3 | High-Speed Positioning System
MTC-WUPH
593 (23.35)
520 (20.47)
MTC-PUPH
Ø 101.6 (4.0)
Ø 146 (5.75)
Ø 146 (5.75)
MTC-CORN-W
MTC-POLE-W
HAC-WAS05
110
(4.43)
140 (5.51)
HAC-WAS30
Dimensions in mm (in.)
Parts included
Quantit
y
1
1
1
1
1
1
1
347.5 (13.68)
347.5
269 (10.59)
269
347.5 (13.68)
269 (10.59)
Component
Head unit with pre-installed camera and lens
Base unit with power supply
Serial cable
Serial adapter
Installation manual
Power supply unit
Set of mounting accessories
• 4 mm Allen wrench
• Bracket with fixing screws
• Cable ties
• Tube
• Label
200 (7.87)
200
200 (7.87)
