Page 1: Reference Manual
Reference Manual Personal Computer CF-C1 Series Model No. CF-F9 Series We recommend that this Reference Manual be printed.
Page 2: Read Me First
Windows Tablet PC Edition Service Pack 3” are indicated as “Windows” or “Windows XP” unless otherwise indicated. <Only for CF-C1 Series> The computer screen supporting two touching methods (using digitizer pen / your fingers) is referred to simply as the “screen”.
Page 3 Read Me First Sound and video in AVI files may be interrupted or produce a time-lag during playback. If this happens, Click on the notification area. Select [High performance]. This may remedy the problem. Depending on the processing status on Windows, sound may be interrupted at Windows startup. You can mute the sound at startup.
Page 4: Using The Touch Pad
Using the Touch Pad In this section, illustrations of the CF-C1 Series are used as examples. Use the Touch Pad to move the cursor on the screen and perform computer operations. A. Work Surface (Touch Pad) B. Left Button C. Right Button...
Page 5 Using the Touch Pad Function Operation Dragging Two quick taps, but on the second tap leaving your finger down (applying pressure) and moving it on the work surface. While holding down the button, moving your finger on the work surface. Scroll Trace a circle around the Touch Pad.
Page 6 [Settings]. When is not displayed: Click (Start)/ [start] - [All Programs] - [Panasonic] - [Touch Pad Utility settings]. Windows 7 Windows XP If a message appears indicating that the Touch Pad utility is not running, click (Start)/ [start] - [All Programs] - [Panasonic] - [Touch...
Page 7 Using the Touch Pad Remove your finger from the pad, then place your finger in the appropriate area to begin scrolling. The finger position on the Touch Pad can be changed using the Touch Pad utility. ( page 8) This explanation assumes in the default setting.
Page 8 Using the Touch Pad Vertical scroll Horizontal scroll Trace counter-clockwise To scroll up To scroll left When the horizontal scroll function has not been enabled, any scrolling will be vertical scrolling. The screen will not scroll if you trace toward the center of the Touch Pad. On screens that cannot be scrolled (e.g., desktop screen), if you scroll, the computer may try to scroll the screen, causing the cursor to freeze.
Page 9 Using the Touch Pad Click [OK]. Windows XP Using the Virtual Scrolling Function Set the Virtual Scrolling function using the following procedure. The Touch Pad utility will be disabled. Click on the notification area. Click [Settings]. When is not displayed: page 6, step Remove the check mark from [Activate Touch Pad function] in [General settings], and...
Page 10 Using the Touch Pad Handling the Touch Pad By design, the Touch Pad is to be used with a fingertip only. Do not place any object on the work surface or press down forcefully with sharp-pointed objects (e.g., nails) or hard objects that can leave marks (e.g., pencils and ball point pens). Try to avoid having any harmful substances, such as oil, come in contact with the Touch Pad.
Page 11 Digitizer / Multi Touch Operation <Only for CF-C1 Series> The screen of your computer allows you to perform the same operations as the Touch Pad or mouse by touching its surface. The computer supports two touching methods, using the digitizer pen (included), and using your fingers.
Page 12 Digitizer / Multi Touch Operation Functions Operation Dragging Touch and hold the object (i.e. file or icon), move the digitizer pen on the surface (dragging the object to the desired location), then release the digitizer pen. To right-click You can choose either of the two ways below. Touch and hold with the digitizer pen.
Page 13 Digitizer / Multi Touch Operation Touching with your fingers Functions Operation Moving the cursor The cursor is moved to the location pointed with finger. Clicking (Tapping) One tap with one finger Double-clicking (Double-tapping) Two quick taps with one finger Dragging Touch and hold the object (i.e.
Page 14: Change The Settings For The Screen
Digitizer / Multi Touch Operation The following operations may not be possible depending on the application program being used. Functions Operation Zoom in, zoom out Use two fingers to touch the image or text you want to zoom in or out on, and draw your fingers apart to zoom in and together to zoom out.
Page 15: Calibrating The Screen
Digitizer / Multi Touch Operation NOTE Do not move the digitizer pen too quickly. If the digitizer pen moves too quickly, the cursor may be unable to follow its movement. Calibrating the Screen When you cannot point correctly with the digitizer pen (included) or your fingers, calibrate the screen by following the steps below.
Page 16 Digitizer / Multi Touch Operation Calibration by a standard user NOTE Perform the following calibration for each user. Run [Tablet PC Settings]. Click (start) - [Control Panel] - [Hardware and Sound] - [Tablet PC Settings]. Click [Calibrate]. Click [Pen input] or [Touch input]. To calibrate the screen for the digitizer pen operation, click [Pen input].
Page 17 Digitizer / Multi Touch Operation Handling the Screen Use the digitizer pen included with the computer. Do not use pencils, implements with sharp tips or hard objects for screen operations. The screen may be damaged as a result. Do not place any object on the surface or press down forcefully with sharp-pointed objects (e.g., nails), or hard objects that can leave marks (e.g., pencils and ball point pens).
Page 18 Digitizer / Multi Touch Operation Suggestions About Cleaning the LCD Surface To improve the outdoor visibility of the display, a low reflection coating has been added. In order to avoid scratches and peeling of this coating, an approved soft cloth has been included to wipe the LCD surface of the computer. Before using the computer, be sure to read the instructions provided below.
Page 19 Tablet Buttons <Only for CF-C1 Series> Button Function LCD Brightness : down : up Input Panel Tablet PC Input Panel on/off This button does not work on the Welcome screen. Rotation Rotates the display. ( page Do not press the button again until the display rotation is completed.
Page 20 Tablet Buttons To change the functions of the LCD Brightness buttons Open the Dashboard for CF-C1. Press (USER) button. Select a function in [Brightness buttons]. Brightness Up/Down: Use the buttons to adjust the LCD brightness (default setting) Page Up/Down: Use the buttons to control page up/down Up/Down Arrow keys: Use the buttons to move the cursor up/down Close the Dashboard for CF-C1.
Page 21 Display Rotation <Only for CF-C1 Series> After Windows is started up, you can rotate the display and perform the Touch Pad and screen operations in the rotated mode. Rotating the Display Press (Rotation) button ( page 19). To select the angle and rotate the display...
Page 22 Display Rotation Changing the Settings By using the Display Rotation Tool, you can change the settings of the display rotation. Click on the notification area and right-click Windows 7 Right-click on the notification area. Windows XP Click [Setting...]. Change the settings. A.
Page 23 Display Rotation NOTE If you shut down Windows when you rotate the display, the Touch Pad and screen do not match the display angle next time you start up Windows for a few seconds. The Touch Pad and the screen may not match the display angle if you change display properties or Intel(R) Graphics Media control panel when you rotate the display.
Page 24: Key Combinations
Key Combinations NOTE Do not repeatedly press the keys in quick succession. Do not use the key combinations together with Touch Pad (external mouse), screen or other key operations. Do not use the key combinations before you log on to Windows. Wait until the hard disk drive indicator turns off.
Page 25 Key Combinations Functions Pop-up Icon Fn+F3 Display switching ( page Windows 7 When an external display is connected you can change the operating mode. (The change you made may not be effective until Enter is pressed.) You can also change + P.
