step Action Be sure the cable is long enough to reach the DIN rail mounted RTP. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 108: Loading Fim Firmware
The procedure for loading the FIM's firmware is similar to the one used for loading the CPM's personality image. The boot and personality image files are fimboot.nvs and fimrex.nvs, respectively, and they are at this directory location: c:\Program Files\Honeywell\Experion PKS\Engineering Tools\system\firmware\FIM Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 109: 4.3. Installing Fieldbus Rtp Tc-Ffru01/Tc-Ffrp02 Or Rrtp Tc-Ffsu01/Tc-Ffsp02
Figure 16 RTP model TC-FFRU01 is unpowered and can be used in Division 2 hazardous locations; model TC-FFRP02 is powered and can be used to power fieldbus devices in Intrinsically Safe applications. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 110: Mounting On A Din Rail
Orient the RTP so the top of the unit is over the top of the DIN rail. Slightly rotate the RTP to slip its top mounting flange on the top of the DIN Experion PKS Series A Fieldbus Interface Module User's Guide R400...
Page 111: Mounting Dimensions
Go to the next procedure Wiring. Mounting Dimensions Inches Reference: Millimeters Hole Size: 0.156 3.96 0.425 10.8 142.2 4.75 4.10 120.7 104.2 SEGMENT #1 SEGMENT #2 0.225 152.4 Models TC-FFRU01 and TC-FFRP02 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 112: Wiring
ATTENTION The power requirement for the TC-FFRP02 is 24 Vdc at 270 mA. Use the following procedure to make wiring connections to the RTP. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 113 2 to terminal J10-1 + and the negative (-) lead to J10-2 -. Go to the next section Configuration to include the CIOM-A FIM and fieldbus devices in the configured control strategy. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 114: Figure 18 Simplified Wiring Schematic For Rtp Model Tc-Ffru01, Unpowered. Users Must Provide Conditioned 24 Vdc Power For The Links - Not Shown
Field Devices HHC = Handheld Communicator IMU = Integrated Medium Attached Unit (MAU) * The mating connector for J5 and J9 is Honeywell part number 51190691-102 or Wiedmuller part number 150186. Figure 18 Simplified wiring schematic for RTP model TC-FFRU01, unpowered.
Page 115: Figure 19 Simplified Wiring Schematic For Rrtp Model Tc-Ffxxxx, Unpowered. Users Must Provide Conditioned 24 Vdc Power For The Links - Not Shown
Field Devices HHC = Handheld Communicator IMU = Integrated Medium Attached Unit (MAU) * The mating connector for J5 and J9 is Honeywell part number 51190691-102 or Wiedmuller part number 150186. Figure 19 Simplified wiring schematic for RRTP model TC-FFXXXX, unpowered.
Page 116: Figure 20 Simplified Wiring Schematic For Rtp Model Tc-Ffrp02, Powered. Users Must Provide 24 Vdc Power Supply For The Gi/Is Power Supplies
IMU = Integrated Medium Attached Unit (MAU) Figure 20 Simplified wiring schematic for RTP model TC-FFRP02, powered. Users must provide 24 Vdc power supply for the GI/IS power supplies Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 117: Configuration
If you are new to fieldbus, we suggest that you seek at least some overview level training before trying to implement a fieldbus system. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 118: Are You Ready
Users are responsible for making sure that no alteration could occur from using a non-Experion interface, since Honeywell cannot guarantee that an alteration will not occur. Only highly trained individuals who completely understand Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 119: Free Vcr Recommendation
VCRs allowed, 64 per segment for Series A FIM, you will need to free a VCR before you can complete a device replacement on the given segment. Typically, you can free a VCR by deleting a Control Module or device from the Monitoring tab in Control Builder.
Page 120: Configuring Fieldbus Components In A Control Strategy
Experion control strategy loaded in a Control Process Module (CPM) and associated Control Execution Environment (CEE). This sample application and control strategy will be used for reference to illustrate the applicability of functions in the following procedures Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 121: Figure 21 Sample Application And Control Strategy Integrating Fieldbus Devices With An Experion System
ST3000FF smart pressure transmitter is being used to monitor the level in the surge tank. A fieldbus approved Logix 1400 valve positioner is being used to regulate the control valve in the process feed line. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 122: Configuration Considerations Only For Redundant Ciom-A Fim Applications
The recycle pump is to be restarted at 35 percent. Configuration considerations only for redundant CIOM-A FIM applications Observe the following considerations when configuring fieldbus devices with redundant CIOM-A FIM applications. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 123: Adding Ciom-A Fim Block To Project
5.4. Configuring Fieldbus Components In a Control Strategy ATTENTION If you use a version 4.02.02 or older Honeywell Fieldbus device or a version 2.02.02 or older FlowServe Fieldbus device as a backup Link Master node with redundant CIOM-A FIMs, we recommend that you assign the device to address 40 (decimal).
Page 124 Step Action Result Click File-> New->Interface Modules- Calls up the CIOM-A FIM block >FIM - Fieldbus Interface Module. parameters configuration form Main tab with Name field highlighted. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 125 ControlNet is the default selection. Press <Tab>. Communications Driver must be installed and running before it will appear as a selection in the dropdown menu for this field. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 126 Moves cursor to the Module Slot Number Click button to select the Slot field. number where the ControlNet Module connected to the Supervisory network is installed. Use 00 for this example. Press <Tab>. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 127 ControlNet Network module in the Supervisory chassis that is connected to the ControlNet Network module (Uplink) in the Remote I/O Chassis. Use 04 for this example. Press <Tab>. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 128 ControlNet Network module in the Remote I/O chassis that is connected to the ControlNet Network module (Downlink) in the Supervisory Chassis. Use 05 for this example. Press <Tab>. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 129 Key in the name of the Entity that this Moves cursor to the FIM Command field. object will be associated with in the Enterprise Model Builder hierarchy. Press <Tab>. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 130 Calls up the Server History Tab. this tab in the Monitoring tab of Control Builder, when the CIOM-A FIM/LINK is loaded and communicating with the system. Click the Server History Tab. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 131 Knowledge Builder document for reference. Have also skipped the Identification, Dependencies, and Template Defining tabs that are only valid with the Template license option. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 132 The second view is in a system with the Hierarchical Building license option set for Assignment View. These views are for example purposes only. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010 (Note that the system will generate an...
Page 133: Checking Link Configuration
Link Block Parameters configuration form. Calls up the Link Block Parameters Right-click the Link icon and select configuration form with the Name field Module Properties from the list. highlighted. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 134 Link number (1 or 2, plus the MAC ID and Slot number suffix used for the associated CIOM-A FIM. For the Links used in this procedure, the suggested names would be LINK10105 and LINK20105. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 135 Press <Tab>. Click the arrow button and select whether Calls up the System Management tab. Skew is enabled or not. Click the System Management tab. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 136 Please refer to Link Parameters Reference in Appendix I for a more detailed description of the user configurable LINK parameters in both the Project and Monitor modes. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 137 Timer (T3) field and highlights it. key in a new value. This is the preset value for the System Management set address sequence timer. The default value is 01:30. 0000s. Press <Tab>. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 138 Network Management (LM) tab. ATTENTION The remaining parameters on the System Management tab and the Network Management (Basic) tab are read only and provided for monitoring purposes only. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 139 The Uncommissioned Devices tab is for use in Monitoring mode with FIM/LINK communicating with devices. The Version tab is only valid with the Version Control System license option and is read only in the Project mode. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 140 Knowledge Builder document for reference. Have also skipped the Identification, Dependencies, and Template Defining tabs that are only valid with the Template license option. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 141: Creating A Fieldbus Device Type From Vendor Dd
Enhanced Device Description (EDD) files. This procedure assumes that Control Builder is running and you have appropriate access level to create a control strategy. You must have the Device Description (DD) files or Enhanced Device R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 142 DD file location in the Device DD Files box. In Device List box, click the device you want to add to the Control Builder Library. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 143 5. ATTENTION If the DD file template already exists, the following message appears. Click Save As to save the device with a different name for device R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 144 DD files with constructs are supported. ATTENTION You need Knowledge Builder version 4.2 or greater installed for device help information to be added to the Dynamic Help book in Knowledge Builder. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 145: Editing Device Block Parameters
View or edit parameters for the selected block in the Parameter Definition Editor. Refer to the Parameter Definition Editor Reference book for more information about using the Parameter Definition Editor. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 146: Adding A Fieldbus Device To Project
Once a device is assigned to a Link, it represents a matching physical device that is to reside on the given Link. Method 1: Drag and Drop Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 147 Calls up the Name New Function area in the project tab. (Note Block(s) dialog box. that cursor appears with + sign, when positioned in a valid location.) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 148 Repeat this procedure to add other devices or go to the next procedure Assigning a device to a Link in Project. Method 2: File Menu Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 149 Type function. The FLOWSERVE and LX1400FF selections are shown for example purposes only.) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 150 5.4. Configuring Fieldbus Components In a Control Strategy Step Action Result We suggest that you wait to check all block configuration parameters until after the device is assigned to a Link. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 151: Assigning A Device To A Link In Project
Assigning a device to a Link in Project Use the following procedure to assign a device to a Link associated with the applicable FIM in the Project tab. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 152 Click Edit->Execution Environment Calls up the Execution Environment Assignment. Or, click the assign button Assignments dialog box. This illustration is for example purposes only. in the toolbar. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 153 Select Link list box. Click the Assign button to assign the selected device to the selected Link. This illustration is for example purposes only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 154: Checking Device Configuration
Use the following procedure to check the configuration of a selected fieldbus device in the Project tab. This procedure assumes that the device has been assigned to a Link. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 155 Alarm Summary in Station. This is especially useful for diagnosing problems in devices with several transducer blocks, like temperature multiplexers. Step Action Result R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 156 5.4. Configuring Fieldbus Components In a Control Strategy Step Action Result Double-click the device icon in the Calls up the parameter configuration Project tab. dialog box with Tag Name (NAME) field highlighted. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 157 Key in the name of the Entity that this Moves cursor to the Description (DESC) object will be associated with in the field. Enterprise Model Builder hierarchy. Press <Tab>. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 158 Control Builder returns the area-enabled asset and not the original non-assignable asset entered.) Click the System Management tab. Calls up the System Management tab form. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 159 In most cases, the parameter values will mirror those configured for the Link. The grayed out parameters are only accessible in the Monitoring tab with the FIM/LINK communicating with the system. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 160 Network Management (LM) tab. ATTENTION The remaining parameters on the System Management tab and the Network Management (Basic) tab are read only and provided for monitoring purposes only. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 161 Click the Server History tab. ATTENTION The Version tab is only valid with the Version Control System license option and is read only in the Project mode. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 162 5. Configuration 5.4. Configuring Fieldbus Components In a Control Strategy Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 163 Repeat this procedure for another Return to Step 1. Device, as required. Go to the next section Creating a Control Module for sample PID loop. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 164: Making Fieldbus Block Template And Assigning Function Block To Device
