Please read these instructions carefully before using this product, and save this manual for future use.
OPERATING INSTRUCTIONS
Contents
Getting Started
Introduction .................................................................
Read Me First .............................................................
(Precautions)
Description of Parts ..................................................
First-time Operation ..................................................
Useful Information
On-screen Manual ....................................................
Handling and Maintenance .......................................
Reinstalling Software ................................................
Troubleshooting
Troubleshooting (Basic) ............................................
Appendix
LIMITED USE LICENSE AGREEMENT ...................
Specifi cations ...........................................................
Standard Limited Warranty ......................................
Personal Computer
CF-19
series
2
3
10
13
19
20
22
25
30
31
34
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Panasonic Toughbook CF-19ACUAL1M
Summary of Contents for Panasonic Toughbook CF-19ACUAL1M
-
Page 1: Table Of Contents
For further information about the com- puter, you can refer to the on-screen manual. To access the on-screen manual page 19 “On-screen Manual” Please read these instructions carefully before using this product, and save this manual for future use. OPERATING INSTRUCTIONS Contents Getting Started Introduction ... -
Page 2: Introduction
Introduction Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions carefully. Terms and illustrations in these instructions CAUTION NOTE Enter : Fn + F5 : (Start) - [All Programs] : [start] - [Run] :... -
Page 3: Read Me First
Models for Europe <Only for model with a “CE Declaration of Conformity (DoC) “Hereby, Panasonic declares that this Personal Computer is in compliance with the essential require- ments and other relevant provisions of the Directive 1999/5/EC.” Hint: If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: http:// www.doc.panasonic.de... - Page 4 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
- Page 5 Warnings This equipment is not designed for connection to an IT power system. (An IT system is a system having no direct connections between live parts and Earth; the exposed-conductive- parts of the electrical installation are earthed. An IT system is not permitted where the computer is directly connected to public supply systems in the U.K.) Disconnect the mains plug from the supply socket when the computer is not in use.
- Page 6 Failure to comply with these precautions violates safety stan- dards of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply with these precautions.
- Page 7 SORIES , LIFE SUPPORT SYSTEMS OR OTHER EQUIPMENTS/DEVICES/SYSTEMS THAT ARE INVOLVED WITH ENSURING HUMAN LIFE OR SAFETY. PANASONIC WILL NOT BE RESPONSIBLE FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES. AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems when used during critical phases of fl...
- Page 8 Read Me First Do Not Pull or Insert the AC Plug If Your Hands Are Wet Electric shock may result. Clean Dust and Other Debris of the AC Plug Regularly If dust or other debris accumulates on the plug, humidity, etc.
- Page 9 Use only the specifi ed battery pack ( product. Use of battery packs other than those manufactured and supplied by Panasonic may present a safety hazard (generation of heat, ignition or rupture). When the battery pack has deteriorated, replace it with a...
-
Page 10: Description Of Parts
Description of Parts A: Wireless LAN Antenna <Only for model with wireless LAN> Reference Manual “Wireless LAN” The wireless LAN switch may turn off depending on the reception. B: Bluetooth Antenna <Only for model with Bluetooth> Reference Manual “Bluetooth” C: Stylus/Digitizer pen Holder D: Touch Pad E: LED Indicator Wireless ready... - Page 11 Left side Rear side A: DC-IN Jack B: USB Port Reference Manual “USB Devices” C: IEEE 1394 Interface Connector Reference Manual “IEEE 1394 Devices” D: Modem Port Reference Manual “Modem” E: LAN Port Reference Manual “LAN” F: SD Memory Card Indicator (Blinking: During access) Reference Manual “SD Memory Card”...
- Page 12 Description of Parts This computer contains a magnet and magnetic products at the locations circled in the illustration at right. Avoid leaving metallic object or magnetic me- dia in contact with these areas. Switching to the Tablet mode Attaching the stylus to the computer Attaching the hand strap and the shoulder strap (option) A Lift up the display so it stands perpendicular to the body.
-
Page 13: First-Time Operation
Preparation A Check and identify the supplied accessories. If you do not fi nd the described accessories, contact Panasonic Technical Support. • AC Adaptor ..1 • AC Cord ..1... -
Page 14: Opening The Display
CPU. Wait until the computer cools down, and then turn the power on again. If the computer does not power on even after cooling down, contact Panasonic Technical Support. Any changes from the default setting of the Setup Utility must not be made until the First-time Operation is completed. - Page 15 E Select language and OS (32bit or 64bit) on “Select OS” screen and click [OK]. The language setting will start by clicking [OK] on the confi rmation screen. You can return to the “Select OS” screen by clicking [Cancel]. The language and OS setting will be completed in about 15 minutes. F When termination screen is displayed, click [OK] to turn off the computer.
- Page 16 First-time Operation When you set date/time/time zone and click [Next], the screen may not go to the next step for a few minutes. Do not touch the keyboard or touch pad, and wait until the screen changes. If “An unexpected error has occurred ...” (or a similar message) is displayed, click [OK].
- Page 17 A Run [Calibration Utility]. Click (Start) - [All Programs] - [Panasonic] - [Calibration Utility]. B Select [Touch input]. To calibrate more accurate, add a check mark for [Advanced calibration]. C Using the digitizer pen, touch each of the “+” target marks one by one.
