The Harman PP38+ Pellet Stove
PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR NEW ROOM HEATER. FAILURE TO
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH.
FOR USE IN THE U.S. AND CANADA. SUITABLE FOR INSTALLATION IN MOBILE HOMES
IF THIS HARMAN PELLET STOVE IS NOT PROPERLY INSTALLED, A HOUSEFIRE MAY RESULT. FOR YOUR SAFETY ,
FOLLOW INSTALLATION DIRECTIONS.
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONSAND INSTALLATION INSPECTION
REQUIREMENTS IN YOUR AREA.
CONTACT YOUR LOCAL AUTHORITY (SUCH AS MUNICIPAL BUILDING DEPARTMENT, FIRE DEPARTMENT, FIRE
PREVENTION BUREAU, ETC.) TO DETERMINE THE NEED FOR A PERMIT.
CETTE GUIDE D'UTILISATION EST DISPONIBLE EN FRANCAIS. CHEZ VOTRE CONCESSIONNAIRE DE HARMAN ST OVE
COMPANY.
Installation & Operating Manual
"Ce manuel est disponible en Français sur demande"
SAFETY NOTICE
SAVE THESE INSTRUCTIONS.
Tested by Intertek Testing Service
Tested to: UL 1482, ASTM E 1509-95,
Oregon 814-23-900 THRU 814-23-909,
ULC-S627-M90, WH-PN 025
R8
Advertisement
Table of Contents
Related Manuals for Harman Stove Company PP38+
Summary of Contents for Harman Stove Company PP38+
-
Page 1: Safety Notice
FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH. FOR USE IN THE U.S. AND CANADA. SUITABLE FOR INSTALLATION IN MOBILE HOMES IF THIS HARMAN PELLET STOVE IS NOT PROPERLY INSTALLED, A HOUSEFIRE MAY RESULT. FOR YOUR SAFETY , FOLLOW INSTALLATION DIRECTIONS. -
Page 2: Table Of Contents
Please read this entire manual before you install and use your new room heater. Failure to follow instructions may result in property damage, bodily injury, or even death. SUITABLE FOR MOBILE HOME INSTALLATIONS. SAVE THESE INSTRUCTIONS Harman Stove Company 352 Mountain House Road Halifax, PA 17032 P38+ Pellet Stove... - Page 3 The rear cover panels are packed inside the hopper and should be installed on the stove as shown. This should be done after the stove is in place and flue is connected.
-
Page 4: Assembly & Installation
Repeat as required to achieve a tight door fit. NOTE: Remember to thoroughly clean the glass and the gold door frame before lighting the stove for the first time. HINGE PINS GLASS 4 GLASS... - Page 5 Prior to installing flue pipe, connect a draft meter to the stove as shown in fig. 6 . (The draft meter must have a mini- mum range of 0-.5). Set control board to "1" on the feed rate dial.
- Page 6 NOT E: Where passage t hrough a w all, or partition of combustible construction is desired, the installation shall conform to CAN/CSA-B365. (if in Canada) Inside Corner Detail Fixed Openable Closed = Air supply inlet = Area where terminal is not permitted P38+ Pellet Stove...
-
Page 7: Important Notices
MANUFACTURER. Venting IMPORTANT NOTICES • Due to high temperatures, the stove should be placed out of traffic and away from furniture and draperies. • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burn to skin and/or clothing. -
Page 8: Venting
1-10-08542 should be used to keep bird, rodents etc. out of the pipe. When installing in a house with a Heat Reclaiming Ven- tilation System (HRV) be sure the system is balanced and is not creating a negative pressure in the house. P38+ Pellet Stove... - Page 9 #1 Preferred method This method provides excellent venting for normal op- eration and allows the stove to be installed closest to the wall. Two inches from the wall is safe; however, four inches allows better access to remove the rear panel. The vertical portion of the vent should be three to five feet high.
- Page 10 This method provides excellent venting for normal op- #5 Installing into an existing fireplace chimney ( US only ) This method provides excellent venting for normal op- The damper area must be sealed with a steel plate or P38+ Pellet Stove...
- Page 11 #7 Installing into an existing chimney ( US and Canada ) This method provides excellent venting for normal op- In Canada and some places in the US it is required that In this method a cap should also be installed on the P38+ Pellet Stove...
-
Page 12: Turbo Control
When the Feed Rate dial is turned to the OFF position the fire will slowly die and go out. When the stove cools down enough, all motors will stop. If the stove runs out of pellets and cools down, the control will shut down all but the combustion blower. -
Page 13: Operation
This may cause incomplete combustion and smoke in the firebox. If the load door is opened the smoke may escape. The best way to shut down the stove is simply let it run out of pellets, then turn the control to "OFF". P38+ Pellet Stove... -
Page 14: Maintenance
3. Clean heat exchanger with scraper as shown in fig 27. 4. Brush or scrape the inside of the stove to remove fly ash. 5. Scrape burnpot with flat end of scraper provided with the stove. Fig. 33. - Page 15 (Fig.27) therefore, the vent pipe can also be cleaned to some extent through the flue outlet. 10. Reinstall blower cover and relatch. 11.Slide ash pan into stove and latch into place. Fig. 20 Brush not supplied. Can be found in hardware stores.
-
Page 16: Trouble Shooting
A vacuum cleaner is handy to remove the residue. Be sure the stove is cold if you use a vacuum. Carbon buildup can be scraped loose with the fire burning using the special tool provided with your stove. -
Page 17: Feeder Parts
Feed Rate Hopper Capacity Fuel Flue Size Outside Air Size Fuse Rating Feeder Parts Specifications 212 lbs. 135 cfm .75 to 5.5 lbs. per hr. 50 lbs. Wood Pellets 3 inch 2 3/8 I.D. inch 3 amp P38+ Pellet Stove 22"... -
Page 18: Wiring Diagram
Wiring Diagram P38+ Pellet Stove... - Page 19 70 degrees, the switch will be closed caus- ing the stove to burn on "Turbo" until the room tempera- ture reaches 70 degrees. Then the switch will open, caus- ing the stove to go to "low" which is where the feed rate is set. Installing Thermostat The thermostat should be mounted in a central lo- cation.
- Page 20 If the gold needs to be cleaned, wait until the stove is completely cool, then use a sponge, soap and water to gently remove dirt and stains.
-
Page 21: Options
Options P38+ Pellet Stove Hopper Extension Side Heat Shields The hopper extension allows you to put more pellet Side heat shields are available to reduce the fuel in the hopper and extends burn time on one load of pellets. clearance to combustible materials. -
Page 22: Warranty
MERCHANTABILITY, OR WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. No employee, agent, dealer, or other person is authorized to give any warranty on behal f of Harman Stove Company. Thi s warranty does not apply if the product has been altered in any way after leaving the factory. Harman Stove Company and its agents assume no liability for “ resultant damages of any kind”...