Selects fieldbus Analog Input (AI) block sign for FIELDBUS, and click AI block in the FIELDBUS Library. icon. Click Templates->Make Template. Calls up AI Block configuration form. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 165 Click the OK button. Closes the AI Block configuration form and adds the configured AI block as a template under its assigned name in the USER Library. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 166 In Project view, select and double-click Opens the Control Module (CM) in the an instantiated Control Module chart. (User_1_1) that is to contain the AI_6 block template. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 167 Drag and drop the AI_6 block icon from Adds the AI_6 block to the CM. the USER Library to the open User_1_1 Control Module in the chart. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 168 Right-click the AI-6 block. Opens short cut menu. Click Function Block Assign. Opens Function Block Assignment Dialog that lists all compatible device blocks that have been assigned to a Link. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 169 Click the check box to select the desired dialog appears with warning device. Click the Assign button. message(s), Go to the next Step. Otherwise, Go to Step 11. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 170 5.4. Configuring Fieldbus Components In a Control Strategy ATTENTION When assigning a user template to a non-Honeywell fieldbus device, warning messages may be generated because of manufacturer specific parameters associated with the device. Be sure that default values for manufacturer specific parameters are applicable for your given application.
Page 171 5.4. Configuring Fieldbus Components In a Control Strategy Continuation from Step 9 or 10 The AI_6 block is assigned to the selected device as noted on the face of the block. . R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 172: Creating Control Module For Sample Pid Loop - Optional
Execution Environment (CEE) block to the Project tab. Also, the following fieldbus components have been created in the Project tab, using the previous procedures in this section. FIM named FIM0105 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 173 Creating Control Module in Project Step Action Result Opens System directory. In Library tab, click plus sign for System directory. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 174 Hierarchical Building option, right-click incremental number. the icon and select Instantiate in the menu. Click Edit-> Module Properties. Opens Control Module Block Parameters form with Name field highlighted. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 175 CM's that are assigned to a CEE. It has no affect on contained fieldbus blocks and it is disabled, if the CM is assigned to a Link. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 176 Accept the default value 1S. Press Moves cursor to the Stale Count field and <Tab>. highlights it. Accept the default value 2. Press <Tab>. Moves cursor to the OK button. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 177 This completes the CM creation. Go to the next procedure Adding blocks to CM for sample loop. Adding blocks to CM for sample loop Step Action Result R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 178 Action Result Expands the directories down to the In Project tab, click the plus sign for device block level. the FIM, the LINK10105, and the device ST101. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 179 Step Action Result Adds FF AI block to CM101 chart. Drag AI block to CM101 chart. Opens directory. In Library tab, click plus sign for DATAACQ directory. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 180 Step Action Result Adds DATAACQ block to CM101 chart. Drag DATAACQ block CM101 chart. Opens directory. In Library tab, click the plus sign for the REGCTL directory. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 181 5. Configuration 5.4. Configuring Fieldbus Components In a Control Strategy Step Action Result Adds PID block to CM101 chart. Drag PID block to CM101 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 182 Action Result Opens directory. In Project tab, click plus sign for device LX102. Adds FF AO block to CM101 chart. Drag the AO block to CM101 chart. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 183 Configuring AI block for sample loop Step Action Result In CM101 chart, double-click the AI Opens the AI Block Parameters form with block. Name (Name) field highlighted. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 184 Key in desired Block Tag Description Moves cursor to Mode/Normal selection. consisting of up to 32 characters. Press <Tab>. Accept default selection - AUTO. Press Moves cursor to the Grant/Program <Tab>. selection. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 185 Configuring DATAACQ block for sample loop Step Action Result In CM101 chart, double-click DATAACQ Opens DATAACQ Block Parameters block. form with Name field highlighted. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 186 For this example, we will accept the default values for the other parameters on the Main tab. These values are okay for the sample loop. Please feel free to practice entering data in the other fields, using the online Help for support. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 187 HIGH. Press <Tab>. Key in >8<. Press <Tab>. Moves cursor to PV Low Low field and highlights it. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 188 For this example, we will accept the default values for the other parameters on the Alarms tab. These values are okay for the sample loop. Please feel free to practice entering data in the other fields, using the online Help for support. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 189 Scroll the Parameters list box to Adds PVLLAM.FL as visible block output find PVLLALM.FL. Click it. pin. Check that the Pin Position is Output and Top/Bottom. Click the Add button. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 190 Check that the Pin Position is Output and Top/Bottom. Click the Add button. Click PV in Output - Bottom list box. Click Removes PV from list box. the Remove button. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 191 Configuring PID block for sample loop. Configuring PID block for sample loop Step Action Result In CM101 chart, double-click PIDA block. Opens PID Block Parameters form with Name field highlighted. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 192 Help for support. Moves cursor to Normal Mode Attribute Click button to open dropdown menu field and highlights it. and select AUTO. Press <Tab>. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 193 Moves cursor to Selected Control Action <Tab>. option. Click DIRECT to select it. Click the Set Opens the Set Point tab form with SP Point tab. field highlighted. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 194 Configuring AO block for sample loop Step Action Result In CM101 chart, double-click the AO Opens the AO Block Parameters form function block with Name field highlighted. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 195 Key in >AO_FLOW<. Press <Tab>. Moves cursor to Description field. Key in >Flow Control Output<. Click the Closes the Block Parameters form and OK button. stores the configuration entries. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 196 This completes the wiring of the blocks in CM101. Close the CM101 chart and click Yes to save changes. Go to the next procedure Adding parameter connections for sample loop interlocks. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 197: Figure 22 Completed Cm101 For Sample Loop
This procedure assumes that a CM named CM102 will be created for the pump control loop in the example application. The CM102 will include a standard Device Control R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 198: Figure 23 Sample Cm With Device Control Block For Pump Control In Sample Loop
Discrete I/O Channel blocks to start and stop the pump as shown in the following figure. Figure 23 Sample CM with Device Control block for pump control in sample loop. Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 199 Click button Scroll in the Point Names list box to find Populates the Parameters list box with CM101 DATAACQ_101. Click point. applicable parameters related to the point. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 200 Close Point Selector dialog box. This completes the addition of parameter connections for sample loop interlocks and the CM creation tutorial. Go to the next section Loading Components Online. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 201: Figure 24 Completed Cm102 With Parameter Connections For Sample Loop Interlocks
5. Configuration 5.4. Configuring Fieldbus Components In a Control Strategy Figure 24 Completed CM102 with parameter connections for sample loop interlocks. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 202: Loading Components Online
Control Builder configuration must match the actual addresses and locations of components in the system. The following illustration shows a simplified graphical representation of what happens during a load operation. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 203: Figure 25 Overview Of Load Operations Used To Initiate Components Online
Figure 25 Overview of load operations used to initiate components online. REFERENCE - INTERNAL Please refer to Load Interactions for Fieldbus Related Operations in Appendix J for more information. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 204: About Load Dialog Box
Select whether or not component is to be automatically put into selected Post Load State after the load Figure 26 Load Dialog box provides more load choices. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 205: Load Order Guidelines
Fieldbus Device IOM* CM or SCM* *Please refer to the Control Building Guide for more information about loading these components. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 206: General Load Considerations
SMK in a field device must go through and the associated services for each state before a device can fully function on the network. SMK State System Management Services Uninitialized SM_IDENTIFY SET_PD_TAG (Clear = False) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 207: Fieldbus Device Matching Rules
Initialized The device ID (DEV_ID) and physical device tag (PD_TAG) must match. If the desired address is not in use, FIM will assign it to the device. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 208: Loading A Ciom-A Fim And Its Links
(If ALIV appears in the CIOM-A FIM's left-hand LED on its front panel display. front panel display, you must load the CIOM-A FIM's personality firmware before proceeding.) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 209 5. Configuration 5.5. Loading Components Online Step Action Result Click the CIOM-A FIM block icon in the Opens the Load Dialog box. Project tab. Click Controller->Load. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 210 CIOM-A FIM listed in the Load? following illustration is for example column. purposes only. Click the OK button. When load is complete, click Monitoring Opens Monitoring tab. tab. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 211: Matching Uncommissioned Device To Project Device Or Vice Versa
If Link is inactive (blue icon), go to Step Link must be active to detect uncomminssioned devices on it. If Link is active (green icon), go to Step 6. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 212 5.5. Loading Components Online Step Action Result Click the Link 1 icon. Selects Link 1. Calls up the Change State dialog box. Click the toggle state button. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 213 On the Project tab,click Field Devices- Calls up Link Parameters form with >Device Match. Device Matching Dialog tab selected. The following illustration is for example purposes only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 214 Check for block type matches between Find device that matches block type and listed Uncommissioned Devices and fieldbus device configured in Project tab. Project Devices in the Template column. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 215 Device and Match from Project Device Project Device. to Uncommissioned Device buttons. The following illustration is for example purposes only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 216 (Note that the Warning prompt only appears, if the tag and/or address of the matching device need to be changed. Otherwise, see the result in Step 10.) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 217 The match operation was a success. The that Tag and Address assignments for following illustration is for example the selected Uncommissioned Device purposes only. and Project Device now match. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 218 Click the OK button. Closes the dialog. Go to the next section Loading Link contents or fieldbus device to download the Project Device to the Uncommissioned Device Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 219: Loading Link Contents Or Fieldbus Device
