ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
Using the touch screen (on selected models) ........22 Using the touchpad ..................24 Using the keyboard ..................9 Function keys ....................29 Function keys for ASUS Apps ..............30 Windows®8 keys ....................30 Chapter 3: Working with Windows® 8 Starting for the first time ................ ®...
Page 4
Wi-Fi ......................47 Bluetooth ......................49 Airplane mode ....................51 Turning your Notebook PC off ..............5 Putting your Notebook PC to sleep ............52 Chapter 4: ASUS apps Featured ASUS Apps ..................5 LifeFrame ......................54 Power4Gear Hybrid..................56 Instant On ......................57 USB Charger+ ....................58 Chapter 5: Power-on Self Test (POST) The Power-on Self Test (POST) ..............6...
Page 5
CTR 21 Approval (for Notebook PC with built-in Modem) ....94 ENERGY STAR complied product ..............95 European Union Eco-label ................96 Prevention of Hearing Loss .................96 Global Environmental Regulation Compliance and Declaration .97 ASUS Recycling/Takeback Services ............97 Coating Notice ....................97 Regional notice for Singapore ..............97 Notebook PC E-Manual...
This chapter provides an overview of using Windows® 8 in your Notebook PC. Chapter 4: ASUS Apps This chapter features the ASUS apps included with your Notebook PC’s Windows® 8 operating system. Chapter 5: Power-on Self-test (POST) This chapter shows you how to use POST to change the settings of your Notebook PC.
Conventions used in this manual To highlight key information in this manual, some text are presented as follows: IMPORTANT! This message contains vital information that must be followed to complete a task. NOTE: This message contains additional information and tips that can help complete tasks.
Safety precautions Using your Notebook PC This Notebook PC should only be used in environments with ambient temperatures between 5°C (41°F) and 35°C (95°F). Refer to the rating label on the bottom of your Notebook PC and ensure that your power adapter complies with this rating.
Caring for your Notebook PC Disconnect the AC power and remove the battery pack (if applicable) before cleaning your Notebook PC. Use a clean cellulose sponge or chamois cloth dampened with a solution of nonabrasive detergent and a few drops of warm water.
Proper disposal Do not throw your Notebook PC in municipal waste. This product has been designed to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment and mercury-containing button cell battery) should not be placed in municipal waste.
Getting to know your Notebook PC Top View NOTE: The keyboard's layout may vary per region or country. The top view may also vary in appearance depending on the Notebook PC model. Notebook PC E-Manual...
Page 13
Ambient light sensor This ambient light sensor detects the amount of ambient light in your environment. It allows the system to automatically adjust the brightness of the display depending on the ambient light condition. Camera The built-in camera allows you to take pictures or record videos using your Notebook PC.
Power button Press the power button to turn your Notebook PC on or off. You can also use the power button to put your Notebook PC to sleep or hibernate mode and wake it up from sleep or hibernate mode. In the event that your Notebook PC becomes unresponsive, press and hold the power button for about four (4) seconds until your Notebook PC shuts down.
Bottom NOTE: The bottom side may vary in appearance depending on model. WARNING! The bottom of the Notebook PC can get warm to hot while in use or while charging the battery pack. When working on your Notebook PC, do not place it on surfaces that can block the vents.
Right Side Power indicator The power indicator lights up when the Notebook PC is turned on and blinks slowly when the Notebook PC is in sleep mode. Headphone output jack port The headphone output jack port allows you to connect your Notebook PC to amplified speakers or headphones.
USB 3.0 port This Universal Serial Bus 3.0 (USB 3.0) port provides a transfer rate of up to 5 Gbit/s and is backward compatible to USB 2.0. Power (DC) input port Insert the bundled power adapter into this port to charge the battery pack and supply power to your Notebook PC.
Connecting external devices (on selected models) External display Use the bundled mini VGA to VGA adapter to connect your Notebook PC to an external display. Mini VGA port Mini VGA to VGA adapter VGA cable External display Notebook PC E-Manual...
Getting started Charge your Notebook PC. A. Plug the AC power adapter into a 100V~240V power source. Connect the DC power connector into your Notebook PC’s power (DC) input. IMPORTANT! • Ensure that your Notebook PC is connected to the power adapter before turning it on for the first time.
Gestures for the touch screen (on selected models) and touchpad Gestures allow you to launch programs and access the settings of your Notebook PC. Refer to the following illustrations when using hand gestures on your touch screen (on selected models) and touchpad.
