- Page 1 RACK SOPORTE DE PIE WALL ASIDE STAND AN-WS350 MODELO MODEL AN-WS350R MANUAL DE MANEJO OPERATION MANUAL ESPAÑOL Consulte las páginas S-1 a S-14 ENGLISH Please refer to pages E-1 to E-14..
- Page 2 ENGLISH Thank you for purchasing this SHARP product. Before using the product, please be sure to read this operation manual carefully. In particular, be sure to read the section “To Ensure Safe and Correct Use”. After reading the manual, keep it in a convenient location where it can be accessed at any time.
-
Page 3: To Ensure Safe And Correct Use
Special skill is required to install the LCD colour TV and Wall Aside Stand, so please have them installed by a contractor specializing in such installation. The customer should not attempt to install the TV. Sharp shall not be responsible for improper installation or any accidents, damage, or injury resulting from improper installation. - Page 4 Screw the Support Plate (G) to the Metal Base with 2 pieces of M6 [16mm] screws (K) first, using the M6 Allen key (P). Step 2 Flip the Metal Base upside down. You can see the “SHARP” logo is facing upwards.
- Page 5 Step 3 Place the Centre Bar next to the Metal Base, on top of the Support Plate (G). Side view Ensure that the specification label is facing the floor when combining the Centre Bar and Metal Base. Step 4 From under the Metal Base, place 4 pieces of M8 [50mm] screws (H) with Spring Washers Ø8 (O).
- Page 6 Assembling the Centre Bar and Metal Base (continued) Step 6 Fasten another 4 pieces of M6 [16 mm] screws (K) using M6 Allen key (P) to the Support plate as shown. Step 7 Before peeling off the masking tape securing the legs, hold the legs firmly and be careful not to be hit by them.
- Page 7 Step 2 Step 3 Slot in the LCD support frame to the Centre Bar as Fix the LCD Support Bar (A) with LCD U Bracket shown. (C) using 4 pieces of M6 [16mm] screws (K) and 4 pieces of Flange Nuts (M). Use M6 Allen key (P) to fasten the screws.
- Page 8 Assembling the LCD Support Frame (continued) Notes: z The LCD Support Bar is adjustable to different heights. Maximum height is 1250 mm. Minimum height is 1030 mm. z When fixing the frame, make sure that all the 6 pieces of M6 [16mm] screws are fastened to it.
- Page 9 Falling prevention (optional) It is recommended to secure the fixture to the wall with a safety wire or chain before attach- ing the TV to prevent it from toppling over in case of earthquake occurrence. Fix the safety wire or chain to the wall using a wall anchor bracket which is commercially...
- Page 10 Assembling the glass shelf (continued) Glass protector guide Hole Step 4 Place the glass on the Glass Shelf Supports as shown. Make sure all the Glass Protector guides are inserted perfectly into the holes of the left and right Glass Shelf Supports.
- Page 11 Assembling the Sound bar Support (optional) (continued) Step 3 Step 4 Step 3 Fasten the fixture to the Centre Bar using 4 pieces Hook the sound bar to the Sound bar Support at of M6 [16mm] screws (K) with M6 Allen key (P). both sides.
- Page 12 Fasten them using M6 Allen key (P) or M8 Allen key (Q). Caution: Sharp shall not bear any responsibility for damages, etc., caused by the LCD colour TV falling due to insufficient in- stallation strength or improper installa- Max.
-
Page 13: Wire Arrangement
Attaching the LCD TV Hook to the LCD TV (continued) Step 2 Step 3 Hook the TV to the LCD Support as shown. Fasten 2 pieces of M6 [35 mm] screws (J) as shown to fix the TV position to prevent it from slid- Note: ing sideways. - Page 14 To remove any stain from the stand, wipe the surface with soft cloth. Do not use chemicals as it may damage the surface finish. Specified products The following products are subject to change without notice. Certain models may not be available in certain regions. SHARP LCD colour TV SHARP Sound bar system 46LE700E 37XL8E HT-SB200...
-
Page 15: Specification
Specification 100 mm 1021.7 mm (40 - 7/32”) 675 mm (26 - 9/16”) 470 mm (18 - 1/2”) Dimensions 500 mm 176 mm (6 - 15/16”) 100 mm (3 - 15/16”) 380 mm 27 kg (59.52 lbs.) Weight 60 kg (132.3 lbs.) Stand maximum load 10 kg (22.05 lbs.)