Control Module first, you may get an error message indicating that the "parent" block is not available. Step Action Result In Project tab, click the desired LINK Opens the Load Dialog box. icon. Click Controller->Load With Contents. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 220 If you just want to load a fieldbus device, click the device icon and click Controller- >Load. We suggest using LINK/Load With Contents so you can load more than one device at a time. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 221 Accept the default Partial Load selection Confirm Partial Load for Resource and for the Resource and Transducer blocks Transducer blocks that remain dedicated for a device. to the device. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 222 Click the OK button. Initiates "Load" and opens Load Dialog box to show load progress. This illustration is for example purposes only. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 223 LAS without a schedule. Please see the Checking/changing fieldbus device functional class section for details on reconfiguring a device as a Basic type. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 224 Repeat Steps 1 to 7 to load another Link or device, as required. This completes the LINK/fieldbus device load. Go to the next Section Operation for information on monitoring fieldbus devices. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 225: Configuring Advanced Alarming
You can define a maximum of 32 conditions per device and configure only five parameters per condition. For 32 conditions, parameter references must not exceed 36. You can configure only ten unique parameters per device template. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 226: Opening The Configuration Dialog Box
DD as it is Honeywell specific function. You can invoke the Configuration dialog box in view only mode from the device instance. For more information to open the Configuration dialog box, see Opening Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 227: Configuring/Creating A Condition
To configure a condition, perform the following steps. Step Action From the Configure Advanced Alarming dialog box, click Condition Listing tab. Click New. The Condition Configuration dialog box appears. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 228 An error message appears when you want to configure more than 32 conditions. Click OK to continue. The default values for Alarm Criticality and Priority are Failed and Urgent Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 229 A message appears displaying the information to clear all the configuration information selected for the condition. Click Yes to continue. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 230: Managing The Conditions
In such a case, the device instance value changes when the value is changed in the template. However, the engineer would be assuming that the value Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 231 Select the condition that you want to enable and select the check box under the Enable column. The selected condition is disabled and the changed setting is saved in the database. ATTENTION The conditions can be enabled/disabled in the Device R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 232: Assigning Criticalities And Priorities
Note: You cannot change the criticality assignments in this view. For example, when you select Maintenance criticality, the conditions which are assigned to the same criticalities, are listed. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 233: Editing An Existing Condition
Action From the Configure Advanced Alarming dialog box, click Condition Listing tab. Double-click a condition. Click a condition and Click Edit. The Condition Configuration dialog box appears. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 234: Block Offnet Diagnostic Alarm
This is accomplished with the introduction of a new parameter OFFNETALM_ENABLED. When this parameter is set to “True” and if the device is off Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 235: Behavior Of The Block Offnet And Device Offnet System Alarms In Various Communication Loss Scenarios
Alarms change from “Active” to changes from “Active” to “Returned FF Device and FIM “Returned to Normal” in the Alarm to Normal” in the System Alarm R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 236: Behavior Of The Block Offnet And Device Offnet System Alarms In Various Operational Scenarios
Fieldbus the alarms reported by Fieldbus function block. blocks. blocks. Changing the state Changing the state of a CEE Changing the state of a CEE Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 237 (The precondition is that the Block Offnet Diagnostic Alarm is configured not to be reported for the function block, when R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 238: Configuring Non-Cache Parameters
Therefore, you must configure non-cache parameters under special circumstances recommended by Honeywell, Inc. or device vendors. Step Action On the Project mode, right-click the device instance to select Module Properties. The configuration form appears. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 239 Select the required blocks and the related parameters that appear in the dialog box. Click OK. The selected parameter description appears in the corresponding Parameter Description column. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 240: Summary
The Control Builder for the Experion system lets you add and configure fieldbus components as a natural and intuitive extension to the existing Experion components. This promotes a seamless integration of the fieldbus functions with existing Experion capabilities. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 241 5. Configuration 5.9. Summary R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 243: Operation
The following figure shows a sample CIOM-A FIM Detail display for reference. The fieldbus Detail displays do feature convenient links to related fieldbus component displays for easy access to associated data. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 244: Foundation Fieldbus Detail Displays/Faceplates
FF parameters. The FF vendor-specific parameters are not displayed. This feature is applicable to the following Foundation Fieldbus control points. PID (Proportional Integral Derivative) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 245: Detail Displays Contents Based On Ff Control Points Loading
The following table lists the conventions to be followed to view the FF Detail Displays. Block name Point detail display Group detail display sysdtlffaia sysdtlffai_fp sysdtlffaoa sysdtlffao_fp sysdtlffdia sysdtlffdi_fp sysdtlffdoa sysdtlffdo_fp sysdtlffpida sysdtlffpid_fp R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 246: Tabs Of Ff Detail Displays
Device & Simulation State Alarm Summary Assigned Module IO/Status Options Tab This page contains the options that you can select for altering the Input and output block processing and the Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 247: Detail Displays Tabs Of The Different Foundation Fieldbus Blocks
The Detail Displays of the FF blocks do not display all the display tabs. Not all tabs appear for all FF blocks. Use the following table to determine the tabs that appear for each FF blocks. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 248 I/O status Option Set Point PV & OP The following figure displays a sample FF PID Main tab detail display when the point is loaded in CEE environment. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 249: Figure 28 Ff Pid Main Tab Detail Display When Loaded In Cee Environment
Figure 28 FF PID Main Tab Detail Display when loaded in CEE Environment. The following figure displays a sample FF PID Main tab Detail Display when the point is loaded to FFLINK. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 250: Common Functionalities Of Faceplates
Refer to the Server and Client Configuration Guide for more information on configuring faceplates. The following table lists the common functionalities and the applicable FF point faceplates. Functionality Applicable faceplate Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 251 Off Normal Mode Indication on faceplates systdlffao_fp.htm sysdtlffpid_fp.htm sysdtlffdi_fp.htm sysdtlffdo_fp.htm sysdtlmai_fp.htm sysdtlffai_fp.htm PV Alarm Limits sysdtlffpid_fp.htm sysdtlffpid_fp.htm READBACK Value sysdtlffao_fp.htm sysdtlffpid_fp.htm Auto selection sysdtlffao_fp.htm sysdtlffai_fp.htm sysdtlffmai_fp.htm sysdtlffdi_fp.htm sysdtlffdo_fp.htm R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 252: Ff Detail Displays Example Templates For Control Builder
FF Detail Displays example templates for Control Builder are installed as part of Experion installation. These examples are installed as part of Experion installation. These templates can be found in the following location: C:\Program Files\Honeywell\Experion PKS\Engineering Tools\Examples\ FF Blocks. These example templates are not supported for MAI block as it is not supported as a standard block in the Control Builder.
Page 253: Monitoring Fieldbus Functions Through Monitoring Tab
You can initiate this same function through the corresponding Detail display in Station. Step Action Result In Monitoring tab, click LINK icon. Opens Change State dialog box. Click the Toggle State button the toolbar. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 254 Initiates state change. The LINK icon changes from green to blue. This illustration is for example purposes only. The CIOM-A FIM is only inactivated when both Links are inactivated. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 255 Click the Yes button. Initiates state change. The icon changes from blue to green. This may take a few seconds. This illustration is for example purposes only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 256: Monitoring/Interacting With Given Component/Block
FIM and LINK function blocks must be active to view on-line data. The data can be viewed either by name or parameter reference by not checking or checking the Show Parameter Names checkbox at the bottom of each tab. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 257: Checking/Changing Fieldbus Device Functional Class
The illustrations used are for example purposes only and may differ from the actual forms that appear in your system. Step Action Result In Monitoring tab, double-click device Opens device configuration Parameters icon. form. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 258 6. Operation 6.3. Monitoring Fieldbus Functions Through Monitoring Tab Step Action Result Click Network Management (LM) tab. Opens Network Management (LM) tab. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 259 6. Operation 6.3. Monitoring Fieldbus Functions Through Monitoring Tab Step Action Result R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 260 The Point Picker dialog box appears. Select the required blocks and the related parameters appear in the dialog box. Click OK. The selected parameter description appears in the corresponding Parameter Description column. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 261 Click the Yes button to acknowledge the change. Click the OK button to close the Return to Control Builder application. Parameters form. Double-click the Resource block icon Calls up Resource Block Parameters form. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 262 6. Operation 6.3. Monitoring Fieldbus Functions Through Monitoring Tab Step Action Result Click the Other tab. Calls up the Other tab. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 263 6.3. Monitoring Fieldbus Functions Through Monitoring Tab Step Action Result Initiates online change value prompt. Click button in the User Restart field and select Restart processor from the list. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 264: Checking Live List And Interacting With Uncommissioned Devices
Link. Step Action Result Check the Link icon for the presence of An asterisk signals that an uncommissioned device has been added an asterisk to the link. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 265 Click the for the Link icon. illustration is for example purposes only. Double-click the uncommissioned device Opens the LINK Parameters form with the Uncommissioned Devices tab open. icon R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 266 Control Builder Library. It will be specified in the Template column. Address Range Device ID Template Vendor Model Name Device Rev DD Rev Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 267: Viewing And Optimizing Link Schedule Configuration
Or, you can configure the Link for the system to provide automatic schedule optimization as noted in the following procedure. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 268 See the following procedure to configure the FFLink for automatic schedule optimization. Calling up Link Schedule If You Are in the . . . Then, you can And, the Link Schedule Configuration shows. . . Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 269 Control Modules configured and assigned in Project and loaded to the LINK or CEE. See the Sample Link Schedule configuration display in Monitoring Figure that follows this table for reference. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 270: Figure 31 Sample Link Schedule Configuration Display In Project
6. Operation 6.3. Monitoring Fieldbus Functions Through Monitoring Tab Figure 31 Sample Link Schedule configuration display in Project. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 271: Figure 32 Sample Link Schedule Configuration Display In Monitoring