Page 26 Key Combinations Functions Pop-up Icon Fn+F4 Speaker on/off NOTE (MUTE) Beeps do not sound if you turn off the speaker sound. Fn+F5 Volume (Fn + F5= down / Fn + F6= up) Fn+F6 NOTE When fine-tuning the sound volume, press and hold Fn, and press F5 or F6 intermittently.
Page 27 When you press Fn, the key is locked (pressed-down) until you press another key. Use this when pressing difficult key combinations. • Pop-up icon on/off Start up the Hotkey Settings. Click (Start)/ [start] - [All Programs] - [Panasonic] - [Hotkey Settings]. Windows 7 Windows XP Make the settings. [Use Fn key lock] When using an Fn key combination Press Fn once.
Page 28 Windows 7 Windows XP Alternatively, you can click Windows 7 (Start) / [start] - [All Programs] - [Panasonic] - [Software Windows XP Keyboard]. Touch the software keyboard. To use shortcut key Example : Ctrl + C Press Ctrl (turns blue) and then press C.
Page 29 Software Keyboard Software Keyboard Menu Click (A). Add a check mark to the function you want to use. [Auto Move] The software keyboard moves automatically to avoid overlapping the selected window. [Auto Restore] The software keyboard minimized on the notification area will be restored when you change the input mode. This may not work on some applications.
Page 30 Select a function in [Press:] / [Action:]. Windows 7 Windows XP Select [Start a program] / [Launch an application]. Windows 7 Windows XP Click [Browse…], and input the following. Windows 7 c:\Program Files\Panasonic\MEISKB\Skblnch.exe Windows XP c:\Program Files\Panasonic\MEISKB\MEISKB.exe Click [OK], and then [OK].
Page 31 Starting Hand Writing Utility Click on the notification area and double-click Windows 7 Double-click on the notification area. Windows XP Alternatively you can click (Start) / [start] - [All Programs] - [Panasonic] - [Hand Writing Windows 7 Windows XP Utility].
Page 32 Hand Writing Utility NOTE Select the image size before handwriting by clicking [Option] - [Window size]. If you change the size after handwriting, the image quality will become lower. You can copy the bitmap image by clicking [Edit] - [Copy], and paste it in another application software that supports bitmap format.
Page 33 Dashboard for CF-C1 <Only for CF-C1 Series> You can perform the following operations easily by using the Dashboard for CF-C1. Open the Dashboard for CF-C1. Press (USER) button. Make the operation. [Battery 1] [Battery 2] Check the remaining battery charge for the battery pack 1 ([Battery 1]) and the battery pack 2 ([Battery 2]).
Page 34 Dashboard for CF-C1 Click [OK], and then [OK]. [Resolution] Set the screen resolution and screen orientation / color quality as follows. Windows 7 Windows XP Click [Change settings]. Make settings on the screen that appears. Click [OK]. [Brightness buttons] Assign different functions to (LCD Brightness) buttons.
Page 35 Dashboard for CF-C1 Using Dashboard for CF-C1 as an Application Launcher You can launch application programs easily by registering them to the Dashboard for CF-C1 screen. Log on to Windows as an administrator, and proceed as follows. Open the Dashboard for CF-C1. Press (USER) button.
Page 36 An administrator must click [Change settings that are currently unavailable] to use these functions. Log on to Windows as an administrator, and proceed as follows. Click (Start) / [start] - [All Programs] - [Panasonic] - [Dashboard for Windows 7 Windows XP CF-C1 settings].
Page 37: Battery Power
Battery Power Checking the Battery Status Battery indicator(s) <CF-C1 Series> <CF-F9 Series> Battery pack 1 Battery pack 2 <CF-C1 Series> Battery Indicator Battery Status Not lit Battery pack is not connected or no charging. Orange light on / Charging in progress.
Page 38 There are three methods to check the remaining battery power. To check the remaining battery power on the screen (After logging on to Windows) Press <CF-C1 Series> Display Condition When the battery pack is inserted. (example) When the battery pack is not inserted.
Page 39 Battery Power <CF-F9 Series> Display Condition When the battery pack is inserted. (example) When the battery pack is not inserted. [ECO] is displayed when the battery’s Economy Mode (ECO) is enabled. To check the remaining battery power and remaining time using the Windows Battery Meter (Windows Power Meter) (After logging on to Windows) Click...
Page 40 (When the power is off or in sleep or hibernation) <CF-F9 Series> Close the display and confirm that the latch is locked. <CF-C1 Series> Close the display completely. Disconnect the AC adaptor. Slide the power switch (A) and confirm the battery indicator (B, C).
Page 41 Battery Power <Only for CF-C1 Series> To check the battery with less remaining power When using the main and second battery packs, you can check the battery with less remaining power. Slide one of the latches (A) to the unlocked position without removing the battery pack.
Page 42 When the battery charging status is checked by the indicators, you cannot check to see whether the battery’s Economy Mode is enabled or disabled. <Only for CF-C1 Series> To check the remaining battery power using the Dashboard for CF-C1 The Dashboard for CF-C1 allows you to easily check the remaining battery power ( page 33).
Page 43 Battery Power Computer behavior with low battery The default settings are as follows. When the remaining battery power becomes 10% When the remaining battery power becomes 5% [Low battery level]/ [Low battery [Critical battery level]/ [Critical Windows 7 Windows 7 Windows XP Windows XP alarm]...
Page 44 You can also perform the “Battery Recalibration” with the following procedure. Restart the computer. Press and hold F9 while the [Panasonic] boot screen is displayed just after the computer starts the startup procedure. When the remaining battery power is displayed, press Enter.
Page 45 Click [Enabled] or [Disabled] in [The battery’s Economy Mode (ECO)]. Windows XP Right-click either (Disable) or (Enable) on the notification area. is not displayed, click [start] - [All Programs] - [Panasonic] - [Battery] - [Economy Mode(ECO) Setting Utility].
Page 46 Battery Power Click [Economy Mode(ECO) Enable] or [Economy Mode(ECO) Disable]. [Enabled]/ [Economy [Disabled]/ Windows 7 Windows XP Windows 7 Mode(ECO) Enable] [Economy Windows XP Remaining battery power: Remaining battery power: Mode(ECO) Disable] 81% or more. 80% or less. Blink Economy Mode (ECO) (The battery will discharge Light Indicator...
Page 47 Windows XP Turn your computer over and remove/insert the battery pack. To remove Slide the latch (for CF-C1 Series) / the left and right latches (for CF-F9 Series) to the unlocked position, and pull out the battery pack. <CF-C1 Series>...
Page 48 Do not apply pressure from the top of the closed display when the battery pack has been removed. Doing so may damage the LCD. <For CF-C1 Series operating on the battery packs 1 and 2> If one of the two battery packs has remaining power, you can replace the other battery pack without turning off the computer (Hot swap).
Page 49 Battery Power <Only for CF-C1 Series> Adding the Second Battery Pack When using your computer with a battery pack, you can insert the second battery pack. Proceed as follows. Turn your computer over. Slide the latch corresponding to the battery compartment to which you are going to insert the second battery pack, and remove the battery bay weight saver.
