Page 1
Tall Larder Fridge TFF654W TFF654S SOM 9650...
Page 2
Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you with years of good service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future reference.
CONTENTS 1 Your refrigerator 5 Using your refrigerator 11 Setting the operating temperature 11 Indicator lights ......12 2 Warnings Making ice cubes ......13 ELECTRICAL REQUIREMENTS ..5 Defrosting of the appliance ..13 WARNING! THIS APPLIANCE MUST BE EARTHED ........ 5 6 Maintenance and cleaning 3 Installation...
Your refrigerator MAX. 1. Control Panel 2. Flap (Fast-Freeze compartment) 3. Ice cube tray & Ice bank 4. Drawers 5. Adjustable front feet C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.
• Do not dispose of the appliance on a • Do not use mechanical devices fire. At BEKO, the care and protection or other means to accelerate the of our environment is an ongoing defrosting process, other than those commitment.
With alternative plugs a 13 A fuse must mains lead which can only be obtained be fitted either in the plug or adaptor from a BEKO Authorised Service or in the main fuse box. If in doubt Agent. contact a qualified electrician.
Installation 5. The appliance should be located on INSTALLATION INSTRUCTIONS a smooth surface. The two front feet can be adjusted as 1. The space in the room where the required. appliance is installed must not be smaller than 10 cubic metres. To ensure that,your appliance is standing upright adjust the two front feet by turning clockwise or anti-...
Page 8
“IMPORTANT: Care must be taken while cleaning / carrying the appliance to avoid touching the bottom of the condenser metal wires at the back of theappliance as you might injure your fingers and hands. “IMPORTANT: This appliance is not designed for stacking with any otherappliance.When positioning your appliance, take care not to damage your flooring, pipes,wall coverings etc.
REVERSING THE DOORS 3.Gently prise off plastic hinge covers on both sides of front top panel using a small flat-headed screwdriver. (1-2) We recommend that you reverse the 4-Unscrew the bolts of the top hinge door before switching on for the first and remove top hinge.
Page 10
15-Locate and re-fit door to bottom hinge pin. (14) 16-Re-fit the upper hinge on the opposite side by using a flat headed screwdriver. (15) 17.Fit front top panel plastic hinge covers on the opposite sides. (16) Remove the handle cover gently taking care not to damage the appliance.(17) 19.Unscrew and remove the handle...
Before operating STARTING 9.We recommend that you set the Final Check thermostat knob at MIN setting and Before you start using the refrigerator monitor the temperature to ensure the check that: appliance maintains desired storage temperatures (See Temperature 1.The front feet have been adjusted Control and Adjustment section).
Using your refrigerator We recommend checking the temperature with a thermometer to Setting the operating ensure that the storage compartments temperature are kept to the desired temperature. Remember to take the reading The operating temperature is regulated immediately since the thermometer by the temperature control.
MAX. Thermostat knob Indicator lights The thermostat knob is located on the indicator light frame. There are three coloured indicator lights located inside the appliance Important: which show the operating mode of the When you press the fast-freeze switch freezer. or adjust the set temperature, there may be a short delay before the Amber Indicator...
Do not exceed the freezing capacity It is strongly recommended to keep of your appliance in 24 hours. See the the knob at MAX. position at least rating label. 24 hours to freeze maximum amount In order to maintain the quality of the of fresh food declared as freezing food, the freezing must be effected as capacity.
Maintenance and cleaning ** We recommend that you switch ** Any dust that gathers on the off the appliance at the socket outlet condenser, which is located at the and pull out the mains plug before back of the freezer, should be removed cleaning.
Do's and Don'ts Do-Check contents of the freezer at Don’t- Exceed the maximum freezing regular intervals. capacity (16 kg in any 24 hours) when Do- Clean your freezer regularly. freezing fresh food. Do- Keep food for as short a time as Don’t- Consume ice-cream and water possible and adhere to “Best Before”, ices direct from the freezer.
PROBLEM SOLVING If the appliance does not operate when switched on, check: • The plug is inserted properly in the socket and that the power supply is on. (To check the power supply to the socket, plug in another appliance) •...
• The cost of functional replacement parts, but excluding consumable items. • The labour costs of a Beko approved repairer to carry out the repair. What is not covered? • Transit, delivery or accidental damage or misuse and abuse.
Page 20
Otherwise please call the appropriate number above where service can be obtained at a charge. Should you experience any difficulty in obtaining service please contact the Beko Customer Help-Line. Tel: 0845 6004911 e-mail: service@beko.co.uk...
Page 21
BEKO plc Beko House Caxton Way Watford Hertfordshire WD18 8UF Tel: 0845 6004911 Printed in Turkey Fax: 0845 6004922 e-mail: service@beko.co.uk Part no: 48 9746 0001 website: www.beko.co.uk Revision no:...
