Tripp Lite B060-016-2 Specifications

Model Number: B060-016-2
KVM Switch - 16-Port (2-User) 1U Rackmount Cat5 Matrix KVM Switch
Description
Tripp Lite's 2-User 16-port NetDirector® 1U Rackmount Matrix KVM Switch is the optimal solution for controlling multiple computers (combination of
PS/2, USB or Sun) by two independent, simultaneous users. A single unit occupies a mere 1U of rack space, yet can control up to 16 directly
connected computers. A maximum of 1,024 computers can be connected through a combination of daisy-chaining and cascading. RJ45 connections
allow signals to travel up to 150 meters away (500 ft.) using ordinary Cat5 cable, while maintaining video resolution. Use either PS/2 or USB console
equipment to connect to PS/2, USB or SUN Servers.
For Government purchasers, B060-016-2 is Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases. Constructed of
heavy-duty steel housing.
System Requirements
Console: The Tripp Lite
and Mouse) to the KVM switch
Computers: The Tripp Lite B054-001-SUN,
computer/server to the KVM switch
Package Includes
1 - B060-016-2 KVM Switch
1 - Power Cord
1 - Daisy Chain Cable
1 - CD with Owner's Manual
1 set - Rackmount Hardware
Features
Three Level password security: Super Administrator, Administrator, and Users
Superior video quality - up to 1024 x 768 @ 60Hz at 500ft.
Auto Signal Compensation (ASC) assures optimum video resolution for distances up to 500ft between the switch and the consoles or
computers - no dip switch setting required
PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere. Keep Alive feature ensures that the
keyboard and mouse work properly even if the switch temporarily loses power
Daisy chain up to 7 additional B060-016 KVM Switches
No software required; convenient computer selection via intuitive hotkey combinations or On Screen Display (OSD) menus
OSD port list automatically expands when stations are added - port names are automatically reconfigured when the station sequence is
changed
OSD screen automatically adjusts to resolution changes
Highlights
B062-002-PS2 or B062-002-USB
B054-001-PS2
Two consoles independently and simultaneously control up to 16 directly
connected computers, or over 1,000 when additional KVMs are connected
Multi-platform support: PC, Sun or Mac
Rackmountable in a 1U design...Rackmount Hardware Included
Inexpensive Cat5 cabling makes cable management a breeze; up to 500 ft.
distance from console to switch and up to 500 ft. from switch to servers
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule
purchases
Console Interface Module must be used to connect a console (Keyboard, Monitor
or B054-001-USB Server Interface Module must be used to connect a