Page 50 AC adaptor is used (except for the power saving function in Power Plan Extension screen). Switch the power plan to [Panasonic Power Management] ( page When you switch the power plan, ON/OFF for CD/DVD drive (only for CF-F9 Series), brightness of the screen, rotation of the cooling fan, etc.
Page 51 Power consumption is increased or reduced when Balanced necessary. [Turning display off], [Setting the computer to Sleep], etc. are the same settings as for [Panasonic Power Management], but [Wireless Adaptor Settings], etc. in [Wireless Adaptor Settings] of [Change advanced power settings] differ. When you rarely use Lowered performance saves power.
Page 52 Panasonic’s unique power saving functions The power saving function designed by Windows and Panasonic’s unique power saving functions (Power Plan Extension Utility) are two different types of power saving functions constituting the power plan of this computer. The following explains Panasonic’s unique power saving functions (Power Plan Extension Utility) settings.
Page 53 Customizing the Power Setting Item Power saving contents Fan control mode You can switch the rotation of the cooling fan to: Adjust according to the computer temperature (Standard)/Reduce heat generation by faster rotation (High speed)/Reduce the fan noise by slower rotation (Low speed). NOTE You can also switch according to the procedure of [Extension setting manual temporary switching].
Page 54 Customizing the Power Setting Item Power saving contents The battery’s Economy Mode Switching the full-charging capacity of the battery to 80% (Enabled)/100% (Disabled) (ECO) When [Enabled] is selected, the battery operation time becomes shorter, but the battery deterioration due to full-charging (100%) is alleviated. Consequently, the battery life becomes longer.
Page 55 Customizing the Power Setting Switching Power Plan Extension Utility manually You can manually switch the fan control mode, the optical disc drive’s power (only for CF-F9 Series), and the battery’s Eco Mode (ECO). NOTE The contents set by [Extension setting manual temporary switching] are not associated with the power plan. The settings become disabled if the power plan is switched.
Page 56 Customizing the Power Setting Click on the notification area and click Click [Extension setting editing]. Click [Editing the power plan]. Select [New], [Edit], [Copying and adding], [Setting to active], [Delete] or [Restoring the power plan set at the factory]. Make the settings according to the screen instructions as necessary. Click [Close].
Page 57 Disable Wake Up from wired LAN function when it is not needed. This reduces power consumption in Standby/ Hibernation. To confirm current settings, click [start] - [All Programs] - [Panasonic] - [Power Saving Utility] to view [Wired LAN standby power saving function].
Page 58 Customizing the Power Setting When using this computer with the battery pack only We recommend against using applications that place a significant load on the CPU. Some screen saver place a large burden on the CPU even when you are not operating the computer. We recommend that you do not use a screen saver.
Page 59 Customizing the Power Setting Setup Click [start] - [All Programs] - [Panasonic] - [Power Saving Utility]. Click [Enable] for each function. Click [OK] in the confirmation screen that appears. To enable “Intel video driver power saving function” Select [Enable], and slide the slide bar to the “Maximum Battery”...
Page 60 Sleep/Standby or Hibernation Functions Starting Up Your Computer Quickly sleep/ standby or hibernation functions allow you to shut off the computer without closing Windows 7 Windows XP programs and documents. You can quickly return to the programs and documents that you were working on before sleep or hibernation.
Page 61 Windows XP Failing the password input while resuming from hibernation: • At the next resume, Panasonic boot screen will appear. At this time, do not start the Setup Utility and do not change settings. Otherwise, resume may not operate correctly.
Page 62 The computer does not enter standby or hibernation immediately after resuming. Wait approximately one minute. Entering/Resuming from Sleep/Standby or Hibernation To enter sleep/standby or hibernation Close the display, or slide the power switch (A) until a beep sounds. <CF-C1 Series> <CF-F9 Series> Sleep/ Standby: The power indicator (A) blinks green. Windows 7 Windows XP Hibernation: The power indicator (A) goes off.
Page 63 Sleep/Standby or Hibernation Functions Windows XP To enter standby, click [start] - [Turn Off Computer] - [Stand By]. To enter hibernation, click [start] - [Turn Off Computer], then press and hold Shift and click [Hibernate]. CAUTION While the computer is entering sleep/ standby or hibernation Windows 7...
Page 64 Sleep/Standby or Hibernation Functions To resume from sleep/standby or hibernation Open the display, or slide the power switch (A). <CF-C1 Series> <CF-F9 Series> In the default setting, the Windows password will be requested to resume. CAUTION Do not perform the following operations until resuming is complete. After the display is resumed, wait approximately 15 seconds (normally) or 60 seconds (when the computer is on a network).
Page 65: Security Measures
Security Measures You can set the password and/or enable/disable some functions for security purpose. Another security measure <Only for model that supports TPM> • Embedded Security (TPM) ( page 142): For further information, refer to the Installation Manual of “Trusted Platform Module (TPM)”.
Page 66 Security Measures Preventing Your Computer from Unauthorized Use You can set a start-up password to prevent your computer from unauthorized use. Set the password ( page 65), and select [Enabled] in [Password on boot] in the [Security] menu of the Setup Utility ( page 142).
Page 67 CD/DVD Drive <Only for CF-F9 Series> NOTE Connect the AC adaptor if writing operation takes a long time. If the remaining battery power becomes low and the power is not supplied, writing operation may not be completed. Use Windows features or writing software to write to discs (e.g. “Using Roxio Creator LJB” page 81).
Page 68 CD/DVD Drive When opening/closing the disc cover When the computer is on, use the drive power/open switch. ( page When closing the disc cover, press down the center of the disc cover (position indicated “CLOSE”) to ensure that the cover is locked. Do not access the drive until after the disc cover is closed and the CD/DVD drive indicator changes to lighting from blinking.
Page 69 If discs get very dirty, wipe with a moist, soft cloth from the center toward the edge, then wipe again with a dry cloth to take up remaining moisture. <For recordable/rewritable discs> It is recommended to use the Panasonic disc cleaner. Do not use a cloth. How to hold a disc...
Page 70 CD/DVD Drive Turning On/Off the CD/DVD Drive When you are not using the CD/DVD drive, you can turn the drive power off to minimize power consumption. When you want to minimize power consumption (example) Set [Optical Drive Power] in the Setup Utility to [Off]. ( page 137) The drive power remains off when the computer is started up.
Page 71 CD/DVD Drive Turning on or off immediately There are two methods, as follows. Slide the drive power/open switch (A) to the left. • Each time you slide the switch, you will hear a beep and the drive power will turn on or off.
Page 72 To turn the power on again after it has turned off: See “Turning on or off immediately” ( page To restart this utility after selecting [Exit], click [start] - [All Programs] - [Panasonic] - [Opti- cal Disc Drive Power-Saving Utility], or restart the computer.
Page 73 CD/DVD Drive Disc Information You can read from/write to the following discs. CD-R CD-RW Recordable *2*3*4 *4*5 *4*5*6 *4*5 *4*5 DVD-RAM DVD-R DVD-RW You can read from the following discs. CD-ROM CD DIGITAL CD TEXT CD-EXTRA Video CD Photo CD AUDIO VIDEO CD *5*8...
