INSTALLATION
INSTRUCTIONS
PARTS LIST
Player Attachment Kit (sold separately):
P/N 08B06-SHJ-100
Player bracket
Trim
BUS cable
6 Wire ties
2 Clips
© Honda Access Corp. 2004
Accessory
CASSETTE/IN-DASH 6 DISC/
MP3 PLAYER
ATTACHMENT KIT
Application
2005 ODYSSEY
Cassette Player (sold separately):
P/N 08A03-5E1-000
Cassette player
4 Washer-screws, 5 x 8 mm
Owner's Manual
MP3 Player (sold separately):
P/N 08A06-4E1-200
MP3 player
4 Washer-screws, 5 x 8 mm
Owner's Manual
Publications No.
Issue Date
JUL. 2004
1 of 6
08B06-SHJ-3000-93
Advertisement
Related Manuals for Honda 2005 Odyssey
Summary of Contents for Honda 2005 Odyssey
-
Page 1: Installation Instructions
4 Washer-screws, 5 x 8 mm Trim Owner’s Manual BUS cable MP3 Player (sold separately): P/N 08A06-4E1-200 MP3 player 6 Wire ties 4 Washer-screws, 5 x 8 mm 2 Clips Owner’s Manual 1 of 6 © Honda Access Corp. 2004 08B06-SHJ-3000-93... -
Page 2: Installation
Owner’s Manual Remove the pocket (two bolts and the two clips). CLIPS (2) TOOLS AND SUPPLIES REQUIRED #2 Phillips screwdriver Flat-tip screwdriver Ratchet 10 mm Socket 10 mm Combination wrenches 4219021B POCKET BOLT 2 of 6 © Honda Access Corp. 2004... - Page 3 DAMPER Routing the Harness Without LX Model, VAN Only connect the vehicle 14-pin connector to the BUS cable 14-pin connector. BUS CABLE 14-PIN CONNECTOR VEHICLE 14-PIN CONNECTOR COVER 4324021B GLOVE BOX 4527021B 3 of 6 © Honda Access Corp. 2004...
- Page 4 11. Secure the BUS cable to the vehicle harness with CLIP two wire ties. TRIM 12. Secure the BUS cable to the vehicle harness with two wire ties. PLAYER BUS CABLE 4219061B VEHICLE HARNESS WIRE TIE GLOVE BOX OPENING 4220010B 4 of 6 © Honda Access Corp. 2004...
- Page 5 19. Install the player in the player opening using the two vehicle bolts that you used in step 5. BUS CABLE 14-PIN CONNECTOR CLIPS (2) 4709051B PLAYER POCKET OPENING BOLT 4709071B PLAYER POCKET OPENING 5 of 6 © Honda Access Corp. 2004...
- Page 6 25. Pull up on the driver’s window switch to close the window completely, then hold the switch for 2 seconds or more. 26. Test the AUTO window function. 6 of 6 © Honda Access Corp. 2004...
- Page 7 2005/06/07 ODYSSEY SPARE PARTS LIST ACCESSORY ASSEMBLY PART REPLACEMENT REPLACEMENT DESCRIPTION NUMBER PART DESCRIPTION PART NUMBER Player Attach 08B06-SHJ-300 Clip, Snap Fit 90666-SDA-A01...
- Page 8 2005/06/07 ODYSSEY SPARE PARTS LIST ACCESSORY ASSEMBLY PART REPLACEMENT REPLACEMENT DESCRIPTION NUMBER PART DESCRIPTION PART NUMBER MP3 Player 08A06-4E1-400 Owner's Manual 08A06-4E1-20081 Screw-washer, (4x8) 93892-04008-08...
- Page 9 2005/06/07 ODYSSEY SPARE PARTS LIST ACCESSORY ASSEMBLY PART REPLACEMENT REPLACEMENT DESCRIPTION NUMBER PART DESCRIPTION PART NUMBER CD Player 08A06-3E1-300 Screw Wash, 5x8 93891-05008-08 Screw Wash, 4x6 93891-04006-08 Band Harness 90650-MA6-720...
- Page 10 2005/06/07 ODYSSEY SPARE PARTS LIST ACCESSORY ASSEMBLY PART REPLACEMENT REPLACEMENT DESCRIPTION NUMBER PART DESCRIPTION PART NUMBER Cassette Player 08A03-5E3-000 Owner's Manual 08A03-5E1-00081 Screw-washer, 5x8 93891-05008-08...
- Page 11 2005/06/07 ODYSSEY SPARE PARTS LIST ACCESSORY ASSEMBLY PART REPLACEMENT REPLACEMENT DESCRIPTION NUMBER PART DESCRIPTION PART NUMBER Subwoofer Attach 08B39-SHJ-300 Subwoofer Switch Assy 08B39-SHJ-1M036 Fuse Security 08E55-S30-10004 Bolt, Flange 6x12 96001-06012-07 Cushion, 50x100 91902-SB2-003...