- Page 18 First-time Operation NOTE PC Information Viewer This computer periodically records the management information of the hard disk, etc. The maximum data volume for each record is 1024 bytes. This information is only used for estimating the cause when the hard disk goes down by any possibility. They are never sent to outside via network nor used for any other purpose except for the purpose described the above.
-
Page 19: On-Screen Manual
(Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Reference Manual]. Click [start] - [Reference Manual]. Alternatively click [start] - [All Programs] - [Panasonic] - [On-Line Manuals] - [Reference Manual]. Important Tips The Important Tips will provide you with the battery information so that you can use the battery pack in the optimum condition to obtain longer operation time. -
Page 20: Handling And Maintenance
Handling and Maintenance Operation environment Place the computer on a fl at stable surface. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become damaged. Temperature: Operation : -10 °C to 50 °C (IEC60068-2-1, 2) Storage : -20 °C to 60 °C Humidity:... - Page 21 Preventing your computer from unauthorized use via wireless LAN/Bluetooth/Wireless WAN <Only for model with wireless LAN/Bluetooth/Wireless WAN> Before using wireless LAN/Bluetooth/Wireless WAN, make the appropriate security settings such as data encryp- tion. Maintenance To clean the LCD panel Use the soft cloth included with the computer. (For further information, refer to “Suggestions About Cleaning the LCD Surface”...
-
Page 22: Reinstalling Software
At the confi rmation message, select [Yes] and press Enter. Computer will restart. Press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password. Select the [Exit] menu, then select [Repair Your Computer] and press Click [Reinstall Windows] and click [Next]. - Page 23 At the confi rmation message, select [Yes] and press Enter. Computer will restart. Press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password. Set the Recovery Disc into the CD/DVD drive.
- Page 24 Reinstalling Software Start the Setup Utility and change the settings as necessary. Perform Windows Update.
-
Page 25: Troubleshooting (Basic)
Follow the instructions below when a problem has occurred. There is also an advanced troubleshooting guide in the “Reference Manual”. For a software problem, refer to the software’s instruction manual. If the problem persists, contact Panasonic Technical Support. You can also check the computer’s status in the PC Information Viewer Reference Manual “Troubleshooting (Advanced)”). - Page 26 A Click [start] - [My Computer] and right-click [Local Disk(C:)], and click [Properties]. B Click [Tools] - [Check Now]. C Select the option in [Check disk options] and click [Start]. Start the computer in Safe Mode and check the error details. When the [Panasonic] boot screen disappears at startup, press and hold Menu is displayed.
- Page 27 Entering Password Even after entering the pass- The computer may be in ten-key mode. word, password input screen If the NumLk indicator input. is displayed again. The computer may be in Caps Lock mode. If the Caps Lock indicator mode, and then input. The user name (account name) includes an “@”.
- Page 28 E Click [Yes], click [Yes] and click [OK]. Then restart the computer. F Press while [Panasonic] boot screen is displayed. G Set [GPS] to [Enable] in the [Advanced] - [Serial Port Settings]. H Press and select [Yes] at the confi rmation message, and press When using the external mouse, connect it correctly.
- Page 29 Others No response. Press that is not responding. An input screen (e.g., password input screen at startup) may be hidden behind another window. Press Slide the power switch for four seconds or longer to shut down the computer, and then slide the power switch to turn it on.
-
Page 30: Limited Use License Agreement
DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE. Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intend- ed results, and for the installation, use and results obtained therefrom. -
Page 31: Specifi Cations
Specifi cations This page provides the specifi cations for the basic model. The model number is different according to the unit confi guration. To check the model number: Check the bottom of the computer or the box the computer came in at the time of purchase. To check CPU speed, memory size and the hard disk drive (HDD) size: Run the Setup Utility ( Reference Manual “Setup Utility”) and select [Information] menu. - Page 32 Battery Recalibration Utility, Hand Writing Utility, Display Rotation Tool, Infi neon TPM Professional Package , Wireless Connection Disable Utility Dashboard for Panasonic PC, Aptio Setup Utility, PC-Diagnostic Utility, GPS Viewer ware Keyboard, Hotkey Appendix, Table button Manager Recovery Disc Creation Utility, Power Plan Extension Utility, Quick Boot Manager, Hard Disk Data Erase Utility ®...
- Page 33 Only for model with Smart Card slot SD Memory Cards that support high-speed transfer rates can be used. ported. Operation has been tested and confi rmed using Panasonic SD Memory Cards and SDHC Memory Cards with a capacity of up to 32 , and Panasonic SDXC Memory Card with a capacity of up to 64 Operation on other SD equipment is not guaranteed.
-
Page 34: Standard Limited Warranty
Panasonic shall not be liable for loss of data or other incidental or consequential damages resulting from the use of this product, or arising out of any breach of this warranty. All express and implied warranties, including the warranties of satisfactory quality and fi... - Page 35 This media is originally provided with the unit. Panasonic warrants to you only that the disc(s) or other media on which the Programs are furnished will be free from defects in material and workmanship under normal use for a period of sixty (60) days from the date of delivery thereof to you, as evidenced by your purchase receipt.
- Page 36 As an NERGY ® NERGY Panasonic computers enter a low-power sleep mode after a period of inactivity, saving the user energy. Outline of the International The international NERGY saving through the use of computers and other offi ce equipment. The program backs the development and dis- semination of products with functions that effectively reduce energy consumption.