Page 74 When playing back videos recorded over both layers of a one-sided, dual-layer disc, videos or sounds are interrupted at the point where the recording layers change. Recommended discs for writing Visit the following web site: http://pc-dl.panasonic.co.jp/itn/support/disk/diskinfo.html Using DVD Discs To play DVD-Video or MPEG2 files, you need to use DVD playback software such as WinDVD ( page 78).
Page 75 CD/DVD Drive Inserting/Removing a Disc Turn on the computer. Slide the drive power/open switch (A) to the right. If the CD/DVD drive indicator is off (drive power is off), it will take some time for the drive power to turn on, and for the disc cover to open.
Page 76 CD/DVD Drive Close the disc cover. Press down the center of the disc cover (position indicated “CLOSE”) to ensure that the cover is locked. NOTE To remove a disc when the disc cover cannot be opened or when the computer is powered off: •...
Page 77 Confirm whether the CD/DVD drive power is on. If the drive power is off, turn it on. Click [start] - [All Programs] - [Panasonic] - [Optical Disc Drive Letter-Setting Utility]. (Click in [New drive letter], click the drive letter, and click [OK].
Page 78 [start] - [All Programs] - [InterVideo WinDVD] - [InterVideo Windows 7 Windows XP WinDVD for Panasonic]. Use WinDVD as administrator. If the AutoPlay screen is displayed after a disc is set in the CD/DVD drive, click [Play DVD movie-using InterVideoWinDVD].
Page 79 WinDVD Do not install another player software together with WinDVD. Doing so may interfere with smooth playback. Some DVD-Video discs contain the player software and start installing. In this case, cancel the installation as soon as possible. If you accidentally installed another player software and find a problem in playback, try either of the following procedures.
Page 80 WinDVD Windows XP Log on to Windows as an administrator. Input [c:\util\windvd\setup.exe] in [start] - [Run] and click [OK]. Follow the on-screen instructions and install WinDVD. When the [License Agreement] screen appears, click [Yes] if you agree to the terms. Refer to “LIMITED USE LICENSE AGREEMENT”...
Page 81 Writing to CD/DVD <Only for CF-F9 Series> Applicable Media Refer to the Disc Information ( page 73). Refer to the software’s online manual (below). About Copies When writing to discs, make sure that you are not infringing upon any copyrights. It is illegal to copy audio CDs for non-personal use.
Page 82 Writing to CD/DVD Usage Precautions When an external CD/DVD drive has been connected Do not turn the CD/DVD drive power off on this computer when writing to a disc in an external CD/DVD drive. Turning the power off may result in a malfunction, such as an interruption in the external CD/DVD drive operation. Windows 7 Using DVD-RAM for Windows 7 Formatting must be executed to write a file to a DVD-RAM.
Page 83 Writing to CD/DVD Formatting method When formatting is executed, data recorded on the disc is erased. Back up data as required. Set a DVD-RAM in the CD/DVD drive. Close all applications that use DVD-RAM. Click (Start) - [Computer], right-click the CD/DVD drive and click [Format]. Select the settings and click [Start].
Page 84 Writing to CD/DVD Logical format method Formatting software and drivers required to conduct each type of formatting have been installed on this computer. When formatting is executed, data recorded on the disc is erased. Back up data as required. Log on to Windows with the administrator authority. Set a disc in the CD/DVD drive.
Page 85 Writing to CD/DVD Notes During Use If you have uninstalled Roxio Creator LJB accidentally Reinstall it by following the steps below. Windows 7 (Start) and input [c:\util\sonic\emc] in [Search programs and files], and press Enter. Click Right-click [setup] in [emc] folder and click [Run as administrator]. If there are two or more “setup”...
Page 86: Pc Card
Insert the PC Card with the label side up until it securely fits in the slot. For further information, refer to the instruction manual of the card. <For CF-F9 Series> After the card is inserted, bend the eject button (A). <CF-C1 Series> <CF-F9 Series>...
Page 87 [Stop]. Follow the on-screen instructions. This step is not necessary when removing the card after turning off the computer. Remove the card. <For CF-C1 Series> Push the eject button. Draw the card straight out. <For CF-F9 Series>...
Page 88 PC Card When a card is inserted, power consumption increases. Remove the card when it is not in use, especially when operating by battery power. To connect peripheral devices (SCSI, IEEE1394, etc.) using a PC Card, follow the steps below (one example). Connect the peripheral device to the card.
Page 89 Smart Card <Only for CF-C1 Series with Smart Card slot> You need software to use a Smart Card. CAUTION Do not: • Hit, bend, or drop the card. • Touch the contact part with fingers or metal object. • Place the card in very hot location for a long time.
Page 90 Note that Panasonic assumes absolutely no liability for any loss of data recorded by the user, or any other damages, directly or indirectly.
Page 91 [SD Memory Card], then click [Stop]. Follow the on-screen instructions. This step is not necessary when removing the card after turning off the computer. <CF-C1 Series> <CF-F9 Series> Remove the card. Press the card so it comes out of the slot.
Page 92: Expanding Memory
Expanding Memory Use RAM modules that comply with the specifications below. Using any other module may cause malfunction or result in computer failure. RAM module specifications: DDR3 SDRAM, 204 pins, SO-DIMM, 1.5 V, PC3-6400 CAUTION Use recommended RAM module products. Do not use non-recommended RAM modules. Non-recommended RAM modules may not operate properly, and may cause damage to your computer.
Page 93 Disconnect the AC adaptor and remove the battery pack. Remove the screw (A) and the cover on the bottom of the computer. • Use the appropriate screw driver so as not to strip the thread of screw. <CF-C1 Series> <CF-F9 Series>...
Page 94 RAM module and the protrusion (C) of the RAM module slot is in the same direction. The gold terminals are visible at this point. RAM module is at an angle of 20 - 30 with the horizontal line. ° ° <CF-C1 Series> <CF-F9 Series> RAM Module Slot RAM Module Gold Slot Terminals...
Page 95 Insert the RAM module parallel to the slot firmly until the gold terminals are invisible. If it is hard to insert the RAM module, do not try forcibly but check the module’s direction. <CF-C1 Series> <CF-F9 Series> Press the RAM module down until the right and left hooks (D) lock into place.
Page 96 Expanding Memory Removing the RAM Module Carefully open the left and right hooks (E). The RAM module will be raised. <CF-C1 Series> <CF-F9 Series> Carefully remove the RAM module from the slot. <CF-C1 Series> <CF-F9 Series> Set the cover and battery pack back.
Page 97: Port Replicator
• AC adaptor (CF-VEBU08U/CF-VEBF81W) • External display (CF-VEBU08U/CF-VEBF81W) The LAN port on the computer is disabled (CF-VEBU08U). The external display port on the computer is disabled (CF-VEBF81W). <For CF-C1 Series> Connect or disconnect the port replicator while the computer power is turned off.
Page 98: External Display
External Display You can switch the output destination to an external display. Connect the external display to the external display port (A). <CF-C1 Series> <CF-F9 Series> Switching the Display Mode The following are the display modes. Computer only The screen is displayed only on the internal LCD.
