Programmable MODBUS Card
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
Owner's Manual
Model: MODBUSCARD
Introduction
Features
Configuration
Installation
Operation
Warranty and Product Registration
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
2
2
2
6
6
20

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite MODBUSCARD

Summary of Contents for Tripp Lite MODBUSCARD

  • Page 1 Owner’s Manual Programmable MODBUS Card Model: MODBUSCARD Introduction Features Configuration Installation Operation Warranty and Product Registration PROTECT YOUR INVESTMENT! Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a $100 value! www.tripplite.com/warranty...
  • Page 2 Introduction The MODBUSCARD provides a compatible SmartOnline UPS system communication functionality with a PC by way of the ® MODBUS protocol. Features • Implements MODBUS protocol • Provides MODBUS functions, including Read Coils, Discrete Inputs, Holding Registers, Input Registers, Write Single Coils and Write Single Registers •...
  • Page 3 For RS-422, use terminals 1 (T+), 2 (T-), 3 (R+), 4 (R-), 5 (G) for full-duplex communication. Note: The communication methods chosen must have its configuration dip switches set prior to installing the MODBUSCARD into the UPS systems accessory slot.
  • Page 4 Configuration Figure B: Device ID Configuration Examples Configuration of RS-232 Port Use SW2 to configure the RS-232 interface. Function Card TxD - transfer data to PC Card RxD - receive data from PC Function Switch Value SW-1 SW-2 ON/OFF MODBUS OFF MODBUS ON SW2-1 SW2-2...
  • Page 5 Configuration Configuration of RS-422/485 Port Use SW3 to configure the RS-422/485 interface. Function Card D+ (T+) Card D- (T-) Card R+ Card R- Switch Setting Function RS-485 Enable RS-485 RS-422 Enable RS-422 Function Switch Value SW3-1 SW3-2 2400 (Default) Baud-Rate 4800 9600 19200...

  • Page 6: Installation

    2. Detach the communication terminal connector from the MODBUSCARD. 3. Slide the configured MODBUSCARD into the UPS accessory slot 4. With the screws that were removed in step 1, attach the compatible cover plate that came with MODBUSCARD to the accessory slot mounting points.
  • Page 7 Operation Description Address Value 0 Value 1 Reserved 0x0117 Alarm Rectifier Main Fail 0x0118 Rectifier Main Fail Alarm Rectifier Hi DC Stop 0x0119 Rectifier Hi DC Stop Alarm Over Temp or Fuse Fail 0x011A Over Temp or Fuse Fail Alarm Battery Low 0x011B Battery Low Alarm Battery Low Stop...
  • Page 8 Operation Holding Register (Range 0x0300 - 0x0321, Read Function 0x03, Write Function 0x06) The Read Holding Registers function code is used to read contents of a contiguous block of Holding Registers in a remote device. Starting register address and number of registers is specified by the request Protocol Data Unit. Addresses start at 0 and registers numbered 1-16 address as 0-15.
  • Page 9 Operation Description Address Value Unit Dry Contact Input Status 1 0x0320 Dry Contact Input Status 2 0x0321 Note: Your UPS may not support all fields. Input Register (Range 0x0400 - 0x051C, Read Function 0x04) Rating Value The Read Input Registers function code is used to read 1-125 contiguous input registers in a remote device. The starting register address and number of registers is specified by the request Protocol Data Unit.

  • Page 10: Battery Status

    Operation Battery Status Description Address Value Unit 0: Good Battery Condition 0x041E 1: Weak 2: Replace 0: OK Battery Status 0x041F 1: Low 2: Depleted 0: Floating 1: Charging Battery Charge 0x0420 2: Resting 3: Discharging Seconds on Battery 0x0421 0-65534 Seconds Estimated Minutes Remaining...