(not shown in figures above) along with their descriptions. Term Description Macrocycle Usage Measures percent reduction in used portion of macrocycle, start to end Gain (MUG) of last element. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 272 Refer to Parameters for Link Configuration in Project Mode for more information about the selections. Repeat Steps 2 to 4 for other Links, as applicable. Click the OK button to close the form and save the settings. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 273: Checkingciom-A Fim Redundancy Status And Initiating Manual Switchover
Redundancy Module configuration form in Monitoring mode the same as you would for a redundant Control Processor Module (CPM). The following illustration shows a typical Summary tab for a Redundancy Module as viewed in Monitoring mode for reference. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 274 6.3. Monitoring Fieldbus Functions Through Monitoring Tab REFERENCE - INTERNAL Please refer to the C200 Controller Redundancy Functionality in the Control Builder Component Theory for more information. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 275: Using Controller Menu Functions
Update, and Checkpoint functions. These functions are useful for correcting mismatches that may occur between the components and the database. Please refer to the Control Building Guide for details about a given menu function. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 276 6. Operation 6.3. Monitoring Fieldbus Functions Through Monitoring Tab Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 277: Fieldbus Device Commissioning
The following table outlines the functions you must consider before commissioning a device. For This Function. . . Consider This . . . R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 278 When the FIM first encounters a new uncommissioned device, it will clear its VCRs. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 279: Initial Checks And Operations
Funtion Completed Check and test all physical wire connections and verify correct voltage on H1 segment. References: Fieldbus wiring selection and calculation Load FIM block only. References: R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 280: Connecting Devices
Go to Stage 8 in the next section Connecting Devices Connecting Devices Stage Funtion Completed Connect the next device. References: Wiring Does device appear on link? NO > Go to Stage 10 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 281 NO > Go to Stage 17 YES > Go to Stage 18 Check the integrity of all cable connections, cables and verify the design of the link. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 282: Checking Device
NO > Go to Stage 24 Yes > Go to Stage 25 Upgrade firmware or import new DD file References: Replacing Device Template with a Different One Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 283: Checking Control Strategy
YES > Return to Stage 8 in previous section Connecting Devices. Checking Control Strategy Stage Funtion Completed Is control strategy configured? NO > Go to Stage 32 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 284: Flowchart Summary
This completes the commissioning process. The commissioning process is summarized in the following flowchart. Flowchart Summary The commissioning stages outlined above are summarized in the following flowchart. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 285 7. Fieldbus Device Commissioning 7.5. Flowchart Summary R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 286 7. Fieldbus Device Commissioning 7.5. Flowchart Summary Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 287: Maintenance, Checkout, And Calibration
If you are removing and/or replacing a fieldbus device, proceed with extreme caution. You may have to delete, restore, and/or create all hardware connections and the control R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 288: Guidelines For Adding Fieldbus Device To "Live"/Operating Link
Control Builder to match the device with its block type, and load the device from Project. Load the Control Strategy to CEE from Project. Activate the CEE and its CMs to put the CPM in its RUN mode. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 289: Using Optional Safe Handling Of New Devices
LAS and addresses. Using optional safe handling of new devices If you enable the safe handling option for the Series A FIM through its configuration form in Control Builder, the following actions are automatically initiated when you add a new device to a loaded Fieldbus link.
Page 290: Replacing A Failed Device With A Like Device Having The Same Model Name And Device Revision
The illustrations used are for example purposes only and may differ from the actual forms that appear in your system Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 291 8.1. Adding, Removing and Replacing Components Step Action Result Disconnect the failed device from the Fieldbus device icon turns red in Link. Monitoring tab. Right-click the failed device icon. Opens shortcut menu. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 292 Step Action Result Select Device Replacement. Calls up the LINK Block Parameters form with the failed device listed in the bottom half of the Device Replacement Dialog. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 293 If you did not disconnect the failed device in Step 1, the following message prompt appears instead of the Device Replacement Dialog telling you to do so before you can proceed. In this case, repeat Steps 2 and 3. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 294 Replacement Device. Uncommissioned Replacement Device" button becomes active. Click the "Replace the Failed Device with Warning prompt asks if you want to Uncommissioned Replacement Device" continue. button. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 295 Confirmation dialog to appear. Click the appears. It is normal for an error code Continue button. (Err xxxx) to appear in the Current State column for the blocks. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 296 Control Module and Sequential Control Module that include client/server connections to the blocks in the replacement device from the Monitor tab before putting the device into operation. See Instantiable block implementation considerations for more information. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 297: Replacing A Failed Device With A Different Device Using A Different Block Type
Starting with R400, you can generate an Unlike Device Replacement Report for an FF device. You can view the device-related information and the control Modules that would be affected by Unlike Device Replacement. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 298 Optionally, inactivate any CMs that CM icons are blue. contain blocks associated with the failed device. Disconnect the failed device from the Device icon turns red in Monitoring tab. Link. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 299 Action Result In Monitoring tab, locate all Control The associated fieldbus block icons will Modules (CMs) containing fieldbus be red. function blocks associated with the failed device. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 300 Click the Delete Selected object(s) Deletion errors are displayed in the list button. box for the dialog. You can ignore these, since you know the failed device is off net. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 301 Deletes Failed device from the Link folder button. in Monitoring. In Project tab, double-click the CM Opens CM in control chart. (pidloop) that was deleted from the Monitoring tab. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 302 Result It is a good idea to print out a parameters and connections report for a CM before you modify it. This will serve as a convenient configuration reference. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 303 RCAS_IN or ROUT_IN connection and re-wire it to the block's CAS_IN pin. Repeat Step 11 for other blocks, if required. Opens Save prompt. Click button. Click the Yes button. Closes chart and saves changes to CM. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 304 Opens the Delete Selected object(s) icon and select Delete from popup menu. dialog. Click the Delete Selected object(s) Device (ST101) is deleted from the LINK button. folder, for this example. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 305 In Library tab, drag and drop block type Opens Name New Function Block(s) for replacement device from applicable dialog. vendor directory to open area in Project tab. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 306 8. Maintenance, Checkout, and Calibration 8.1. Adding, Removing and Replacing Components Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 307 Destination column and click the Finish button. Calls up the Execution Environment Click the device icon and click the Assignment dialog box. assign button in the toolbar. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 308 With Devices tab open and device Assigns device (ST101) to LINK (ST101) selected, click the Assign button. (LINK10105), for this example. Click the Close button. Closes the dialog. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 309 Click Ok to close form. In Project tab, double-click CM (pidloop) Opens CM in control chart. that contains unassigned function block for failed device. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 310 Function Block Assign from popup Dialog. menu. Click the checkbox for Device Name Assigns block FFAI101 to new device ST101 and click the Assign button. ST101, for this example. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 311 Link. uncommissioned device (UCD) icon in the LINK folder in the Monitoring tab. Double-click the UCD icon. Calls up the LINK Block Parameters Uncommissioned Devices form. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 312 Click checkbox to left of Tag column for Selects project device and activates the matching Project Device (ST101). Match buttons. Always initiate match from Project Device to UCD for replacement devices. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 313 Project Device. Click the OK button. In Project tab, click LINK with new project Calls up the Load Dialog. device (ST101) and click Controller- >Load with Contents. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 314 Load With Contents dialog appears to components to be loaded include a track progress of the load. check mark. Click checkbox to add/remove component as applicable. Click the OK button. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 315 Wait for load to complete and check that UCD changes to commissioned device, in Monitoring tab. In Project tab, click CEE with Calls up Load Dialog. reconfigured CM and click Controller- >Load With Contents. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 316 Load With Contents dialog appears to components to be loaded include a track progress of the load. check mark. Click checkbox to add/remove component as applicable. Click the OK button. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 317: Unlike Device Replacement Report
With R400, Unlike Device Replacement (UDR) Report can be generated to view information about the device to be replaced and the control modules that are affected due to replacement of the failed device. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 318 Vendor Name VFDVENNAME parameter of Resource block Device Revision DEV_REV parameter of Resource block DD Revision DD_REV parameter of Resource block FF Link Name “Parent” of device Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 319 COLUMN CM Name “Container Module Name” CM Description (DESC “Description” parameter) “Device Function Block” Name of the device function block The controller name in which “Controller Name” R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 320: Replacing Device Template With A Different One
Prerequisites You have logged onto Control Builder with sufficient security level to make control strategy changes. You have created fieldbus device types. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 321: Considerations
All the illustrations used in the following procedure are for example purposes only. Step Action In the Project tab, select the fieldbus device you want to replace. Use CTRL R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 322 Or, just click the Select All button to move all the listed devices to the Selected Controls column. (Use the Remove or Remove All button to remove one selected or all devices from the Selected Controls column, as needed.) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 323 View and List View tabs below. In the Tree View or List View tab, select the replacement device. Click the Next button to call the Validation page. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 324 Check the check box in the Select column to select the device for replacement. All devices that passed validation are automatically selected, and those that failed cannot be selected. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 325 If error or warning messages appear in the Validation Results list box, click the View Replacement Log button to call up the FF_UTR_Log to review validation results. Click the Next button to call up the Replace Device page. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 326 (Click the Cancel button to exit the operation and start over after making any necessary corrections.) Check that the Status for each selected control turns to Replaced, when the function is completed. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 327 (4L.101.10110)], the last five digits (10110) represent the error code. Click the DONE button to close the wizard. If applicable, correct any errors and repeat the procedure. The completes the procedure, go to the next section. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 328: Correcting Some Common Utr Errors
Monitoring tab in Control Builder. CAUTION Do not upgrade firmware in Honeywell model ST3000 or model STT35F, or Flowserve Logic 1400 devices on a running fieldbus link. Be sure to take all Experion PKS Series A Fieldbus Interface Module User's Guide...