Page 99 External Display Using Graphics Driver Right-click the desktop, and click [Graphics Properties]. Click [Multiple Displays]. Select the display in [Operating Mode]. To display the image only on the internal LCD, select [Single Display] and select [Built-in Display] for [Primary Display]. To display the same image on both the internal LCD and an external display, select [Clone Displays].
Page 100 External Display It may take some time to switch between displays depending on the displays used. ® Use the [Intel Graphics and Media Control Panel] screen to set the color depth, resolution and refresh rate. When you change the output destination after Windows starts up, do not press any key until switching is complete. You cannot use the simultaneous display until Windows starts up.
Page 101 External Display Using Extended Mode Windows XP To switch to the extended desktop Click [start] - [Control Panel] - [Other Control Panel Options] - [Intel(R) Graphics and Media] - [Display Devices]. Click [Extended Desktop], and make the settings for [Primary Device] and [Secondary Device].
Page 102 External Display An error may occur when resuming from the sleep / standby or hibernation. In such cases, Windows 7 Windows XP change the mouse pointer to the standard pointer with the following procedure: Click (Start) - [Control Panel] - [Hardware and Sound] - [Mouse]. Windows 7 Click [start] - [Control Panel] - [Printers and Other Hardware] - [Mouse].
Page 103: Usb Devices
USB Devices Connecting/Removing USB Devices To connect the device Connect the USB device to one of the USB ports (A). <CF-C1 Series> <CF-F9 Series> For further information, refer to the instruction manual of the USB device. To remove the device Disable the USB device.
Page 104 USB Devices CAUTION Do not remove a USB device while your computer is in the sleep/ standby or hibernation. Windows 7 Windows XP Save important data and close all applications. NOTE You may need to install the driver for the USB device. Follow the instruction manual of the USB device. You may need to install the driver again when connecting the device to another port.
Page 105: Fingerprint Reader
Fingerprint Reader <Only for model with Fingerprint Reader> <CF-C1 Series> <CF-F9 Series> Fingerprint Reader NOTE Enrollment and authentication is unavailable to an extremely minority of people including those whose fingerprints give little data for personal identification. How to Use the Fingerprint Reader This section explains how your fingerprints are enrolled and authenticated.
Page 106 We shall not be liable for any loss or damage whatsoever resulting from your Fingerprint device or neglect of Fingerprint device use, or any data loss resulting from such developments as Fingerprint authentication device malfunctioning. <CF-C1 Series> To protect the fingerprint sensor, be sure to close the cover when not using the fingerprint reader.
Page 107: Security Functions
Fingerprint Reader To access the online manual This manual describes Step 2, and the initial part of Step 4. For further steps, refer to the Protector Suite Help menu. Click (Start) / [Start] - [All Programs] - [Protector Suite] - [Control Center] - [Help] - [Help]. Windows 7 Windows XP Precautions...
Page 108 Fingerprint Reader Click [Next]. Installation starts. Follow the on-screen instructions. When the “Protector Suite *.* has been successfully installed.” message appears, click [Finish]. At the confirmation message, click [Yes]. The computer restarts. Log on to Windows as an Administrator. The “Fingerprint software Icon” appears in the notification area.
Page 109 Fingerprint Reader NOTE The numbers of fingers to register for the fingerprint sensor may vary depending on the characteristics of fingers. • Enrollment to the hard disk All enrolled fingerprints are stored on the hard disk. There are no limits for the numbers of fingers to register, although there is a limit for the numbers of those for Power-on Security.
Page 110 Fingerprint Reader More Advanced Security You can increase your computer’s security level by setting the BIOS level described in this section. There is [Fingerprint Security] in [Security] menu in the Setup Utility. Can be changed only when [Set Supervisor Password] is set.
Page 111 Fingerprint Reader Useful Information Backup The file described below is necessary for recovering the Fingerprint authentication data. Back up this file periodically in a safe location such as removable disk to avoid data loss resulting from some accidents. We recommend you to store the file in a removable disk or network drive because the benefit of Fingerprint authentication security can be reduced if you keep the file in the internal hard disk drive.
Page 112 Fingerprint Reader Limitations in Use Password Bank limitations: The following web pages cannot be supported. Web pages which are created by the following technologies: • Web forms created on the fly using JavaScript. • Web forms which looks as one form (e.g. login field, password field), but internally created with two independent forms. •...
Page 113 Fingerprint Reader NOTE The data enrolled in the fingerprint sensor is not image data. You cannot restore fingerprint image data from the data enrolled in the fingerprint sensor. Disable Power-on Security. Log on to Windows as an Administrator. Click (Start) / [start] - [All Programs] - [Protector Suite] - [Control Center].
Page 114 Fingerprint Reader • The computer restarts. Starting Over If the specific solutions for your problem in Fingerprint Reader ( page 164) do not work, you can use these instructions as the last measure and start over. However, please note that you can lose your data - passwords, secret keys and fingerprints. Log on to Windows as an Administrator.
Page 115 Connect the computer and the telephone jack (A) using the telephone cable (B). Hold the cable so that the shape of the connector (C) matches the port, and insert fully until it clicks. <CF-C1 Series> <CF-F9 Series> Windows 7...
Page 116 Modem Windows XP Click [start] - [Control Panel] - [Printers and Other Hardware] - [Phone and Modem Options] and change the settings as necessary. NOTE Do not enter sleep/ standby or hibernation during communications. Windows 7 Windows XP To remove the cable, press and hold the lever and pull out.
Page 117 Modem Ring Resume Function The computer automatically resumes from sleep/ standby when the telephone connected to the Windows 7 Windows XP modem rings. You will need software to keep the computer in an idle state waiting for a phone call, and if you prefer, to turn the computer to Windows 7 sleep/ standby again afterward.
Page 118 Modem Click [Device Manager] in [start] - [Control Panel] - [Performance and Maintenance] - [System] - [Hardware]. Double-click [Modems], and then double-click the internal modem. Click [Power Management], add the check mark for [Allow this device to bring the computer out of standby], then click [OK]. To set the time to return the computer to sleep/standby The computer will enter sleep/...
Page 119: Turn Off Your Computer
Turn off your computer. Do not use sleep/ standby or hibernation. Windows 7 Windows XP Connect the cable. Connect the LAN port (A) and the network system (server, HUB, etc.) using a LAN cable. <CF-C1 Series> <CF-F9 Series> Turn on the computer.
Page 120 Power On by LAN/Wake Up from Wired LAN NOTE Even when a password is set in the Setup Utility and [Password on boot] is set to [Enabled], entering the password is unnecessary for turning on or resuming the computer. Connect the AC adaptor. The Power On by LAN function is off under the following conditions: •...
Page 121 Enabling/Disabling the Wake Up from wired LAN function When the Wake Up from wired LAN function is enabled, the computer automatically resumes from sleep or hibernation when the computer is accessed from the network server via the internal LAN port. (Default setting) The Wake Up from wired LAN function can be switched to enable/disable by performing the following procedure.
Page 122 124) Windows XP The Wireless Switch To disable all wireless communication <CF-C1 Series> Switch to OFF. To enable wireless communication Switch to ON. <CF-F9 Series> In the default setting, the wireless switch enables all wireless devices when it is set to ON.
