Panasonic CF-19 Series Reference Manual

Personal computer
Hide thumbs Also See for CF-19 Series:
Table of Contents

Advertisement

Quick Links

See also: User Manual
1

Reference Manual

Personal Computer
CF-19 Series
Model No.
We recommend that this Reference Manual be printed.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CF-19 Series

Summary of Contents for Panasonic CF-19 Series

  • Page 1: Reference Manual

    Reference Manual Personal Computer CF-19 Series Model No. We recommend that this Reference Manual be printed.

  • Page 2: Key Combinations 2

    Key Combinations NOTE Do not repeatedly press the keys in quick succession. Do not use the key combinations together with touch pad (external mouse), touchscreen (only for model with touch- screen), dual touch (only for model with dual touch), tablet buttons, or other key operations. Do not use the key combinations before you log on to Windows.

  • Page 3: Key Combinations

    Key Combinations Function Popup menu icon Speaker on/off Fn+F4 NOTE Beeps do not sound if you turn off the speaker sound (MUTE) Volume Fn+F5 (Fn+F5= down / Fn+F6= up) Fn+F6 Fn+F7 Activate standby ( page Fn+F8 Concealed Mode on/off You can select on/off of LCD Backlight, LED, Sound , Wireless Radio, Camera Light, and Backlit Keyboard.

  • Page 4: Hotkey Settings

    Fn is locked (pressed-down) until you press another key. Use this when pressing difficult key combinations. • Popup menu icon on/off Start up the Hotkey Settings. Click [start] - [All Programs] - [Panasonic] - [Hotkey Settings]. Make the settings. [Use Fn key lock] When using an Fn key combination Press Fn once.

  • Page 5: Tablet Buttons

    Tablet Buttons Button Function LCD Brightness : down / : up Input Panel <Only for model with Windows XP Professional> Software keyboard on/off ( page <Only for model with Windows XP Tablet PC Edition> Tablet PC Input Panel on/off This button does not work on the Welcome screen. Enter Works as Enter.
  • Page 6 Open the setting screen. <Only for model with Windows XP Professional> Click [start] - [All Programs] - [Panasonic] - [Tablet Buttons Settings]. <Only for model with Windows XP Tablet PC Edition> Click [start] - [Control Panel] - [Printers and Other Hardware] - [Tablet and Pen Settings] - [Tablet Buttons].

  • Page 7: Touchscreen Calibration

    Touchscreen <Only for model with touchscreen> You can use the touchscreen function to perform the same operation as the touch pad and mouse. Touch the screen surface with the stylus (included). To right-click Click on the notification area. changes to Click the object you want to right-click.

  • Page 8: Dual Touch

    Dual Touch <Only for model with dual touch> You can use the digitizer function to perform the same operation as the touch pad and mouse by touching the screen surface with the digitizer pen (included). And you can use the touchscreen function to perform the same operation as the touch pad and mouse by touching the screen with your finger.
  • Page 9 Dual Touch Check the following to prevent the surface of the screen from being scratched Is the surface clean? Is the soft cloth clean? Is the tip of the digitizer pen clean? Things to keep in mind when using the dual touch Do not apply excessive force to the screen Do not lift the computer while holding the LCD screen, or allow the screen to be twisted.
  • Page 10 Dual Touch Touchscreen Calibration Return the rotated display to [Primary Landscape] before the touchscreen calibration. Run [Touch Settings]. Click [start] - [Control Panel] - [Other Control Panel Option] - [Touch Settings]. Click [Calibrate...]. Touch each of the 9 “+” target marks one by one, and then click [Finished]. Restart the computer.

  • Page 11: Software Keyboard

    You can touch the screen keyboard using the stylus (included) to perform the same operation as the internal keyboard. Starting the Software Keyboard Press the Input Panel button (A). Alternatively you can click [start] - [All Programs] - [Panasonic] - [Software Keyboard]. Touch the software keyboard using the stylus. To use shortcut key Example: Ctrl + C Press Ctrl (turns blue) and then press C.
  • Page 12 Software Keyboard Software Keyboard Menu Click (A). Add a check mark to the function you want to use. [Auto Move] The software keyboard moves automatically to avoid overlapping the selected window. [Auto Restore] The software keyboard minimized on the notification area will be restored when you change the input mode. This may not work on some applications.

  • Page 13: Panasonic Hand Writing

    [Exit Panasonic Hand Writing], and then restart Panasonic Hand Writing. Panasonic Hand Writing may not work properly if another application software is active. In this case, close the applica- tion software and try handwriting again.

  • Page 14: Display Rotation

    Display Rotation Rotating the Display Press the Rotation button (A). ° Each time you press the button, the screen display rotates counter-clockwise by 90 NOTE Alternatively you can rotate the display by the following procedure. <Only for model with Windows XP Professional> Double-click on the notification area.

