Grizzly T10048 Instructions

Collet/tooling cart for nt40

Download this manual

Figure 1. Model t10048 collet/tooling cart.

Figure 2. example of use.

WARNING: NO pORTION OF ThIS MANUAL MAy bE REpRODUCED IN ANy ShApE

OR FORM WIThOUT ThE WRITTEN AppROvAL OF GRIzzLy INDUSTRIAL, INC.

#ts10611 printed in ChinA

MODEL T10048

COLLET/TOOLING CART

FOR NT40

INSTRUCTIONS

Introduction

the Model t10048 is a specialized cart to keep

your nt40 collets and tooling organized, pro-

tected, and close at hand. the top and middle

shelves hold a total of 48 collets with additional

space for storing tooling on the lower and two end

shelves. Collet holders are non-marring and can

be marked for quick identification—ideal for CnC

machines. the heavy-duty rubber casters provide

easy movement of the cart and can lock the cart

in place.

Specifications

number of Collet holders ................................ 48

overall dimensions ........39"L x 18

end shelf dimensions .................... 18"W x 9

Weight .......................................................70 lbs.

If you need help with your new item, call our Tech

Support at: (570) 546-9663.

This cart is designed to ONLy hold metal-

working collets and tooling. DO NOT stand

or sit on any part of this cart. DO NOT use or

modify this cart for any other purpose than

what it was designed for. Failure to heed

these instructions could lead to serious per-

sonal injury or property damage.

⁄

"W x 34

⁄

Page 1 Figure 2. example of use. Copyright © ApriL, 2008 By grizzLy industriAL, inC. WARNING: NO pORTION OF ThIS MANUAL MAy bE REpRODUCED IN ANy ShApE OR FORM WIThOUT ThE WRITTEN AppROvAL OF GRIzzLy INDUSTRIAL, INC. MODEL T10048 COLLET/TOOLING CART INSTRUCTIONS...
Page 2 HEX BOLT M6-1 X 12 PLN03M LOCK NUT M6-1 PWR810 COMBO WRENCH 8/10MM Figure 3. Model t10048 inventory (1). Figure 4. Model t10048 inventory (2). Figure 5. Model t10048 inventory (3). Assembly only hand tighten the hex bolts and lock nuts until the assembly is complete, except where other- wise instructed.
Page 3 Figure 8. top shelf and handle installed. t10048 Collet/tooling Cart for nt40 Attach the side shelf supports to the side shelves with 8 hex bolts and lock nuts, as shown in Figure 9. Fully tighten these fasten- ers.
Page 4 Fixed Casters swivel Casters Figure 11. Casters installed. With assistance, tip the cart upright, then check for stability and use. if necessary, loosen fasteners, readjust the panels and shelves, then re-tighten the fasteners. t10048 Collet/tooling Cart for nt40...