Page 123 Disabling/Enabling Wireless Communication The Wireless Switch Utility icon The icon appears when click ( when click ) on the notification area. It shows the status of wireless devices. Windows 7 • : Indicates that the wireless devices are enabled. • : Indicates that the wireless devices are off.
Page 124: Installing The Utility
Disabling/Enabling Wireless Communication To check the wireless communication status Windows 7 Click on the notification area and place the cursor over the Wireless Switch Utility icon. Windows XP Place the cursor over the Wireless Switch Utility icon on the notification area. NOTE Do not turn on/off the switch repeatedly at too short intervals.
Page 125: Status Indication
Disabling/Enabling Wireless Communication Checking the status of the Wireless Connection NOTE The Wireless Switch Utility should also be installed so that the Wireless Connection Disable Utility works. The utility does not automatically disable the Bluetooth connection. Status indication After installation, the Wireless Connection Disable Utility is automatically started after a user is logged in. An icon appears when click on the notification area.
Page 126: Wireless Lan
NOTE Communication is established through the wireless LAN antenna (A). Do not block the antenna area with your hand or body. <CF-C1 Series> <CF-F9 Series> Do not use the Fast User Switching function. The wireless LAN cannot perform. The transmission rate will be lower when a microwave oven is used.
Page 127 Wireless LAN Using the Wireless LAN Function Before using a wireless LAN, turn the wireless LAN communication on. Turning on/off the wireless LAN communication Slide the wireless switch to turn on/off wireless LAN. ( page 122) When turning on wireless LAN If you cannot turn on wireless LAN using the wireless switch, confirm the Wireless Switch Utility setting ( page 122).
Page 128 Wireless LAN Double-click on the notification area. ® The [Intel PROSet/Wireless] screen appears. When is displayed, skip step When you double-clicked in step 2, slide the wireless switch to turn on. Click [Profiles...] at the lower right corner of the window, and click [Add...]. Enter the profile name and wireless network name (SSID), and make other necessary changes, then click [Next].
Page 129 Wireless LAN When the icon on the notification area is changed to , the wireless LAN setting is complete. Click [Close]. NOTE The settings depend on the network environment. For further information, ask the system administrator or the person in charge of the network. If you use the stealth type wireless LAN access point which restricts automatic detection of the wireless LAN access point, take the following procedure.
Page 130 Wireless LAN Setting the Wireless LAN Standard IEEE802.11a (802.11a) Click on the notification area and click Windows 7 Click on the notification area. Windows XP Click [802.11a Enabled] or [802.11a Disabled]. NOTE In some countries, communication using IEEE802.11a (5 GHz wireless LAN) standard is restricted by law. The Wireless Switch Utility icon ( ) indicates the on/off status of wireless LAN and/or wireless WAN, not the setting of IEEE802.11a.
Page 131: Bluetooth
NOTE Communication is established through the Bluetooth antenna (A). Do not block the antenna area with your hand. <CF-C1 Series> <CF-F9 Series> When Bluetooth is installed, [Bluetooth] is displayed in the [Advanced] menu of Setup Utility. To use Bluetooth, set [Bluetooth] to [Enabled] (default) in the [Advanced] menu of the Setup Utility.
Page 132: Fast User Switching Function
Bluetooth Fast User Switching Function When switching to a different user with the Fast User Switching function, Bluetooth may not be used. In this case, log off all users without using Fast User Switching function and perform the operation once more. If the problem persists, restart the computer.
Page 133: Inserting/Removing The Hard Disk Drive
Hard Disk Drive <Only for CF-C1 Series> Inserting/Removing the Hard Disk Drive To change your hard disk drive, contact your technical support office. CAUTION Back up all the important data before removing the hard disk drive. If you need to read the hard disk data on another computer for repair or any other purpose, set [Hard Disk Lock] to...
Page 134 Hard Disk Drive To insert Insert the hard disk drive until it securely fits in the slot. CAUTION Confirm that the latch is surely locked so that the hard disk does not fall when you carry the computer. NOTE You can erase the data before changing the hard disk drive ( page 179).
Page 135: Setup Utility
Starting the Setup Utility Turn on or restart the computer. Press while [Panasonic] boot screen is displayed soon after the computer starts the startup procedure. When [Enter Password] is displayed, enter your password. When you start the Setup Utility with Supervisor Password You can make the settings of all items of the Setup Utility.
Page 136 Setup Utility Information Menu Underlined items are the factory presets. Language English Japanese Product Information Model No. Computer information (cannot be changed.) Serial No. System Information Processor Type Computer information (cannot be changed.) Processor Speed Memory Size Available Memory Hard Disk BIOS Information BIOS Computer information...
Page 137 Setup Utility Main Menu Underlined items are the factory presets. System Date [xxx xx/xx/xxxx] • Day of the Week/Month/Day/Year. • You can use Tab to move the cursor. System Time [xx:xx:xx] • 24-hr. style. • You can use Tab to move the cursor. Main Configuration Touch Pad Disabled...
Page 138 Setup Utility Battery Charging LED Mode Single • Only for CF-C1 Series Multiple • You can use the LED indicators on the front of the computer to check the battery charging status page 41). When [Single] is selected, the battery charging status is indicated by the single LED.
Page 139 • Set the PC Card Slot operation mode. Compatible Normally select [Standard]. SD Slot Disabled Enabled Smart Card Disabled • Only for CF-C1 Series with Smart Card slot Enabled USB Port Disabled Enabled Legacy USB Support Disabled • <CF-C1 Series>...
Page 140 Setup Utility Boot Menu Boot Mode Fast Normal Boot Option Priorities <CF-C1 Series> <Default order> Boot Option #1 USB Floppy Disk Boot Option #2 Hard Disk Boot Option #3 CD/DVD Drive Boot Option #4 Boot Option #5 USB Hard Disk...
Page 141 • When you select [Disabled] in the following menu, the disabled [Boot Option] is ignored and the boot device in the next [Boot Option] operates. Hard Disk CD/DVD Drive USB Floppy Disk USB Hard Disk USB CD/DVD Drive Disabled The operation is confirmed by Panasonic USB floppy disk drive (optional: CF-VFDU03U). For CF-C1 Series: [Boot Option (#1 to #7)]...
Page 142 • When [Setup Utility Prompt] is set to [Disabled], the message “Press F2 for Setup / F12 for LAN” Enabled is not displayed on [Panasonic] boot screen. However, F2 and F12 will work even if the message is not displayed.
Page 143 Setup Utility Exit Menu Save Values and Reboot To reboot the system after saving the changes. Reboot Without Saving Changes To reboot the system without saving the changes. Save Options Save Current Values To save the changes for all Setup options. Load Previous Values To load previous values for all Setup options.
Page 144 Outlook Express. Some characters of website and e-mail may not be enlarged. Preparation Close all of the applications before using “Icon Enlarger”. Click [start] - [All Programs] - [Panasonic] - [Icon Enlarger]. Select the size. Click [OK]. The screen will be displayed in the selected size.
