Honeywell HBD92SX Specifications

HBD92SX
600 TVL DAY/NIGHT BULLET CAMERA (2.8-12 MM LENS)
The Honeywell HBD92SX day/night bullet camera with IR illumination captures
perfect colour images by day and clear black-and-white images at night.
The 2.8 -12 mm IR-corrected aspherical Vari-focal Auto Iris lens offers a wide field of
view range and does not shift focus when the camera switches from day to night
mode. Digital Noise Reduction (DNR) removes noise artifacts, resulting in improved
motion detection performance and longer recording times. Digital Slow Shutter (DSS)
technology offers increased light sensitivity, extending the camera's usable range.
The HBD92SX is easy to install and set up. Externally accessible screw gears let you
adjust the lens field of view and focus. A bottom-mounted porthole provides access
to the on-screen display menu and IR power adjustment. The camera is locked in
position by a secure mounting bracket. Wiring is concealed so it cannot be cut or
disconnected. The HBD92SX can be mounted to a wall or ceiling in minutes.
Market Opportunities
The HBD92SX is a surveillance solution designed for object recognition in locations
where low or variable light conditions exist. Setting up is quick and easy and can be
customised with user-friendly on-screen displays and preset modes. The HBD92SX
is suitable for both indoor and outdoor applications, including lobbies, atriums,
foyers, vestibules, gated entrances, driveways, and loading bays.
Features
• Switchable IR cut filter
• 56 IR LEDs
• 2.8-12 mm, F1.4 Vari-focal Auto Iris
IR-corrected lens with external
adjustments for zoom and focus
• High resolution colour: 600 TVL, 1/3"
Sony Super HAD ™ CCD
• Digital noise reduction technology
for noise-free images
• On-screen display (OSD) menu for
quick camera set-up
• Power connection self-configures to
12 VDC or 24 VAC with transient
surge protection
• Twelve programmable privacy zones
• Built-in breather vent prevents
condensation
• Local video output for set-up