  • Page 15: Changing The Settings

    Display Rotation Changing the Settings Right-click on the notification area and click [Setting]. The Display Rotation Tool screen appears. Change the settings. Click [OK]. NOTE In the following cases, the display angle automatically returns to the default angle. • When starting up Windows •...

  • Page 16: Standby And Hibernation Functions

    Standby and Hibernation Functions The standby or hibernation function allows you to shut off the computer without closing programs and documents. You can quickly return to the programs and documents that you were working on before standby or hibernation. Function Data is saved to Recovery time Power supply...
  • Page 17 Standby and Hibernation Functions Do not enter standby or hibernation in the following conditions, otherwise the data or file may be corrupted, standby or hibernation may not work, or malfunction may occur in the computer or the peripheral devices. • When the hard disk drive indicator or the SD Memory Card indicator is on.
  • Page 18 Standby and Hibernation Functions In standby or hibernation Do not attach or remove a peripheral device. Doing so may cause malfunction. Power is consumed in standby mode. Power consumption may increase when a PC Card is inserted. When power is exhausted, the data retained in memory will be lost.

  • Page 19: Saving Power

    Disable Wake Up from wired LAN and Wake Up from wireless LAN functions when they are not needed. This reduces power consumption in Standby/Hibernation. To confirm current settings, click [start] - [All Programs] - [Panasonic] - [Power Saving Utility] to view [Wired LAN standby power saving function] or [Wireless LAN standby power saving function].
  • Page 20 Disable this function if you want to use the Wake Up from wireless LAN function. Setup Click [start] - [All Programs] - [Panasonic] - [Power Saving Utility]. Click [Enable] for each function. Click [OK] in the confirmation screen that appears.
  • Page 21 Saving Power Click [OK]. Click [Restore initial settings] to return to the factory default settings, and click [OK]. NOTE You can also enable the Intel video driver power saving function as follows. Click [start] - [Control Panel] and click [Other Control Panel Options] under [See Also] on the left side of the screen and select [Intel(R) GMA Driver for Mobile].

  • Page 22: Security Measures

    Do not forget your password. If you forget your Supervisor Password, you will not be able to use your computer. Con- tact Panasonic Technical Support. When running the Setup Utility, do not leave and go away from your computer even for a short time, since other people may set or change the password.

  • Page 23: Set The Password

    22). When you have your hard disk drive repaired • Contact Panasonic Technical Support. • Before sending back the hard disk drive, be sure to set the [Hard Disk Lock] to [Disabled]. NOTE The hard disk lock function works with the built-in hard disk. It does not work with the external hard disk.

  • Page 24: Battery Power

    Battery Power Battery Indicator Battery indicator Battery status Not lit The battery pack is not inserted or not being charged. Orange Charging is in progress. Green The battery is fully-charged. Blinking green In high temperature mode, the battery pack is discharging the power to 80% of normal temperature mode ( page...

  • Page 25: Checking The Remaining Battery Charge

    Battery Power Checking the Remaining Battery Charge You can check the remaining battery charge on the screen. (After logging on to Windows) Press When the battery pack is inserted (example) : Normal temperature mode ( page : High temperature mode ( page When the battery pack is not inserted NOTE...

  • Page 26: High Temperature Mode

    Battery Power High temperature mode The high temperature mode can prevent the battery from deteriorating when the computer is used in high-temperature envi- ronment or used for a long time with its battery fully charged. Select [Auto] (default) or [High Temperature] in [Environment] of the [Main] menu of the Setup Utility ( page 88).
  • Page 27 Battery Power Computer behavior with low battery The default settings are as follows. When the battery level becomes 10% When the battery level becomes 5% [Low battery alarm] [Critical battery alarm] Displays a message that the battery level is low. Displays a message that the battery level is low, and then the computer enters hibernation.
  • Page 28 You can also perform the battery recalibration with the following procedure. Restart the computer. Press and hold F9 while the [Panasonic] boot screen is displayed just after the computer starts the startup proce- dure. When the remaining battery capacity is displayed, press Enter.

  • Page 29: Replacing The Battery Pack

    Battery Power Replacing the Battery Pack The battery pack is a consumable item so the replacement will be necessary. If the battery operation time becomes noticeably short and not recovered even after recalibrating the battery, replace with a new battery. CAUTION The battery pack is not charged when you first purchase it.
  • Page 30 Battery Power To insert Insert the battery pack until it securely fits the connector. Close the cover until it clicks. Slide the latch (C) to the left to lock the cover. CAUTION Make sure the latch is securely locked, otherwise the battery pack may fall when you carry the computer.