Page 145 You can magnify the specific part of the screen. Activating the Loupe Utility Click (Start)/ [start] - [All Programs] - Windows 7 Windows XP [Panasonic] - [Loupe Utility]. Click [OK]. appears on the notification area. If does not appear, click on the notification area. Windows 7...
Page 146 Loupe Utility The magnified text or image in the loupe window is fixed at the moment that the part is magnified (e.g., at the moment you press and hold Alt and right-click). To reflect the change you made on the original screen to the loupe window, click the loupe window.
Page 147 Cannot boot from a floppy disk Depending on the floppy disk you are using, the computer may not boot properly. The operation is confirmed by Panasonic USB floppy disk drive (optional: CF-VFDU03U) when the computer boots from the floppy disk.
Page 148 Troubleshooting (Advanced) The computer does not enter sleep/standby or hibernation If a peripheral is connected, first remove the peripheral, and then enter Windows 7 sleep/ standby or Windows XP hibernation. If the computer still fails to enter sleep/ standby or hibernation, restart the computer. Windows 7 Windows XP It may take a minute or two to enter...
Page 149 Troubleshooting (Advanced) Check a disk error using the following procedure: Remove all peripheral devices (including an external display). Windows 7 Click (Start) - [Computer], right-click [Local Disk (C:)] and click [Properties]. Windows XP Click [Start] - [My Computer], right-click [Local Disk(C:)] and click [Properties]. Click [Tools] - [Check Now].
Page 150 Troubleshooting (Advanced) Some applications may not work properly When switching to a different user with the Fast User Switching function, the following problems may occur: • Some applications may not work properly. • Key combination with the Fn may not work. •...
Page 151 Troubleshooting (Advanced) Problems with Battery The battery indicator lights red The remaining battery power is very low (the charge is approx. 9% or less). Connect the AC adaptor. You can use the computer when the battery indicator light is orange. If you do not have an AC adaptor, save your data and power off your computer.
Page 152 Troubleshooting (Advanced) Problems with Cursor The cursor cannot be controlled properly Make sure [Touch Pad] is set to [Enabled] on the [Main] menu of the Setup Utility. ( page 137) With the following procedure, check that no external mouse driver is installed. If it is installed, it may not possible to use the Touch Pad.
Page 153 Troubleshooting (Advanced) Problems with Display Screen is too dark or too bright Press Fn + F2 or push (LCD Brightness Up) button (becomes brighter). Press Fn + F1 or push (LCD Brightness Down) button (becomes darker). If the screen becomes darker after disconnecting the AC adaptor: The computer has different set brightness levels for when the AC adaptor is connected and for when it is not connected.
Page 154 Troubleshooting (Advanced) Nothing is displayed on the screen Check if the power-saving mode is active. • If the power indicator is lit: The display is turned off. Press a key with no independent effect, such as Ctrl or Shift. Do not use a key that may make a selection (Enter, Space, Esc, Y, N, numeric keys, and so on). •...
Page 155 When more than one power plan is displayed, click [Change plan settings] for the power plan you want to delete and click [Delete this plan]. The [Panasonic] boot screen is not displayed on the external display As soon as the computer starts up, press F2 or Del several times and start the Setup Utility.
Page 156 137). Change the setting back to [Normal], or if continuing with [Replace] selected, use Ctrl in place of Fn. <Only for CF-C1 Series> Cannot point the correct position using the included digitizer pen Perform the screen calibration. ( page...
Page 157 Troubleshooting (Advanced) <Only for CF-C1 Series> When you want to use the input panel Windows 7 Touch the screen, Input Panel (a part of) may appears at left side on display. Windows XP Click on the taskbar. For information about how to use it, click on the input panel and click [Help Topics] or [Tutorial].
Page 158 Troubleshooting (Advanced) <Only for CF-F9 Series> Cannot play back TV programs recorded on a commercial DVD recorder In order to play media other than DVD-RAM, they must be finalized using the DVD recorder. Check whether the DVD is supported in this computer. ( page <Only for CF-F9 Series>...
Page 159 Troubleshooting (Advanced) <Only for CF-F9 Series> When a disc is inserted, it is not played automatically Remove the disc and reinsert it. • If an AutoPlay CD does not start after the computer resumes from the sleep or hibernation, remove the disc from the drive, then reinsert the disc again after a 15 second wait.
Page 160 Troubleshooting (Advanced) Windows XP In the following cases, it is not possible to turn off using [Manual Switching] of the Optical Disc Drive Power-Saving Utility: • When WinDVD is running • During writing or reading of a disc • When the drive is being used by an application such as Roxio Creator LJB <Only for CF-F9 Series>...
Page 161 Troubleshooting (Advanced) <Only for CF-C1 Series> A clacking sound is heard while operating the screen with the digitizer pen The built-in microphone is picking up the pen operation sounds. Mute the microphone. The audio is distorted During audio playback, operating a key with Fn may cause distortion of the sound. Stop playing and start again.
Page 162 Troubleshooting (Advanced) Depending on the device connected, the computer may not recognize when the device is connected or disconnected, or the device may not operate properly. Use the following procedure: Windows 7 Click (Start) - [Computer] - [System properties] - [Device Manager]. Windows XP Click [Start] - [Control Panel] - [Performance and Maintenance] - [System] - [Hardware] - [Device Manager].
Page 163 Troubleshooting (Advanced) Windows XP Click [Start] - [Control Panel] - [Performance and Maintenance] - [System] - [Hardware] - [Device Manager]. Double-click [PCMCIA adapters], and double-click the relevant device. In [Resources], if [Conflicting device list] shows [No conflicts], there is no conflict. Read the instructions supplied with the PC Card, or consult the PC Card manufacturer.
Page 164 [Battery (Windows XP Standard)] in [CPU Idle Setting], and return [Power schemes] in [Power Options] to [Panasonic Power Management]. As a result of the LAN communications speed being extremely low, or a wireless LAN connection being lost, if the CPU power-saving setting is set, then when the LAN or whatever is not used, it is recommended to return to the above settings.
Page 165 Troubleshooting (Advanced) Some limited functions (e.g. deleting passport) are available without a functional sensor. In case of deleted operation, it is necessary to cancel the fingerprint verification operation to get to the password dialog. User cannot use enrolled finger. (e.g. injury) It is strongly recommended to enroll at least two fingers to avoid this problem.
Page 166 Troubleshooting (Advanced) Replacing sensor If you need to replace a non-functioning fingerprint reader, follow this procedure. Enrollment to the hard disk: If enrollment to hard disk is used, “Protector Suite” has not stored any data on the device and therefore has no problem to continue after you replaced the sensor.
Page 167 Troubleshooting (Advanced) Removing data from the reader When enrollment to the device is used, passport data is stored to the device. To remove it, go to the [Delete user data] passport wizard and delete existing passports. “Lift Finger” is displayed during operation You can temporarily disable the fingerprint sensor with the following procedure.
Page 168 Troubleshooting (Advanced) Click (Start)/ [start] - [All Programs] - [Accessories] - [Command Prompt]. Windows 7 Windows XP Input [getmac/fo list /v], and press Enter. Windows 7 Insert a space between “fo” and “list”, and between “list” and “/v”. Input [ipconfig /all], and press Enter. Windows XP Wireless LAN’s MAC address: Make a note of the 12-digit string of alphanumerics displayed on the wireless LAN’s “Physical Address”...