Page 329: R400 Experion Pks Series A Fieldbus Interface Module User's Guide July
This illustration is for example purposes only. If the Load Firmware button is inactive (grayed out), try changing the device address to a lower number in the 30 to 40 range. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 330 Opens the Device Firmware Upgrade dialog box. This illustration is for example purposes only. Click the Upgrade button. Opens the Open dialog box. This illustration is for example purposes only. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 331 Creating a Fieldbus device type from vendor DD in the previous Configuration section. This completes the firmware upgrade. Closes the LINK Parameters form. Click the OK button. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 332: Changing Or Clearing Tag And/Or Address Of Uncommissioned Device
Step Action Result Double-click the uncommissioned device Opens the LINK Parameters form with the Uncommissioned Devices tab open. icon This illustration is for example purposes only. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 333 Initiates change and opens progress tracking dialog box to show status of the change. Wait for change to complete. Press Moves cursor to the Address field. <Tab>. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 334: Using Fieldbus Device Simulate Function
The following procedure shows the general steps involved in using the simulate function with an Analog Input block in a Honeywell ST3000 transmitter. All the illustrations used in the procedure are for example purposes only. You can easily adapt this procedure to any applicable fieldbus device.
Page 335 Monitoring tab in Control Builder. In Monitoring tab, open the directory for Calls up the Block Parameters form. the fieldbus device icon and double click the Analog Input function block. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 336 8. Maintenance, Checkout, and Calibration 8.7. Using Fieldbus Device Simulate Function Step Action Result Click the Maintenance tab. Opens the Maintenance form. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 337 8. Maintenance, Checkout, and Calibration 8.7. Using Fieldbus Device Simulate Function Step Action Result R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 338 Press <Tab> four times. Moves cursor to Simulate En/Disable field. Opens Change Online Value Click the button and select Simulate confirmation dialog. Active. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 339 For this example, select Good from the Opens Change Online Value menu. confirmation dialog. Click Yes. Sets Simulate Status to Good. Press <Tab>. Moves cursor to the Simulate Value field. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 340 Therefore, you can configure this alarm before loading and it can be changed at runtime while the device is offline. You can silence the alarm and prevent the report generation. Click the OK button. Closes the Block Parameters form. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 341 8. Maintenance, Checkout, and Calibration 8.7. Using Fieldbus Device Simulate Function Step Action Result In Monitoring tab, double-click pidloop Opens pidloop control chart. icon, for this example only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 342 Close pidloop control chart. Double-click Calls up the Block Parameters form. the AI.FF block icon. On Maintenance tab, press <Tab> four Moves cursor to Simulate En/Disable times. field. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 343: Preparing Fieldbus Device For A Move Or Software Migration
Use the following procedure to prepare a device before migrating the system to a new software release or moving the device to another Link. All the illustrations used in the procedure are for example purposes only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 344 Displays the FIM menu tree. In the Monitoring mode, click symbol for FIM, LINK, and Device icons. Right-click the function block icon. Calls up the popup menu. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 345 Click the Yes button. Initiates the action. Check that the function block icon turns Blue. Double-click the function block icon. Calls up the Block Parameters configuration form. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 346 On the Process tab, check that the Actual Confirms that the block is in Out-Of- Mode has changed to OOS. Service (OOS) mode. Click the OK button. Closes Block Parameters form. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 347: Migrating Fieldbus Device Type To A Release Supporting Enable Block Offnet Diagnostic Alarm
Select Edit Type. In the Font box, type OFFNETALM_ENABLED. Select OK. Perform this procedure for each Fieldbus block if you want the parameter to appear in the configuration form. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 348: Interpreting Component Led Indications
In the midst of a firmware load sequence. Flashing Green/Off Initiating its startup or boot sequence. BOOT or Solid Green Flashing Green/Off in its ALIVE state and ready for its Personality ALIV Image load. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 349: 8.10 Fim Self-Test Diagnostic Codes
If FIM hangs on a test code during power up, cycle power to reboot the FIM. If error persists, replace the FIM. Test Code Target Device(s) Failure Modes Function T000 Signals start of the selftest. Display Diagnostics R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 350 T021 RAM, CPU Lower RAM Word Verifies that word patterns can be Access Test written and read back as bytes, half-words, words, misaligned words. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 351 RAM may still be valid. In the absence of parity errors, RAM is considered valid at boot level. It passes test, bumps R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 352 Verify that it runs faster than it would if the cache were broken or disabled. Flush/disable cache and verify that the data was written to RAM Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 353 . This means it is not modules asserted for longer than a to be determined period necessary to accommodate other modules' tests. T068 Stuck IRQ7 CPU, PLD Verifies that interrupt from R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 354 T109 ICP RAM Unique RAM, PLD, CPU, Verifies that each address can be Address Test buffers accessed uniquely. Runs with data parity enabled and fatal. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 355 ASIC Echo_REV test by : Locking the bus, Telling the ASIC to write a specified address, Looking at the address to see that it did not change, Unlocking the bus, and R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 356 RAM segment. T124 Upper RAM Parity FPGA, CPU, RAM Verifies that an odd and even RAM Test parity error can be generated and Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 357 Incomplete load of Application Image, Bad flash memory T255 End of POST Confirms that self test is Diagnostics successful and there is a valid Application Image stored in Flash. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 358: 8.11 Checking Fieldbus Device Calibration
Monitoring tab in Control Builder. The following illustrations show typical Tune and Other tabs for reference. Figure 34 Typical Tune tab for fieldbus device's Transducer block. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 359: 8.12 Using Fieldbus Methods Manager
Create the block type for a device from its manufacturer's DD files that include methods data using the Type command in Control Builder. Instantiate (create) and load the device block through Control Builder. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 360: Launching Methods Manager
Experion release. These methods will be grayed out and unavailable for execution. If Methods Manager Dialog . . . Then, You Are Prompted to . . . Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 361 While using the Fieldbus Methods Manager to execute a method, some methods may display messages that are very specific to a vendor. In this case, please consult the vendor's user/maintenance manual to verify/validate it. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 362 Wait for action to complete before continuing. Shows selection from a list. Select desired action by selecting an option and follow the instruction given in the Methods Manager dialog. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 363 . . . Requests user acknowledgement. Follow the instruction given in the Methods Manager dialog. Requests user action. Follow the instruction given in the Methods Manager dialog. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 364 Displays error message or code Note error and follow the instruction given in the Methods Manager dialog. Shows an abort message Wait until the abort sequence is completed. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 365: Experion Pks Host Registration
The capability to set or clear the physical device tag of Assignment an FF device. Convert Link Master to The capability to change FF devices from Link Master Basic Device to Basic class. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 366 Handling alert notifications and display or record the process alert notifications. Process Alert Management The capability to configure the report VCR for process Configuration alert notifications. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 367: Conditional Support For Ff Devices
To support Conditional evaluation, the Parameter Definition Editor (PDE) is enhanced in Control Builder. For more information, see Parameter Definition Editor Reference. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 368: Eddl
EDDL for the selected FF block. This tab appears only for those blocks that support EDDL technology. For more information, see Parameter Definition Editor Reference. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 369 On the FF blocks configuration form, DD View tab appears only if the imported DD files have the EDDL and visualization constructs like menus, charts and so on. On the DD View tab, parameters and its values appears. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 370 9. Experion PKS Host Registration 9.1. Overview Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 371 9. Experion PKS Host Registration 9.1. Overview R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 372 9. Experion PKS Host Registration 9.1. Overview Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 373: Following Are Some Of The Considerations For Ff Blocks With Dd View
Tool tip consists of information on parameter name, parameter description and unit if available. In Guage control, name of the guage control and value of the guage appears. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 374 To zoom out To zoom in To zoom and view at a fixed point To copy to clipboard To save the changes To print the page Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 375: Persistent Data Handling
For example: If a Device block refers to a File_TC_001 then this same file is referred in the Project and Monitoring view with the latest values available. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 376 9. Experion PKS Host Registration 9.1. Overview Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 377: 10.1 Fieldbus Technology
Communication Session Layer Stack Transport Layer Network Layer Data Link Layer Data Link Layer Physical Layer Physical Layer Physical Layer Figure 36 OSI versus Fieldbus communication model. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 378: Communication Layer Description
Identifies device types as Basic Device, Link Live List Master, or Bridge. A Link Master device type can become a Link Active Scheduler (LAS) for Link Active Scheduler the network. (LAS) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 379 Upload/Download, and Program Invocation. Uses a formal syntax description language called Abstract Syntax Notation 1 (ASN-1) to format FMS messages and applies special behavioral rules for certain types of objects. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 380 The four defined views are View 1 - Operation Dynamic, View 2 - Operation Static, View 3 - All Dynamic, and View 4 - Other Static. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 381: 10.2 Standard Function Blocks
NaN value that is to be passed outbound through the FIM will not be written and usually results in retention of R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 382 If the device would not behave in the application as you desire, you must add appropriate function blocks or logic to test for and replace the NaN with an acceptable value. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 383: Overview
Analog Input and Proportional/Integral/Derivative blocks can be used with a valve containing an Analog Output block to form a control loop, as shown in the following figure. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 384: About Modes Of Operation
Set Point is maintained at last value. Initialization Manual IMan The block output is being set in response to the back-calculation input parameter status. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 385 The block's normal algorithm uses this Set Point to determine the primary output value. The block maintains a remote- cascade out parameter to support R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 386: Analog Input Block
Analog Input block Transducer Filter Simulate Convert CHANNEL PV_FTIME SIMULATE L_TYPE LOW_CUT XD_SCALE OUT_SCALE Output FIELD_VAL Mode Alarms SHED_OPT HI/LO Figure 39 Functional schematic for Analog Input function block. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 387 Indirect : PV = (FIELD_VAL / 100) x (EU@100% - EU@0%) + EU@0% [OUT_SCALE] Ind Sqr Root: PV = sqrt(FIELD_VAL / 100) x (EU@100% - EU@0%) + EU@0% [OUT_SCALE] R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 388: Analog Output Block