  • Page 11: Output Status

    Operation Output Status Description Address Value Unit 0: Normal 1: Battery 2: Bypass (Reserve) 3: Reducing Output Source 0x0442 4: Boosting 5: Manual Bypass 6: Other 7: None Output Frequency 0x0443 0-999 0.1 Hz Output Number Lines 0x0444 Output Voltage 1 0x0445 0-9999 0.1 Voltage...
  • Page 12 Operation Test Status Description Address Value Unit 0: No Test Performed 1: Test Passed 2: Test In Progress Test Result 0x0467 3: General Test Fault 4: Battery Test Fault 5: Deep Battery Test Fault 6: Test Aborted Output Relay Description Address Value Unit...
  • Page 13 Operation TempStatus Description Address Value Unit TempStatus Byte 1, 2 0x0476 Low: Byte 1, Hi: Byte 2 TempStatus Byte 3, 4 0x0477 Low: Byte 3, Hi: Byte 4 TempStatus Byte 5, 6 0x0478 Low: Byte 5, Hi: Byte 6 TempStatus Byte 7, 8 0x0479 Low: Byte 7, Hi: Byte 8 TempStatus Byte 9, 10...
  • Page 14 Operation Temp Byte 15 (Lo): B0: TR1 Over Temperature Temp Byte 16 (Hi): B0: Converter Board Power Abnormal (O/P TR Over Heat Shutdown) B1: EPO Happened B1: TR2 Input Choke Over Heat B2: Manual Bypass On (I/P TR Over Heat Shutdown) B3: Converter Board Communication B2: Rectifier Over Temperature Warning Error...
  • Page 15 Operation Power Module General Status Description Address Value Unit Power Module ID / General Status 0x048C Lo: ID (1-4), Hi: Status Power Module ID / General Status 0x048D Power Module ID / General Status 0x048E Power Module ID / General Status 0x048F Reserved 0x0490...
  • Page 16 Operation Power Module Inverter Status Description Address Value Unit Power Module ID / Status 0 0x049E Lo: ID (1-4), Hi: Status 0 Inverter Status 1,2 0x049F Lo: Status 1, Hi: Status 2 Power Module ID / Status 0 0x04A0 Inverter Status 1,2 0x04A1 Power Module ID / Status 0 0x04A2...
  • Page 17 Operation Power Module Temperature Status Description Address Value Unit Power Module ID 0x04B0 Temperature PFC 0x04B1 0-9999 0.1 Voltage Temperature TBD 0x04B2 0-9999 0.1 Voltage Temperature INV 0x04B3 0-9999 0.1 Voltage Temperature INV R 0x04B4 0-9999 0.1 Voltage Temperature INV S 0x04B5 0-9999 0.1 Voltage...
  • Page 18 Operation Power Module Inverter Voltage Description Address Value Unit Power Module ID 0x04DA Inverter Voltage R 0x04DB 0-9999 0.1 Voltage Inverter Voltage S 0x04DC 0-9999 0.1 Voltage Inverter Voltage T 0x04DD 0-9999 0.1 Voltage Power Module ID 0x04DE Inverter Voltage R 0x04DB 0-9999 0.1 Voltage...

  • Page 19: Firmware Version

    Operation Manufacture Description Address Value Unit Manufacture Byte 0, 1 0x04F8 Lo: Byte 0, Hi: Byte 1 Manufacture Byte 2, 3 0x04F9 Lo: Byte 2, Hi: Byte 3 Manufacture Byte 4, 5 0x04FA Lo: Byte 4, Hi: Byte 5 Manufacture Byte 6, 7 0x04FB Lo: Byte 6, Hi: Byte 7 Manufacture Byte 8, 9...

  • Page 20: Warranty And Product Registration

    Operation UPS Connection Status Description Address Value Unit UPS Connection Status 0x051C 0: Disconnection 1: Connection Note: Filed value 0xFFFF in Input Registers represents that field is not supported by UPS. Warranty & Product Registration LIMITED WARRANTY Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in materials and workmanship for a period of 2 years (except internal UPS system batteries outside USA and Canada, 1 year) from the date of initial purchase.
