To understand docking status lights

The red and green lights on the docking system indicate the current status of the
docking system. The status lights are located in the lower left corner of the docking
system.
This light Indicates
Hard disk drive activity
This light turns on when the OmniBook is reading
from or writing to the hard disk drive.
Floppy disk drive activity
This light turns on when the OmniBook is reading
from or writing to the floppy disk drive.
Password protection on
This light blinks when a password is required.
Docking status
This light turns green when the OmniBook
is successfully docked, on, and can be undocked.
AC power
This light turns red when ac power is connected to
the docking system. The light turns red and green
when ac power is connected and the OmniBook is
docked.
Using the Docking System
Understanding the Basics
1-15
