Summary of Contents for Electrolux EWD 1409 I
-
Page 2: Important Safety Information
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. -
Page 3: Table Of Contents
Contents For the User Maintenance and Cleaning 20-21 Descaling Important Safety Information After each wash Maintenance wash Your New Washer Dryer External cleaning Description of the Appliance Cleaning the dispenser drawer Detergent dispenser drawer Cleaning the drawer recess Child safety feature Cleaning the filter 6-10 The Control Panel... -
Page 4: Your New Washer Dryer
Your New Washer-Dryer Your new washer-dryer fitted with the Electrolux “NEW JET SYSTEM”, meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Even small loads are washed “economically” because the amount of water used is regulated automatically according to the load and type of fabric. -
Page 5: Description Of The Appliance
Description of the Appliance 1 Detergent dispenser drawer 2 Programme guide 3 Control panel 4 Door opening handle 5 Filter 6 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener The programme chart is in the interior part of the drawer. -
Page 6: The Control Panel
The Control Panel 5 “Spin speed” button 1 Detergent dispenser drawer Press this button to reduce the maximum speed of the The programme chart is in the interior part of the final speed proposed by the machine for the selected drawer. - Page 7 6 “Quick wash” button to 130 minutes. For automatic Washing & Drying programmes the This option can be used for lightly soiled cotton, drying time is displayed for 3 seconds, then the duration synthetic or delicate items hat have been used or worn of the programme will appear.
- Page 8 Reset/cancellation of the programme Delayed start If the programme selector dial is turned to Off position, The selected delay (23 hours max) set by means of the three blinking dashes are displayed. relevant button appears on the display for 3 seconds, Now you can select a new programme.
-
Page 9: Programme Progress Display
End of programme • Handwash /Wool When the programme has finished a flashing zero is • Special programmes displayed. The door can be opened when the “End” Reset programme Off pilot light has gone out and if the Rinse hold Night Cycle option has not been selected. -
Page 10: Programme Information
Drain Interrupting a programme Depress the Start/Pause button to interrupt a For emptying out the water of the last rinse in programme which is running: the corresponding light programmes with the Rinse Hold or Night Cycle starts to flash. option. Depress the same button to restart the programme. -
Page 11: Operating Sequence
Operating Sequence Washing only 1/3 less than the detergent manufacturer recommends on the packet or bottle, making the appropriate allowances Before the first wash, we recommend that you run a for soft or hard water, and light or heavy soilage of cotton cycle at 95°C, without any laundry in the clothes. -
Page 12: Select The Spin Speed Or Rinse Hold Option
During this period it is possible to load other laundry: 5. Select the Spin speed or Rinse press the Start/Pause button. Open the door. Load the Hold option laundry. Close the door and press the Start/Pause Depress the spin speed button to choose the required button again. -
Page 13: Drying Only
Automatic washing and drying Switch the machine off by pressing the ON/OFF (NON-STOP programme) button. Remove the laundry from the drum and carefully check Warning! For NON-STOP programmes, it is also that the drum is empty so as to avoid any forgotten essential not to exceed the maximum load sizes of items being damaged in a subsequent wash (e.g. -
Page 14: Washing And Drying Hints
Washing and Drying Hints Do NOT overload the machine. Weigh the laundry the Some stains such as fruit, wine, grass, rust etc. are ● first few times you use the appliance. difficult to remove and should be treated before washing with specific products, which can be found The average weights of the most common items are in most household shops. -
Page 15: Which Detergent
Which detergent?..And in which form? To ensure you obtain the best wash results from your Not only are there different types of detergent, but they appliance, it is important to use the right detergent in are also available in different forms. Whether you chose your everyday wash, and only detergents recommended a powder or liquid in traditional or compact form is for use in automatic machines. -
Page 16: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 17: Washing And Special Programmes
Washing Programmes Consumption* ype of Programme Additional Max. Section Temp. Energy Water fabric description functions load 95° Whites Wash at 95°C SPIN SPEED/R. H. 5 kg OTTON PREWASH 3 rinses QUICK WASH Normal spin NIGHT CYCLE SENSITIVE Whites Wash at 60°C E60°... -
Page 18: Special Programmes
Special Programmes Consumption Selector dial position/ Additional Programme description Max. load Programme functions Energy Water Rinses 3 rinses with liquid additive 5 kg SPIN SPEED RINSE HOLD if required SENSITIVE Long spin NIGHT CYCLE 5 kg Drain For emptying out the last rinse water in programmes with the “rinse hold”... -
Page 19: Drying Programmes
Drying Programmes Drying time Degree of drying Type of fabric Max. load Spin speed mins 1400 105-1115 Extra dry 2.5 kg Cotton and linen Ideal for (bathrobes, bath towelling towels, etc.) 50-60 materials 1 kg 1400 1400 95-105 2.5 kg Cotton and linen (towels, T-shirts, bathrobes) -
Page 20: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 21: The Dangers Of Freezing
The dangers of freezing Unscrew and remove the filter. Clean carefully under a fast running tap. If the machine is exposed to temperatures below 0°C, certain precautions should be taken. Turn off the water tap. ● Unscrew the inlet hose. ●... -
Page 22: Something Not Working
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 23: Service And Spare Parts
Symptom Possible causes The machine vibrates when spinning The internal packing has not been removed. ● The machine is in contact with the wall or furniture. ● The machine is not level. ● The washing load is badly distributed in the drum. ●... -
Page 24: Guarantee Conditions
Customer Customer Care Department - Electrolux Major Appliances For general enquiries concerning your Electrolux Addington Way appliance or for further information on Electrolux Luton products, please contact our Customer Care Department Bedfordshire by letter or telephone at the address below or visit our LU4 9QQ website at www.electrolux.co.uk Tel 08705 980 950*... -
Page 25: Installation Instructions
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 26: Unpacking
Unpacking Set the machine upright and remove the two remaining All transit bolts and packing must be removed bolts from the back. before using the appliance. Pull out the three plastic spacers from the holes into which the bolts were fitted. You are advised to keep all the packaging for re-use in Plug the open holes with the plugs supplied with the case the machine is to be transported again. -
Page 27: Water Drainage
If you cannot make the cold water connection direct When discharging into a standpipe ensure that the top of from the rising mains, you may be able to operate the the standpipe is no more than 90cm (35.4'') and no less appliance from your cold water storage system. -
Page 28: Levelling
Special conditions If the floor is carpeted or covered with crumbly or soft material, insert a rigid support base under the feet to prevent noise, vibration or displacement. The base should protrude a few centimetres beyond the edges of the machine. Warning The machine should NOT be placed on deep pile The drain hose may be extended to a maximum of 4... -
Page 29: Electrical Connection
Electrical connection The wire coloured green and yellow must be connected to the terminal marked with the letter «E» or by the Any electrical work required to install this appliance earth symbol or coloured green and yellow. should be carried out by a qualified electrician or The wire coloured blue must be connected to the competent person. -
Page 30: Building-In
Building-in The height (C-Fig. C) depends on the height of the adjacent furniture's base. This appliance has been designed to be built into the kitchen furniture. The recess should have the dimensions shown in picture A. b) Hinges To mount the hinges it is necessary to drill two holes (dia. - Page 31 If the door has to be opened from left to right, invert the Position the base into the recess with its front edge as position of the plates (7), the magnet (4) and the plate far forward as the adjoining plinth line will allow. (5) (Fig.
- Page 32 © Electrolux plc 2005...
