fx-100MS
fx-115MS
fx-570MS
fx-991MS
User's Guide
CASIO Worldwide Education Website
http://edu.casio.com
CASIO EDUCATIONAL FORUM
http://edu.casio.com/forum/
EEE Yönetmeli¤ine Uygundur
RJA526827-001V02
E

Advertisement

Table of Contents
loading

Related Manuals for Casio fx-100MS

Summary of Contents for Casio fx-100MS

  • Page 1 User’s Guide CASIO Worldwide Education Website http://edu.casio.com CASIO EDUCATIONAL FORUM http://edu.casio.com/forum/ EEE Yönetmeli¤ine Uygundur RJA526827-001V02...

  • Page 2: Table Of Contents

    Contents Important Information .............2 Sample Operations ............2 Initializing the Calculator ..........2 Safety Precautions ............2 Handling Precautions ............2 Removing the Hard Case ..........3 Turning Power On and Off ..........3 Adjusting Display Contrast ..........3 Reading the Display ............4 Specifying the Calculation Mode ........4 Configuring the Calculator Setup ........4 Inputting Expressions and Values .........6 Basic Calculations ............7...

  • Page 3: Important Information

    • The contents of this manual are subject to change without notice. • In no event shall CASIO Computer Co., Ltd. be liable to anyone for special, collateral, incidental, or consequential damages in connection with or arising out of the purchase or use of this product and items that come with it.

  • Page 4: Removing The Hard Case

    * Company and product names used in this manual may be registered trademarks or trademarks of their respective owners. Removing the Hard Case fx-115MS fx-100MS/570MS/991MS Turning Power On and Off Press O to turn on the calculator. Press 1A(OFF) to turn off the calculator.

  • Page 5: Reading The Display

    Reading the Display The display of the calculator shows expressions you input, calculation results, and various indicators. Input expression Indicators Calculation result Specifying the Calculation Mode When you want to perform this type Perform this key of operation: operation: N1(COMP) General calculations N2(CMPLX) Complex number calculations...
  • Page 6 Note: In this manual, the v symbol next to a sample operation indicates degrees. 1Fix 2Sci 3Norm Specifies the number of digits for display of a calculation result. Fix: The value you specify (from 0 to 9) controls the number of decimal places for displayed calculation results. Calculation results are rounded off to the specified digit before being displayed.

  • Page 7: Inputting Expressions And Values

    Inputting Expressions and Values 4 × sin30 × (30 + 10 × 3) = 120 v 4 *s 30 *( 30 + 10 * 3 )= Note: • The memory area used for calculation input can hold 79 “steps”. One step is taken up each time you press a number key or arithmetic operator key ( +, -, *, /).

  • Page 8: Basic Calculations

    Making Corrections During Input • Use d and e to move the cursor to the location you want. • Press D to delete the number or function at the current cursor position. • Press !D(INS) to change to an insert cursor t. Inputting something while the insert cursor is on the display inserts the input at the insert cursor position.

  • Page 9: Using Engineering Notation

    300 grams are added to a test sample originally weighing 500 grams, producing a final test sample of 800 grams. What percent of 500 grams is 800 grams? (160%) 300 + 500 1=(%) 160. What is the percentage change when a value is increased from 40 to 46? (15%) 46 - 40 1=(%) Degree, Minute, Second (Sexagesimal)
  • Page 10 To input this symbol: Perform this key operation: Unit 1g(k) k (kilo) 1h(M) M (Mega) 1i(G) G (Giga) 1j(T) T (Tera) 1f(m) −3 m (milli) 1e( ) −6 (micro) 1d(n) −9 n (nano) 1c(p) −12 p (pico) 1b(f) −15 f (femto) 100 m (milli) ×...
  • Page 11 After performing the calculations 1+1, 2+2, 3+3, 4+4, 5+5, and 6+6, the multi-statement will show 4+4:5+5:6+6. 1 + 1 = 2 + 2 = 3 + 3 = 4 + 4 = 5 + 5 = 6 + 6 = 4+4 : 5+5 : 6+6 _ 4+4 : 5+5 : 6+6 _ 1f(COPY)