RCAS_OUT Output Setpoint Out Convert CAS_IN PV_SCALE SP_RATE_DN SP_RATE_UP XD_SCALE RCAS_IN SP_HI_LIM SP_LO_LIM Simulate CHANNEL SIMULATE Mode PV Convert Fault State XD_SCALE SHED_OPT FSTATE_TIME PV_SCALE FSTATE_VAL READBACK Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 389: Figure 40 Functional Schematic For Analog Output Function Block
The SIMULATE parameter is for testing purposes only and always initializes in the disabled state. Temp = (SP - EU@0%) / (EU@100% - EU@0%) Equation Options [PV_SCALE] R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 390: Bias/Gain Block
ST_REV IO_OPTS STATUS_OPTS MODE_BLK STRATEGY TAG_DESC UPDATE_EVT PV_SCALE XD_SCALE RCAS_IN Reference Refer to Standard Function Block Parameters in Appendix B for definitions of each parameter. Bias/Gain block Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 391: Figure 41 Functional Schematic For Bias/Gain Function Block
(IMan) Local Override (LO), Manual (Man), Automatic (Auto), Cascade (Cas), and Remote Cascade (RCas) modes. The output supports the track algorithm. The Balance Ramp option is supported. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 392 If the status of TRK_VAL is Bad, the last usable value will be used. If there is no last usable value, the present value of the OUT will be used. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 393: Control Selector Block
TAG_DESC MODE_BLK TRK_IN_D TRK_SCALE OUT_HI_LIM TRK_VAL OUT_LO_LIM UPDATE_EVT OUT_SCALE Reference Refer to Standard Function Block Parameters in Appendix B for definitions of each parameter. Control Selector block R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 394: Figure 42 Functional Schematic For Control Selector Function Block
If an input has a sub-status of Do Not Select, it will not be selected. Three separate back calculation outputs (BKCAL_SEL_1, 2, 3) are available - one for each Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 395 When the mode is Manual, no input is selected. All three back calculation outputs will have a Not Invited status and Constant limits, with a value equal to OUT. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 396: Discrete Input Block
Figure 43 Functional schematic for Discrete Input function block. Description The Discrete Input function block takes the discrete input data from a selected Transducer block channel and Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 397: Discrete Output Block
DISC_LIM STRATEGY DISC_PRI TAG_DESC FIELD_VAL_D UPDATE_EVT GRANT_DENY XD_STATE IO_OPTS Reference Refer to Standard Function Block Parameters in Appendix B for definitions of each parameter. Discrete Output block R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 398: Figure 44 Functional Schematic For Discrete Output Function Block
The Discrete Output function block converts the value in SP_D to something useful for the hardware linked to the CHANNEL selection. A functional schematic of the block is shown in the previous illustration for reference. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 399 ST_REV FSTATE_VAL_D STATUS_OPTS GRANT_DENY STRATEGY IO_OPTS TAG_DESC MODE_BLK UPDATE_EVT OUT_D XD_STATE PV_D Reference Refer to Standard Function Block Parameters in Appendix B for definitions of each parameter. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 400: Manual Loader Block
An operator can set its output in the Manual mode or a program in the Remote-Out mode. A functional schematic of the block is shown in the previous illustration for reference. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 401 If the status of TRK_VAL is Bad, the last usable value will be used. If there is no last usable value, the present value of the OUT will be used. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 402: Proportional/Derivative Block
TAG_DESC TRK_IN_D LO_ALM TRK_SCALE LO_LIM TRK_VAL LO_LO_ALM UPDATE_EVT LO_LO_LIM LO_PRI Reference Refer to Standard Function Block Parameters in Appendix B for definitions of each parameter. Proportional/Derivative block Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 403: Figure 46 Functional Schematic For Proportional/Derivative Function Block
Control SP_LO_LIM GAIN BIAS Status BAL_TIME BKCAL_HYS RATE Filter PV_FTIME Alarm HI/LO Output Track Mode TRK_SCALE SHED_OPT TRK_IN_D TRK_VAL Figure 46 Functional schematic for Proportional/Derivative function block. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 404 GAIN and RATE is used for the Derivative term. Some controllers use the inverse values of Proportional Band and repeats per minutes for their tuning constants. Users can choose which tuning constants they want to display. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 405 TRK_IN_D is true, the converted TRK_VAL replaces the output (OUT), when the block is in Automatic (Auto), Cascade (Cas), Remote Cascade (RCas), or Remote-Out (ROut) mode. The CONTROL_OPTS R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 406 CONTROL_OPTS to use SP value after limiting in Cas or RCas mode. Use the Use PV for BKCAL_OUT CONTROL_OPTS to the PV value for the BKCAL_OUT value. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 407 TAG_DESC HI_HI_LIM TRK_IN_D HI_HI_PRI TRK_SCALE HI_LIM TRK_VAL HI_PRI UPDATE_EVT LO_ALM Reference Refer to Standard Function Block Parameters in Appendix B for definitions of each parameter. Proportional/Integral/Derivative block R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 408: Figure 47 Functional Schematic For Proportional/Integral/Derivative Function Block
Control SP_LO_LIM GAIN RESET Status BAL_TIME BKCAL_HYS RATE Filter PV_FTIME Alarm HI/LO Output Track Mode TRK_SCALE SHED_OPT TRK_IN_D TRK_VAL Figure 47 Functional schematic for Proportional/Integral/Derivative function block. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 409 GAIN, RESET is used for the Integral term, and RATE is used for the Derivative term. Both RESET and RATE are time constants expressed in seconds. Some controllers use the inverse values of Proportional Band R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 410 If the status of TRK_IN_D is Bad, its last usable value will be maintained and acted upon. If the device restarts, losing the last usable value, it will be set to false. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 411 SHED_OPT DV_LO_PRI FF_GAIN SP_HI_LIM FF_SCALE SP_LO_LIM FF_VAL SP_RATE_DN GAIN SP_RATE_UP GRANT_DENY ST_REV HI_ALM STATUS_OPTS HI_HI_ALM STRATEGY HI_HI_LIM TAG_DESC HI_HI_PRI TRK_IN_D HI_LIM TRK_SCALE HI_PRI TRK_VAL UPDATE_EVT LO_ALM LO_LIM R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 412: Ratio Block
SP_HI_LIM SP_LO_LIM Calc PV Filter GAIN IN_1 RA_FTIME Filter Alarm PV_FTIME HI/LO Output Track TRK_SCALE Mode SHED_OPT TRK_IN_D TRK_VAL Figure 48 Functional schematic for Ratio function block. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 413 NI or IR at BKCAL_IN adjusts the SP to balance the output to the value of BKCAL_IN. The IA status is sent as soon as IR is detected. The R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 414 CONTROL_OPTS to use SP value after limiting in Cas or RCas mode. Use the "Use PV for BKCAL_OUT" CONTROL_OPTS to the PV value for the BKCAL_OUT value. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 415 HI_HI_PRI STRATEGY HI_LIM TAG_DESC HI_PRI TRK_IN_D TRK_SCALE IN_1 TRK_VAL LO_ALM UPDATE_EVT LO_LIM Reference Refer to Standard Function Block Parameters in Appendix B for definitions of each parameter. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 416: 10.3 Device Descriptions And Block Parameters
The Fieldbus Foundation defines a four-level infrastructure for Device Descriptions for the sake of consistency. See the following illustration for a graphical representation of the DD infrastructure. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 417: Block Parameter Definitions
Function Block and Transducer Block parameters. These added parameters will be included in the DD supplied by the manufacturer. Block parameter definitions R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 418: 10.4 Fieldbus Foundation Documents
31.25 kbit/s Intrinsically Safe Systems Application Guide AG-180 Fieldbus Installation and Planning Guide FD-043 Technical Overview Final Specifications Please contact the Fieldbus Foundation for information about availability of current specifications. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 419: Standard Function Block Parameters
FF Data Type Float Range 0 to 50 percent of PV span Usage C/Contained Length Valid Views VIEW_4 Storage Static Remarks Initial value is 0.5 percent ALARM_SUM R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 420: Alert_Key
FF Data Type Unsigned 8 Range 1 to 255 Usage C/Alert Key Length Valid Views VIEW_4 Storage Static Remarks Initial value is 0 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 421: Bal_Time
Normally, the operator has permission to write these values, but PROGRAM or LOCAL remove the permission and grant it to a supervisory computer or a local control panel. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 422: Bkcal_Hys
The data type consists of the value and status of floating point parameters that are Inputs or Outputs. It uses the following two elements. 1 Status 2 Value Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 423: Bkcal_Out
FF Data Type DS-66 Range Usage O/Back Calculation Output Length Valid Views VIEW_3 Storage Dynamic R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 424: Bkcal_Sel_1
The selector output value and status associated with SEL_2 input that is provided to BKCAL_IN of the block connected to SEL_2 to prevent reset windup. FF Data Type DS-65 Range Usage O/Back Calculation Output Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 425: Bkcal_Sel_3
1 Status 2 Value BLOCK_ALM Classification Record Description The block alarm is used for all configuration, hardware, connection failure, or system problems in the block. The R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 426: Block_Err
It is a bit string that can show multiple errors. FF Data Type Bit String Range Usage C/Block Error Length Valid Views VIEW_1, VIEW_3 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 427: Block_Err.disabled
When the disable is removed for an active block error, the Alarm Display or System Status Display displays the alarm as active and Event Summary receives the event for that particular alarm. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 428: Bypass
11. Appendix B 11.1. Standard Function Block Parameters This is not a Fieldbus block parameter. It is a Honeywell parameter, which is stored internally on the FIM but appears to reside on the Fieldbus block template. BYPASS Classification Simple Variable Description Provides the means to bypass the normal control algorithm.
Page 429: Cas_In_D
The number of the logical hardware channel that is connected to this I/O block. It defines the transducer used to connect to the physical world. FF Data Type Unsigned 16 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 430: Clr_Fstate
The operator can control PROGRAM or LOCAL access to these values. CONFIRM_TIME Classification Simple Variable Description Defines the time between retries of alert reports. FF Data Type Unsigned 32 Range Positive Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 431: Control_Opts
Table 2 CONTROL_OPTS Bit Selections Meaning Function Block Bypass Enable (LSB) SP-PV Track in Man SP-PV Track in ROut SP-PV Track in LO or IMan SP Track retained target R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 432: Cycle_Sel
FF Data Type Bit String Range Usage C/Contained Length Valid Views VIEW_2 Storage Static Remarks Changing this parameter may be fatal to communication. CYCLE_TYPE Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 433: Dev_Rev
Static Remarks Read Only DEV_TYPE Classification Simple Variable Description Identifies the manufacturer's model number associated with the resource. An interface device uses it to locate the DD R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 434: Dd_Resource
Identifies the revision of the Device Description associated with the resource so an interface device can locate the DD file for the resource. FF Data Type Unsigned 8 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 435: Disc_Alm
The data type consists of data that describes discrete alarms. It uses the following five elements. 1 Unacknowledged 2 Alarm State 3 Time Stamp 4 Subcode 5 Value DISC_LIM R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 436: Disc_Pri
Valid Views VIEW_4 Storage Static Remarks DV_HI_ALM Classification Record Description Identifies the status and time stamp associated with the high deviation alarm. FF Data Type DS-71 Range Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 437: Dv_Hi_Lim
FF Data Type Float Range 0 to PV Span, + infinity Usage C/Contained Length Valid Views VIEW_4 Storage Static Remarks Initial value is + infinity DV_HI_PRI Classification Simple Variable R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 438: Dv_Lo_Alm
The Data type consists of data that describes floating point alarms. It uses the following five elements. 1 Unacknowledged 2 Alarm State 3 Time Stamp 4 Subcode 5 Value Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 439: Dv_Lo_Lim
Condition set by loss of communication to an output block, failure promoted to an output block or a physical contact. When the fault state action is active, the output function R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 440: Features
Valid Views VIEW_4 Storage Static Remarks Read Only FEATURE_SEL Classification Simple Variable Description Bit string that identifies the selected resource block options. FF Data Type Bit String Range Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 441: Ff_Gain