  • Page 31: Pc Card / Expresscard

    PC Card / ExpressCard You can insert the following cards. ExpressCard/34 or ExpressCard/54 to the ExpressCard slot (A) (Only for model with ExpressCard slot) PC Card Type I (3.3 mm) or II (5.0 mm) to the PC Card slot (B) For model with Smart Card slot ( page NOTE...
  • Page 32 PC Card / ExpressCard Inserting/Removing the Card To insert the card Open the cover. Slide the latch (C) to the right to unlock the cover. Slide the latch (C) down, and open the cover. Insert the ExpressCard (upper slot) (D) or the PC Card (lower slot) (E) with the label side up until it securely fits in to the slot.
  • Page 33 PC Card / ExpressCard To remove the card Disable the card function. Double-click on the notification area and select the card, then click [Stop]. Follow the on-screen instructions. This step is not necessary when removing the card after turning off the computer. Open the cover and remove the card.

  • Page 34: Sd Memory Card

    To format the SD Memory Card on this computer, do not use [Format] of Windows, but use the SD Memory Card format software. You can download the software from the web site below. http://panasonic.jp/support/global/cs/sd/download/sd_formatter.html To use the SD Memory Card on other devices, format the card on those devices. For further information, refer to the instruction manual of the devices.

  • Page 35: Inserting/Removing The Sd Memory Card

    Note that Panasonic assumes absolutely no liability for any loss of data recorded by the user, or any other damages, direct or indirect.

  • Page 36: Remove The Card

    SD Memory Card To remove the card Preparation Save the data and close all applications. Open the cover and confirm the SD Memory Card indicator (B) is off. Disable the card function. Double-click on the notification area and click [Secure Digital Storage Device], then click [Stop].

  • Page 37: Smart Card

    Smart Card <Only for model with Smart Card slot> You need software to use a Smart Card. You can insert the following cards. PC Card Type I (3.3 mm) or II (5.0 mm) to the PC Card slot (A) Smart Card to the Smart Card slot (B) CAUTION Do not: •...
  • Page 38 Smart Card To remove the card Open the cover and draw the card straight out.

  • Page 39: Ram Module

    RAM module specifications: 200 pins, SO-DIMM, 1.8 V, DDR2 SDRAM, PC2-5300 (For information of RAM module compatibility, contact Panasonic Technical Support.) CAUTION RAM modules are extremely sensitive to static electricity and can be affected even by static electricity from the human body.
  • Page 40 RAM Module Insert/Remove the RAM module. To insert Tilt the module slightly and insert it in the slot. Press down the module so that the right and left hooks (C) are locked. To remove Carefully open the right and left hooks (C). The module will rise.

  • Page 41: Port Replicator / Car Mounter

    Port Replicator / Car Mounter You can use an optional port replicator and a car mounter. These devices free you from being bothered by a lot of cable connections when you carry the computer. They also allow you to connect various peripherals. Connect the port replicator or the car mounter to the expansion bus connector (A) on the bottom side of the computer.
  • Page 42 Port Replicator / Car Mounter Click [PS/2 Compatible Mouse] and click [Next]. At the confirmation message, click [Yes]. Click [Finish] and click [Close]. When the message requests restart of Windows, click [Yes]. The computer will restart. NOTE If you cannot use the functions of the external mouse and trackball even after the steps above, perform the steps below.

  • Page 43: External Display

    External Display You can switch the output destination to an external display. Connect the external display to the external display port (A). NOTE After resuming from hibernation or restarting the computer, the output destination may not be the same as the selected in the previous status.

  • Page 44: Switching The Display

    External Display Switching the Display Press Each time you press the key combination: Internal LCD Simultaneous display External display Extended Desktop The extended desktop function allows you to use the working area across both the internal LCD and the external display. You can drag an object from the internal LCD to the external display and vice versa.

  • Page 45: Usb Devices

    USB Devices Connecting/Removing USB Devices To connect the USB device Open the cover and connect the USB device to one of the USB ports (A). For further information, refer to the instruction manual of the USB device. To remove the USB device Disable the USB device.

  • Page 46: Ieee 1394 Devices

    IEEE 1394 Devices You can connect a digital video camcorder or other IEEE 1394 standard device to the computer. To connect IEEE 1394 device Turn on the computer and the IEEE 1394 device. Open the cover and connect the IEEE 1394 device to the IEEE 1394 interface connector (A).

  • Page 47: Fingerprint Reader

    Fingerprint Reader <Only for model with Fingerprint Reader> Fingerprint Reader NOTE Enrollment and authentication is unavailable to an extremely minority of people including those whose fingerprints give little data for personal identification. How to Use the Fingerprint Reader This section explains how your fingerprints are enrolled and authenticated. Slide your finger to the right or left.
  • Page 48 Fingerprint Reader CAUTION To protect the fingerprint sensor, be sure to close the cover when not using the fingerprint reader. We shall not be liable for any loss or damage whatsoever resulting from your Fingerprint device or neglect of Fingerprint device use, or any data loss resulting from such developments as Fingerprint authentication device malfunctioning.