  • Page 12: Function Calculations

    To multiply the contents of variable A by 10 Sy(A) * 10 = (Continuing) To recall the contents of variable A ty(A) (Continuing) To clear the contents of variable A 0 1t(STO) y(A) Independent Memory (M) You can add calculation results to or subtract results from independent memory.
  • Page 13 when you perform the following key operation: 1G(DRG '). See : Exponential functions. See log : Logarithmic function. See ln : Natural logarithm to base . See ) , ', −1 , ^ ( : Powers, power roots, and reciprocals. −1 Note: can be used in complex number calculations.
  • Page 14 Integration and Differential Calculation Precautions • Integration and differential calculations can be performed in the COMP Mode (,1) only. • When using a trigonometric function in ), specify Rad as the angle unit. Precautions for Integration Calculation Only • You can specify an integer in the range of 1 to 9 as the number of partitions, or you can skip input of the number of partitions entirely, if you want.
  • Page 15 + 8) = 150.6666667 ( = 6) f 2 S)(X) x+ 3 S)(X) + 8 , 1 , 5 , 6 )= 150.6666667 To determine the derivative at point = 2 for the function is Δ – 5 + 2, when the increase or decrease in = 2 ×...

  • Page 16: Complex Number Calculations (Cmplx)

    Complex Number Calculations (CMPLX) To perform complex number calculations, first press N2(CMPLX) to enter the CMPLX Mode. You can use either rectangular coordinates ∠ ) to input complex numbers. Complex ) or polar coordinates ( number calculation results are displayed in accordance with the complex number format setting on the setup menu.

  • Page 17: Using Calc

    results. The command overrides the calculator’s complex number format setting. = 1.414213562 ∠ 45, 1.414213562 ∠ 45 = 1 + 1 +W( ) 1+( ' ∠ ) = = 1.414213562 1=(Re ⇔ Im) ∠ 9 2 1-( ∠ ) 45 1-( ' Real part 1=(Re ⇔...

  • Page 18: Statistical Calculations (Sd, Reg)

    To solve when = 0, = 1, and = –2 S,(Y) Ss(=) S-(A) +B _ +B _ S)(X) w+Se(B) Y=AX Y=AX 1s(SOLVE) Prompts for input of a value for Y Current value of Y - 2 =f 1s(SOLVE) 1.414213562 1.414213562 Solution screen To exit SOLVE: A Important:...
  • Page 19 Inputting Data • In the SD Mode and REG Mode, the l key operates as the 7 key. • Always start data input with !,(CLR)b(Scl)= to clear statistical memory. • Input data using the key sequence shown below. -data> 7 SD Mode: <...
  • Page 20 Σ , Σ , Σ ..11(S-SUM)ee 1 to 3 (Quadratic Regression only) , Population Standard Deviation: σ *, σ Mean: , Sample Standard Deviation: s *, s , σ ....12(S-VAR) 1 to 3 , σ ....12(S-VAR)e 1 to 3 Regression Coefficients: A, B, Correlation Coefficient: Regression Coefficients for Quadratic Regression: A, B, C 12(S-VAR) ee 1 to 3...

  • Page 21: Base- N Calculations (Base)

    Calculating Estimated Values Based on the regression formula obtained by paired-variable statistical calculation, the estimated value of can be calculated for a given value. The corresponding -value (two values, , in the case of quadratic regression) also can be calculated for a value of in the regression formula.

  • Page 22: Converting Calculation Result

    number modes: w(DEC) for decimal, M(HEX) for hexadecimal, l(BIN) for binary, or i(OCT) for octal. To enter the BASE Mode, switch to the binary mode, and calculate 11 NN3(BASE) l(BIN) 11 + 1 = 100. 100. Note: • Use the following keys to input the letters A through F for hexadecimal values: -(A), $(B), w(C), s(D), c(E), t(F).

  • Page 23: Logical And Negation Operations

    × 3 To calculate 15 in the decimal mode, and then convert the result to hexadecimal, binary, and octal Ax(DEC) 15 * 3 = M(HEX) l(BIN) 101101 i(OCT) Note: • You may not be able to convert a value from a number system whose calculation range is greater than the calculation range of the resulting number system.
  • Page 24 Quadratic equation (ax + bx + c = 0) Cubic equation (ax + bx + cx + d = 0) 3. Use the Coefficient Editor that appears to input coefficient values. – 3 = 0, for example, press e2 in step 2, and •...

