DSP COLOR CAMERA
GC-715N24
GC-715P24
* "
BMB
" is the Trade Mark of Honeywell, CCTV CoE.
BMB
TM
TM
MEMO
Control Products Business Unit
18F, Kukje Center Building, 191,
Hangangro-2ga, Yongsan-gu,
Seoul 140-702, Korea
Tel : 82-2-799-6109
Fax : 82-2-749-6119
READ AND RETAIN THIS OPERATION MANUAL
E-mail : cctv@honeywell.com
http://www.honeywell.co.kr/cctv
Printed in Korea
G-110821

Advertisement

Table of Contents
loading

Related Manuals for Honeywell GC-715N24

Summary of Contents for Honeywell GC-715N24

  • Page 1 DSP COLOR CAMERA GC-715N24 GC-715P24 * “ ” is the Trade Mark of Honeywell, CCTV CoE. MEMO Control Products Business Unit 18F, Kukje Center Building, 191, Hangangro-2ga, Yongsan-gu, Seoul 140-702, Korea Tel : 82-2-799-6109 Fax : 82-2-749-6119 READ AND RETAIN THIS OPERATION MANUAL E-mail : cctv@honeywell.com...
  • Page 2 CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK. CAUTION DO NOT REMOVE COVER(OR BACK). RISK OF ELECTRIC SHOCK NO USER SERVICEABLE PARTS INSIDE DO NOT OPEN REFER SERVICING TO QUALIFIED SERVICE PRERSONNEL Explanation of Graphical Symbols. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage”...

  • Page 3: Cautions For Safe Operation

    CAUTIONS FOR SAFE OPERATION ! ● Changes or modifications not approved by manufacturer could void the user’s authority to operate the equipment. ● To prevent fire or shock hazard, do not expose this camera to rain or moisture. ● To prevent electric shocks and other hazards, do not use different from the specified power source.

  • Page 4: Name And Function Of Each Section

    GC-715N/P24 Outlines Honeywell’s GC-715N/P24 is a high sensitivity CCD color camera with high sensitivity function of the field integration technique. Features ☞ 1/3” IT Super HAD CCD ( NTSC: 410,000 / PAL: 470,000 ) ☞ Outstanding BLC implementation with Honeywell’s BMB(Black Mask BLC) function.

  • Page 5: Installation

    Installation Mounting a Lens 1. Remove the protective cap in front of the camera. 2. Confirm the mount ring whether it is for C or CS. * Caution1 3. Attach the lens to the lens mount ring. 4. If the lens has an Auto Iris mechanism, connect the iris cable to the Lens connector (EE/VSD S/W must be set to VSD on the side of the camera) A.
  • Page 6 Flange back focus adjustment 1. In case of fixed focus lens a. Loosen the locking ring and set the focus ring of lens to infinity ( b. Tune the mount ring to get a clear picture( distance from camera to object is more than 23m) and fasten the locking ring.
  • Page 7 3. Connector “4” Used for EEPROM data setting in factory. 4. DIP switch “5” Shipment setting consists of “AGC High”, “AWC”, “SENS”. ① ② ③ ④ ⑤ EE DC ME VSD VSD H SENS AUTO ① “EE/ME” Mode ( Electronic Exposure / Manual Exposure ) If using electronic exposure or a lens with automatic iris, the “EE/ME”...
  • Page 8 ② “EE/VSD” Mode ( Lens type selection ) VSD(Auto) ③ “DC/VSD(AUTO)” Mode ( Auto Iris Lens type selection ) Auto Iris Lens are DC Type or VSD Type. Auto If using a manual lens, the “EE/VSD” switch has to be set to “EE”.
  • Page 9 ⑤ “BMB/SENS” Mode What is BMB? -. BMB is the trade mark of Honeywell, that means BLACK MASK BLC. ( -. It is to improve the weak points of Electronic Iris & BLC. -. Mask the excessive light by 3 making level and minimize the loss of outlines of Objects due to strong light.
  • Page 10 ☞ It is impossible to use BMB and SENS functions simultaneously !!! To use BMB or SENS, select “BMB/SENS” switch one of two, To use neither BMB nor SENS, select “BMB” and level “H1,H0” to OFF. or select “SENS” and set the Rotary switch “7” to “0”. ◆...
  • Page 11 ! Cautions in SENS mode 1. In high sensitivity mode , moving object is displayed as if it is flowing, because the integration time of the CCD becomes long. Further, movement is unnatural due to intermittent read-out. 2. In high sensitivity mode, white blemishes may be remarkable. 3.
  • Page 12 ⑧ ⑨ ⑩ “WB” Mode ( White Balance Mode ) WB Mode can be selected by WB1,WB2,WB3, UP,DOWN, PUSH LOCK switch. UP DOWN PUSH LOCK Use in MWB mode Fig 6. WB Mode Table ◆ “ATW” Mode Auto Trace White Balance Mode. This mode is the feedback system that automatically aligns the white balance.
  • Page 13 ◆ “AWC” Mode Auto White Balance Control Mode. This mode performs more faster action than ATW mode without operating range. AWC operation is also performed in one push lock mode. while the button “3” on the side view is pressed, AWC action started and then the button is released, WB operation is locked to fit the present shooting scene.

  • Page 14: Specifications

    SPECIFICATIONS GC-715N24 Imaging device 1/3” CCD(total 410,000pixels) Effective pixel 768H * 494V(380,000pixels) Scanning system 525 Lines 2:1 Interlace Sync system Internal/ Line lock Scanning frequency 15.734KHz(H), 59.94Hz(V) H Resolution 480 TV Lines Video out VBS 1.0Vp-p / BNC S/N Ratio more than 50dB Min.
