Summary of Contents for Tripp Lite MODBUSCARD

  • Page 1 Owner’s Manual Programmable MODBUS Card Model: MODBUSCARD Introduction Installation Features Configuration Operation Warranty & Warranty Registration 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2010 Tripp Lite. All rights reserved.
  • Page 2: Installation

    If your UPS system does not have an SNMPWEBCARD installed, use a screwdriver to remove the accessory slot cover from the UPS. While the UPS is turned on, align the MODBUSCARD with the guides in the accessory slot and push the card into the slot until the ports are nearly even with the rear surface of the UPS.
  • Page 3 Configuration Configuration of RS-232 Port Use SW2 to configure the RS-232 interface. Function Card TxD - transfer data to PC Card RxD - receive data from PC Function Switch Value SW-1 SW-2 ON/OFF MODBUS OFF MODBUS ON SW2-1 SW2-2 2400 (Default) Baud-Rate 4800 9600...
  • Page 4: Led Indicators

    Configuration continued Configuration of RS-422/485 Port Use SW3 to configure the RS-422/485 interface. Function Card D+ (T+) Card D- (T-) Card R+ Card R- Switch Setting Function RS-485 Enable RS-485 RS-422 Enable RS-422 Function Switch Value SW3-1 SW3-2 2400 (Default) Baud-Rate 4800 9600...
  • Page 5 Operation Discrete Inputs (Range 0x0100 - 0x012F, Read Function 0x02) The Read Discrete Inputs function code is used to read 1-2000 contiguous status of Discrete Inputs in a remote device. The starting address and number of inputs is specified by the request Protocol Data Unit. Addresses start at 0 and Discrete Inputs numbered 1-16 would address as 0-15. Description Address Value 0...
  • Page 6 Operation continued Coils (Range 0x0200 - 0x020F, Read Function 0x01, Write Function 0x05) The Read Coils function reads 1-2000 contiguous status of coils in a remote device. The starting address and number of coils is specified by the request Protocol Data Unit. Addresses start at 0 and Coils numbered 1-16 would address as 0-15. The Write Coils function writes a single output to ON/OFF in a remote device.
  • Page 7 Operation continued Holding Register (Range 0x0300 - 0x0321, Read Function 0x03, Write Function 0x06) continued Description Address Value Unit 1: Disable 2: Daily UPS Periodic Auto-Test 0x030D 3: Weekly 4: Bi-Weekly 5: Monthly Buzzer Test 0x030E 1-99 Seconds UPS Boot Delay 0x030F 0-999 Seconds...
  • Page 8: Battery Status

    Operation continued Input Register (Range 0x0400 - 0x051C, Read Function 0x04) Rating Value continued Description Address Value Unit 0: On-Line 1: Off-Line 2: Line-Interactive UPS Type 0x040E 3: 3-Phase 4: Split Phase 5: Others Rating Battery Voltage 0x040F 0-999 Voltage Low Tx Frequency Point 0x0410 0-999...
  • Page 9: Input Status

    Operation continued Input Status Description Address Value Unit Input Number Lines 0x0430 Input Frequency 1 0x0431 0-999 0.1 Hz Input Voltage 1 0x0432 0-9999 0.1 Voltage Input Current 1 0x0433 0-9999 0.1 Amp Input Power 1 0x0434 0-65534 10 Watt Input Frequency 2 0x0435 0-999...
  • Page 10: Output Relay

    Operation continued Bypass Status Description Address Value Unit Bypass Frequency 0x0456 0-999 0.1 Hz Bypass Number Lines 0x0457 Bypass Voltage 1 0x0458 0-9999 0.1 Voltage Bypass Current 1 0x0459 0-9999 0.1 Amp Bypass Power 1 0x045A 0-65534 10 Watt Bypass Voltage 2 0x045B 0-9999 0.1 Voltage...
  • Page 11 Operation continued Select Voltage Description Address Value Unit Selected Output Voltage 0x0471 0-999 Voltage Select Output Voltage 1 0x0472 0-999 Voltage Select Output Voltage 2 0x0473 0-999 Voltage Select Output Voltage 3 0x0474 0-999 Voltage SRAM Exist Description Address Value Unit SRAM EXIST 0x0475...
  • Page 12 Operation continued TempStatus continued Temp Byte 16 (Hi): B0: Converter Board Power Abnormal Temp Byte 13 (Lo): Battery Temperature B1: EPO Happened Temp Byte 14 (Hi): B0: Bypass Voltage Over B2: Manual Bypass On B1: Bypass Voltage Under B2: Low Battery Shutdown B3: Converter Board Communication Error B4: Battery Cabinet Over Temperature Warning B3: Low Battery Warning...
  • Page 13 Operation continued Power Module General Status Description Address Value Unit Power Module ID / General Status 0x048C Lo: ID (1-4), Hi: Status Power Module ID / General Status 0x048D Power Module ID / General Status 0x048E Power Module ID / General Status 0x048F Reserved 0x0490...
  • Page 14 Operation continued Power Module Inverter Status Description Address Value Unit Power Module ID / Status 0 0x049E Lo: ID (1-4), Hi: Status 0 Inverter Status 1,2 0x049F Lo: Status 1, Hi: Status 2 Power Module ID / Status 0 0x04A0 Inverter Status 1,2 0x04A1 Power Module ID / Status 0...
  • Page 15 Operation continued Power Module Temperature Status Description Address Value Unit Power Module ID 0x04B0 Temperature PFC 0x04B1 0-9999 0.1 Voltage Temperature TBD 0x04B2 0-9999 0.1 Voltage Temperature INV 0x04B3 0-9999 0.1 Voltage Temperature INV R 0x04B4 0-9999 0.1 Voltage Temperature INV S 0x04B5 0-9999 0.1 Voltage...
  • Page 16 Operation continued Power Module Inverter Voltage Description Address Value Unit Power Module ID 0x04DA Inverter Voltage R 0x04DB 0-9999 0.1 Voltage Inverter Voltage S 0x04DC 0-9999 0.1 Voltage Inverter Voltage T 0x04DD 0-9999 0.1 Voltage Power Module ID 0x04DE Inverter Voltage R 0x04DB 0-9999 0.1 Voltage...
  • Page 17: Firmware Version

    Operation continued Model Description Address Value Unit Model Byte 0, 1 0x0503 Lo: Byte 0, Hi: Byte 1 Model Byte 2, 3 0x0504 Lo: Byte 2, Hi: Byte 3 Model Byte 4, 5 0x0505 Lo: Byte 4, Hi: Byte 5 Model Byte 6, 7 0x0506 Lo: Byte 6, Hi: Byte 7...
  • Page 18: Warranty & Warranty Registration

    Not compatible with PoE (Power over Ethernet) applications. WARRANTY REGISTRATION Visit www.tripplite.com/warranty today to register the warranty for your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary.