Page 169 Confirm that [Wireless LAN] is set to [Enabled]. ( page 138) • Wireless LAN power supply Slide the wireless switch to the right (ON). <CF-C1 Series> <CF-F9 Series> This computer uses channels 1 through 11 when using IEEE802.11b/g. Check the channel being used by the access point.
Page 170 Troubleshooting (Advanced) Windows XP When is displayed on the notification area: Right-click , and click [Open Network Connections]. When is not displayed on the notification area: Click [start] - [Control Panel] - [Network and Internet Connections] - [Network Connections]. Right-click [Wireless Network Connection], and click [Properties] - [General] - [Internet Protocol (TCP/IP)] - [Properties].
Page 171 Troubleshooting (Advanced) Communications with access point are cut off Shorten the distance between the computer and the access point, and try the detection again. If there are multiple access points aside from the access point to which this computer is connected, confirm that different channels have been set for each access point.
Page 172: Hardware Diagnostics
Touch Pad Touchscreen Only when a port replicator with CD/DVD drive is connected. (CF-C1 Series) When the PC-Diagnostics Utility is running a loud beep will sound, so do not use headphones as this time. Note that a loud beep will also sound when headphones are not used.
Page 173 During the diagnostic check, do not remove the AC adaptor, or attach any peripheral devices. Turn on or restart the computer, and press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password.
Page 174 Enter Press At the confirmation message, select [Yes] and press Enter. The computer will restart. While [Panasonic] boot screen is displayed, press and hold until “Please Wait” Ctrl appears at the bottom of the display. When the PC-Diagnostic Utility starts up, it will automatically begin the diagnostic check for all hardware components.
Page 175: The Computer
Hardware Diagnostics Click the icon for the hardware that is not to be checked, so that the icon is displayed in gray (B). e.g. hard disk When running a check on the memory or the hard disk, clicking the icon once will turn on the extended diagnostic check (“FULL”...
Page 176: Hard Disk Backup/Restore Function
[Backup and Restore Center] and [System Recovery Options] allow you create a backup of the entire hard disk data, which can be used to recover from hardware failure. Panasonic Corporation will bear no responsibility for any damage suffered (including loss of data) as a result of the use of this function.
Page 177 <CF-C1 Series> Turn off the computer and insert the CD/DVD drive to the computer. Turn on the computer, and press F2 or Del while [Panasonic] boot screen is displayed. • The Setup Utility starts up. • If the password is requested, enter the Supervisor Password.
Page 178 • At the confirmation message, select [Yes] and press Enter. • The computer will restart. Press F2 or Del while [Panasonic] boot screen is displayed. • The Setup Utility starts up. • If the password is requested, enter the Supervisor Password.
Page 179 If you need to erase highly confidential data, we recommend that you contact a company that specializes in this process. Panasonic Corporation will bear no responsibility for losses or damages suffered as a result of the use of this utility.
Page 180 At the confirmation message, select [Yes] and press Enter. The computer will restart. Press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password. Set the Product Recovery DVD-ROM Windows 7 into the CD/DVD drive.
Page 181: Error Message
Error Message Follow the instructions below when an error code or message appears. If the problem persists or if the error code/message displayed is not shown here, contact your technical support office. Error Message Solution Bad System CMOS An error has occurred in the memory of system settings. This occurs when the memory content is changed by an unexpected program operation, etc.
Page 182 The following procedures are example. It is different according to your environment. Contact your technical support office. Press Ctrl + P when [Press <CTRL - P> to enter Intel(R) ME Setup] is shown after the [Panasonic] boot screen disappears. Press 1.
Page 183 ® Intel Active Management Technology Select [Intel(R) ME General Settings] and press Enter. Select [Activate Network Access] and press Enter. Press Y on the [Caution] screen. Select [Previous Menu] and press Enter. Select [Intel(R) AMT Configuration] and press Enter. Press Enter. Select [SOL/IDER] and press Enter.
Page 184: Installing The Driver
® Intel Active Management Technology When an unintended character is entered, we recommend that you make a memo of the key you pressed and the character that was entered. Keyboard used Difference examples Intended character “ £ Entered character ¦ “...
Page 185 Active Management Technology Release AMT configuration Turn on the computer, and press while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the password is requested, enter the Supervisor Password. If the Supervisor Password is not set, select the [Security] menu, then set Supervisor Password.
Page 186 Depending on your network environment, it may take about 1 minute to start up PC Information Viewer. Running PC Information Viewer Click (Start)/ [start] - [All Programs] - [Panasonic] - [PC Information Viewer] - [PC Windows 7 Windows XP Information Viewer].
Page 187 You can also save a copy of the screen to a file using the following procedure: Click (Start)/ [start] - [All Programs] - [Panasonic] - [PC Information Viewer] - [Screen Copy]. Windows 7 Windows XP At the time of purchase, the computer is set so that a copy of the screen can be saved to a file by pressing Ctrl + Alt + F7.
Page 188 When you log on to Windows for the first time, the screen to enable the automatic display function of PC Information Popup appears. Perform the following steps. Click [1 Notification From Panasonic]. Click [Yes] on the confirmation screen. The function is enabled and automatically inform you of the information on how to use the hard disk.
Page 189 Hard Disk Handling can be displayed with the following steps as well. Click (Start)/ [start] - [All Programs] - [Panasonic] - [On-Line Manuals] - [Hard Disk Handling]. Windows 7 Windows XP Confirm information on how to use the hard disk Right-click PC Information Popup icon on the notification area and click [Check for information now].
Page 190 PC Information Popup NOTE When the icon is not displayed, click (Start)/ [start] - [All Programs] - [Panasonic] - [PC Windows 7 Windows XP Information Viewer] - [PC Information Popup].
Page 191: Protecting Your Computer From Viruses
Protecting Your Computer from Viruses A computer virus propagates through infections from one computer to another. Some viruses are highly malicious, destroying computer data, or preventing the computer from starting up properly. When “Check your computer security” is displayed Click (red icon) on the notification area and make the appropriate settings.
Page 192: Technical Information
Technical Information Network Connections and Communications Software Close the communications software before using the power saving function. If the power saving function (sleep or hibernation) is activated while communications software is used, the network connection may be interrupted, or the performance may be adversely affected. In this case, restart the computer. In a network environment: Set [Never] for [Put the computer to sleep:] and [Hibernate after].
Page 193 ® is a registered trademark of Absolute Software Corp. • Computrace • Bluetooth™ is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation. ® • PS/2 is a registered trademark of International Business Machines Corporation. • Corel, InterVideo, WinDVD™, the InterVideo logo and the Corel logo are trademarks or registered trademarks of Corel Corporation and/or its subsidiaries in Canada, the United States and/or other countries.

This manual is also suitable for:

Cf-f9 series

Panasonic CF-C1 Series Reference Manual

Quick Links

Reference Manual

Related Manuals for Panasonic CF-C1 Series

Summary of Contents for Panasonic CF-C1 Series

This manual is also suitable for:

Table of Contents