Page 23
Top edge swipe Finger slide • In the Start screen, swipe Slide your finger to scroll up from the top edge of the and down and slide your finger screen to view the All Apps to pan the screen left or right. bar.
Using the touchpad Moving the pointer You can tap or click anywhere on the touchpad to activate its pointer, then slide your finger on the touchpad to move the pointer onscreen. Slide horizontally Slide vertically Slide diagonally Notebook PC E-Manual...
Page 25
One-finger gestures Tap/Double tap • In the Start screen, tap an app to launch it. • In Desktop mode, double-tap an application to launch it. Left-click Right-click • In the Start screen, click an • In the Start screen, click an app to launch it.
Page 26
Drag and drop Double-tap an item, then slide the same finger without lifting it off the touchpad. To drop the item to its new location, lift your finger from the touchpad. Top edge swipe In the Start screen, swipe from the top edge to launch the All •...
Two-finger gestures Rotate Tap two fingers on the touchpad To rotate an image, place two to simulate the right-click fingers on the touchpad then function. turn one finger clockwise or counterclockwise while the other stays still. Two-finger scroll (up/down) Two-finger scroll (left/right) Slide two fingers to scroll up or Slide two fingers to scroll left or down.
Drag and drop Select an item then press and hold the left button. Using your other finger, slide down the touchpad to drag and drop the item to a new location. Three-finger gestures Swipe up Swipe down Swipe three fingers upward to Swipe three fingers downward to show all running applications.
Using the keyboard Function keys The function keys on your Notebook PC’s keyboard can trigger the following commands: Puts the Notebook PC into Sleep mode Turns Airplane mode on or off NOTE: When enabled, the Airplane mode disables all wireless connectivity. (on selected models) Decreases keyboard brightness for Notebook PC models with a backlit keyboard...
Function keys for ASUS Apps Your Notebook PC also comes with a special set of function keys that can be used to launch ASUS apps. Toggles the ASUS Splendid Video Enhancement Technology app to switch between these display...
Starting for the first time When you start your computer for the first time, a series of screens appear to guide you in configuring the basic settings of your Windows® 8 operating system. To start your Notebook PC for the first time: Press the power button on your Notebook PC.
® Windows Windows® 8 comes with a tile-based user interface (UI) which allows you to organize and easily access Windows® apps from the Start screen. It also includes the following features that you can use while working on your Notebook PC. Start screen The Start screen appears after successfully signing in to your user account.
Hotspots Onscreen hotspots allow you to launch programs and access the settings of your Notebook PC. The functions in these hotspots can be activated using the touchpad. Hotspots on a running app Hotspots on the Start screen Notebook PC E-Manual...
Page 35
Hotspot Action upper left corner Hover your mouse pointer on the upper left corner then tap on the recent app’s thumbnail to revert back to that running app. If you launched more than one app, slide down to show all running apps. lower left corner From a running app screen: Hover your mouse pointer on the lower left...
® Working with Windows apps Use your Notebook PC’s touch screen, touchpad, or keyboard to launch, customize, and close apps. Launching apps (on selected models) Tap an app to launch it. Position your mouse pointer over the app then left-click or tap once to launch it.
Resizing apps (on selected models) Swipe down the app tile to select and launch the settings bar. to reduce or to enlarge the app tile. Right-click on the app to activate its settings bar then tap Unpinning apps (on selected models) Swipe down the app tile to select and launch the settings bar.
Closing apps (on selected models) Tap and hold the top side of the running app then drag it down to the bottom of the screen to close it. Move your mouse pointer on the top side of the launched app then wait for the pointer to change to a hand icon.
Accessing the Apps screen Aside from the apps already pinned on your Start screen, you can also open other applications through the Apps screen. Horizontal scroll bar Launching the Apps screen Launch the Apps screen using your Notebook PC's touch screen, touchpad, or keyboard.
Page 40
Pinning more apps on the Start screen You can pin more apps on the Start screen using your touch screen or touchpad. (on selected models) In the Apps screen, swipe down the app to select and launch the settings bar. to pin the selected app on the Start screen.
Charm bar The Charm bar is a toolbar that can be triggered on the right side of your screen. It consists of several tools that allow you to share applications and provide quick access for customizing the settings of your Notebook PC. Charm Bar Launching the Charm bar NOTE: When called out, the Charm bar initially appears as a set of...
Inside the Charm bar Search This tool allows you to look for files, applications, or programs in your Notebook PC. Share This tool allows you to share applications via social networking sites or email. Start This tool reverts the display back to the Start screen. From the Start screen, you can also use this to revert back to a recently opened app.