  • Page 49: Tpm Installation

    Fingerprint Reader Precautions Security Functions Fingerprint Authentication Technology does not guarantee complete authentication and individual identification. Please acknowledge we shall not be liable for any loss or damage whatsoever resulting from the use of, or inability to use your Fingerprint device. The Fingerprint authentication method uses multiple fingerprints, encryption keys, credentials data and passwords.
  • Page 50 Fingerprint Reader TPM Fingerprint Utility Initialization Performed by the Computer Administrator. The “Invalid TPM status” message is displayed by the “Protector Suite QL Icon” in the notification area. If the TPM is not being used, skip this step. Click on the “Invalid TPM status” message to start [Advanced Security Initialization Wizard]. Follow the on-screen instructions.
  • Page 51 Fingerprint Reader We recommend you use the Power-on Security feature. This feature prevents unauthorized access to the user’s computer at the BIOS level. After first finger enrollment, [Power-on Security] message appears. Select [Yes]. When the [Power-on Security] screen appears, click [Manage Passwords]. Select [Power-On] in [Password Types], and click [Set password].
  • Page 52 If you have not done this, have enrolled your fingerprint using Protector Suite QL, and have already made Power-on Security effective, after step B, your fingerprint authentication will be necessary. Turn on or restart the computer. Press F2 or Del while [Panasonic] boot screen is displayed soon after the computer starts the startup procedure. Select the [Security] menu.

  • Page 53: Useful Information

    Fingerprint Reader Useful Information Backup The file described below is necessary for recovering the Fingerprint authentication data. Back up this file periodically in a safe location such as removable disk to avoid data loss resulting from some accidents. We recommend you to store the file in a removable disk or network drive because the benefit of Fingerprint authentication security can be reduced if you keep the file in the internal hard disk drive.

  • Page 54: Handling And Maintenance

    Fingerprint Reader Limitations in Use Password Bank limitations: The following web pages cannot be supported. Web pages which are created by the following technologies: • Web forms created on the fly using javascript. • Web forms which looks as one form (e.g. login field, password field), but internally created with two independent forms. •...
  • Page 55 Fingerprint Reader Disable Power-on Security Log on to Windows as an Administrator. Click [start] - [All Programs] - [Protector Suite QL] - [Control Center]. • The [Fingerprint Control Center] screen appears. Click [Settings], and click [Power-on Security]. Remove the check mark from [Enable power-on security using fingerprints], and click [OK]. Click [Fingerprints], and click [Enroll or Edit Fingerprints].
  • Page 56 Fingerprint Reader Delete Fingerprint Data. Performed by each user. Click [Fingerprints], and click [Delete]. The [Swipe finger] screen will appear. Swipe user’s finger. • If the authentication is successfully completed, the confirmation message appears. Click [Yes]. • Confirm that all users’ data was deleted. NOTE If the enrollment mode is set to “Enrollment to the hard disk”...

  • Page 57: Starting Over

    Make sure your fingerprint sensor is working. • Use the Tutorial wizard to verify that the fingerprint sensor works. If not, reboot and try again. If it still does not work, please contact Panasonic Technical Support. Restore or create passport.

  • Page 58: Description Of Parts

    Camera <Only for model with Camera> Description of Parts <Bottom> Camera Light Camera Lens Tablet Button CAUTION Do not look directly at the camera light since it is too bright. NOTE The protection seals have been put on the camera lens and camera light at the factory default setting. Remove the protection seal before using the camera.

  • Page 59: Using The Hand Strap

    Camera Using the Hand Strap The hand straps are attached on both sides of the computer respectively. To remove the hand strap, use a driver to remove the screws on each corner (A). CAUTION Do not use the strap to carry a heavier weight than the computer. Otherwise the strap may become loose by itself. Do not use the strap if it becomes worn or damaged.

  • Page 60: Using The Camera

    Camera Using the Camera Hold the side of the computer to aim the camera <Tablet mode> <Laptop mode> NOTE Make sure to close the latch (C) in Tablet mode since the camera image is displayed inverted. When the computer is moved from hot and humid environment to low temperature environment, dew condensation may mist up inside the lens.

  • Page 61: Taking Pictures

    Starting up AMCap for TOUGHBOOK Start up AMCap for TOUGHBOOK to take pictures and Video. Click [start] - [All Programs] - [Panasonic] - [AMCap for TOUGHBOOK]. NOTE If you use this software and other multi-media software at the same time, or error may occur. Close all multi-media software including this software and restart this software.

