Device errors occur when a component has degraded health, a non-critical device-specific error, or has
failed. Device errors might occur on all components, including:
•
Server blades
•
Storage blades
•
Power supplies
•
Interconnect modules
•
Onboard Administrator modules
•
Fans
•
AC power inputs
To correct a device error:
Use the arrow buttons to navigate to Fix This, and press OK.
1.
Review and complete the corrective action suggested by the Insight Display. In most cases, you must
2.
remove the failed component to clear the error.
Replace the failed component with a spare, if applicable.
3.
If the device failure error is an AC power input error, be sure the AC power input is supplied with power
to clear the error.
If the suggested corrective action does not correct the error, see the device-specific troubleshooting
4.
section. Begin troubleshooting by using the symptom table at the beginning of each section.

Fan troubleshooting

Fans provide proper cooling for the enclosure. This section provides the steps required to ensure that the fans
are operating properly and in the correct locations within the enclosure.
For all removal and replacement procedures used in this document, see the appropriate enclosure
maintenance and service guide on the HP website (http://www.hp.com/go/bladesystem/documentation).
For specific component LED definitions and component identification, see "Component identification (on
page 73)."
Symptoms: Fan failure
Fan LED condition
A single fan LED is flashing amber.
The Insight Display may also be reporting
a device identification error for the fan.
A single fan LED is solid amber.
The Insight Display may also be reporting
a device failed error for the fan.
All fan LEDs are flashing amber.
A row of fan LEDs are all dim amber or all
off.
A single fan LED is off.
Initial step
—
—
—
—
—
Required steps
Begin with step 1 of "Procedures:
Fan LED is flashing amber (on page
27)."
Begin with step 1 of "Procedures:
Fan LED is solid amber (on page
29)."
Begin with step 5 of "Procedures:
Fan LED is flashing amber (on page
27)."
Begin with step 4 of "Procedures:
Fan LED is off (on page 28)."
Begin with step 4 of "Procedures:
Fan LED is off (on page 28)."