Snap feature The Snap feature displays two apps side-by-side, allowing you to work or switch between apps. IMPORTANT! Ensure that your Notebook PC’s screen resolution is set to 1366 x 768 pixels or higher before using the Snap feature. Snap bar Using Snap Use your Notebook PC’s touch screen, touchpad, or keyboard to activate and use Snap.
Page 44
Launch the app you wish to snap. Hover the mouse point on the top side of your screen. Once the pointer changes to a hand icon, drag then drop the app to the left or right side of the display panel.
Other keyboard shortcuts Using the keyboard, you can also use the following shortcuts to help you launch applications and navigate Windows®8. Switches between the Start screen and the last running app Launches the desktop Launches the Computer window on Desktop mode Opens the File search pane Opens the Share pane...
Page 46
Opens the Second screen pane Opens the Apps search pane Opens the Run window Opens Ease of Access Center Opens the Settings search pane Opens a menu box of Windows® tools Launches the magnifier icon and zooms in your screen Zooms out your screen Opens the Narrator Settings Enables the print screen function...
Connecting to wireless networks Wi-Fi Access emails, surf the Internet, and share applications via social networking sites using your Notebook PC’s Wi-Fi connection. IMPORTANT! Ensure the Airplane mode is turned off to enable the Wi-Fi function of your Notebook PC. For more details, refer to the Airplane mode section in this manual.
Page 48
Tap Connect to start the network connection. NOTE: You may be prompted to enter a security key to activate the Wi-Fi connection. If you want to enable sharing between your Notebook PC and other wireless-enabled systems, tap Yes, turn on sharing and connect to devices.
Bluetooth Use Bluetooth to facilitate wireless data transfers with other Bluetooth-enabled devices. IMPORTANT! Ensure the Airplane mode is turned off to enable the Bluetooth function of your Notebook PC. For more details, refer to the Airplane mode section in this manual. Pairing with other Bluetooth-enabled devices You need to pair your Notebook PC with other Bluetooth-enabled devices to enable data transfers.
Page 50
Select a device from the list. Compare the passcode on your Notebook PC with the passcode sent to your chosen device. If they are the same, tap Yes to successfully pair your Notebook PC with the device. NOTE: For some bluetooth-enabled devices, you may be prompted to key in the passcode of your Notebook PC.
Airplane mode The Airplane mode disables wireless communication, allowing you to use your Notebook PC safely while in-flight. Turning Airplane mode on Launch the Charm bar. and tap Move the slider to the right to turn the Airplane mode on. Press Turning Airplane mode off Launch the Charm bar.
Turning your Notebook PC off You can turn off your Notebook PC by doing either of the following procedures: from the Charm bar then tap • > Shut down to do a normal shutdown. > Shut down. • From the log-in screen, tap •...
Featured ASUS Apps LifeFrame Enhance your webcam functions through the LifeFrame app. Create snapshots, edit photos, record videos, record audio files, use your webcam as a security monitoring device, and play games using this app. To launch LifeFrame Press The archive toolbar displays a function's saved files in thumbnail view.
Page 55
LifeFrame functions Camera Use this function to take pictures using your webcam. Camcorder Use this function to take videos through your webcam. Monitor This function lets you use your webcam as a security video monitor as it automatically detects movement then captures it on photo.
Power4Gear Hybrid Optimize the performance of your Notebook PC using the power saving modes in Power4Gear. NOTE: Unplugging the Notebook PC from its power adapter automatically switches Power4Gear Hybrid to Battery Saving mode. To launch Power4Gear Hybrid Press Select from these power saving modes. Allows you to hide the desktop icons Use these options to customize onscreen and turns the presentation...
Instant On Save battery power while your Notebook PC is on deep sleep mode (Deep S3) using Instant On. NOTE: Deep S3 is a technology that lets you save more battery power while your Notebook PC is on sleep mode. IMPORTANT! The standby time varies according to your Notebook PC's remaining battery capacity, computer model, configuration, and operating conditions.
USB Charger+ USB Charger+ allows you to quick-charge mobile devices via your Notebook PC’s USB charge port. This feature can also be used even while your Notebook PC is on sleep, hibernate, or shutdown mode (available on selected models only). NOTE: USB Charger+ is available in your USB 3.0 charge port with the icon.
