DIGITAL VIDEO CAMERA

GR-DVL805
GR-DVL505
Please visit our Homepage on the World Wide
Web and answer our Consumer Survey
(in English only):
http://www.jvc-victor.co.jp/english/index-e.html
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No. which is located on the
bottom of cabinet. Retain this information for future reference.
Model No.
Serial No.
CONTENTS
Basic Recording For Video .................... 16
Digital Still Camera (D.S.C.) ................ 19
Video And D.S.C. ............................. 23
Basic Playback For Video ..................... 33
Advanced Features For Video ................ 34
Basic Playback For D.S.C. ..................... 36
Advanced Features For D.S.C. ............... 38
Basic Connections .............................. 42
Advanced Connections ......................... 44
Dubbing To A VCR ............................. 46
The Built-in Memory ......................... 49
Playback and Playback Zoom .............. 52
Playback Special Effects ...................... 53
Random Assemble Editing .................... 54
For More Accurate Editing .................... 58
Audio Dubbing .................................. 60
Insert Editing ................................... 61
Indications ...................................... 69
LYT0575-001B
ENGLISH
8 - 15
16 - 32
33 - 41
42 - 45
46 - 49
50 - 61
62 - 68
69 - 75
76
77 - 79
80 - 81
82 - 83
