Grizzly T34007 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The T34007 is 59 ⁄ " wide, 45
1
2
tall, and has a maximum load capacity of 1100
lbs. The cart has four load levels on one side for
boards, strips, and other narrow stock, while the
other can be loaded with sheets of plywood, MDF,
etc. Use the locking swivel casters to lock the cart
in place, or unlock them to transport your stock.
To reduce your risk of
serious injury, read this
entire
assembling or using cart.
• To reduce risk of crushing injuries from
cart tipping over on you:
— Do not stand or climb on any part of
cart.
— Push cart only. Do not pull it.
— Always lock swivel casters before load-
ing or unloading stock.
• Do not exceed weight capacities:
— Each upper shelf arm: 66 lbs. (265 lbs.
for any of the three upper shelf levels).
— Bottom shelf level: 440 lbs. for either
side.
— Entire cart: 1100 lbs.
• Always lock swivel casters when cart is
not being used to transport stock.
• Do not allow children unsupervised
access to cart.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ " deep, and 55
1
2
manual BEFORE
COPYRIGHT © SEPTEMBER, 2023 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 09/23) #CS22911 PRINTED IN CHINA
***Keep for Future Reference***
MODEL T34007
LUMBER/PLYWOOD
Inventory
Main Items (Figure 1)
⁄ "
1
2
A. Beams ........................................................ 2
B. Shelf Frames .............................................. 4
C. Base Frame ................................................ 1
D. Fixed Casters .............................................. 2
E. Swivel Casters ............................................. 2
C
D
CART
INSTRUCTIONS
A
MODEL T34007
LUMBER
/PLYWOO D CART
To reduce 1. Read and risk of serious injury when
Date 2. Ensure cart is correctly understand owner's manual using cart:
Mfd. for Grizzly SN 4. Always 3. Never climb or stand set up before using. before using.
in China 5. Do not lock casters after moving. on cart.
lbs., bottom exceed weight level: 440 capacities (upper levels:
lbs., total: 1100 lbs.). 265
B
E
Figure 1. Main items.
Qty
V1.09.23