Page 59
Select one or both of these charging options: Enable quick charge when the system is running or Enable quick charge when the system is in sleep/hibernate/ shutdown mode. Move the percentage slider to the left or to the right to set the limit for charging devices.
The Power-on Self Test (POST) The Power-on Self Test (POST) is a series of software-controlled diagnostic tests that run when you turn on or restart your Notebook PC. The software that controls the POST is installed as a permanent part of the Notebook PC’s architecture. Using POST to access BIOS and Troubleshoot During POST, you can access the BIOS settings or run troubleshooting options using the function keys of your Notebook...
BIOS Settings NOTE: The BIOS screens in this section are for reference only. The actual screens may differ by model and territory. Boot This menu allows you to set your boot option priorities. You may refer to the following procedures when setting your boot priority. On the Boot screen, select Boot Option #1.
Security This menu allows you to set up the administrator and user password of your Notebook PC. It also allows you to control the access to your Notebook PC’s hard disk drive, input/output (I/O) interface, and USB interface. NOTE: If you install a User Password, you will be prompted to input this •...
Page 65
To clear the password: On the Security screen, select Administrator Password or User Password. Type in the current password then press Leave the Create New Password field blank then press Select Yes in the confirmation box then press I/O Interface Security In the Security menu, you can access I/O Interface Security to lock or unlock some interface functions of your Notebook PC.
Page 66
USB Interface Security Through the I/O Interface Security menu, you can also access USB Interface Security to lock or unlock ports and devices. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Security If LOCKED, all USB USB Interface Security devices will be disabled USB Interface...
Page 67
Set Master Password In the Security menu, you can use Set Master Password to set up a password-enabled access to your hard disk drive. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Main Advance Boot...
To update the BIOS: Verify the Notebook PC’s exact model then download the latest BIOS file for your model from the ASUS website. Save a copy of the downloaded BIOS file to a flash disk drive. Connect your flash disk drive to your Notebook PC.
Page 69
Wake On Lid Open [Enabled] Power Off Energy Saving [Enabled] Legacy USB Support [Enabled] USB 3.0 Support [Enabled] ASUS USB Charger+ in battery mode [Disabled] Trusted Computing SATA Configuration →← : Select Screen : Select Item Network Stack ↑↓ Enter: Select +/—...
Troubleshoot By pressing during POST, you can access Windows® 8 troubleshoot options which includes the following: • Refresh your PC • Reset your PC • Advanced options Refresh your PC Use Refresh your PC if you want to refresh your system without losing your current files and applications.
Reset your PC IMPORTANT! Back up all your data before performing this option. Use Reset your PC to restore your Notebook PC to its default settings. To access this during POST: Restart your Notebook PC then press during POST. Wait for Windows® to load the Choose an option screen then tap Troubleshoot.
Advanced options Use Advanced options to perform additional troubleshooting options in your Notebook PC. To access this during POST: Restart your Notebook PC then press during POST. Wait for Windows® to load the Choose an option screen then tap Troubleshoot. Tap Advanced options.
Page 73
In the Advanced options screen, select System Image Recovery. Choose an account you would like to recover using a system image file. Type your account password then tap Continue. Select Use the latest available system image (recommended), then tap Next. You can also choose Select a system image if your system image is in an external device or DVD.
DVD-ROM Drive Information (on selected models) The DVD-ROM drive allows you to view and create your own CDs and DVDs. You can purchase an optional DVD viewer software to view DVD titles. Regional Playback Information Playback of DVD movie titles involves decoding MPEG2 video, digital AC3 audio and decryption of CSS protected content.
Region Definitions Region 1 Canada, US, US Territories Region 2 Czech, Egypt, Finland, France, Germany, Gulf States, Hungary, Iceland, Iran, Iraq, Ireland, Italy, Japan, Netherlands, Norway, Poland, Portugal, Saudi Arabia, Scotland, South Africa, Spain, Sweden, Switzerland, Syria, Turkey, UK, Greece, Former Yugoslav Republics, Slovakia Region 3 Burma, Indonesia, South Korea, Malaysia, Philippines, Singapore,...
Blu-ray ROM Drive Information (on selected models) The Blu-ray ROM Drive allows you to view high definition (HD) videos and other disc file formats such as DVDs and CDs. Region Definitions Region A North, Central and South American countries, and their territories; Taiwan, Hong Kong, Macao, Japan, Korea (South and North), South East Asian countries and their territories.
