Efficient Networks SpeedStream 5400 Series Product Features Manual

4 port ethernet soho dsl router
Hide thumbs Also See for SpeedStream 5400 Series:

Advertisement

Quick Links

Download this manual See also: User Manual
Efficient Networks, Inc.
SpeedStream
4 port Ethernet SOHO

DSL Router

Product Feature Matrix
®
5400 Series
4849 Alpha Road
Dallas, Texas 75244-3666
tel: +1(972) 852-1000 fax: +1(972) 852-1001
http://www.efficient.com
Revision 1.3

Advertisement

loading

Related Manuals for Efficient Networks SpeedStream 5400 Series

Summary of Contents for Efficient Networks SpeedStream 5400 Series

  • Page 1: Dsl Router

    Efficient Networks, Inc. Revision 1.3 ® SpeedStream 5400 Series 4 port Ethernet SOHO DSL Router Product Feature Matrix 4849 Alpha Road Dallas, Texas 75244-3666 tel: +1(972) 852-1000 fax: +1(972) 852-1001 http://www.efficient.com...
  • Page 2 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 1 Introduction ® The SpeedStream 5400 Series 4 Port Ethernet SOHO DSL router is designed for the small office or home office (SOHO) that needs to share DSL access across a small network. The ®...
  • Page 3 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 2.2 Physical Interfaces Feature Comments 10/100 Base-T connector (4) RJ-45 LAN port RJ-11 connector RJ-11 ADSL WAN port Serial console Reset Button 2.3 Visual Indicators Feature Comments Front panel LED for Power status...
  • Page 4 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 2.5.3 Physical Packaging Feature Comments Dimensions 6.2W x 4.4D x 1.6H in. 157W x 111D x 40H mm Weight: 1.15 lbs (521 g) Shock resistant individual shipping package 2.6 Environmental Feature Comments...
  • Page 5 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 4 User Plane Capabilities 4.1 10/100 BASE-T Ethernet Interface Feature Comments Number of switch ports Factory MAC address IEEE 802.3/802.3u Ethernet Ethernet v2 Half/Full duplex Ethernet Auto MDI-MDIX support 4.2 DMT ADSL WAN Interface...
  • Page 6 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 5 Control Plane Capabilities 5.1 AAL5, ATM and Cell Transmission Convergence Feature Comments Maximum simultaneous VCCs Pre-configured PVCs Yes, 0/32, 0/35, 0/36, 0/37, 0/38, 8/35 and 1/35; (customer specific PVC configuration can be supported.)
  • Page 7 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 5.3 Packet Forwarding 5.3.1 Layer 3 Routing – IP Feature Comments Static routing Yes, maximum of 16 Default route Variable length subnet masks RIP version 1 Yes, active and passive RIP version 2...
  • Page 8 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 6 Management Plane Capabilities 6.1 Management Interfaces 6.1.1 Local and Remote Console Feature Comments Command line interface via serial port Password Protection Command line interface via Telnet Telnet access via LAN and WAN ports 6.1.2...
  • Page 9 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 6.2 ATM Layer In-band Management Feature Comments Generate and reply to F4 & F5 No, reply only Loopback OAM cells F4 & F5 AIS/RDI OAM cell flow support 6.3 ADSL In-band Management...
  • Page 10 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 6.4.2 IP Address and DNS Name Management Feature Comments LAN interface factory default IP 192.168.254.254 address Manual IP address assignment for Ethernet UPnP Support Yes, UPnP discovery initially, Full UPnP support Q4,...
  • Page 11 SpeedStream 5400 Series SOHO DSL Router Revision 1.3 6.6 Performance and Accounting Management Feature Comments Ethernet port statistics Bridging statistics IP statistics Yes, via SNMP only – Future GUI support ICMP statistics Yes, via SNMP only – Future GUI support PPP statistics Yes, via SNMP only –...

  • Page 12: Document Revision History

    SpeedStream 5400 Series SOHO DSL Router Revision 1.3 Document Revision History Version Date Editor Description 04/02/02 Initial document creation 04/15/02 Initial document release 05/03/02 Minor format corrections. 07/03/02 Changes to reflect new part number/naming schema Efficient Networks, Inc. Confidential Page 12 of 12...
