The Insight Display is powered off when the overall health is good to save the life of the Insight Display.

Diagnosing the overall system health

Background color
Green
Amber
Blue
The overall system health is also indicated by the health icon on the bottom left corner of every Insight Display
screen.
Health icon
Green check mark
Yellow exclamation point System health is degraded.
Red X

Diagnosing the component health

Highlight color
Black
Gray
Dark green
Bright green
Blue
Yellow
Red

Navigating the Insight Display

Navigate through the menus and selections by using the arrow buttons on the Insight Display panel
BladeSystem Insight Display
page 77). Use the arrow buttons to move the selection box to a menu item, and then press OK to go to
selected screen.
Description
System health is good.
System health is degraded.
Enclosure UID is active. Enclosure UID overrides the
green and amber background colors. Use the Insight
Display main menu to turn the enclosure UID on and
off.
Description
System health is good.
System health is failed.
Description
Component bay is not populated
DVD-ROM drive is populated, no disc is inserted
Component bay is populated, component is powered off
Component bay is populated, component is powered on
Component bay has additional status information
Component bay is populated, component health is
degraded
Component bay is populated, component health failed
components" on page 84, "HP BladeSystem Insight Display
("HP
components" on
Getting started 7