  • Page 62: Take Photo

    Camera Take Photo You can record the camera image as a picture. Adjust the direction of camera, zoom (below), picture quality ( page 64), etc. Click or click [Photos] - [Take photo]. You can assign the Snap function to the Tablet Button. page 67 “Assigning the Snap/Zoom In/Light Functions to the Tablet Button”) When you specify the destination to save and the file name for the photo you about to take, click [Photos] -...
  • Page 63 Camera You can assign the Zoom In function to the Tablet Button. page 67 “Assigning the Snap/Zoom In/Light Functions to the Tablet Button”) Each time you click the magnification ratio goes up in the order of [x 1.0], [x1.5], [x 2.0], [x 2.5], [x 3.0]. To return to [x 1.0], click when the ratio is [x 3.0].
  • Page 64 Camera Taking Still Pictures at Fixed Intervals Click [Photos] - [Start Burst Shooting]. NOTE Pictures will be taken until you click [Start Burst Shooting] again. Changing the Settings for Taking Pictures Click [Photos] - [Settings]. Change to arbitrary settings and click [OK]. NOTE At [Storage path for image], if you specify the externally-connected recording device as a destination to save, software operation may become slow.

  • Page 65: Shooting Video

    Camera Shooting Video Shooting Video Start recording into the buffer. Click [Video] - [Start Recording Temporary]. Finish recording into the buffer. Click [Video] - [Stop Recording Temporary]. Save the buffer as a motion picture. Click [Video] - [Save Temporary Recorded Video]. Specify the destination to save and file name, and then click [Open].

  • Page 66: Setting Audio

    Camera NOTE You can record over the file size specified, but jumpiness may occur for the excess of the file size during playback Specify a sufficient area to save Motion Pictures. Settings Setting Audio Set your preferred sound on [Audio Control] screen. Click [Settings] - [Audio Control].
  • Page 67 ) buttons. <Only for model with Windows XP Professional> Click [start] - [All Programs] - [Panasonic] - [Tablet Buttons Settings]. <Only for model with Windows XP Tablet PC Edition> Click [start] - [Control Panel] - [Printers and Other Hardware] - [Tablet and Pen Settings] - [Tablet Buttons].
  • Page 68 Modem <only for model with internal modem> Connecting the Internal Modem with a Telephone Jack CAUTION Do not use the PBX internal phone lines installed in company offices. Doing so may lead to a fire or electric shock. You cannot connect the modem to the following lines. •...
  • Page 69 Modem Ring Resume Function The computer automatically resumes from standby when the telephone connected to the modem rings. You will need software to keep the computer in idle state waiting for a phone call, and if you prefer, to turn the computer to standby again afterward.

  • Page 70: Connecting Lan

    Connecting LAN CAUTION Do not connect the telephone cable to the LAN port. Turn off the computer. Do not use standby or hibernation. Open the cover and connect the cable. Connect the LAN port (A) and the network system (server, HUB, etc.) using a LAN cable.
  • Page 71 Enabling the Power On by LAN function The computer automatically turns from off to on when the computer is accessed from the network server via the internal LAN port. Select [Allow] in [Power On by LAN] in the [Advanced] menu of the Setup Utility ( page 89).
  • Page 72 Enabling/Disabling the Wake Up from wired LAN function When the Wake Up from wired LAN function is enabled, the computer automatically resumes from standby or hibernation when the computer is accessed from the network server via the internal LAN port. (Default setting) The Wake Up from wired LAN function can be switched to enable/disable by performing the following procedure.

  • Page 73: Disabling/Enabling Wireless Communication

    Disabling/Enabling Wireless Communication <Only for model with wireless LAN, Bluetooth and/or wireless WAN> There are 4 ways of disabling and enabling wireless communication. The wireless switch on the left side of the computer (below) Wireless Switch Utility ( page Settings in the [Advanced] menu of the Setup Utility ( page Setting in the Wireless Connection Disable Utility ( page...
  • Page 74 Disabling/Enabling Wireless Communication NOTE If you uninstall the Wireless Switch Utility, set the wireless switch to ON beforehand. Do not turn on/off the switch repeatedly at too short intervals. Do not restart, log off, or enter standby or hibernation immediately after turning on/off the switch. Do not turn on/off the switch while Windows is starting up.

  • Page 75: Wireless Switch Utility

    Disabling/Enabling Wireless Communication Wireless Switch Utility This utility allows you to control the function of the wireless switch. This utility also allows you to enable or disable wireless devices from a pop-up menu in the notification area. In the default setting, all wireless devices are enabled. The Wireless Switch Utility icon The icon appears in the notification area.

  • Page 76: Installing The Utility

    Disabling/Enabling Wireless Communication Wireless Connection Disable Utility You can automatically disable the wireless LAN/wireless WAN connection when a LAN cable is connected to your computer. You need to install the Wireless Connection Disable Utility to use this function. Installing the utility Log on to Windows as an administrator.

