- Page 1 Heavy-Duty Double Air Filter MODEL G9956 INSTRUCTION MANUAL COPYRIGHT © APRIL, 2004 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #6008 PRINTED IN TAIWAN...
- Page 2 Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
-
Page 3: Table Of Contents
Speeds and Timer ... 12 SECTION 6: MAINTENANCE ... 13 Cleaning the Filters ... 13 SECTION 7: REFERENCE INFO ...14 Aftermarket Accessories ... 14 G9956 Parts Breakdown ... 15 G9956 Parts List ... 16 G9956 Wire Diagram ... 17 Warranty and Returns ... 18... -
Page 4: Section 1: Safety
G9956 Heavy-Duty Double Air Filter... - Page 5 14. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest performance. Follow instructions for lubri- cating and changing accessories. G9956 Heavy-Duty Double Air Filter 15. USE RECOMMENDED ACCESSORIES. 16. REDUCE THE RISK OF UNINTENTIONAL 17. MANY WOODWORKING TOOLS CAN...
-
Page 6: Additional Safety For Double Air Filters
Operations that gener- ate large amounts of any kind of dust may warrant the use of a respirator even though the air filter is running. The double air filter is not a substitute for a respirator! G9956 Heavy-Duty Double Air Filter DUST... -
Page 7: Section 2: General Information
We are also pleased to provide this manual with the Model G9956. It was written to guide you through assembly, review safety considerations, and cover general operating procedures. It repre- sents our latest effort to produce the best docu- mentation possible. -
Page 8: Section 3: Circuit Requirements
Never use a larger circuit breaker than stated below. Circuit Breaker ... 10 Amp, 1 Pole Plug Type The Model G9956 is supplied with a 5-15 plug, similar to Figure 1. Grounded Outlet Box Grounding Prong is... -
Page 9: Section 4: Set Up
When you are completely satisfied with the con- dition of the shipment, you should inventory the equipment. G9956 Heavy-Duty Double Air Filter After all the parts have been removed from the carton, you should have: A. Double Air Filter ... 1 B. -
Page 10: Site Planning
Air circulation must be thought out and all obstructions in the air path considered. The G9956 Double Air Filter is supplied with a pair of directional vents which allows the user to direct the flow of circulation. However, while the... -
Page 11: Filter Capacity
Filter Capacity The G9956 Heavy-Duty Double Air Filter is designed to recirculate the entire volume of air in a 20' x 20' x 8' room approximately 26 times in one hour. For the best filtering effect, the vol- ume in a room should be recirculated at least 6-8 times every hour. -
Page 12: Hanging The Filter
The double air filter may fall and cause serious injury if it is not properly mounted. DO NOT fasten it to sheet rock, press board, paneling or anything other than joists. G9956 Heavy-Duty Double Air Filter -10- G9956 Heavy-Duty Hanging Air Filter -10-... -
Page 13: Section 5: Operations
The double air filter is not a substitute for a respirator! Operations Operating the G9956 Double Air Filter can be done in two ways. Refer to Figure 6 while follow- ing the instructions below. For manual ON/OFF use: Connect power to the double air filter. -
Page 14: Speeds And Timer
CONTINUE ON/HR Figure 7. Lights indicate a fan speed of 3. -12- G9956 Heavy-Duty Hanging Air Filter To set the fan timer: NOTE—When the automatic shut off feature is not going to be used, press the decrease button until the light over “continue” is illuminated. -
Page 15: Section 6: Maintenance
It is important to look for holes in the filter that would reduce the filtering effect. Please see the current Grizzly catalog for replacement information. G9956 Heavy-Duty Double Air Filter... -
Page 16: Section 7: Reference Info
Warranty/Return information for the Model G9956. If you have any comments regarding this manual, please write to Grizzly at the address below: Grizzly Industrial, Inc. Technical Documentation P.O. Box 2069 Bellingham, WA 98227-2069... -
Page 17: G9956 Parts Breakdown
G9956 Parts Breakdown G9956 Heavy-Duty Hanging Air Filter -15- G9956 Heavy-Duty Double Air Filter -15-... -
Page 18: G9956 Parts List
-16- G9956 Heavy-Duty Double Air Filter G9956 Parts List PART # DESCRIPTION H2452 REAR FILTER H2451 INNER FILTER P9956003 BODY P9956004 EYE BOLT 1/4-20 x 7/8 P9956005 HANDLE P9956006 OUTLET COVER PSB30 CAP SCREW 5/16-18 x 1/2 PS07M PHLP HD SCR M4-.7 x 8... -
Page 19: G9956 Wire Diagram
Failure to do this will result in a shock hazard leading to injury or death. Ground Motor -17- G9956 Heavy-Duty Hanging Air Filter G9956 Wire Diagram Pull Chain Switch Pin Plug for Receiver Main Switch Spade Plug for Receiver... -
Page 20: Warranty And Returns
Warranty and Returns Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. - Page 21 ___No Would you recommend Grizzly Industrial to a friend? ___Yes ___No Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than three times. ___Yes ___No Comments:__________________________________________________...