Defines the feed-forward input high and low scale values, engineering units code, and number of digits to the right of the decimal. FF Data Type DS-68 Range 0-100 percent Usage C/Scaling Length Valid Views VIEW_4 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 442: Ff_Val
The Data type consists of the value and status of floating point parameters that are Inputs or Outputs. It uses the following two elements. 1 Status 2 Value FIELD_VAL Classification Record Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 443: Field_Val_D
FF Data Type DS-66 Range Usage C/Contained Length Valid Views VIEW_1, VIEW_3 Storage Dynamic Remarks Read Only The data type consists of the value and status of discrete R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 444: Free_Space
Identifies the percent of block processing time that is free to process additional blocks. FF Data Type Float Range 0 - 100 percent Usage C/Contained Length Valid Views VIEW_1, VIEW_3 Storage Dynamic Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 445: Fstate_Time
Value is ignored, if the IO_OPTS Fault state to value option is false. FF Data Type Float Range PV_SCALE +/- 10 percent Usage C/Contained Length Valid Views VIEW_4 Storage Static Remarks R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 446: Fstate_Val_D
Classification Simple Variable Description Represents dimensionless gain used by several different algorithms. FF Data Type Float Range Usage C/Contained Length Valid Views VIEW_4 Storage Static Remarks GRANT_DENY Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 447: Hard_Types
Identifies types of hardware that are available as channel numbers on this resource. FF Data Type Bit String Range Set by manufacturer Usage C/Contained Length Valid Views VIEW_4 Storage Static Remarks Read Only HI_ALM R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 448: Hi_Hi_Alm
Classification Record Description Identifies the status and time stamp associated with the high high alarm. FF Data Type DS-71 Range Usage C/Alarm Length Valid Views Storage Dynamic Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 449: Hi_Hi_Lim
Initial value is + infinity HI_HI_PRI Classification Simple Variable Description Defines priority of the high high alarm. FF Data Type Unsigned 8 Range 0 to 63 Usage C/Alert Priority R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 450: Hi_Lim
Defines priority of the high alarm. FF Data Type Unsigned 8 Range 0 to 63 Usage C/Alert Priority Length Valid Views VIEW_4 Storage Static Remarks Initial value is 0 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 451: Io_Opts
SP Track retained target Increase to close Fault state to value Use Fault state value to restart Target to Man if fault state activated Use PV for BKCAL_OUT Low Cutoff R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 452: In_1
Inputs or Outputs. It uses the following two elements. 1 Status 2 Value IN_1 Classification Record Description Represents the auxiliary input value to the block. It is used Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 453: Lim_Notify
FF Data Type Unsigned 8 Range 0 to MAX_NOTIFY Usage C/Contained Length Valid Views VIEW_2 Storage Static Remarks Initial value is MAX_NOTIFY L_TYPE Classification Simple Variable R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 454: Lo_Alm
Classification Record Description Represents the status of the low alarm and its associated time stamp. FF Data Type DS-71 Range Usage C/Alarm Length Valid Views Storage Dynamic Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 455: Lo_Lim
Initial value is - Infinity LO_LO_ALM Classification Record Description Represents the status of the low low alarm and its associated time stamp. FF Data Type DS-71 Range Usage C/Alarm R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 456: Lo_Lo_Lim
Usage C/Contained Length Valid Views VIEW_4 Storage Static Remarks Initial value is - Infinity LO_LO_PRI Classification Simple Variable Description Represents the priority of the low low alarm. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 457: Lo_Pri
IO_OPTS. If the calculated PV falls below this limit, the PV value is set to zero (0). FF Data Type Float Range Positive R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 458: Manufac_Id
Read Only MAX_NOTIFY Classification Simple Variable Description Defines the maximum number of unconfirmed notify messages possible. FF Data Type Unsigned 8 Range Set by manufacturer Usage C/Contained Length Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 459: Memory_Size
Defines the time duration of the shortest cycle interval that the resource can support. FF Data Type Unsigned 32 Range Set by manufacturer Usage C/Contained Length Valid Views VIEW_4 Storage Static Remarks Read Only R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 460: Mode_Blk
4 Normal NV_CYCLE_T Classification Simple Variable Description Defines interval between writing copies of Non-Volatile (NV) parameters to NV memory. Zero means never. FF Data Type Unsigned 32 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 461: Offnetalm_Enabled
Device Offnet Process Alarm Length Valid Views Storage Dynamic Remarks This is not a Fieldbus block parameter. It is a Honeywell parameter, which is stored internally on the FIM but appears to reside on the Fieldbus block template. Classification Record Description Represents the primary analog value calculated as a result of executing the function.
Page 462: Out_D
The data type consists of the value and status of discrete value parameters. It uses the following two elements. 1 Status 2 Value Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 463: Out_Hi_Lim
CONTROL_OPTS selection No Out limits in Manual is chosen. FF Data Type Float Range OUT_SCALE +/- 10 percent Usage C/Contained Length Valid Views VIEW_2 Storage Static Remarks Initial value is 0. OUT_SCALE R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 464: Out_State
Represents the index to the text describing the states of a discrete output. FF Data Type Unsigned 16 Range Usage C/Contained Length Valid Views VIEW_2 Storage Static Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 465: Pv_D
It may also be calculated from the READBACK_D value of a Discrete Output block. FF Data Type DS-66 Range Usage C/Process Variable R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 466: Pv_Ftime
PV parameter and parameters that have the same scaling as PV. FF Data Type DS-68 Range Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 467: Pv_State
Valid Views VIEW_2 Storage Static Remarks RA_FTIME Classification Simple Variable Description Defines the time constant of a single exponential filter for the value to be ratioed in seconds. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 468: Rate
Represents target set point and status provided by a supervisory host to the analog control or output block. FF Data Type DS-65 Range Usage C/Remote-Cascade In Length Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 469: Rcas_In_D
Represents block set point and status after ramping. It serves as input to a supervisory host for back calculation that allows action to be taken under limiting conditions or mode change. FF Data Type DS-65 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 470: Rcas_Out_D
Dynamic Remarks Read Only The data type consists of the value and status of discrete value parameters. It uses the following two elements. 1 Status 2 Value Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 471: Readback
Represents the "readback" of the actual discrete valve or other actuator position in the transducer state. FF Data Type DS-66 Range Usage C/Contained Length Valid Views VIEW_1, VIEW_3 Storage Dynamic R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 472: Reset
Allows a manual restart to be initiated. The following degrees of restart are possible. 1: Run 2: Restart Resource 3: Restart with Defaults 4: Restart Processor FF Data Type Unsigned 8 Range 1: Run Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 473: Rout_In
The data type consists of the value and status of floating point parameters that are Inputs or Outputs. It uses the following two elements. 1 Status 2 Value R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 474: Rout_Out
Defines the state of the function block application state machine. FF Data Type Unsigned 8 Range 1: Start/Restart 2: Initialization 3: On-Line Linking 4: On-Line 5: Standby Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 475: Sel_1
Inputs or Outputs. It uses the following two elements. 1 Status 2 Value SEL_2 Classification Record Description Represents second input value to the selector. FF Data Type DS-65 R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 476: Sel_3
The data type consists of the value and status of floating point parameters that are Inputs or Outputs. It uses the following two elements. 1 Status 2 Value Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 477: Sel_Type
FF Data Type Unsigned 8 Range 1: Off 2: Set Usage C/Contained Length Valid Views Storage Dynamic Remarks The operator can control PROGRAM or LOCAL access to this value. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 478: Shed_Opt
Note 3: Target mode changes to Auto on detection of a shed condition. Note 4: Target mode changes to Man on detection of a shed condition. SHED_RCAS Classification Simple Variable Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 479: Shed_Rout
Allows the transducer analog input or output to the block to be manually supplied, when SIMULATE is enabled. When SIMULATE is disabled, the simulate value and status track the actual value and status. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 480: Simulate_D
DS-83 Range Usage C/Simulate Length Valid Views Storage Dynamic Remarks The data type consists of a simulate and transducer discrete value and status and a simulate enable/disable Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 481 The data type consists of the value and status of floating point parameters that are Inputs or Outputs. It uses the following two elements. 1 Status 2 Value R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 482: Sp_D
2 Value SP_HI_LIM Classification Simple Variable Description Defines the high limit for set point entry. FF Data Type Float Range PV_SCALE +/- 10 percent Usage C/Contained Length Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 483: Sp_Lo_Lim
VIEW_4 Storage Static Remarks If the ramp rate is set to zero or the block is not in Auto mode, the set point change is invoked immediately. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 484: Sp_Rate-Up
FF Data Type Unsigned 16 Range Usage C/Static Revision Length Valid Views VIEW_1, VIEW_2, VIEW_3, VIEW_4 Storage Static Remarks Read Only STATUS_OPTS Classification Simple Variable Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 485: Table 4 Status_Opts Bit Selections
Propagate Failure Forward Propagate Failure Backward Target to Manual if BAD IN Uncertain if Limited BAD if Limited Uncertain if Man Mode Do not select if not R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 486: Strategy
Usage C/Strategy Length Valid Views VIEW_4 Storage Static Remarks TAG_DESC Classification Simple Variable Description Serves as user defined description of the block. FF Data Type Octet String Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 487: Test_Rw
4 Value 4 (Integer 32) 5 Value 5 (Unsigned 8) 6 Value 6 (Unsigned 16) 7 Value 7 (Unsigned 32) 8 Value 8 (Floating Point) 9 Value 9 (Visible String) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 488: Trk_In_D
Defines the high and low scale values, engineering units code, and number of digits to the right of the decimal point associated with TRK_VAL. FF Data Type DS-68 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 489: Trk_Val
The data type consists of the value and status of floating point parameters that are Inputs or Outputs. It uses the following two elements. 1 Status 2 Value R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 490: Update_Evt
WRITE_ALM Classification Record Description Represents alert that is generated if the write lock is cleared. FF Data Type DS-72 Range Usage C/Alarm Length 1, 3 Valid Views Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 491: Write_Lock
Unsigned 8 Range 1: Unlocked 2: Locked Usage C/Contained Length Valid Views VIEW_2 Storage Static Remarks The operator can control PROGRAM and LOCAL access to this value. WRITE_PRI R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 492: Xd_Scale
The Data type consists of data that describes floating point values for display purposes. It uses the following four elements. 1 Engineering Units at 100 percent 2 Engineering Units at 0 percent Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 493: Xd_State
Represents index to the text describing the states of a discrete for the value obtained from the Transducer. FF Data Type Unsigned 16 Range Usage C/Contained Length Valid Views VIEW_2 Storage Static Remarks R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 494 11. Appendix B 11.1. Standard Function Block Parameters Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 495: Appendix C