  • Page 77: Status Indication

    Disabling/Enabling Wireless Communication Status indication After installation, the Wireless Connection Disable Utility is automatically started after a user is logged in. An icon appears on the notification area. : Indicates that • the utility is enabled, and • the wireless connection is disabled since a LAN cable is connected. : Indicates that •...

  • Page 78: Wireless Lan

    Wireless LAN <Only for model with wireless LAN> CAUTION Do not use wireless LAN on airplanes, in hospitals, or in other locations where wireless LAN signals may affect peripheral devices. Follow the instructions of airline companies and hospitals. If you use the computer in these locations, turn off the wire- less LAN.
  • Page 79 Wireless LAN Setting the Profiles Double-click on the notification area. ® The [Intel PROSet/Wireless] screen appears. When is displayed, skip step When you double-clicked in step 1, slide the wireless switch to turn on. Click [Profiles...] at the lower right corner of the window, and click [Add...]. Enter the profile name and wireless network name (SSID), and make other necessary changes, then click [Next].
  • Page 80 Wireless LAN Enabling/Disabling the Wireless LAN Standard IEEE802.11a (802.11a) Click on the notification area. Click [802.11a Disabled] or [802.11a Enabled]. NOTE In some countries, communication using IEEE802.11a (5 GHz wireless LAN) standard is restricted by law. The Wireless Switch Utility icon ( ) indicates the on/off status of wireless LAN and/or Bluetooth and/or wireless WAN, not the setting of IEEE802.11a.
  • Page 81 Wireless LAN Wake Up from Wireless LAN Enabling the Wake Up from Wireless LAN function The computer automatically resumes from standby or hibernation when the computer is accessed from the network server via the wireless LAN. Click [start] - [Control Panel] - [Performance and Maintenance] - [System] - [Hardware] - [Device Manager] - [Network adapters] and double-click [Intel(R) WiFi Link 5100 AGN], and then click [Power Management].

  • Page 82: Using The Bluetooth Function

    Bluetooth <Only for model with Bluetooth> You can access internet and other Bluetooth devices without connecting cables. NOTE Communication is established through the Bluetooth antenna (A). Do not block the antenna area with your hand or body. To use Bluetooth, set [Bluetooth] to [Enabled] (default) in the [Advanced] menu of the Setup Utility ( page 90).

  • Page 83: Hard Disk Drive

    Hard Disk Drive Inserting/Removing the Hard Disk Drive To change your hard disk drive, contact Panasonic Technical Support. CAUTION Back up all the important data before removing the hard disk drive. If you need to read the hard disk data on another computer for repair or any other purpose, set [Hard Disk Lock] to...

  • Page 84: Insert The Battery Pack

    Hard Disk Drive To insert Insert the hard disk drive until it surely fits in the slot. Close the cover until it clicks, and slide the latch (C) to the left to lock the cover. Insert the battery pack ( page 29).

  • Page 85: Starting The Setup Utility

    Starting the Setup Utility Turn on or restart the computer. Press while [Panasonic] boot screen is displayed soon after the computer starts the startup procedure. When [Enter Password] is displayed, enter your password. When you start the Setup Utility with Supervisor Password You can make the settings of all items of the Setup Utility.

  • Page 86: Information Menu

    Setup Utility Information Menu Underlined items are the factory presets. Language English Japanese Product Information Model No. Computer information (cannot be changed.) Serial No. System Information Processor Type Computer information (cannot be changed.) Processor Speed Memory Size Available Memory Hard Disk Optical Drive BIOS Information BIOS...
  • Page 87 Setup Utility Main Menu Underlined items are the factory presets. System Date [xxx xx/xx/xxxx] • Day of the Week/Month/Day/Year. • You can use Tab to move the cursor. System Time [xx:xx:xx] • 24-hr. style. • You can use Tab to move the cursor. Main Configuration Touch Pad Disabled...
  • Page 88 Setup Utility Environment Normal Temperature High Temperature Auto Current Status Depending on the • Only when [Environment] is set to [Auto]. battery status, either “Normal Temperature” or “High Temperature” is displayed. Concealed Mode Configuration Enter the sub- menu. The submenu that appears when [Concealed Mode Configuration] is selected: Concealed Mode Disabled Enabled...

