Grizzly G0514X2 Machine Data Sheet

Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
19" BANDSAW w/CAST IRON TRUNNIONS
Product Dimensions:
Weight ........................................................................................................................................................................... 383 lbs.
Length/Width/Height .......................................................................................................................................... 36" x 32" x 76"
Foot Print (Length/Width) ....................................................................................................................................... 29
Shipping Dimensions:
Type ................................................................................................................................................................. Wood Slat Crate
Content .......................................................................................................................................................................... Machine
Weight ............................................................................................................................................................................ 460 lbs.
Length/Width/Height ............................................................................................................................................ 21" x 33" x 85"
Electrical:
Switch .................................................................................................................... Magnetic with Thermal Overload Protection
Switch Voltage ................................................................................................................................................................... 220V
Cord Length ..........................................................................................................................................................................6 ft.
Cord Gauge .................................................................................................................................................................14 gauge
Recommended Breaker Size ........................................................................................................................................20 amps
Recommended Plug Type ................................................................................................................................................ L6-20
Plug Included ......................................................................................................................................................................... No
Motor:
Type ......................................................................................................................................... TEFC Capacitor Start Induction
Horsepower .........................................................................................................................................................................3 HP
Voltage ............................................................................................................................................................................... 220V
Phase ................................................................................................................................................................................Single
Amps .................................................................................................................................................................................... 16A
Speed .........................................................................................................................................................................1725 RPM
Cycle ................................................................................................................................................................................. 60 Hz
Number Of Speeds ...................................................................................................................................................................1
Power Transfer ........................................................................................................................................................... Belt Drive
Bearings ......................................................................................................................... Shielded and Permanently Lubricated
Main Specifications:
Operation Information
Blade Speed ........................................................................................................................................... 1700, 3500 FPM
Table Tilt ................................................................................................................................................ Left 5°, Right 45°
Cutting Capacities
Maximum Cutting Height ............................................................................................................................................. 12"
Throat Capacity Left of Blade ................................................................................................................................... 18
Blade Information
Standard Blade Length .............................................................................................................................................. 143"
Blade Width Range ..............................................................................................................................................
Blade Guides ................................................................................................................................................. Ball Bearing
Model G0514X2

MACHINE DATA

MODEL G0514X2
SHEET
⁄ " x 17 ⁄ "
1 3
2 4
⁄ "
1
4
⁄ "–1 ⁄ "
1 1
8 4
Page 1 of 2
