Owner's Manual
We recently made the following changes to the g9730/g9731 toolroom lathe:
•
Changed the wiring inside the electrical cabinet.
•
Changed the wiring for the spindle direction switch and the master power switch.
•
Changed the g9731 spindle motor and coolant pump wiring.
Aside from the information contained in this update, all other content in the owner's manual applies to this
machine. For your own safety, you MUSt read and understand this update and the applicable owner's
manual. Keep this update for future reference!
If you have any further questions about this manual update or the changes made to the machine, contact
our Technical Support at (570) 546-9663 or email techsupport@grizzly.com.
Warning: no portion of this manual may be reproduced in any shape
or form Without the Written approval of grizzly industrial, inc.
Copyright © AUgUSt, 2011 By grizzly indUStriAl, inC.
#tS14371 printed in tAiwAn
model g9730/g9731
***IMPORTANT UPDATE***
applies to models mfg. since 5/11
and owner's manual printed 1/11