  • Page 89: Advanced Menu

    Setup Utility Advanced Menu CPU Configuration Underlined items are the factory presets. Execute-Disable Bit Capability Disabled • [Enabled] indicates that this computer supports hardware-based Data Execution Prevention (DEP). Enabled Core Multi-Processing Disabled Enabled Intel (R) Virtualization Technology Disabled Enabled Intel (R) Trusted ExecutionTechnology Disabled Enabled Peripheral Configuration...
  • Page 90 Setup Utility Disabled • Only for model with GPS Enabled Auto I/O IRQ 3F8/IRQ4 • Can be changed only when [Serial Port A] is set to [Enabled]. 2F8/IRQ3 • Can be changed only when [GPS] is set to [Enabled]. 3E8/IRQ7 2E8/IRQ5 Wireless Switch Disabled...
  • Page 91 • When you select [Disabled] in the following menu, the disabled [Boot Option] is ignored and the boot device in the next [Boot Option] operates. Hard Disk USB Floppy Disk USB Hard Disk USB CD/DVD Drive Disabled Use the Panasonic USB floppy disk drive (optional: CF-VFDU03U)

  • Page 92: Security Menu

    • When [Setup Utility Prompt] is set to [Disabled], the message “Press F2 for Setup / F12 for LAN” Enabled is not displayed on [Panasonic] boot screen. However, F2 and F12 will work even if the message is not displayed.
  • Page 93 Setup Utility Exit Menu Save Values and Reboot To reboot the system after saving the changes. Reboot Without Saving Changes To reboot the system without saving the changes. Save Options Save Current Values To save the changes for all Setup options. Load Previous Values To load previous values for all Setup options.

  • Page 94: Icon Enlarger

    Outlook Express. Some characters of website and e-mail may not be enlarged. Preparation Close all of the applications before using “Icon Enlarger”. Click [start] - [All Programs] - [Panasonic] - [Icon Enlarger]. Select the size. Click [OK]. The screen will be displayed in the selected size.

  • Page 95: Loupe Utility

    Loupe Utility You can magnify the specific part of the screen. Activating the Loupe Utility Click [start] - [All Programs] - [Panasonic] - [Loupe Utility]. Click [OK]. appears on the notification area. Using the Loupe Utility Point the cursor at the part of the screen you want to magnify.

  • Page 96: Click [Settings]

    Loupe Utility NOTE The magnified text or image in the loupe window is fixed at the moment that the part is magnified (e.g., at the moment you press and hold Alt and right-click). To reflect the change you made on the original screen to the loupe window, click the loupe window.

  • Page 97: Hardware Diagnostics

    If it appears that the hardware installed in this computer is not operating properly, you can use the PC-Diagnostic Utility to determine whether or not there is a problem. If the utility discovers a problem in the hardware, contact Panasonic Technical Support. Software cannot be checked using this utility.
  • Page 98 During the diagnostic check, do not remove the AC adaptor, or attach any peripheral devices. Turn on or restart the computer, and press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password.
  • Page 99 Hardware Diagnostics Press At the confirmation message, select [Yes] and press Enter. The computer will restart. While [Panasonic] boot screen is displayed, press and hold until “Please Wait” Ctrl appears at the bottom of the display. When the PC-Diagnostic Utility starts up, it will automatically begin the diagnostic check for all hardware compo- nents.

  • Page 100: The Computer

    Hardware Diagnostics NOTE Using the following procedure, you can run a diagnostic check on a specified hardware component, or run an extended diagnostic check on the memory or the hard disk (The extended diagnostic check is only for the memory and the hard disk). The extended diagnostic check is more detailed, and so requires a longer period of time to run.

  • Page 101: Hard Disk Data Erase Utility

    If you need to erase highly confidential data, we recommend that you contact a company that specializes in this process. Panasonic Corporation will bear no responsibility for losses or damages suffered as a result of the use of this utility.
  • Page 102 Hard Disk Data Erase Utility Select the [Exit] menu, then select your CD/DVD drive in [Boot Override]. Press Enter The computer restarts. If [Enter Password] is displayed during the following procedures, input the Supervisor Password or the User Password. Press to execute [2.

  • Page 103: Technical Information

    Technical Information Network Connections and Communications Software Close the communications software before using the power saving function. If the power saving function (standby or hibernation) is activated while communications software is used, the network con- nection may be interrupted, or the performance may be adversely affected. In this case, restart the computer. In a network environment, set the [System standby] and [System hibernates] settings to [Never].

  • Page 104: Serial Devices

    Technical Information Using the Windows Associated Files The Windows files included in the Windows XP DVD-ROM for OS are contained in the following folders: <Only for model with Windows XP Professional> c:\windows\docs, c:\windows\dotnetfx, c:\windows\i386, c:\windows\support, c:\windows\valueadd <Only for model with Windows XP Tablet PC Edition> c:\windows\docs, c:\windows\dotnetfx, c:\windows\i386, c:\windows\support, c:\windows\valueadd, c:\windows\cmpnents Serial Devices The COM ports of the computer are assigned as below.

  • Page 105: Error Message

    Error Message Follow the instructions below when an error message appears. If the problem persists or if the error message is not shown here, contact Panasonic Technical Support. Error Message Solution Bad System CMOS An error has occurred in the memory of system settings. This occurs when the memory content is changed by an unexpected program operation, etc.