Internal Modem Compliancy The Notebook PC with internal modem model complies with JATE (Japan), FCC (US, Canada, Korea, Taiwan), and CTR21. The internal modem has been approved in accordance with Council Decision 98/482/EC for pan-European single terminal connection to the public switched telephone network (PSTN).
Network Compatibility Declaration Statement to be made by the manufacturer to the user: “This declaration will indicate the networks with which the equipment is designed to work and any notified networks with which the equipment may have inter-working difficulties. The manufacturer shall also associate a statement to make it clear where network compatibility is dependent on physical and software switch settings.
Page 81
This table shows the countries currently under the CTR21 standard. Country Applied More Testing Austria Belgium Czech Republic Not Applicable Denmark Finland France Germany Greece Hungary Not Applicable Iceland Ireland Italy Still Pending Still Pending Israel Lichtenstein Luxemburg The Netherlands Norway Poland Not Applicable...
This information was copied from CETECOM and is supplied without liability. For updates to this table, you may visit http://www.cetecom. de/technologies/ctr_21.html 1 National requirements will apply only if the equipment may use pulse dialling (manufacturers may state in the user guide that the equipment is only intended to support DTMF signalling, which would make any additional testing superfluous).
Page 83
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING! The use of a shielded-type power cord is required in order to meet FCC emission limits and to prevent interference to the nearby radio and television reception.
RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government.
FCC Radio Frequency (RF) Exposure Caution Statement WARNING! Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. “The manufacture declares that this device is limited to Channels 1 through 11 in the 2.4GHz frequency by specified firmware controlled in the USA.
CE Marking CE marking for devices without wireless LAN/Bluetooth The shipped version of this device complies with the requirements of the EEC directives 2004/108/EC “Electromagnetic compatibility” and 2006/95/EC “Low voltage directive”. CE marking for devices with wireless LAN/ Bluetooth This equipment complies with the requirements of Directive 1999/5/ EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and mutual recognition of conformity.
Déclaration d’Industrie Canada relative à l’ exposition aux ondes radio Cet appareil est conforme aux limites d’exposition aux radiations d’ Industrie Canada définies pour un environnement non-contrôlé. Pour maintenir la conformité avec les exigences d’exposition RF d’IC, veuillez éviter tout contact direct avec l’antenne pendant l’ émission.
Wireless Operation Channel for Different Domains N. America 2.412-2.462 GHz Ch01 through CH11 Japan 2.412-2.484 GHz Ch01 through Ch14 Europe ETSI 2.412-2.472 GHz Ch01 through Ch13 France Restricted Wireless Frequency Bands Some areas of France have a restricted frequency band. The worst case maximum authorized power indoors are: •...
Page 89
Departments in which the use of the 2400–2483.5 MHz band is permitted with an EIRP of less than 100mW indoors and less than 10mW outdoors: 01 Ain 02 Aisne 03 Allier 05 Hautes Alpes 08 Ardennes 09 Ariège 11 Aude 12 Aveyron 16 Charente 24 Dordogne...
UL Safety Notices Required for UL 1459 covering telecommunications (telephone) equipment intended to be electrically connected to a telecommunication network that has an operating voltage to ground that does not exceed 200V peak, 300V peak-to-peak, and 105V rms, and installed or used in accordance with the National Electrical Code (NFPA 70).
REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm. Nordic Lithium Cautions (for lithium-ion batteries) CAUTION! Danger of explosion if battery is incorrectly replaced.
Page 92
VORSICHT! Explosionsgefahr bei unsachgemäßen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers. (German) ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren.
Optical Drive Safety Information Laser Safety Information CD-ROM Drive Safety Warning CLASS 1 LASER PRODUCT WARNING! To prevent exposure to the optical drive’s laser, do not attempt to disassemble or repair the optical drive by yourself. For your safety, contact a professional technician for assistance. Service warning label WARNING! INVISIBLE LASER RADIATION WHEN OPEN.
Department of Energy helping us all save money and protect the environment through energy efficient products and practices. All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 15 and 30 minutes of user inactivity.
European Union Eco-label This Notebook PC has been awarded the EU Flower label, which means that this product has the following characteristics: Decreased energy consumption during use and stand-by modes. Limited use of toxic heavy metals. Limited use of substances harmful to the environment and health.
ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements.
Page 98
ASUSTeK COMPUTER INC. Address, City: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN R.O.C. Country: TAIWAN Authorized representative in Europe: ASUS COMPUTER GmbH Address, City: HARKORT STR. 21-23, 40880 RATINGEN Country: GERMANY declare the following apparatus: Product name :...