  • Page 25: Matrix Calculations (Mat)

    (x2=) 0.25 !=(Re⇔Im) (x2=) −0.75 • If a result is a complex number, the real part of the first solution appears first. Press !=(Re⇔Im) to toggle the display between the real part and imaginary part of a solution. – 2 –...
  • Page 26 7. Press A to advance to the calculation screen, and perform the first calculation (MatA × MatB): 14(MAT) 3(Mat) 1(A) *14 (MAT) 3(Mat) 2(B) =. • This will display the MatAns screen with the calculation results. Mat A×Mat B _ Mat Ans Note: “MatAns”...
  • Page 27 2. Use the Matrix Editor that appears to edit the elements of the matrix. • Use the f, c, d, and e keys to display the element you want to edit. Input a new value and then press =. Matrix Calculation Examples 2 –1 The following examples use MatA = and MatB =...

  • Page 28: Vector Calculations (Vct)

    Vector Calculations (VCT) (fx-570MS/991MS only) Use the VCT Mode to perform 2-dimensional and 3-dimensional vector calculations. To perform a vector calculation, you first assign data to special vector variables (VctA, VctB, VctC), and then use the variables in the calculation as shown in the example below. To assign (1, 2) to VctA and (3, 4) to VctB, and then perform the following calculation: (1, 2) + (3, 4) 1.
  • Page 29 Assigning and Editing Vector Variable Data Important: The following operations are not supported by the Vector Editor: m, 1m(M–), 1t(STO). Pol, Rec, and multi-statements also cannot be input with the Vector Editor. To assign new data to a vector variable: 1.

  • Page 30: Scientific Constants (Fx-570Ms/991Ms Only)

    Obtain the absolute values of VctC. Abs Vc t C Abs Vc t C A1)(Abs) VctC = Determine the angle formed by VctA and VctB to three decimal places (Fix 3). v • • –1 (cos , which becomes = cos 1(Fix) 3 A(VctA 15(VCT) e1(Dot) VctB )/ (1)(Abs) VctA 1)(Abs)

  • Page 31: Metric Conversion (Fx-570Ms/991Ms Only)

    13: ( γ p) proton gyromagnetic 14: ( λ cp) proton Compton ratio wavelength 15: ( λ cn) neutron Compton 16: (R ∞ ) Rydberg constant wavelength 18: ( p) proton magnetic 17: (u) atomic mass unit moment 19: ( e) electron magnetic 20: ( n) neutron magnetic moment moment...

  • Page 32: Calculation Ranges, Number Of Digits, And Precision

    The following shows the two-digit numbers for each of the metric conversion commands. 01: in ' cm 02: cm ' in 03: ft ' m 04: m ' ft 05: yd ' m 06: m ' yd 07: mile ' km 08: km ' mile 09: n mile ' m 10: m ' n mile...
  • Page 33 Same as sin , except when = (2 −1) π/2. Same as sin , except when = (2 −1) Same as sin , except when = (2 −1) 100. –1 –1 –1 9.999999999 sinh 230.2585092 cosh –1 sinh 4.999999999 –1 cosh 4.999999999 tanh...

  • Page 34: Error Messages

    G 0, –1 Œ   Œ = 0: +1, 1 G 0;  is an integer)   However: –1 Total of integer, numerator, and denominator must be 10 digits or less (including division marks).    σ , σ...

  • Page 35: Before Assuming Malfunction Of The Calculator

    Stack ERROR Cause: • The calculation you are performing has caused the capacity of the numeric stack or the command stack to be exceeded. • The calculation you are performing has caused the capacity of the matrix or vector stack to be exceeded. Action: •...

  • Page 36: Replacing The Battery

    Built-in solar cell; button battery LR44 (GPA76) × 1 Approximate Battery Life: fx-100MS: 17,000 hours (continuous display of flashing cursor) fx-570MS: 9,000 hours (continuous display of flashing cursor) fx-115MS/991MS: 3 years (based on one hour of operation per day) Power Consumption: 0.0001 W (fx-100MS/570MS)
  • Page 37 Dimensions (H×W×D)/Approximate Weight (including the battery) fx-100MS 20.0 × 78 × 155 mm 133 g × 3 × 6 (4.7 oz) fx-115MS 12.6 × 80 × 159 mm 100 g × 3 × 6 (3.5 oz) fx-570MS 12.7 × 78 × 154.5 mm...
  • Page 38 Manufacturer: CASIO COMPUTER CO., LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan Responsible within the European Union: CASIO EUROPE GmbH Casio-Platz 1 22848 Norderstedt, Germany This mark applies in EU countries only.
  • Page 39 CASIO COMPUTER CO., LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan SA1211-B Printed in China © 2012 CASIO COMPUTER CO., LTD.