  • Page 106: Troubleshooting (Advanced)

    Refer to the following instructions when a problem occurs. If the remedies indicated in the chart do not solve the problem, contact Panasonic Technical Support. For a software problem, refer to the instruction manual of the software. • To check the computer’s usage status ( page 117).
  • Page 107 Troubleshooting (Advanced) Sound Cannot change the volume by press- Activate the Windows sound function. When it is not active, the volume does ing Fn+F5 or Fn+F6. not change even if is displayed. “There was an error updating the reg- Sound Recorder is started by a limited account user whose language setting is istry”...

  • Page 108: Wireless Communication

    Troubleshooting (Advanced) Network Cannot connect to a network. Set [LAN], or [LAN] and [Modem] to [Enabled] in the [Advanced] menu of the Setup Utility ( page 89). Cannot check the computer’s MAC Follow the steps below. address. Click [start] - [All Programs] - [Accessories] - [Command Prompt]. Input [ipconfig/all], and press Enter.
  • Page 109 87). USB floppy disk drive does not work You can use only the Panasonic CF-VFDU03U USB floppy disk drive (optional). as a boot drive. Connect the floppy disk drive directly to a USB port of the computer. Do not connect it via a USB hub or USB connector of the port replicator or the car mounter.
  • Page 110 Troubleshooting (Advanced) Connecting Peripherals You do not know the address map for To check the current address map, click [start] - [Control Panel] - [Performance IRQ, I/O port address, etc. and Maintenance] - [System] - [Hardware] - [Device Manager] - [View] - [Resources by type].

  • Page 111: Touch Pad / Touchscreen (Only For Model With Touchscreen)/Dual Touch (Only For Model With Dual Touch)

    IEEE1394 PC Card). Follow the on-screen instructions. <Only for model with wireless LAN> Click [start] - [All Programs] - [Panasonic] - [CPU Idle Setting]. Wireless LAN connection is cut. Click [Performance] and click [OK], then click [Yes].

  • Page 112: Pc Card / Expresscard (Only For Model With Expresscard Slot)

    Troubleshooting (Advanced) PC Card / ExpressCard (only for model with ExpressCard slot) A card does not work. Insert the card correctly. The card does not conform to the card standard. Restart the computer after installing a driver (of card or other device). Set [PC Card Slot] and [ExpressCard Slot] to [Enabled] in the [Advanced] menu of the Setup Utility ( page...

  • Page 113: Fingerprint Reader (Only For Model With Fingerprint Reader)

    54). The fingerprint sensor may be malfunctioning when it continues to perform poorly after the steps described above have been performed. Contact Panasonic Technical Support. Sensor does not work. Exported passport can help you if you need to replace the sensor.
  • Page 114 Troubleshooting (Advanced) Fingerprint Reader (only for model with Fingerprint Reader) User cannot use enrolled finger. (e.g. It is strongly recommended to enroll at least two fingers to avoid this problem. injury) If you enrolled multiple fingers, simply use other finger. If you only enrolled one finger that can be used, we recommend to use the [Enroll or Edit Fingerprints] wizard and enroll additional fingerprints.
  • Page 115 Troubleshooting (Advanced) Fingerprint Reader (only for model with Fingerprint Reader) Replacing sensor. If you need to replace a non-functioning fingerprint reader, follow this procedure. Enrollment to the hard disk: If enrollment to hard disk is used, “Protector Suite QL” has not stored any data on the device and therefore has no problem to continue after you replaced the sensor.

  • Page 116: Fast User Switching Function

    Troubleshooting (Advanced) Fingerprint Reader (only for model with Fingerprint Reader) Removing data from the reader. When enrollment to the device is used, passport data is stored to the device. To remove it, go to the [Delete] passport wizard and delete existing passports, and then use the [Fingerprint Storage Inspector] to remove remaining fingerprints (e.g.

  • Page 117: Checking The Computer's Usage Status

    As long as it is activated, the PC Information Viewer will appear in front of all other screens. Depending on your network environment, it may take 1 minute to start the PC Information Viewer. Click [start] - [All Programs] - [Panasonic] - [PC Information Viewer] - [PC Information Viewer].
  • Page 118 44), a copy of the primary device screen is saved. The default key combination to copy is Ctrl+Alt+F7. You can change it in the following procedure. Log on to Windows as an administrator, and click [start] - [All Programs] - [Panasonic] - [PC Information Viewer].
  • Page 119 This manual is copyrighted by Panasonic Corporation with all rights reserved. No part of this manual may be reproduced in any form without the prior written permission of Panasonic Corporation. No patent liability is assumed with respect to the use of the information contained herein.

Table of Contents