No Limits Bad,DevFail Device Failure Low Limit Bad,DevFail,L Device Failure High Limit Bad,DevFail,H Device Failure Constant Bad,DevFail,C Sensor Failure No Limits Bad,SensFail Sensor Failure Low Limit Bad,SnFail,L R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 496 Constant Bad,OutSvc,C UNCERTAIN Non-Specific No Limits Uncertain UNCERTAIN Non-Specific Low Limit Uncertain,L UNCERTAIN Non-Specific High Limit Uncertain,H UNCERTAIN Non-Specific Constant Uncertain,C UNCERTAIN Last Usable No Limits Unc,LastOK Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 497 Unc,NotAcc,H Conversion Not Accurate UNCERTAIN Sensor Constant Unc,NotAcc,C Conversion Not Accurate UNCERTAIN Engineering No Limits Unc,Range Unit Range Violation UNCERTAIN Engineering Low Limit Unc,Range,L Unit Range Violation R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 498 Alarm GOOD (Non- Active Block Constant Alarm-Blck,C Cascade) Alarm GOOD (Non- Active Advisory No Limits Alarm-Advis Cascade) Alarm GOOD (Non- Active Advisory Low Limit Alarm-Advis,L Cascade) Alarm Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 499 Unacknow- Constant Alm-U-Blck,C Cascade) ledged Block Alarm GOOD (Non- Unacknow- No Limits Alm-U-Advis Cascade) ledged Advisory Alarm GOOD (Non- Unacknow- Low Limit Alm-U-Advs,L Cascade) ledged Advisory Alarm R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 500 Non-Specific High Limit High Limit (Cascade) GOOD Non-Specific Constant Constant (Cascade) GOOD Acknowledge No Limit InitAck (Cascade) Initialization (IA) GOOD Acknowledge Low Limit InitAck,L (Cascade) Initialization (IA) Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 501 Constant NotInvited,C (Cascade) GOOD Not Selected No Limits NotSelected (Cascade) (NS) GOOD Not Selected Low Limit NotSelectd,L (Cascade) (NS) GOOD Not Selected High Limit NotSelectd,H (Cascade) (NS) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 502: 12.2 Substatus Definitions For Quality Status
State (IFS) GOOD Initiate Fault- High Limit HiLim,InitFS (Cascade) State (IFS) GOOD Initiate Fault- Constant Const,InitFS (Cascade) State (IFS) 12.2 Substatus Definitions for Quality Status Quality Substatus Description Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 503 Engineering Unit Set if the value lies outside of the range of Range Violation values defined for this parameter. The limits define which direction has been exceeded. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 504 Initialization Request The value is an initialization value a source (back calculation input parameter), because the lower loop is broken or the mode is wrong. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 505 Fault State. This is determined by a block option to initiate Fault State if the status of the primary input and/or cascade input goes Bad. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 506 12. Appendix C 12.2. Substatus Definitions for Quality Status Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 507: Appendix D
Good - from last Initialization executio Acknowledge; and n or actual mode attribute MAN or last execution was not mode as ROUT. determin ed by Shed Option R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 508 MAN or changed from OOS to evaluate evaluated evaluated evaluate evaluate another mode since d mode mode mode d mode d mode the block was last executed. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 509 Resource state as reflected in the resource block parameter resource state is Standby. *Shed to the next lowest priority that is permitted and supported by the available inputs. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 510 13. Appendix D 13.1. Mode Change Conditions Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 511: Appendix E
Conforms to present practices Host “Home Run” Cable (Trunk) Wiring savings are I.S. realized only in Barrier “home run” cable (Optional) Figure 50 Overview of fieldbus wiring topologies R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 512: Power Conditioning
Fieldbus polarity consistent throughout the plant. " RELCOM inc., Fieldbus Wiring Design and Installation Guide (2221 Yew Street, Forest Grove, OR 97116) p. 5. Reprinted by permission. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 513: Power Distribution
12 devices). Be sure to check the fieldbus device specifications to determine the power requirements, since they can vary by device type and manufacturer. For example, Honeywell's smart pressure transmitter ST3000 and smart temperature transmitter STT350 require 18mA at 9Vdc and Flowserve's Logix 1400 digital positioner/controller requires 23mA at 9Vdc.
Page 514: Cable Guidelines Summary
Total cable length is the sum of trunk and spur lengths. If different cable preference types are used, apportion each type against its limit and be sure the total is less than one (1). Experion PKS Series A Fieldbus Interface Module User's Guide R400...
Page 515: Cable Attenuation
Each spur is converted to an equivalent capacitance. All spurs are assumed to be at the extreme end of the trunk. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 516: Attenuation Calculation Summary
The tester and signal generator work together to determine the resistance of the wires and measure the signal quality of the transmission. This testing also determines if the wiring polarity is consistent. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell...
Page 517: Appendix F
PDE through Control Builder where it appears in the control drawing view area. REFERENCE - INTERNAL Refer to the Parameter Definition Editor Reference book for more information about using the Parameter Definition Editor. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 518 15. Appendix F 15.1. About Parameter Definition Editor for Fieldbus Device Block Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 519: Appendix G
Step Action Result Flip the switch on the Chassis Applies power to the chassis and power supply to the ON installed modules initiate their "boot" position. routines. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 520: Checking Firmware Version
In this case, skip Steps 1 and 2 in the following procedure. This procedure assumes that the Experion software has been installed and the Experion Server is running. Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 521 Click the Start button in the task bar and Opens the Run dialog box. click Run. If you have a ControlNet supervisory Opens the Network Tools utility. network, key in >ntools -u -c<. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 522 If this is the first time Ntools has been used on the system, the Settings dialog box opens. Otherwise, see the next Result row and skip to Step 6. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 523 Detail in your system on the given tabs and pane. This illustration is for example click the OK button. purposes only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 524 16. Appendix G 16.1. Loading CIOM-A FIM firmware Step Action Result Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 525: Loading Boot Code
Loading Boot code This procedure assumes that you have launched Ntools and determined that the CIOM-A FIM firmware needs to be updated. Step Action Result R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 526 Detail pane. show that it is selected. This illustration is for example purposes only. Opens Warning! Use Extreme Care Click the Flash button in the toolbar. message box. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 527 Initiates shutdown and reboot of the it is okay to shutdown the CIOM-A FIM. CIOM-A FIM and calls up the Open dialog box. This illustration is for example purposes only. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 528 Wait for the Ntools to complete its next the update completed with no errors. scan. Check that the updated boot version (BV) now appears on the CIOM-A FIM graphic in green. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 529: Loading Personality Image
CIOM-A FIM has started up in the ALIV mode. Step Action Result With CIOM-A FIM graphic still selected, Opens Warning! Use Extreme Care message box. click button. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 530 A FIM to reboot to its normal run state. Click the OK button to acknowledge that Wait for Ntools to complete its next scan. the update completed with no errors. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 531 Step Action Result Check that the updated application (Personality) version (AV) now appears on the CIOM-A FIM graphic in green. This completes the CIOM-A FIM firmware update. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 532 16. Appendix G 16.1. Loading CIOM-A FIM firmware Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 533: Appendix H
Basic type and restart it to initiate the change, if the Link Schedule is too large for it to handle. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 534 (Control Builder) to a device, but only if the parameter LD attribute is LOAD. Factory-set calibration parameters that should not be overwritten should be set to "NOLOAD". Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 535 ROUT_IN connection was connection from a made is not removed. Experion Block. Or, deleting RCAS_IN or ROUT_IN connection from Fieldbus block and re-wiring it to block's CAS_IN pin. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 536 BAD and BAD status in configured situation. Experion function value will be changed to block for use as value 0.0 when sent to fieldbus with status. device. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 537 Experion function current value is indicated as BAD via Experion function block value to NaN. the status. This is Not consistent with block normal Experion system operation. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 538 17. Appendix H 17.1. Important Functional Considerations Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 539: Appendix I
(FMS) provides VCR application-messaging services, such as reading and writing variables. Some device Applications Processes (APs) may access the Fieldbus Access Sublayer (FAS) directly rather than use the FMS. The System Management Kernel R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 540: More Detailed Information
(Where xxx 16 characters that must be equals a valid unique within the system. number) Description Blank User defined descriptive text (DESC) consisting of up to 132 characters. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 541 If an optimized schedule is required later, change this parameter selection to OPT or OPT_NOFORCE. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 542 This is a sequence duration timer. It ensures that incorrectly executed or incomplete sequences are aborted in the SMK. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 543 Protocol Data Units (DLPDU) Physical Layer Overhead (PhLO) value, which permits the sending of one URGENT DLPDU, and its unit is the transmission duration of one octet. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 544 (ST) value, which permits the probing of one node address and the sending of one time available DT DLPDU. The unit is the transmission duration of one octet. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 545 LAS database status SPDUs sent on the local link. Its range is 100 milliseconds to 55 seconds. The unit is one millisecond. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 546 PhL, and the PhL/DLL interfaces, all of which limit the speed of two-way DLE interaction on the local link. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 547 DLE's not specified by the local link live list. Its range is 21 to 247. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 548 Data Unit (PhPDU) to synchronize bit times. The period may be extended, but not reduced. It is an Unsigned8 variable with allowable values between 0 and 7. Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 549 The value of the post transmission gap shall be greater than the value of inter channel skew. It is an Unsigned8 variable with allowable values between 0 and R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 550 Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 551: Parameters For Link Configuration In Monitor Mode
Please note that not all parameters can be changed in the Monitoring mode. For example, you cannot change any of the parameters on the Server Parameters tab in the Monitoring mode. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 552 This is a confirmation service of local significance only, which provides a device with the facility to test the integrity and functionality of the Physical Layer circuitry, excluding the Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 553 Link Master for both of its Links. The value of this parameter may only be set to On (check mark) through a FMS Write or a local interface. R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 554 Function Class that the device (BOOT_OPER) assumes when it is powered up. The class selections are Basic, Link Master, and Bridge. The FIM is the Primary Link Master Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 555: Some Term Abbreviations
Medium Attachment Unit - For wire media MAU = transceiver Medium Dependent Sublayer Network Management Agent Open Systems Interconnection Physical Layer PhLO Physical Layer Overhead PhPDU Physical Layer Protocol Data Unit R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 556: Honeywell R400 July
18. Appendix I 18.2. Description PT DLPDU Pass Token Data Link Protocol Data Unit System Management Kernel SMKP System Management Kernel Protocol Virtual Communications Relationship Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 557: Load Interactions For Fieldbus Related Operations
Link=Active Load Link with All LM- Blocks in related Contents capable CMs = OOS, Device = OOS, Link = N/A Load Link Link = N/A (without contents) R400 Experion PKS Series A Fieldbus Interface Module User's Guide July 2010 Honeywell...
Page 558 Device = N/A Load CM (from Blocks in CM = Monitor) CM=Inactive, Link=Active, Device=N/A Delete CM from All LM- Blocks in CM = Loaded capable CM=Inactive, Link=Active, Device=N/A Experion PKS Series A Fieldbus Interface Module User's Guide R400 Honeywell July 2010...
Page 560 Honeywell Process Solutions 1860 W. Rose Garden Lane Phoenix, AZ 85027 USA...

This manual is also suitable for:

Experion pks series a

Honeywell Series A User Manual

1 Introduction

2 What Is Fieldbus

3 Fieldbus Integration with Experion System

4 Installation

5 Configuration

6 Operation

7 Fieldbus Device Commissioning

8 Maintenance, Checkout, and Calibration

9 Experion Pks Host Registration

10 Appendix A

Appendix A

11 Appendix B

Appendix B

Quick Links

Related Manuals for Honeywell Series A

Summary of Contents for Honeywell Series A
