Grizzly H0587 Instruction Sheet

EYE INJURY HAZARD!
Always wear safety glasses
during
serious personal injury.
When servicing, always dis-
connect tool from air to pre-
vent unexpected operation.
Exceeding this PSI may
result in injury/tool damage.
LUNG INJURY HAZARD!
Always wear a respirator
during
exposure to dust.

Specifications

Operating Pressure .................................. 90 PSI
Air Inlet ....................................................
Weight ......................................................1
Inventory (Figure 1)
A. Hose ........................................................... 1
B. Vacuum ...................................................... 1
C. Extension Tube .......................................... 1
D. Hose Clamps .............................................. 2
E. Dust Collection Bag .................................... 1
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
use to prevent
INJURY HAZARD!
120 PSI
MAX AIR PRESSURE!
use to reduce
⁄ " NPT
1
4
1
COPYRIGHT © MARCH, 2007 BY GRIZZLY INDUSTRIAL, INC.
#BL9088 PRINTED IN TAIWAN
INSTRUCTION SHEET
D
C
Figure 1. Model H0587 inventory.
Assembly
1. Insert the extension tube into the front of the
vacuum, and install a
connect fitting (not included) into the bottom
of the vacuum.
2. Place a clamp on the funnel-shaped end of
the hose, insert the vacuum into the hose,
and tighten the clamp (see Figure 2).
⁄ lbs.
2
Qty
3. Place a clamp over the dust collection bag,
insert the end of the hose into the bag, and
tighten the clamp (see Figure 2).
MODEL H0587
AIR WONDER
VACUUM KIT
E
B
⁄ " NPT male quick-dis-
1
4
Trigger
Figure 2. Vacuum kit assembled.
A
Hose
Clamps
